Instruction Manual
Corded Big Button Telephone with Speakerphone
L05CBIG10
Contents
Locating the Base Unit ..............................................................................................7
Control Overview ......................................................................................10
Operation ..................................................................................................12
To Make a call ............................................................................................................. 12
To Answer a Call ........................................................................................................ 12
To Adjust the Handset Volume ............................................................................ 12
To Adjust the Speakerphone Volume ............................................................... 12
To End a Call ............................................................................................................... 12
To Switch between the Handset and the Speakerphone .......................... 12
Last Number Redial ................................................................................................. 12
Mute Function in Handset mode........................................................................13
Mute Function in Speakerphone Mode ........................................................... 13
Use on PBX ..................................................................................................................13
Inserting a Pause in the Dialing Sequence ..................................................... 13
Storing a Number in (0-9) two-touch memories .......................................... 13
Dial out Stored number (0-9) two-touch memories ....................................14
Helpful Information ..................................................................................15
Specications ............................................................................................15
4
Safety First
For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below.
• Read all instructions carefully before using the telephone and keep them for future reference.
• Retain the manual. If you pass the telephone onto a third party, make sure to include this manual.
• Follow all warnings and instructions marked on the telephone.
• Do not use the product near water for example near a bathtub, kitchen
sink, etc.
• Place the product securely on a stable surface. Serious damage and/or injury may result if the product falls.
• Do not cover slots and openings on the telephone. They are provided for ventilation and protection against overheating. Never place the telephone near radiators, or in places with poor ventilation.
• Do not place objects on the telephone line cable. Install the phone where no one can step or trip on the telephone line cable.
• To reduce the risk of injury or electric shock, do not disassemble the telephone. Incorrect reassembly can cause electric shock when the product is subsequently used.
• During thunderstorms, avoid using telephones except cordless types. There may be a remote risk of an electric shock from lightning.
• Do not use the telephone to report a gas leak, when in the vicinity of the leak.
• Young children should be supervised to ensure that they do not play with the telephone.
• The telephone is not intended for use by persons (including children) with reduced sensory or mental capabilities, or lack of experience and knowledge unless they have been given supervision or instructions concerning the use of the telephone by a person responsible for their safety.
5
CAUTION:
Installation
• Never install telephone wiring during a lightning storm.
• Never install a telephone wall socket in wet locations unless it is
specifically design for wet locations.
• Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
• The telephone is designed for use on vertical walls constructed of
solid brick, solid concrete, solid wood and solid wood columns. It is the installers responsibility to verify that the wall structure/surface will safely support the total load (combined weight of telephone base and handset). If the installer has any uncertainties about the wall structure/ surface, they must contact a qualified installer.
• Do not use this product for any applications other than its intended purpose.
• Do not over tighten the screws.
6
Thank you for purchasing your new Logik
Corded Big Button Telephone with Speakerphone. We recommend that you spend some time to read this Instruction
Manual in order to fully understand how to install and operate it. Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so according to local regulations.
Handset Cord
Telephone Line
Cord
Handset
Instruction Manual
Main Unit
If items are missing, or damaged please contact Partmaster (UK only).
Tel: 0344 800 3456 for assistance.
Instruction
Manual
7
Getting Started
Locating the Base Unit
1. The base unit should be placed on a level surface, in a position where:
• The telephone line cord will reach your telephone line wall socket.
• It is not close to a sink, bath or shower, or anywhere else where it
might get wet.
• It is not close to other electrical equipment - fridges, washing
machines, microwave ovens, TVs, fluorescent lights, etc.
2. Plug the handset cord into the handset. Plug the other end into the side of the base unit.
3. Place the handset on the base unit.
4. Plug one end of the telephone line cord into the socket of the base unit, and the other end into your telephone line wall socket.
5. Lift the handset and check for a dial tone.
Make sure the plugs click into place.
Ringer HI/LOW switch.
To telephone line wall socket.
Always use the telephone line cord supplied with your telephone. Other telephone
line cords may not work.
8
Wall Mounting (optional)
1. Mark two points on the wall that are 80mm apart to lay the fixing
centres as shown below.
Wall
Wall plug
Screw
80mm
wall mount slots
2. Drill holes in the wall.
3. Insert the wall plugs into the holes.
4. Drive in the screws and make sure to leave approximately 5mm of the
screw head from the wall to hold the base unit securely.
5. Hang the base unit on the screws using the wall mount slots.
Before you drill any holes, make sure there is no electrical wiring or pipes hidden
in the wall.
9
Parking Recess
Parking Hook
Slide-out
Rotate
Slide-back in
1
2
3
6. You may need to remove the telephone from the wall and tighten the screws so that the base unit is securely fixed and does not wobble. Place the Handset on the base unit with the parking hook on the base unit arranged to fit in the parking recess under the earpiece on the handset.
10
Control Overview
1
5
12 13 14 15
6 7
8
2
9
3
4
10
11
11
1. Switch Allows you to make a follow-on call without replacing the handset.
2. Wallmount hook Allows your handset to rest securely on the base unit when it’s wall mounted.
3. Speaker For the speakerphone function.
4. Handset volume adjust switch
5. Memory button
6. Store button
7. Hold button
8. Dialpad Use it for entering the number you will be calling.
9. Speakerphone volume adjust switch
10. Speakerphone button
11. Line in Use Light This is on when the phone is on a call.
12. button
13. Redial / Pause button
14. Hold Light This is on when a caller is put on hold.
15. Ringer light This flashes when the phone is ringing for an incoming call.
12
Operation
To Make a call
1. Lift the handset, listen for the dial tone.
2. Dial the telephone number you wish to call.
3. To end the call, return the handset to the base unit.
To Answer a Call
When the phone rings, lift the handset or press the button to answer the call.
To Adjust the Handset Volume
During a call, adjust the volume of the handset earpiece by using the handset volume switch.
To Adjust the Speakerphone Volume
During a call, adjust the volume of the speakerphone by using the switch located on the base unit.
To End a Call
Replace the handset onto the base unit cradle or press the button on the base unit. The light indicator will turn OFF.
To Switch between the Handset and the Speakerphone
1. During a phone conversation through the handset, press the button
to speak hands-free.
2. The light will illuminate, but conversation remains through the
handset until the handset is placed on the base unit.
3. While in speakerphone mode, lift the handset to enable a private
conversation.
Last Number Redial
1. Lift the handset, and listen for a dial tone.
2. Press the button. The phone automatically dials the last number
you called (maximum of 32 digits).
13
Mute Function in Handset mode
1. During a call press the button. When the phone is holding, the person at the other end of the call can hear music from the phone, but cannot hear you. You can hear the music, as well, but can also hear the caller if they speak.
2. To get back to the call, press the button again.
Mute Function in Speakerphone Mode
1. Press the button. The person at the other end of the call will hear music but cannot hear you. You can hear the music as well, but can also hear the caller if they speak.
2. To return to the call, press the button.
Use on PBX
If you are using your telephone on a PBX, and the PBX user guide tells you to press the RECALL or FLASH button, press the button on the base unit.
Inserting a Pause in the Dialing Sequence
1. For some switchboard systems, an access number must be dialled (usually an 8 or 9) to get another dial tone and an outside line.
2. Press the button immediately after the access number to insert a pause of about 3.6 seconds, and the desired number can be dialled immediately.
3. Press the button to insert a pause when dialling or storing Long Distance Access Codes.
Storing a Number in (0-9) two-touch memories
1. Lift the handset press the button.
2. Key in the telephone number you wish to store. Up to maximum 16 digits.
3. Press the button.
4. Press a 0-9 button to store the number in the selected memory.
5. Replace the handset on the base unit.
Do not press the HOLD button again or the call will end.
14
Dial out Stored number (0-9) two-touch memories
1. To dial a number stored in two-touch memory (0-9).
2. Lift up the handset.
3. Press the button.
4. Key in the memory location number (0-9).
5. The number dials automatically.
15
Helpful Information
• Environment
Place the unit in a room where the temperature is between 0°C and 40°C. Allow 5cm clearance around the unit for proper ventilation. Avoid excessive smoke, dust, mechanical vibration, shock, or direct sunlight.
• Cleaning
Wipe the unit with a soft cloth. Do not use benzine, thinner, or any abrasive cleaners.
• If there is no sound
Disconnect the unit from the telephone line and connect a known working phone. If the known phone does not operates or have sound, then it could be a phone line problem. Please contact your telephone company for assistance.
• Moving your phone
Carefully pack your unit, preferably in the original packaging.
• Disposal
Old units still have some residual value. An environmentally friendly method of disposal will ensure that valuable raw materials can be recovered and used again. Up to date information concerning options of the disposal of your old unit and packaging from the new one can be obtained from your local council office.
Specications
Product Dimension: L20cm x W16cm x H7cm Weight: 0.6kg Dialing Mode: Tone (DTMF) Operating Environment: 0 - 40°C
Features and specifications are subject to change without prior notice.
The symbol on the product or its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop o your waste for recycling, please contact your local authority, or where you purchased your product.
Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories. With over 1
million spares and accessories available we can deliver direct to your door the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers only) Calls charged at National Rate.
For general information about this appliance
and handy hints and tips, please visit
www.knowhow.com/knowledgebank or call 0344 5611234.
All trademarks are the property of their respective owners and all rights are acknowledged.
IB-L05BIG10-160602V4
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
