Full Motion TV Wall Mount
for 23“-42“ TV
Art. No.: BP0006
Best Connectivity
2-pieces easy installation design, compatible with VESA standard max. 200x200mm.
Features:
» Super strong mounting brackets: Solid-reinforced Cold Steel, durable product with
maximum capacity of 25kg
» Compatible with VESA 75x75mm,100x100mm, 200x100mm, 200x200mm
» Easy to install
» Fit for 23-42 inch LED LCD plasma TV, PC Monitor screens
Remove the wall plate from the wall mount
Install the wall plate to the wall
Install the wall mount to back of the TV
swivel
±25°
+7.5°
tilt
-7.5°
76mm
Apply the TV with wall mount to the wall plate
Full Motion TV Wall Mount
for 23“-42“ TV
Art. No.: BP0006
Best Connectivity
Specification:
Screen Size
Rated Load 25kg/55Ibs
VESA
Tilt
Swivel
Distance to the wall 76mm
Product Size 230 x 230 x 76mm
Package Contents:
» 1 x TV Wall Mount
» 1 x Screw Package
» 1 x User Manual
Package Informations:
» Packing Dimension: 249 x 239 x 80mm
» Packing Weight: 1.32kg
» Carton Dimension: 497 x 265 x 448mm
» Carton Q‘ty: 10pcs
» Carton Weight: 14.4kg
23"-42"
75x75, 100x100, 200x100, 200x200
7.5°~-7.5°
25°~-25°
This pro duct is design ed to be installed on wood stud walls, so lid conc rete walls or brick walls.
Make sur e that th e suppo rtin g surface will safely suppo rt the combin ed weight of the e quipme nt and all a ttached ha rdware and component s.
This pro duct is intened for ind oor use o nly. Using this product outdoors could l ead to product failure and per sonal injury.
