Best Connectivit
y
www.LogiLink.
Art No. PC0057
com
USB3.0 4-Port PCI-Express Card
With this PCI Express controller card you easily add 4 extra Super Speed USB
ports to your desktop computer and upgrade the dataspeed to 5Gb/s! The
PC0057 has a maximum dataspeed of 5Gbs, which makes it very fast to copy
very large files or documents to and from your desktop computer. You simply
place this USB 3.0 PCI Express controller card in the PCI-e slot of your computer,
install the included drivers and ready you are!
Specification:
General:
• Chipset: VIA VL800
• Compliant with PCI-Express Revision 2.0
• Full single lane PCI- Express throughput
• Fully Plug & Play and Hot Plug
• Supports Windows XP/Vista/7/8
USB3.0
• 4 Ports USB3.0 A female
• Compliant with USB3.0 Specification
Rev 1.0
• Compliant with USB3.0 (5Gbps),
USB2.0 (480Mbps), and USB1.1
(12Mbps)Specification
• Supports USB legacy function
• USB Bus Power/Self Power
• Supports External Power Socket in
order to supply power for each USB3.0
Connector up to 900Ma Max/port
Package contents
• 1 x USB3.0 4-Port PCI-Express Card
• 1 x CD Driver
• 1 x User Manual
Packaging Information:
• Packing Dimension: 172x167x60 mm
• Packing Weight: 0.14kg
• Carton Dimension: 400x400x370 mm
• Carton Q'ty: 40pcs
• Carton Weight: 5kgs
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
