Full Motion TV Wall Mount
for 23“-42“ TV
Art. No.: BP0008
Best Connectivity
2-pieces easy installation design, compatible with VESA standard max. 200x200mm.
Features:
» Super strong mounting brackets: Solid-reinforced Cold Steel, durable product with
maximum capacity of 25kg
» 72mm-403mm Profile from wall with Tilt capacity: 7.5°~-7.5° and
Swivel capacity: 90°~-90°
» Compatible with VESA 75x75mm,100x100mm, 200x100mm, 200x200mm
» Easy to install
» Cable clips included keep cables organized
» Fit for 23-42 inch LED LCD plasma TV, PC Monitor screens
Remove the wall plate from the wall mount
Install the wall plate to the wall
Install the wall mount to back of the TV
Apply the TV with wall mount to the wall plate

Full Motion TV Wall Mount
for 23“-42“ TV
Art. No.: BP0008
Best Connectivity
Specification:
Screen Size
Rated Load 25kg/55Ibs
VESA
Tilt
Swivel
Distance to the wall 72-403mm
Product Size 230 x 230 x 403mm
Package Contents:
» 1 x TV Wall Mount
» 1 x Screw Package
» 1 x User Manual
Package Informations:
» Packing Dimension: 265 x 239 x 70mm
» Packing Weight: 2.32kg
» Carton Dimension: 480 x 280 x 340mm
» Carton Q‘ty: 8pcs
» Carton Weight: 19.74kg
23"-42"
75x75, 100x100, 200x100, 200x200
7.5°~-7.5°
90°~-90°
This pro duct is designed to be inst alled on wood stud walls, solid concre te walls or b rick walls.
Make sur e that the s uppor ting sur face w ill safely support the combined weight of the equipment and all attach ed hardw are and component s.
This pro duct is in tened for indoor u se only. Using this product outdoors could lea d to produc t failur e and pers onal inju ry.
