HDMI Adapter
HDMI-A Female to Mini HDMI Male
Art. No.: AH0009
Best Connectivity
The LogiLink Adapter connects HDMI-A to HDMI C (Mini HDMI) and features gold-plated contacts to ensure an optimum connection. The adapter supports the HDMI High Speed with Ethernet standard, is backwards compatible and therefore suitable for the image formats 480i, 480p,
720p, 1080i, 1080p, 1440p and 2160p.
Features:
» Connector 1: HDMI 19-pin Type A female
» Connector 2: HDMI 19-pin Type C male
» Gold plated contacts
» Transmission of audio, video and ethernet data
» Standard: HDMI High Speed with Ethernet
» 480i, 480p, 720p, 1080i, 1080p, 1440p, 2160p
» Max Data Transfer: Type A: 8.16 Gbit/s
Electrical Test:
1. 100% Open, Short & Mis-wire Test
2. Contact Resistance 2ohms max.
3. Insulation Resistance 5M ohm Min
Package Contents:
» 1 x HDMI Adapter
Package Informations:
» Packing Dimension: 8 x 8.5mm
» Packing Weight: 0.014kg
» Carton Dimension: 440 x 330 x 220mm
» Carton Q‘ty: 1000pcs
» Carton Weight: 14.5kg
