Page 1
USB-C Multifunction
Power Meter
Art. No.: PA0160
Best Connectivity
Protect your USB and USB-C devices effectively by real-time monitoring of charge data, and find
charging problem of USB cables, wall chargers and car charger with the Power Meter.
Features:
» Detecting USB charging current, voltage, discharge
capacity, quantity of electric charge, power and timing for
Android
BC 1.2 (Battery Charging) devices
» Easily for you to find charging problem of USB cables, wall
chargers and car charger
» Built in protective electronic switch element for detecting
safety, it will cut off output automatically to protect the
appliance from damaging
» Premium LCD display with low power consumption
» Wide testing range with a display switch
» Compact size, easy to carry
TM
, Apple® and Qualcomm® 2.0/3.0 (5V/9V/12V),
Easily to find charging problem of USB cable, wall charger and car charger
4 display interfaces
Page 2
USB-C Multifunction
Power Meter
Art. No.: PA0160
Best Connectivity
Specification:
Voltage Measuring Range
Current Measuring Range
Quantity of Electric Charge Range 0~999999MWh (Precision 0.001Wh)
Power Metering Range 0~299.999W (Precision 0.001W)
Timing Maximum Time
Time to Refresh
Measurement Rate 0.5 times/s
Working Temperature
Working Humidity
Self Current Consumption
The Pressure of Work 80~160kPa
Product Dimension
Product Weight 15g
3.6V~30V (Precision 0.01V)
0~5A (Precision 0.01A)
0~999hours 59min 59s (Accuracy: 1s)
>500ms/time
-10°C~60°C
10%~80% RH
<0.015A
67 x 62 x 11mm
Package Contents:
» 1 x USB Digital Power Meter
» 1 x User Manual
Package Informations:
» Packing Dimension: 135 x 105 x 25mm
» Packing Weight: 0.04kg
» Carton Dimension: 460 x 290 x 250mm
» Carton Q‘ty: 100pcs
» Carton Weight: 6kg
