Best Connectivit
y
t
www.LogiLink.
Art No. CAB1101Ar
com
Toslink Audio Cable M/M,
Metal, 1.5 m
Our Toslink Cable is Gold Plated for optimized connectivity, longevity
and signal strength. The Fiber-Optic tip is precision-polished for
maximum signal transfer. Use our premium Toslink Cable to transfer
100% Digital Optical Audio from Dolby Digital Receivers, Digital
Signal Processors, DivX Players, DVD players, CD players, DSS
receivers, Sony Playstation 2 & 3, XBox and much more.
Technological Parameter
Item Spec.
Fiber Diameter 1 mm
Outside Diameter 2.2 mm
Fiber Material PMMA
Application Lighwave 650 nm
Attenuation ≤ 0.18 dB/m
Bend Radius 5X core Diameter
Used Temperature -15º ~ 80º
Connection Loss ≤0.5 dB
Duttter PVC Diameter 5.0+0.2
Packaging Information:
L T Q'ty Carton Dimension
150 cm 3 cm 20 pcs 420x340x270 mm
Fiber Specification
Item Spec.
Center
Core
Outer
Coating
Outer
Sheath
Material Plastic Fiber
Construct mm/No. 0.98 mm x 1
O.D. mm 0.98
Material PE
O.D. mm 2.2
Color Black
Material PVC
O.D. mm 5.0±0.2
Color Black
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
