USB-C™ 3.2 Gen 2 Cable
with E-mark & PD
Art. No.: CU0130
CU0131
This USB-C 3.2 Gen 2 cable provides you the fastest charging and synchronization; the PD fast charging
with E-mark chip supports the device intelligently and delivers the fastest available current up to 20 V/5 A
(100 W). Sync the data of your laptops, tablets and smartphones at high speed up to 10 Gbps.
» Supports Power Delivery 3.0 up to 100 W (20 V/5 A); with an E-mark chipest allows you to reliably
power USB-C devices at the possible fastest speed
» Supports data transfer speeds of up to 10 Gbps
» Compatible with Thunderbolt 3
» Supports charging, data transfer for audio and video resolution up to Ultra HD 4K@60 Hz
» Works for source devices with USB-C or Thunderbolt 3 port interfaces that support the DisplayPort
alternate mode ( DP Alt mode )
» Enjoy the highly qualified image quality and sound effect
» Supports reversible USB-C connector
» Compatible with most USB-C enabled Laptop, smartphone and tablet devices
(Thunderbolt 3 compatible)
4K
60Hz
100W
Power
Delivery
Laptop
PD3.0
10 Gbps
Data
Transfer
Fast Charging
High Speed Data Transfer
USB-C
USB-C
with E-mark
*The maximum power output is depending on
the device to be charge and the power
adapter used.
*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
Tablet/Smartphone
100 W USB-C Power Adapter
4K
Monitor/TV
v.2
USB-C™ 3.2 Gen 2 Cable
with E-mark & PD
Art. No.: CU0130
CU0131
Art-No.
CU0130 0.5 m 4052792050462
CU0131
Cable Length
1 m
EAN Code
4052792050479
Specifications:
Connection 1 USB-C 3.2 Gen 2, male
Connection 2 USB-C 3.2 Gen 2, male
Connector Material Nickel-Plated
Data Transfer Rate Up to 10 Gbps
Max. Resolution 4K@60 Hz
Max. Current Up to 5 A
Color White
Package Content:
» 1x USB-C 3.2 Gen 2 Cable
Package Information:
Art-No. Packing Dimension Packing Weight Carton Dimension Carton Q‘ty Carton Weight
CU0130 175x185x3 mm 0.03 kg 420x380x220 mm 100 pcs 4 kg
CU0131 175x185x4 mm
*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
0.042 kg
420x380x220 mm
100 pcs 5.2 kg
v.2
