VGA with Audio to
HDMI Converter
Art. No.: CV0060
This VGA with Audio to HDMI converter allows you to connect analog VGA video signal to a digital HDMI
display; comes with 3.5mm audio input for combining audio into the HDMI output.
Plug
&
VGA HDMI
» Compliant with High Speed HDMI
» Compatible with PC VGA resolutions 480i/480p/576i/576p/720p/1080i/1080p
» HDMI transmission rate: 4.95 Gbps
» Supports 165 MHz/1.65 Gbps per channel (4.95 Gbps all channels) bandwidth
» Supports 12 bit per channel (36 bit all channels) deep color
» Supports uncompressed 2 channel audio such as LPCM
» Cable length: 15 cm
» Product dimensions: 5.4x3.7x1.3 cm
» Product weight: 0.05 kg
Play
Input
Audio
Transmission
Output
HDT V/M onitor
3.7 cm
5.4 cm
15 cm
*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
v.2
VGA with Audio to
HDMI Converter
Art. No.: CV0060
Specifications:
Input VGA, male
Input Video Signal 0.5–1.0 volts p-p
Output HDMI-A, female
Resolution 480i/576i/480p/576p/720p/1080i/1080p
Video Amplifier Bandwidth 1.65 Gbps/165 MHz
Vertical Frequency Range 50/60 Hz
Operating Temperature 0–70 ˚C
Operating Humidity 10–85% RH (no condensation)
Storage Temperature -10 – 8 0 ˚C
Storage Humidity 5–90% RH (no condensation)
Power Connection USB Power cable
Power Consumption 5 W max.
Package Contents:
» 1 x VGA with audio to HDMI Converter
» 1 x Audio Cable
» 1 x USB Cable
» 1 x User Manual
Package Information:
» Packing Dimension: 137x146x16mm
» Packing Weight: 0.075 kg
» Carton Dimension: 575x235x340 mm
» Carton Q‘ty: 160 pcs
» Carton Weight: 12.7 kg
*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
