USB3.0 2-Port Front Panel to
2-Port PCI Express Card
Art. No.: PC0058
Best Connectivity
This USB 3.0 product by Logilink expands your PC by four USB 3.0 interface. Insert the PCI Express
card into a PCI Express slot and install the front panel into a free 3.5 bay of your PC. Since the
USB-A interface is compatible to its forerunners USB 2.0 and USB 1.1, you can still use your existing
USB devices.
Features:
» Chipset: VIA VL805
» Front Panel: 2 x USB 3.0 type A with connecting cable
» PCI Express x1: 2 x External USB 3.0 type A
1 x Internal power connector big 4 pin
1 x Internal USB3.0 19 pin header
» Data transfer rate up to: Super-Speed 5 Gb/s, High-Speed 480 Mb/s, Full-Speed 12Mb/s,
Low-Speed 1.5 Mb/s
» USB 3.0 cable of the front panel will be connected internal to the PCI Express card
» Easy solution for extending two USB ports on front of computer and two USB ports on the back
of computer
» Built-in 4-pin power connector of PCI express card for receiving extra power supply from system
» Length of internal USB 3.0 cable: ca. 60 cm
System Requirements:
» Windows XP/XP-64/Vista/Vista-64/7/7-64/8/8-64/10, Linux ex Kernel 2.6
» One free PCI Express Slot
» One free 3.5 Bay
» One free Power Connector big 4 pin
USB3.0 2-Port Front Panel to
2-Port PCI Express Card
Art. No.: PC0058
Best Connectivity
Package Contents:
» 1 x 3.5” Front Panel USB3.0 with Connecting Cable
» 1 x USB 3.0 PCI Express Card 2-Port
» 1 x Screw Set for Assembling
» 1 x Driver CD
» 1 x User Manual
Package Informations:
» Packing Dimension: 180 x 140 x 70mm
» Packing Weight: kg
» Carton Dimension: 380 x 370 x 300mm
» Carton Q‘ty: 20pcs
» Carton Weight: kg
