Fibre Uniboot Patch Cord OM4, LC-LC
Technical Features
Halogenfree outer jacket
Cable OD: 3.0mm
OM4 50/125µm
For 10 Gbit Ethernet
UPC Polish
Changeable uniboot
Used in high density integration system
Color: Erika violet
Technical Drawings
LC Dust
Cap White
LC Uniboot
Duplex Connector, Erika Violet
Made in China
LC MM
Ferrule
Ceramic
LC White Boot
Heat Shrink
Tube White
Fiber Optical Cable Duplex Ø3.0mm OM4 Erika Violet LSZH
( one tube with 2 fiber)
www.logilink.de
Test Method (Grade Designation)
Type Multi-Mode Standard
Insertion Loss ≤0.25dB IEC61300-3-4
Return Loss ≥25dB IEC61300-3-6
Test Wavelength 850mm
Typical ≤0.12dB
Durability 0.2dB after 500 times mating IEC61300-2-2
Temperature Range -20˚C~60˚C IEC60794-2
End Face x IEC/PAS 61300-3-35
Fiber Cable Straight Pull 6.8kg GR-326-CORE
x
x
LC Uniboot Connector Switch Polarity
1
Get ready to switch.
2
Open the connector bottom.
3
Made in China
Switch the polarity.
4
Close the connector.
www.logilink.de
Length Art-No. EAN Code
0.50 m FP4UB00 4052792056815
1.00 m FP4UB01 4052792056822
2.00 m FP4UB02 4052792056839
3.00 m FP4UB03 4052792056846
5.00 m FP4UB05 4052792056853
7.50 m FP4UB07 4052792056860
10.00 m FP4UB10 4052792056877
15.00 m FP4UB15 4052792056884
20.00 m FP4UB20 4052792056891
Package Contents
1 x Fiber Uniboot Patch Cord OM4
Packaging Information
Art no. Packing Dimension Packing Weight Carton Dimension Carton Q‘ty Packing Weight
FP4UB00
FP4UB01
FP4UB02
FP4UB03
FP4UB05
FP4UB07
FP4UB10
FP4UB15
FP4UB20
Made in China
160 x 200 x 20mm 1.153kg 450 x 250 x 250mm
160 x 200 x 20mm 0.139kg 450 x 250 x 250mm
160 x 200 x 20mm 1.952kg 450 x 250 x 250mm
160 x 200 x 20mm 0.301kg 450 x 250 x 250mm
200 x 240 x 20mm 4.433kg 450 x 250 x 250mm
200 x 240 x 20mm 0.732kg 450 x 250 x 250mm
200 x 240 x 20mm 8.925kg 450 x 250 x 250mm
200 x 240 x 20mm 0.127kg 450 x 250 x 250mm
200 x 240 x 20mm 1.356kg 450 x 250 x 250mm
300pcs
300pcs
250pcs
200pcs
120pcs
50pcs
80pcs
50pcs
50pcs
www.logilink.de
3.96kg
4.67kg
5.38kg
6.52kg
5.82kg
4.16kg
7.64kg
6.85kg
7.28kg
