Art No. UA0216
de
USB3.0 2-port Sharing Switch
UA0216 allows two computers to share one USB printer or one USB3.0 device. It
provides you a great solution to share USB devices between two 2 PCs to save the
limited budgets on USB devices. This switch can support up to data transfer rate to
5Gbps.
It is built-in not only one push button but also “Hot Key” function for PC compatible.
There is only one computer can access USB3.0 device each time. The “Hot Key”
function enables the user to press the select button without leaving the desk and
retrieve the USB port back to him right away. It can also be connected to a USB hub.
To expand the number of devices, you can share between the two connected systems.
Feature:
• 2 PCs share one USB printer or the other USB3.0 device
• Supports data transfer rate up to 5 Gbps
• Plug-and-Play
• USB Bus Powered, no additional power adapter or wall outlet required
• Using push button, Hot Key to switch USB device port between PCs and easy
operation
• LED indicator work status
• Compatible with USB 1.1 / USB 2.0 / USB 3.0
• Connects a USB hub to share additional peripherals
• Supports Windows 2000 / XP / Vista / 7/8 and Mac OS 10.3 and higher
Specifications:
Function
PC Port 2 x USB3.0 B-Type Female
USB Device Port 1 x USB3.0 A-Type Female
Port Selection Push button (For PC/MAC)
& Hot key (Only for PC) 1Gbps / non-blocking
LED 3 x LED
Compatible USB Device USB 1.1 / 2.0 / 3.0
Maximum Data Transfer Rate USB3.0 5Gbps
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
Page 2
Best Connectivit
y
www.LogiLink.
Art No. UA0216
USB3.0 2-port Sharing Switch
USB device selection Push button & Hot key
Operation Temperature 0~40 °C
Storage Temperature 0~60 °C
Dimension (L x W x H) 95x68x23.5 (mm)
Weight 40g
Operating System Windows (2000, XP, Vista, 7,8) and Mac (OS 10.3 and
higher)
Enclosure Type Plastic
Color Black
de
Package Contents:
• 1 x USB3.0 2-port Sharing Switch
• 1 x User Manual
Packaging Information:
• Package Dimension: mm
• Package Weight: kg
• Carton Q’ty: pcs
• Carton Dimension: mm
• Carton Weight: kg
