USB3.1 PCI-Express Card,
2-Port
Art. No.: PC0080
Best Connectivity
Support the USB3.1 standard with a transfer rate of up to 10 Gbps.
Features:
» Supports PCI Express Gen2 x2
» Compliant with USB3.1 Gen2 specification
» Up to 10Gbps bandwidth performance with low latency
» Backward compatible with USB3.0/2.0/1.1 devices
» Bridge PCI Express to USB3.1
» Support 2 ports USB3.1 type A connector, 5V/1.5A (7.5W) per port
» Adapts Asmedia ASM1142 chipset
» Supports driver on Win7
» Win8, Win8.1 and Win10 build-in driver support, just Plug & Play
Specification:
» Supports PCI Express Link power management
» Compliant with PCI Express Base 3.0 Specification
» Compliant with Universal Serial Bus 3.1 Specification Revision 1.0
» Compliant with PCI Bus Power Management Interface Specification Revision 1.2
» Compliant with xHCI (eXtensible Host Controller Interface) specification Revision 1.1
» Compliant with UASAP (USB attached SCSI Protocol) Revision 1.0
» Supports USB3.1 and USB2.0 Link Power Management
» Supports Control, Bulk, Stream, Interrupt, Isochronous transfer type
» Supports independent port power control
» Supports over-current detection
» Supports Remote/Wakeup event
» Backward compatible with Legacy USB function and device
» Product Dimension (LxWxH): 94mm x 120mm x 22mm
» Product Weight: 48.5g
USB3.1 SuperSpeed+
USB3.1 PCI-Express Card,
2-Port
Art. No.: PC0080
Best Connectivity
Package Contents:
» 1 x USB3.1 PCI-Express Card
» 1 x Low Profile Bracket
» 1 x CD
» 1 x User Manual
Package Informations:
» Packing Dimension: 173 x 163 x 25mm
» Packing Weight: kg
» Carton Dimension: 520 x 366 x 185mm
» Carton Q‘ty: 40pcs
» Carton Weight: kg
