DIN-Rail Digital Time Switch
Art. No.: ET0010
Best Connectivity
24 hours/7days programming Time switch with LCD screen automatically switch on/off your
electric equipment such as neon lights, water heater, street lamps or garden watering at a preset
time.
Features:
» Total of 8 On/Off programs with 16 combinations of day
or blocks of days are available
» Easily to change setting between automatic or manual
» Switchable 12/24 hour mode
» Supports Daylight saving mode
Specification:
Input Voltage 220-240V AC 50Hz
Switch Capacity 16A 3600W
Minimum Function Time 1 minute
Type Din-rail
Display LCD
Accuracy ±1 minute per month
Battery Backup NiMH 1.2V>100 hours
Package Contents:
» 1 x Din-Rail Digital Timer Switch
» 1 x User Manual
Package Information:
» Packing Dimension: 99 x 68 x 42mm
» Packing Weight: 0.13kg
» Carton Dimension: 360 x 210 x 115mm
» Carton Q‘ty: 50pcs
» Carton Weight: 4.2kg
*If the time switch is to be used in combination with other devises; it is necessary to
verify that no parastic disturbances will be caused by the group.
