www.LogiLink.
Art No. PC0017
PCI Multi I/O Controller Card,
4-Port Serial
com
Specification:
General
• Compliant with PCI Local Bus
specification Rev. 2.3
• Automatically selects IRQ and I/O
address
• Supports PCI IRQ sharing feature saving
valuable resources for other add-on
card
• Supports PCI power Management
• Supports Multiple cards on one PC
• Fully Plug and Play Compatible
• Supports Windows 98SE/
ME/2000/2003/2008/XP/Vista/7, Linux
Kernel 2.6.14 or above, and Dos 6.22
RS232 (Serial) Interface:
• 4 x RS232 (D-Sub 9P) External Ports
• Compatible with industrial standard
16C550 UART
• On-chip 256-byte depth FIFO in
Transmit & Receive paths of each port
• Fast Date Rate up to 115.2K bits/sec on
each port
• Supports hardware and software flow
control
• Supports 5-, 6-, 7-, 8-, 9-bit serial
format
• Supports Even, Odd, None, Space &
Mark parity
• Supports 1 or 2 Stop bit operation
Package Content:
• 1 x 2-Port Serial PCI Card
• 1 x 2-Port Serial Bracket Cable
• 1 x CD
• 1 x User Manual
Packaging Information:
• Packing Dimension: 172x182x37 mm
• Packing Weight: 0.19kg
• Carton Dimension: 760x410x210 mm
• Carton Q'ty: 40pcs
• Carton Weight: 8kgs
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
