Best Connectivity
www.LogiLink.
Art No. BT0037
de
USB Bluetooth V4.0 Dongle
The LogiLink USB Bluetooth V4.0 Dongle - Size ultra small, but Performance
much better. With only 2.3cm in length including USB connector, you will love it
without interfering with other objective with your Notebook.
Integrated Bluetooth V3.0 technology so you can enjoy the high speed wireless
data transfer rate,and ultra low energy consumption.
Feature:
• Chipset: CSR / BC8510
• Bluetooth V4.0 + EDR, Class 1, up to 100 meters
• Data Rate: up to 3Mbps
• Compatible to USB1.1/2.0/3.0 standard
• Audio Gateway on PC with Bluetooth Headset for VoIP, MSN, Skype
• Share/Edit/Print documents via Bluetooth; Synchronize info of Mobile/PDA with PC
• Supports Windows XP/Vista/7/8/8.1/10
• Software: IVT BlueSoleil 10.0
Specification:
Bluetooth Standard V4.0+EDR (Backward compatible with V1.1/V1.2/V2.0/V2.1/
V3.0)
Profiles Support BLE PXP(Proximity), FMP(Find Me), ScPP(Scan Parameters), HID (HID
over BLE)
Profiles Support A2DP, APT-X, AVRCP, BIP, BPP, DUN, FTP, GAP, GATT, GAVDP,
HCRP, HF, HS, HDP, HID, HOGP, OBEX, OPP, PAN, PBAP, SPP,
SYNCH, SYNC ML, VDP
Frequency Range 2.402-2.480 GHz / 79 Channel FHSS
Transfer Rates (Max.) 3 Mbps(Max.)
Power Class Class 1 (100M distance)
Receiving Sensitivity -88dBm for basic rate
Antenna Integrated PCB Antenna
Current Consumption Standby mode: 25mA / Transmission mode: 80mA
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
Best Connectivity
www.LogiLink.
Art No. BT0037
USB Bluetooth V4.0 Dongle
Input Power DC 5V (via USB port)
Interface USB A type, USB 2.0 full-speed compliant
OS Support Windows XP/Vista/Win 7/Win 8/Win10
Environment Temp. Operation Temp.: -10°C ~ 50°C
Storage Temp: -20°C ~ 60°C
Dimension 23 x 14.2 x 4.5 mm (L x W x H)
Weight Approx. 2.4 grams
de
Package Contents:
• 1 x USB Bluetooth V4.0 Dongle
• 1 x Quick Installation Qiude
• 1x CD
Packaging Information:
• Packing Dimension: 108 x 125 x 14mm
• Packing Weight: 0.025kg
• Carton Dimension: 405 x 315 x 280mm
• Carton Q'ty: 200pcs
• Carton Weight: 5.6kg
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
