Page 1
Best Connectivity
www.LogiLink.
Art No. FM0001A
com
FM Transmitter + MP3 Player
Specification:
• Supports SD cards and has one USB and Audio interface to connect MP3 and MP4
devices
• Supports MP3 and WMA format
• Reads files from SD card and USB interface directly
• LED Display; shows frequency information
• Full frequency range (87.5 – 108 MHz)
• Saves frequency and music title
• Secure transmitter power and frequency transfer
• Rotatable axis for easy use
• Modern and stylish design
• Device starts with the last saved parameter for frequency, volume and title number
• Supports SD card up to 16GB.
20 Keys Remote Control:
Play / Pause Start / Stop the music
CH ( - ) / CH (+) Frequency down / Frequency up
EQ 8 Models to change the sound characteristics:
Volume ( - ) Volume down
Volume (+) Volume up
PREV Previous track
NEXT Next track
0123456789 Number keys for setting the frequency &
Pick Song Confirms picking a song after selection with
CH Set Confims setting the frequency after selection
E1: NORMAL (Default setting), E2: ROCK, E3:
POP, E4: CLASSIC, E5: SOFT, E6: JAZZ, E7:
DBB, E8: SRS
picking songs
the number keys
with the number keys
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
Page 2
Best Connectivity
www.LogiLink.
Art No. FM0001A
FM Transmitter + MP3 Player
Overview:
1. FM Frequency Choose
2. Play / Pause
3. Previous / Volume "-"
4. Next / Volume "+"
5. LED Display
6. Audio output Jack
7. SD Card
8. Connect to USB Flash or USB Card Reader
com
Package Contents
• 1 x FM Transmitter
• 1 x Remote Control
• 1 x Audio Cable
• 1 x User Manual
Packaging Information:
• Packing Dimension: 157x198x87 mm
• Packing Weight: 0.15kg
• Carton Dimension: 470x290x340 mm
• Carton Q'ty: 20pcs
• Carton Weight: 3.6kgs
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 2 -
