19“ FULL HD LCD 1-Port KVM Console
HDMI KVM Module Features
Single USB console control 1HDMI interface computer and two additional USB devices
Supports USB TYPE A interface type keyboard and mouse device
HDMI LCD Console resolution in Optimum:1920x1080p@60 Hz
KVM module resolution in Max: 4K@30 Hz (3840x2610@30 Hz)
Switch the computer through the front panel buttons, keyboard hotkeys and screen menu (OSD)
Connect to the controlled device for BIOS-level access without worrying about the risk of viruses and Trojans
The controlled computer does not need to install any software and drivers, and the controlled computer directly recognizes KVM
Upgrade remote network control mode by extending IP BOX
Supports OSD to set user login mode and increase KVM login security requirements
Supports widescreen resolution
Supports DDC communication to adapt to different graphics devices
Auto scan function monitors all computer operations
Supports for cross-platform operations - Windows, Linux, Mac, and Sun
Art-No.
LC903GE DE (German) 4052792065848
LC903US US (English) 4052792065855
Made in China
Keyboard Layout
EAN Code
www.2direct.de
*All trade names referenced are the registered trademarks of their respective owners.
*The specifications and pictures are subject to change without prior notice.
19” High-Definition Monitor Specifications
Ratio 18,47” Screen, 16:9
Video Wide AHVA TFT-LCD
Visible Square 409,96(H)x230,04(V)
Resolution 1920x1080@60 Hz
LCD Monitor
Support Color 16,7M, True 8 bit
Contrast 1000:1 (Typ)
Back Light LED
Pixel Pitch 213x213µm
LED MTBF 100.000 hours
Input power 12V
Keyboard 100Keys, detachable (9 different languages for choose)
Keyboard (demountable
design)
Compatible IBM/AT
Port Standard PS/2; USB
Using Life >1.000.000 Times
Type Touch Screen
Port Standard PS/2
Mouse
X/Y Resolution >1000dots/inch, (40x40/mm)
Using Life >1.000.000 Times
Installation Dimension 40,7x44,5x4,5 cm
Weight 8,5 kg
Microsoft Windows 9, Me/NT/2000/XP, Win 7, Server 2003,
Win 8, Win 10
Made in China
www.2direct.de
*All trade names referenced are the registered trademarks of their respective owners.
*The specifications and pictures are subject to change without prior notice.
