Logik L150CF12 Instruction Manual

Chest Freezer

Instruction Manual
L150CF12

Contents

Unpacking .................................................................................................................................... 4

Installation ................................................................................................................................... 5

Location ..................................................................................................................................................................... 5

Levelling the Unit ................................................................................................................................................... 5

Cleaning Before Use ..............................................................................................................................................5

Before Using Your Unit ..........................................................................................................................................5

Product Overview ........................................................................................................................ 6

Operation ..................................................................................................................................... 7

Switching On Your Unit ........................................................................................................................................ 7

Adjusting the Temperature ................................................................................................................................. 7

Fast Freezing.............................................................................................................................................................7

Noises Inside the Unit! .......................................................................................................................................... 8

Shopping for Frozen Foods ................................................................................................................................8

Preparations for Freezing.....................................................................................................................................8

Defrosting Frozen Food ........................................................................................................................................9

Cleaning .....................................................................................................................................10

Defrosting ...............................................................................................................................................................10

Cleaning the Interior and the Exterior of the Unit ....................................................................................10

Cleaning Tips ..........................................................................................................................................................10

Maintenance ..............................................................................................................................11

Care When Handling / Moving the Unit .......................................................................................................11

Servicing ..................................................................................................................................................................11

Switching O for Long Periods of Time ........................................................................................................11

Disposal ...................................................................................................................................... 11

Troubleshooting ........................................................................................................................ 12

Power Cut ...............................................................................................................................................................12

The Freezer is Particularly Cold .......................................................................................................................12

The Freezer is Particularly Warm ....................................................................................................................12

The Freezer is Not Working ..............................................................................................................................12

Condensation Appears on the Outside of the Freezer ..........................................................................12

Specications ............................................................................................................................. 13

Safety Warnings ......................................................................................................................... 14

4

The Main Unit

Freezer Basket

P.N.: 502903050026

Instruction Manual

P.N.: L150CF12-001

Unpacking

Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.

The following items are included:

OFF

Power Run Alarm

SUPER

5

4

3

2

1

Thank you for purchasing your new Logik Chest Freezer.

You must spend some time reading this instruction manual in order that you
fully understand all the operational features it offers.

You must read all the safety instructions carefully before use and keep this
instruction manual for future reference.

If items are missing or damaged, please contact Partmaster (UK only).

Tel: [phone] for assistance.

Plastic Scraper

P.N.: 501105040009

INSTALLATION

5

Location

When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 38°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.

When installing the unit, ensure that 100 mm of free space is left at both sides, 100 mm at
the rear. Please ensure there is adequate space for the door to fully open at the top.

Levelling the Unit

To do this adjust the two levelling feet (positioned
on the left) of the unit.

If the unit is not level, the door and magnetic seal
alignments will not be covered properly.

Cleaning Before Use

Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a ‘wrung-out’ sponge or cloth. Wipe completely dry before. Clean the exterior of
the unit with a damp cloth.

If you require more information refer to the Cleaning section.

Installation

Before Using Your Unit

Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is
working properly and to allow it time to fall to the correct temperature. Your unit should not
be overfilled.

• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with

the unit.

• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs

time to settle.

6

OFF

Power Run Alarm

SUPER

5

4

3

2

1

OFF

Power Run Alarm

SUPER

5

4

3

2

1

Product Overview

Freezer Basket

Levelling

Feet

Water Drain

Plug

Power

Indicator

Run

Indicator

Alarm

Indicator
