Art No. CH0021 to CH0025
HDMI to Mini HDMI Cable
The optimized HDMI cable is specially designed for the latest HDMI version. The HDMI Ethernet Channel technology consolidates video, audio, and data streams into a single HDMI
cable, and enables high-speed networking at up to 100 Mb/ sec. Audio Return Channel allows an HDMI-connected TV with a built-in tuner to send audio data "upstream" to a surround audio system. Imaging 3D via HDMI and support all HDTV formats including 480p, 720p, 1080i, 1080p and 4K (4096 x 2160). In addition to RGB color and x.v.Color, it supports for three additional color spaces (sYCC60, Adobe RGB, and Adobe YCC601), enabling to deliver better accurate color on an HDTV.
Specification:
• HDMI type A male to Mini HDMI type C male cable
• Connector: Gold Plated
• Color: Black
• OD: 6.0MM
• HDMI M 19P Solder Type, Insulation: Black, Shell Gold Plated
• Mini HDMI M 19P Solder Type, Insulation: Black, Shell Gold Plated
• Cable:
- CH0021-24: (30AWG*lPR+AL)*4C+(30AWG*lPR+EAM)*lC+30AWG*4C+EA
- CH0025: (28AWG*lPR+AL)*4C+(30AWG*lPR+EAM)*lC+30AWG*4C+EA
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
www.LogiLink.
Art No. CH0021 to CH0025
HDMI to Mini HDMI Cable
Electrical Test:
1. 100% Test (Open, Short, Mis Wire)
2. Contact Resistance: 3 ohm max.
3. Insulation Resistance: 10M ohm min.
4. Hi-Pot Test: DC 300V/10ms
com
Packaging Information:
Model Name
CH0021 100cm 15mm 0.057kg 140pcs 500x320x210 mm 9.0kgs 4260113573273 CH0022 150cm 20mm 0.075kg 100pcs 500x320x210 mm 8.5kgs 4260113573280 CH0023 200cm 30mm 0.091kg 80pcs 500x320x210 mm 8.3Kgs 4260113573297 CH0024 300cm 40mm 0.139kg 60pcs 500x320x210 mm 8.8kgs 4260113573303 CH0025 500cm 50mm 0.213kg 40pcs 500x320x210 mm 9.5kgs 4260113573310
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
L T Packing
Weight
Q'ty Carton
Dimension
Carton Weight
EAN Code
