Art No. AD0006A
com
IDE to SATA Converter
The Logilink AD0006A connects a SATA device (HDD/CDROM/DVD etc. ) to IDE
interface (motherboard, and controller card etc.). It allows to use SATA hard
drives and other devices in a computer without a SATA port and converts the
signal. This bridge plugs into an open IDE connector on your motherboard or
controller card and let you connect high-speed SATA drives without the cost and
effort of upgrading. The adapter supports up to 1.5Gbps fast data transfer.
Specification:
• Compliant to Serial ATA 1.0 Standard
• Connect an SATA drives to any computer with internal IDE controller
• Ultra low power consumption with the power management
• Supports Master and Slave
• Plug and Play installation
• Supports ATA/ATAPI Ultra DMA Modes and PIO modes 0-4 up to 1.5Gbps
• Connector: 1 x IDE 40 pin, 7 pin SATA connector, and 1 x 4 pin power connector
Package Content:
• 1 x IDE to Serial ATA Converter
• 1 x Y-Power Cable
• 1 x SATA Power Adapter
• 1 x SATA Connection Cable
• 1 x Quick User Guide
Packaging Information:
• Packing Dimension: 170x175x50 mm
• Packing Weight: 0.1kg
• Carton Dimension: 400x400x370 mm
• Carton Q'ty: 40pcs
• Carton Weight: 6kgs
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
AD0006A
4 260113 566329
Made in China
