LogicMark 3X911 Users Manual
English
With DECT Technology
SET-UP&OPERATINGINSTRUCTIONS
Guardian Alert
Model#37911
v0.3
PLEASE READ THIS MANUAL COMPLETELY AND SAVE IT
FOR REFERENCE.
Thank you for choosing LifeSentry® – the most unique Personal Emergency
Response System in the world, and covered by both US and Canadian patents.
Because you are speaking through the pendant, This system allows you to
personally communicate your emergency from anywhere in your home or
yard. Emergencies can happen anyplace. And just one button activation.
Voice prompts provide easy set-up and testing.
Base unit comes with 4 rechargeable batteries that provide up to 24 hours of
standby power in the event of a power outage.
Need others to share the system in your home? No problem, you can add up
to 3 additional Pendants to one Base unit for a total of 4 pendants as you wish.
Caution - To ensure proper operation, this System’s equipment must be
installed according to the enclosed installation instructions. To verify
that the equipment is operating properly and can successfully report
an alarm, this equipment must be tested immediately after installation,
and periodically thereafter, according to the enclosed test instructions.
This System is designed to be used in conjunction with a professionally
monitored call center. This system must be programmed by an experienced installer to be fully functional.
2
LifeSentry
®
v0.3
TABLE OF CONTENTS
System Components ..................................................................................4
Limitations of Liability .............................................................................5
Installing the Batteries ..............................................................................6
Connecting the Base Unit
Power Connection ...........................................................................8
Telephone Connections ...................................................................8
Operating the LifeSentry
Emergency Dialing Using the Pendant ...........................................9
Holding the Pendant ......................................................................10
Hanging Up ...................................................................................10
Lanyard, Belt Clip or Wrist-Strap .................................................10
Battery Check ................................................................................11
System Check ................................................................................12
Operating Range ...........................................................................13
Water Resistance ...........................................................................13
Key to LEDs on product ...............................................................14
Periodic Testing / Maintenance
Replacing Batteries .......................................................................14
Adding Additional Pendants to the System ..................................15
Out of Service Storage or Transportation .....................................16
Troubleshooting Guide ...........................................................................17
Disclaimer / General Warnings & Precautions / Safety ......................19
Warranty ..................................................................................................20
Replacement Parts / Additional Accessories Available ........................22
Product Specications ............................................................................23
v0.3 LifeSentry
®
3
System Components:
The items below are included with your system .
Pendant
Rechargeable Lithium-Ion Special
Pendant Batteries - 2 Pieces
Belt Clip
Wrist / Walker / Wheelchair
strap
Base Unit
Rechargeable AA Batteries - 4 Pieces
AC Adapter
Phone Cord
Lanyard
4
LifeSentry
Screwdriver
®
v0.3
Limitation of Liability
This page is a summary of the Disclaimer and Limited Warranty disclosed
in full at the end of this instruction manual. Read these carefully.
The purchaser agrees by using this LifeSentry (the “System”) to the terms
and conditions below and in the Disclaimer and Limited Warranty. The
purchaser also agrees to read and follow all instructions and warnings on the
product and contained within these Installation and Operation Instructions.
It will be the sole responsibility of the purchaser and user to assure that this
System is installed and programmed properly, and that the unit is used and
maintained correctly. This includes, but is not limited to, periodic use to
assure that the system, including batteries, are in proper working order, that
the unit is located in an appropriate location in the home, that the electrical outlet is supplying power, and that the user has been educated as to the
operation and functionality of the product as a whole.
The System’s equipment is not designed or guaranteed to prevent any loss or
injury. This Limited Warranty and Disclaimer of Liability discussed in full
at the end of this instruction manual constitutes the terms of sale and use of
the system (and accessories) equipment, and if, notwithstanding these terms
of sale and use of the product, there should arise any liability on the part of
LogicMark LLC as a result of any cause whatsoever, regardless of whether
or not such loss, damage, or personal injury was caused by or contributed to
by LogicMark’s negligence to any degree or failure to perform any obligation
or strict products liability, such liability will be limited to an amount paid by
the Purchaser for the product.
Further, LogicMark has no obligation to assure that calls are made, received
or responded to, nor is LogicMark responsible for acts, or consequences of
the acts, of those responding.
LogicMark provides no monitoring service for this product. It is up to the
persons at the numbers called to respond in an appropriate manner.
v0.3 LifeSentry
®
5
Installing the Batteries
Pendant - small white batteries. The Pendant requires one of the white
Li-Ion (Lithium Ion) batteries at any given time. The pendant should be able
to run over 4 months on a fully charged battery. The second battery is to be
charging in the Base unit when not being used in the Pendant. There is no
problem of over charging while in the base charger.
The battery should already be installed for you at this time. You can conrm this by simply pushing the gray button on the back of the pendant for a
second. You will hear the battery status.
If your Pendant did not come with the batteries installed - simply follow these
directions: Unscrew the battery cap counter-clockwise. Pull the battery cap
off. Install the battery with the negative side up facing the cap. Re-install
the cap by screwing the cap clockwise until snug .
When the battery is rst installed into the Pendant - you will hear an audible
announcement of the battery status: “Battery is ok”; “Battery is low” or
“Replace battery now”. If the battery is fully discharged when you get your
unit - you may not hear anything - at which point you will need to charge
one of the batteries up overnight in the base charger (at the top front edge of
the base unit) before you will be able to use the system.
You can check the battery status at any time by simply pushing the gray battery test button on the back of the Pendant for a second.
NOTE: These white batteries are very special batteries that are not available
at your local store. See Specication on page 23 for more details, or contact
your dealer or service provider to purchase replacement batteries.
Place the extra Pendant battery into the front charging area of the Base unit
so that it will charge and be ready when its time to swap the batteries around.
The LED on the right side will turn red when charging and green when fully
charged.
6
LifeSentry
®
v0.3
Base - larger AA rechargeable batteries: The Base unit requires 4 rechargeable 2400 NiMH batteries. Unlike the Pendant battery - these are readily
available in many retail stores. These are to provide you with up 24 hours
of battery back-up protection in the event of a power failure. They will not
be damaged by continually charging in the base unit.
These should have been installed for you during the set-up. If they are not
installed, simply follow these directions here.
When you rst get your unit - these
batteries will probably be low, or even
fully discharged - and will need to be
charged overnight before being able to
provide you the 24 hour battery backup protection.
Unscrew the cover on the bottom of
the Base unit with the supplied screwdriver. Install the 4 batteries as shown
in the plastic engraving in the battery
compartment area. A few seconds after you install these, you might hear
“Running on battery power”. This will continue once every minute for the
rst 15 minutes, then once every 30 minutes until power is applied through
the power adaptor - or until the batteries are depleted. (If you do not hear
anything - this simply means your batteries will need to be fully charged
overnight. Or it may mean that you have already plugged in the power
adaptor - which is why it would not announce “Running on battery power”.
NOTE: the voice prompts of “battery is OK” etc only apply to the pendant
battery - not to the status of the base unit’s batteries. It is recommended that
you replace the base unit batteries with a new set of similar batteries every
two years.
v0.3 LifeSentry
®
7
Connecting the Base Unit
Power Connection. Simply plug in the AC Adapter in to the nearest elec-
trical outlet. Plug the other end of the AC power adapter into the Base unit.
You need to push the plug into the opening in the Base unit and twist 90’
clockwise to lock in place. To remove in the future, simply rotate 90’ counter-clockwise and pull outward.
Caution: Do not plug the AC Adapter into an outlet which is controlled
by a switch. The switch could accidentally be turned off, thus rendering
the Base unit inoperable after approximately 24 hour when the back up
batteries become discharged.
Telephone Connection. A standard telephone line is required to use your
system. Your phone will work with your existing touch-tone phone line and
existing service. It works the same way as any cordless phone. NOTE:
Touch Tone service is required.
Simply plug one end of the telephone cord into your telephone jack in the
wall, and the other end into the “Line In” at the back of the Base unit. Note
- you will feel a ‘click’ when the cords are rmly seated in the wall and the
Base unit jack receptacles.
If you need to plug a conventional telephone into same outlet used by the Base
unit, simply plug the telephone into the spare jack labeled “To House Phone”
How to Handle VoIP, DSL and other Internet phones: It is NOT recommended to operate this product over VoIP internet phone systems such as
8
LifeSentry
®
v0.3
