LOGICDATA LOGIC OFFICE, LOGIClink Series Manual

MANUAL

Document Version 2.0 / April 2019

LOGIClink

Valid for:

• LOGIClink Corporate

• LOGIClink Personal Standard

• LOGIClink Personal Lite

• Motion@Work App

LOGICLINK - MANUAL // PAGE 2

LOGIClink - Operating Manual

Document Version 2.0/April 2019

This document was originally published in English.

LOGICDATA Electronic & Software Entwicklungs GmbH

Wirtschaftspark 18

8530 Deutschlandsberg

Austria

Phone: [phone]

Fax: [phone]

Internet: http://www.logicdata.net

Email: o[e-mail]

LOGICLINK - MANUAL // PAGE 3

CONTENTS

1 General information 5

1.1 Other applicable documents 5

1.2 Copyright 5

1.3 Royalty-free use of images and text 5

1.4 Trademarks 5

2 Safety 6

2.1 Target audience 6

2.2 General safety regulations 6

2.3 Intended use 6

2.4 Reasonably foreseeable misuse 6

2.5 Explanation of symbols and signal words 7

2.6 Liability 7

2.7 Residual risks 8

2.8 Skilled Persons 9

2.9 Notes for Resellers 9

3 Scope of delivery 10

4 Unpackaging 10

5 Products 11

5.1 Key Product Features 11

5.2 Dimensions 12

5.3 Drilling Template 13

6 Assembly 14

6.1 Safety During Assembly 14

6.2 Other Assembly Requirements 14

6.3 Mounting the LOGIClink 15

6.2.1 Required Components 15

6.2.2 Process 15

6.2.3 Completing Assembly 16

7 Connecting the System 17

7.1 Compatibility 17

LOGICLINK - MANUAL // PAGE 4

7.1.1 Control Box Compatibility 17

7.1.2 Dynamic Motion System 17

7.2 Connection Variants 18

7.3 Connection: Standard Option 19

7.3.1 Required Components 19

7.3.2 Connecting the LOGIClink 19

7.3.3 Next Steps 19

7.4 Connection:Retrot Option 20

7.4.1 Required Components 20

7.4.2 Connecting the LOGIClink 20

7.4.3 Next Steps 21

7.5 Connection:DYNAMIC MOTION system Option 22

7.5.1 Required Components 22

7.5.2 Connecting the LOGIClink 22

7.5.3 Next Steps 22

7.6 Marking the NFC Reading Area 23

8 Operation (Manual) 24

8.1 Adjusting the Table Top Height 24

8.2 Restart 25

8.3 Factory Reset 25

9 Operation via the App 26

9.1 About the Motion@Work App 26

9.2 Pairing Smart Devices with LOGIClink 26

9.2.1 Navigating the Pairing Windon 27

9.3 Standard Operation 28

9.3.1 Adjusting the Table Top Height 28

9.3.2 Saving a Memory Position 29

9.3.3 Adjusting the Table Top to a Memory Position 29

10 Additional Information 31

10.1 API 31

10.2 Software-Dependent Function 31

10.3 Disassembly 31

10.4 Maintenance 31

10.5 Troubleshooting 31

10.6 Disposal 31

LOGICLINK - MANUAL // PAGE 5

1 GENERAL INFORMATION

Documentation for the LOGIClink consists of this Manual and several other documents (Other applicable

documents, page 5). Assembly personnel must read all documentation before starting assembly. Keep all

documentation for as long as the product is in your possession. Ensure that all documentation is provided to

subsequent owners. Go to www.logicdata.net for more information and support. This Manual may change

without notice. The most recent version is available on our website.

1.1 OTHER APPLICABLE DOCUMENTS

This Manual contains assembly and operating instructions for all versions of the LOGIClink. Other applica-

ble documents include:

• Datasheet for the LOGIClink (Corporate, Personal Standard, or Personal Lite).

• Datasheet and Operating Manual for the Control Box in the Table System

• DYNAMIC MOTION system Manual (if applicable)

• Relevant documentation for the Motion@Work App

1.2 COPYRIGHT

© April 2019 by LOGICDATA Electronic und Software Entwicklungs GmbH. All rights reserved, except for

those listed in Chapter 1.3 Royalty-free use of images and text on page 5.

1.3 ROYALTY-FREE USE OF IMAGES AND TEXT

After purchase and full payment of the product, all text and images in Chapter 2 “Safety”, may be used free of

charge by the customer for 10 years after delivery. They should be used to prepare end user documentation

for Height-Adjustable Table Systems. The license does not include logos, designs, and page layout elements

belonging to LOGICDATA. The Reseller may make any necessary changes to the text and images to adapt

them for the purpose of end user documentation. Texts and images may not be sold in their current state,

and may not be published or sublicensed digitally. The transfer of this license to third parties without per-

mission from LOGICDATA is excluded. Full ownership and copyright of the text and graphics remain with

LOGICDATA. Texts and graphics are oered in their current state without warranty or promise of any kind.

Contact LOGICDATA to obtain text or images in an editable format ([e-mail]).

1.4 TRADEMARKS

Documentation may include the representation of registered trademarks of goods or services, as well as

information about copyright or other proprietary expertise of LOGICDATA or third parties. In all cases, all

rights remain exclusively with the respective copyright holder. LOGICDATA® is a registered trademark of

LOGICDATA Electronic & Software GmbH in the USA, the European Union, and other countries.

LOGICLINK - MANUAL // PAGE 6

2 SAFETY

2.1 TARGET AUDIENCE

This Operating Manual is intended for Skilled Persons only. Refer to Chapter 2.8 Skilled Persons on page 9 to

ensure that personnel meet all requirements.

2.2 GENERAL SAFETY REGULATIONS

In general, the following safety regulations and obligations apply when handling the product:

• Do not operate the product unless it is in a clean and perfect condition

• Do not remove, change, bridge, or bypass any protection, safety, or monitoring equipment

• Do not convert or modify any components without written approval from LOGICDATA

• In the event of malfunction or damage, faulty components must be replaced immediately

• Unauthorized repairs are prohibited

• Do not attempt to replace hardware unless the product is in a de-energized state

• Only Skilled Persons are allowed to work with the LOGIClink

• Ensure that national worker protection conditions and national safety and accident prevention

regulations are observed during operation of the system

2.3 INTENDED USE

The LOGIClink is a range of Connectivity Hubs for Height-Adjustable Table systems. There are three versions

of the LOGIClink: Corporate, Personal Standard, and Personal Lite. The products are installed by Resellers

into Height-Adjustable Table systems. They are used to control Height-Adjustable Table systems via a Control

Box or via the DYNAMIC MOTION system. Products are intended for indoor use only. Products may only

be installed in compatible Height-Adjustable Tables and with LOGICDATA-approved accessories. Contact

LOGICDATA for further details. Use beyond or outside the intended use will void the product’s warranty.

2.4 REASONABLY FORESEEABLE MISUSE

Usage outside of the intended use may lead to minor injury, serious injury, or even death. Reasonably fore-

seeable misuse of the LOGIClink includes, but is not limited to:

• Connecting unauthorized parts to the product. If you are unsure as to whether a part can be used

with the LOGIClink, contact LOGICDATA for further information

• Connecting unauthorized software to the product. If you are unsure as to whether a software can

be used with LOGIClink, contact LOGICDATA for further information

• Using the system as a climbing or lifting aid for people or animals

• Overloading the Table System

LOGICLINK - MANUAL // PAGE 7

2.5 EXPLANATION OF SYMBOLS AND SIGNAL WORDS

Safety Notices contain both symbols and signal words. The signal word indicates the severity of the hazard.

DANGER

WARNING

CAUTION

NOTICE

NOTICE

INFO

INFO

Indicates a hazardous situation which, if not avoided, will result in death or serious
injury.

Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.

Indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury.

Indicates a situation which, if not avoided, could result in damage to the product
through electrostatic discharge (ESD).

Indicates a situation that will not lead to personal injury, but could lead to damage to
the device or the environment.

Indicates the protection class of the device: Protection Class III.
Protection Class III devices may only be connected to SELV or PELV power sources.

Indicates important tips for handling the product.

2.6 LIABILITY

LOGICDATA products comply with all currently applicable health and safety regulations. However, risk can

result from incorrect operation or misuse. LOGICDATA is not liable for damage or injury caused by:

• Improper product use

• Disregard of the documentation

• Unauthorized product alterations

• Improper work on and with the product

• Operation of damaged products

• Wear parts

• Improperly performed repairs

• Unauthorized changes to the operating parameters

• Disasters, external inuence, and force majeure

The information in this Operating Manual describes the characteristics of products without assurances.

Resellers assume responsibility for the LOGICDATA products installed in their applications. They must en-

sure their product complies with all relevant directives, standards, and laws. LOGICDATA shall not be held

LOGICLINK - MANUAL // PAGE 8

liable for any damage that is directly or indirectly caused by the delivery or use of this document. Resellers

must observe the relevant safety standards and guidelines for each product in the Table System.

2.7 RESIDUAL RISKS

Residual risks are the risks that remain after all relevant safety standards have been complied with. These

have been evaluated in the form of a risk assessment. Residual risks associated with the installation of the

LOGIClink are listed here and throughout this Operating Manual. See also Chapter 1.1 Other Applicable

Documents on page 5. The symbols and signal words used in this Operating Manual are listed in Chapter 2.5

Explanation of Symbols and Signal Words on page 7.

WARNING Risk of death or serious injury through electric shocks

The LOGIClink is an electrical device. Basic safety precautions must be taken at all
times. Failure to observe electrical safety precautions may lead to death or serious inju-

ry through electric shocks.

• Never open the LOGIClink

• Ensure that the LOGIClink is not connected to the Control Box during assembly

• Do not convert or modify the LOGIClink in any way

• Do not immerse the LOGIClink or its components in liquid. Clean only with a dry
or slightly damp cloth

• Do not place the Cable of the LOGIClink on heated surfaces

• Check the housing and Cables of the LOGIClink for visible damage. Do not install
or operate damaged products

WARNING Risk of death or serious injury in explosive atmospheres

Operating the LOGIClink in potentially explosive atmospheres may lead to death or se­rious injury through explosions.

• Read the relevant directives to determine if an atmosphere is potentially explosive

• Do not operate the LOGIClink in potentially explosive atmospheres

CAUTION Risk of minor or moderate injury through tripping

During the assembly process, you may have to step over Cables. Tripping over Cables
may lead to minor or moderate injury.

• Ensure that the assembly area is kept clear of unnecessary obstructions

• Be careful not to trip over Cables

CAUTION Risk of minor or moderate injury through crushing

If any Key becomes stuck while the system is in motion, the system may not stop prop­erly. This may lead to minor or moderate injury through crushing.

• Disconnect the system immediately if any Key becomes stuck

CAUTION This appliance can be used by children from 8 years and above and people with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning the use of the appliance in a safe
way and understand the hazards involved. Children must not play with the appliance.
Cleaning and maintenance by the user must not be performed by children, unless they
are over 8 years old and supervised.

LOGICLINK - MANUAL // PAGE 9

2.8 SKILLED PERSONS

CAUTION Risk of injury through incorrect assembly

Only Skilled Persons have the expertise to complete the assembly process safely.
Assembly by Unskilled Persons may lead to minor or moderate injury.

• Ensure that only Skilled Persons are allowed to complete assembly

• Ensure that persons with limited ability to react to danger do not take part in the
assembly process

The LOGIClink may only be installed by Skilled Persons. A Skilled Person is dened as someone who:

• Is authorized for installation planning, installation, commissioning, or servicing of the product

• Has read and understood all documentation relevant to the LOGIClink

• Has the technical education, training, and/or experience to perceive risks and avoid hazards

• Has knowledge of the specialist standards applicable to the product

• Has the expertise to test, assess, and manage electrical and mechatronic products and systems in

accordance with the generally accepted standards and guidelines of electrical engineering and

furniture manufacturing

2.9 NOTES FOR RESELLERS

Resellers are companies that purchase LOGICDATA products for installation in their own products.

INFO

INFO

INFO

For reasons of EU conformity and product safety, Resellers should provide end users
with an Operating Manual in their native EU ocial language.

The Charter of the French Language (La charte de la langue française) or Bill 101
(Loi 101) guarantees the right of the population of Quebec to conduct business and
commercial activities in French. The bill applies to all products sold and used in Quebec.

For table systems that will be sold or used in Quebec, Resellers must provide all product­relevant texts in French. These include, but are not limited to:

• Operating Manuals

• All other product documentation, including datasheets

• Inscriptions on the product (such as labels), including those on product packaging

• Warranty certicates

The French inscription may be accompanied with a translation or translations, but no
inscription in another language may be given greater prominence than that in French.

Operating Manuals must include all the safety instructions that end users require to
handle the product safely. They must also include an instruction to always keep the
Operating Manual in the immediate vicinity of the product.

INFO

INFO Resellers must perform a risk assessment on their product that covers residual hazards.

No unauthorized persons (young children, persons under the inuence of medications,
etc.) should be allowed to handle the product.

It must include measures to mitigate risk, or reference the product's Operating Manual.

LOGICLINK - MANUAL // PAGE 10

3 SCOPE OF DELIVERY

The standard scope of delivery the LOGIClink consists only of the LOGIClink itself. All other components

necessary for installing the LOGIClink (e.g. Mounting Screws and Cables) must be ordered from LOGICDATA

or supplied separately by the reseller.

4 UNPACKAGING

NOTICE

To unpackage the product:

1. Remove all components from the packaging

2. Check the contents of the package for completeness and damage

3. Provide the Operating Manual to the operating personnel

4. Dispose of the packaging material

NOTICE

Ensure proper ESD handling during unpackaging. Damage that can be attributed
to electrostatic discharge will void warranty claims. Always wear an anti-static
wristband.

Dispose of the packaging material in an environmentally friendly manner. Remember
to separate plastic parts from the cardboard packaging.

LOGICLINK - MANUAL // PAGE 11

5 PRODUCT

The LOGIClink is available in three congurations:

• LOGIClink Corporate

• LOGIClink Personal Standard

• LOGIClink Personal Lite

Variants may be equipped with additional features or dierent congurations. The exact variant is denoted

by the product's order code. Consult the accompanying data sheet to check ensure that you have received

the correct variant.

5.1 KEY PRODUCT FEATURES

1

5

1 NFC Area (LOGIClink Corporate and Personal Standard Only)

2 Wi-Fi Communication Module (LOGIClink Corporate Only)

3 LED Signal Lights (LOGIClink Corporate and Personal Standard Only)

4 Mounting Points

2

76

9

8

4

3

5 UP / DOWN Keys

6 Micro-USB Port

7 Reset Key (Bluetooth Pairing Key)

8 Presence Sensor (LOGIClink Corporate and Personal Standard Only)

9 Mini-Fit Port

Fig. 1: Key Product Features, LOGIClink

LOGICLINK - MANUAL // PAGE 12

5.2 DIMENSIONS

Length 137.3 mm | 5.406 "

Width 108.0 mm | 4.253 "

Height (to underside of Table Top) 23.1 mm | 0.910 "

* NOTE: The drawing below is an example (LOGIClink Personal Standard). The design of the shutter depends

on the conguration of the LOGIClink you have ordered. The outer dimensions of the LOGIClink are the

same for all variants. Consult your Product's Datasheet for more information.

0.217 "

3x

5,5 mm

3x

5.406 "

137,3 mm

Fig. 2: Product Dimensions

0.910 "
23,1 mm

4.253 "

108,0 mm

LOGICLINK - MANUAL // PAGE 13

Side Edge

5.3 DRILLING TEMPLATE

3.425“

87.0 mm

1.593“

40.45 mm

Front Edge

4.409“

112.0 mm

Fig. 3: Drilling Template, LOGIClink

LOGICLINK - MANUAL // PAGE 14

6 ASSEMBLY

This chapter describes the process of installing the LOGIClink into the Height-Adjustable Table System.

6.1 SAFETY DURING ASSEMBLY

The assembly location must be level, vibration-free and free from dirt, dust, etc. Ensure that there is no ex-

cessive exposure to dust, toxic or corrosive gases and vapors, or excessive heat at the location. The following

safety instructions are valid for all LOGIClink products.

CAUTION Risk of minor or moderate injury through improper handling

Improper handling of the product during assembly may lead to minor or moderate in­jury through cutting, pinching, and crushing.

• Avoid contact with sharp edges

• Be careful while handling tools that may cause personal injury

• Ensure assembly complies with the generally accepted standards and guidelines of
electrical engineering and furniture manufacturing

• Read all instructions and safety advice carefully

CAUTION Risk of minor or moderate injury through tripping

During assembly and operation, poorly routed Cables may become a trip hazard.
Tripping over Cables may lead to minor or moderate injury.

• Ensure that Cables are routed properly to avoid trip hazards

• Be careful not to trip over Cables when installing the LOGIClink

NOTICE Ensure proper ESD handling during assembly. Damage that can be attributed to electro-

static discharge will void warranty claims.

NOTICE

NOTICE Before assembly, all parts must be acclimatised to the ambient conditions.

INFO Perform a product risk assessment so that you can respond to potential residual haz-

To avoid damage to the LOGIClink, measure its dimensions before assembly.

ards. Assembly instructions must be included in your end user Operating Manual.

6.2 OTHER ASSEMBLY REQUIREMENTS

LOGIClink is suitable for table tops made of medium density berboard (MDF), high density berboard

(HDF), and plywood. The thickness of the table top be a maximum of 31 mm. Thicker surfaces will prevent

the NFC reader from functioning properly. Screws, cables, and other metal parts must be at least 5 cm away

from the LOGIClink.

LOGICLINK - MANUAL // PAGE 15

6.3 MOUNTING THE LOGICLINK

6.3.1 REQUIRED COMPONENTS

1 LOGIClink

2 3 Mounting Screws (supplied by Reseller)

Tool Screwdriver

Tool Drill

Tool Pencil

INFO Contact LOGICDATA for specications regarding Mounting Screws.

6.3.2 PROCESS

NOTICE The LOGIClink must be at least 50 mm away from metal parts and Cables.

NOTICE Ensure that the Signal LEDs can be seen from the front of the table.

INFO

1. Mark the position of the drilling holes. Use the Drilling Template in Chapter 5.3 to help you.

2. Drill the holes into the Table Top.

3. Use the screwdriver and Mounting Screws to attach the LOGIClink to the Table Top at the marked

drilling points (Fig. 4).

LOGICDATA recommends placing the LOGIClink roughly 70 cm from the user's normal
sitting position.

Fig. 4: Mounting the LOGIClink

NOTICE

The required tightening torque depends on the material of the Table Top. Do not exceed
2 Nm.

LOGICLINK - MANUAL // PAGE 16

4. (Not applicable for LOGIClink Lite). Align the Presence Sensor to the desired user position. If

the LOGIClink will be on the user's right-hand side, turn the sensor towards "R". If the LOGIClink

will be on the user's left-hand side, turn the sensor towards "L".

Fig. 5: Aligning the Presence Sensor

6.3.3 COMPLETING ASSEMBLY

After the LOGIClink is attached to the Table Top, you must connect it to the Control Box or DYNAMIC

MOTION system. Refer to Chapter 7 for instructions.

LOGICLINK - MANUAL // PAGE 17

7 CONNECTING THE SYSTEM

CAUTION

Risk of minor or moderate injury through crushing

Connecting the system before the LOGIClink is properly mounted may lead to unex­pected movement of the table system. Unexpected movements may lead to minor or
moderate injury through crushing.

• Do not connect the system before the LOGIClink has been properly mounted

• Read Chapter 6 to ensure assembly is completed correctly and safely

7.1 COMPATIBILITY

7.1.1 CONTROL BOX COMPATIBILITY

Most LOGICDATA-compatible Control Boxes have "Works with LOGIClink" on their type plate (Fig. 6)

Fig. 6: Type Plate for a LOGIClink-compatible Control Box

NOTICE

If your Control Box does not have "Works with LOGIClink" on its type plate, you must
contact LOGICDATA before connecting the LOGIClink in order to conrm compatibili­ty. Failure to comply is classied as misuse and will void warranty claims.

The following products are compatible with LOGIClink:

Control Boxes: COMPACT-e (after April 2017), SMART-e (after April 2017), SMARTneo, and SMARTneo-pro.
Handsets: All Handsets in the TOUCH family (with the Retrot Cable).

The following products are not compatible with LOGIClink as standard, but can be used safely with

the Retrot Cable:

Control Boxes: COMPACT-e (before April 2017), SMART-e (before April 2017).

Always contact LOGICDATA before connecting a Control Box that does not have "Works with

LOGIClink" on its type plate.

NOTICE

The COMPACT-e+ and SMART-e+ are not compatible with LOGIClink and must not be
connected under any circumstances. This may cause damage to the table system.

7.1.2 DYNAMIC MOTION SYSTEM

The LOGIClink is compatible with all variants of the DYNAMIC MOTION system.

LOGICLINK - MANUAL // PAGE 18

7.2 CONNECTION VARIANTS

There are three connection options for LOGIClink:

Standard Option:

You require the standard installation variant if the following statements apply:

• Your LOGICDATA Control Box has "Works with LOGIClink" on its type plate (see Chapter 7.1)

• LOGIClink is used as the only control element.

• No additional Handset is connected.

• The Control Box Type Plate reads "Works with LOGIClink"

INFO

Retrot Option:

Use this system setup if one or more of the following conditions apply:

• You will connect an additional Handset to the LOGIClink

• You will connect the LOGIClink to a COMPACT-e or SMART-e Control Box was produced before April

2017 and is therefore not compatible with its factory settings.

• You will install the LOGIClink to a xed workstation with an external Power Converter

INFO

DYNAMIC MOTION system Option:

You require the DYNAMIC MOTION system installation variant if the following statements apply:

• You will connect the LOGIClink to the DYNAMIC MOTION system

INFO

Instructions for the Standard Option can be found in Chapter 7.3 on page 19

Instructions for the Retrot Option can be found in Chapter 7.4 on page 20

Instructions for the DYNAMIC MOTION system Option can be found in Chapter 7.5 on
page 22

LOGICLINK - MANUAL // PAGE 19

7.3 CONNECTION: STANDARD OPTION

7.3.1 REQUIRED COMPONENTS

1 LOGIClink

2 LOGIClink-compatible Control Box

3 Standard LOGIClink Cable (LOG-CBL-LOGICLINK-CB-STANDARD)

4 Micro-USB Cable

INFO

INFO

The LOG-CBL-LOGICLINK-CB-STANDARD Cable has 2 connectors:

• DIN (plugs into the Control Box)

• 10-pin Mini-Fit (plugs into the LOGIClink)

The Micro-USB Cable is used to connect LOGIClink to your PC or Mac. It is not required
during standard operation of the table system. For further advice on software options,
contact LOGICDATA.

7.3.2 CONNECTING THE LOGICLINK

CAUTION Risk of minor or moderate injury through electric shocks

Connecting Cables while the Control Box is connected to the Power Unit may lead to
minor or moderate injury through electric shocks.

• Do not connect the Control Box to the Power Unit before the LOGIClink has been
safely connected.

1. Insert the LOG-CBL-LOGICLINK-CB-STANDARD Cable into the LOGIClink using the 10-pin

Mini-Fit connector.

2. Lay the Cable along the underside of the table top, making sure it is secured.

3. Connect the blue, DIN cable to the Control Box, at the plug port marked "HS".

4. (Optional) connect the LOGIClink to your PC or Mac using the Micro-USB cable

5. Connect the Control Box to the mains. Consult the Manual for your chosen Control Box for as-

sembly and safety advice.

7.3.3 NEXT STEPS

2

After the LOGIClink is connected to the Control Box, assembly diers depending on the version of the

LOGIClink you have installed.

LOGIClink Corporate and Personal Standard: Go to Chapter 7.6, Marking the NFC Reading Area.

All other variants: Assembly is now complete. Go to Chapter 8, Operation.

LOGICLINK - MANUAL // PAGE 20

7.4 CONNECTION: RETROFIT OPTION

7.4.1 REQUIRED COMPONENTS

1 LOGIClink

2 LOGIClink Retrot Cable (LOG-CBL-LOGICLINK-CB-RETROFIT)

3 LOGIClink-compatible Control Box (Optional)

4 LOGIClink-compatible Handset (Optional)

5 Micro-USB Cable (Optional - Supplied by Reseller)

6 External Power Adapter (Optional - Supplied by Reseller)

INFO The LOG-CBL-LOGICLINK-CB-RETROFIT Cable has 4 connectors:

• Male DIN (plugs into the Control Box)

• Female DIN (accommodates the external Handset Cable)

• 10-pin Mini-Fit (plugs into the LOGIClink)

• USB (Connects to External Power Hub)

INFO The Micro-USB Cable is used to connect LOGIClink to your PC or Mac. It is not required

during standard operation of the table system. For further advice on software options,
contact LOGICDATA.

INFO The External Power Adapter can be used to connect the LOGIClink to the mains in xed

table systems (i.e. tables that are not adjustable and do not have a Control Box) and
also to connect to COMPACT-e or SMART-e Control Boxes produced before April 2017.
LOGICDATA does not supply this accessory and cannot provide guarantees regarding
quality, safety, or performance.

7.4.2 CONNECTING THE LOGICLINK

CAUTION Risk of minor or moderate injury through electric shocks

Connecting Cables while the Control Box is connected to the Power Unit may lead to
minor or moderate injury through electric shocks.

• Do not connect the Control Box to the Power Unit before the LOGIClink has been
safely connected

1. Insert the Retrot Cable into the LOGIClink using the 10-pin Mini-Fit connector.

2. Lay the Cable along the underside of the table top, making sure it is secured.

If you are connecting a LOGIClink-compatible Handset

3. Connect the Male DIN Cable of the Handset to the Female DIN Connector on the Retrot Cable.

If you are connecting a COMPACT-e or SMART-e Control Box produced before April 2017

4. Connect the blue, Male DIN Cable to the Control Box, at the plug port marked "HS".

Then:

5. (Optional) connect the LOGIClink to your PC or Mac using the Micro-USB Cable.

6. Insert the USB Connector of the Retrot Cable into the External Power Adapter.

7. Insert the Power Adapter into the Mains.

8. Connect the Control Box to the Mains. Consult the Manual for your chosen Control Box for as-

sembly and safety advice.

LOGICLINK - MANUAL // PAGE 21

7.4.3 NEXT STEPS

After the LOGIClink is connected, assembly diers depending on the version of LOGIClink you have in-

stalled.

LOGIClink Corporate and Personal Standard: Go to Chapter 7.6, Marking the NFC Reading Area.
All other variants: Assembly is now complete. Go to Chapter 8, Operation.

LOGICLINK - MANUAL // PAGE 22

7.5 CONNECTION: DYNAMIC MOTION SYSTEM
OPTION

7.5.1 REQUIRED COMPONENTS

1 LOGIClink

2 DYNAMIC MOTION system-compatible Power Hub (e.g. DMP240)

3 Micro-USB Cable (Optional - Supplied by Reseller)

4 LOGIClink-DM system Cable (DMC-LL-y-1800)

INFO

INFO

The DMC-LL-y-1800 Cable has 2 connectors:

• 4-pin Mini-Fit (plugs into the Power Hub)

• 10-pin Mini-Fit (plugs into the LOGIClink)

The Micro-USB Cable is used to connect LOGIClink to your PC or Mac. When connected
to the DYNAMIC MOTION system, it can also be used as a parameterization tool. It is
not required during standard operation of the table system. For further advice on soft­ware options, contact LOGICDATA.

7.5.2 CONNECTING THE LOGICLINK

CAUTION Risk of minor or moderate injury through electric shocks

Connecting Cables while the DYNAMIC MOTION system is connected to the Power Unit
may lead to minor or moderate injury through electric shocks.

• Do not connect the DYNAMIC MOTION system to the Power Unit before the
LOGIClink has been safely connected.

1. Insert the DMC-LL-y-1800 Cable into the LOGIClink using the 10-pin Mini-Fit connector.

2. Lay the Cable along the underside of the table top, making sure it is secured.

3. Connect the 4-Pin Mini-Fit connector to the Power Hub.

4. (Optional) connect the LOGIClink to your PC or Mac using the Micro-USB cable.

5. Connect the DYNAMIC MOTION system to the mains. Consult the DYNAMIC MOTION system

Manual for assembly and safety advice.

7.5.3 NEXT STEPS

After the LOGIClink is connected to the DYNAMIC MOTION system, assembly diers depending on the ver-

sion of the LOGIClink you have installed.

LOGIClink Corporate and Personal Standard: Go to Chapter 7.6, Marking the NFC Reading Area.

All other variants: Assembly is now complete. Go to Chapter 8, Operation.

LOGICLINK - MANUAL // PAGE 23

7.6 MARKING THE NFC READING AREA

The following instructions are not relevant for the LOGIClink Personal Lite. If you are installing a LOGIClink

Personal Lite, continue at the next chapter.

1. Locate the NFC Reading Area on the table top. The Reading Area should be a 60 x 6o mm square

directly over the LOGIClink, 10 mm from the back edge (Fig. 7).

2. Ensure the Reading Area is positioned properly. There should be no metal parts in or around it.

3. Use a suitable material (e.g. Adhesive Film) to mark the NFC Reading Area.

NFC
Reading
Area

Fig. 7: Marking the NFC Reading Area

Side Edge

Front Edge

LOGICLINK - MANUAL // PAGE 24

8 OPERATION (MANUAL)

CAUTION Risk of minor or moderate injury through uncontrolled movement

The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.

• Wait until the system has completely stopped before attempting to use the table

CAUTION Risk of minor or moderate injury through unsecured objects

While the table moves up and down, unsecured objects may fall o the table and onto
body parts. This may lead to minor or moderate injury through crushing.

• Ensure loose objects are kept away from the edge of the table

• Do not leave unnecessary objects on the table during movement

This section of the Operating Manual contains a selection of instructions for operating the Table System to

which the LOGIClink is connected using the buttons on the LOGIClink's housing.

LOGIClink is compatible with a large number of LOGICDATA Control Boxes and the DYNAMIC MOTION

system:

• Before using a Control Box-connected Table System, you must also read the Operating Manual

for the installed Control Box, including all relevant safety information, in full.

• Before using a DYNAMIC MOTION system-connected Table System, you must also read the

DYNAMIC MOTION system Manual, including all relevant safety information, in full.

• If you have connected another Handset to the LOGIClink using the Retrot Cable, consult the

Manual of your chosen Handset for operating instructions.

8.1 ADJUSTING THE TABLE TOP HEIGHT

CAUTION

INFO The Table Top will move up or down until the UP or DOWN Key is released, or if a pre-de-

To move the Table Top UP:

Risk of minor or moderate injury through crushing

Your ngers may be crushed when you attempt to change the height of the table

• Keep ngers away from moving parts

• Ensure that no persons or objects are in the table's range of motion

ned stopping point has been reached

Press and hold the UP Key until the desired height has been reached

To move the Table Top DOWN:

Press and hold the DOWN Key until the desired height has been reached

LOGICLINK - MANUAL // PAGE 25

8.2 RESTART

This function restarts the LOGIClink. All saved settings are retained.

Hold the Restart Key for 5 Seconds

8.3 FACTORY RESET

With this function, you can reset the LOGIClink to its factory settings. All saved settings are deleted

1. Disconnect the Table System from the Mains by removing the plug.

2. Press and hold the UP and DOWN Keys.

3. While holding the UP and DOWN Keys, reconnect the Table System to the Mains.

▸ The LEDs will ash (LOGIClink Corporate and Personal Standard only).

4. Before the LEDs have stopped ashing, release the UP and DOWN Keys.

▸ The Factory Reset is complete.

INFO If you do not release the UP and DOWN Keys before the LEDs stop ashing, the Factory

Reset will be aborted and you will need to start again from step 1.

LOGICLINK - MANUAL // PAGE 26

9 OPERATION VIA THE APP

WARNING

This section of the Operating Manual contains a selection of instructions for operating the Table System to

which the LOGIClink is connected using the Motion@Work App. Before using the Table System, you must

also read the Operating Manual for the installed Control Box, including all safety information, in full.

Risk of death or serious injury through unauthorized application

If your LOGIClink-connected table will be controlled by a third-party application, this
chapter is not valid and should not be understood as an accurate representation of
the Table System's functions, nor of those functions' associated risks. Consult the rel­evant documentation of the app that is connected for more information. If you have
developed your own application to control the LOGIClink, you must ensure its safety
and the accuracy of its documentation through means of a risk assessment. Contact
LOGICDATA for further details.

9.1 ABOUT THE MOTION@WORK APP

The Motion@Work App is an application for smart devices that controls their LOGIClink-connected Table

System wirelessly. Motion@Work is available from the Google Play Store (Android) and the App Store (iOS).

9.2 PAIRING SMART DEVICES WITH LOGICLINK

CAUTION

Risk of minor or moderate injury through uncontrolled movement

It is possible that more than one LOGIClink in pairing mode will be in range of your
smart device. Connecting a smart device to the incorrect LOGIClink may lead to minor
or moderate injury through crushing.

• Ensure that your smart device is connected to the correct LOGIClink. Consult the
sticker on the LOGIClink's housing to identify it correctly

• Do not operate the Motion@Work App if the smart device is paired with the incor­rect LOGIClink

INFO

To pair your smart device with LOGIClink:

Ensure you have installed the Motion@Work app correctly

Double-click the restart button on the LOGIClink to start Bluetooth pairing mode.

In the Motion@Work App, open the pairing window, select your LOGIClink and enter the pairing
Key (000000). Use Chapter 9.2.1 on the next page to help you.

Pairing Mode has a timeout of 30 seconds. If you do not begin pairing in this time, the
LEDs will stop ashing and you will have to restart the pairing sequence to continue.

▸ The LEDs on the LOGIClink ash green (LOGIClink Personal Standard and LOGIClink

Corporate only)

▸ If pairing was successful, the LEDs on the LOGIClink ash red twice (LOGIClink Personal

Standard and LOGIClink Corporate only)

LOGICLINK - MANUAL // PAGE 27

9.2.1 NAVIGATING THE PAIRING WINDOW

Tap the icon in the top-left
of the screen to begin
pairing.

When prompted, tap "Pair
and Connect" to pair with

4

LOGIClink.

Tap "Scan and Connect"

21 3

to nd your LOGIClink.

Enter the pairing Key
(standard 000000) to

5

complete pairing.

Select the correct
LOGIClink from the list of
available devices.

Check the top-left
corner to see if you are

6

successfully paired

Fig. 8: Navigating the Pairing Window

LOGICLINK - MANUAL // PAGE 28

9.3 STANDARD OPERATION

CAUTION Risk of minor or moderate injury through uncontrolled movement

The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.

• Wait until the system has completely stopped before attempting to use the table

CAUTION Risk of minor or moderate injury through unsecured objects

While the table moves up and down, unsecured objects may fall o the table and onto
body parts. This may lead to minor or moderate injury through crushing.

• Ensure loose objects are kept away from the edge of the table

• Do not leave unnecessary objects on the table during movement

9.3.1 ADJUSTING THE TABLE TOP HEIGHT

CAUTION Risk of minor or moderate injury through crushing

Your ngers may be crushed when you attempt to change the height of the table

• Keep ngers away from moving parts

• Ensure that no persons or objects are in the table's range of motion

INFO The Table Top will move up or down until the UP or DOWN Key is released, or if a pre-de-

ned stopping point has been reached

To move the Table Top UP:

On the home screen, press and hold the "UP" but-

1

To move the Table Top DOWN:

2

Fig. 9: Adjusting the Table Top Height

ton until the desired height has been reached

On the home screen, press and hold the "DOWN"

button until the desired height has been reached

1

2

LOGICLINK - MANUAL // PAGE 29

9.3.2 SAVING A MEMORY POSITION

This function saves a set Table Top position. You can save up

to one sitting and one standing position with the Motion@

Work App.

1

2

Fig. 10: Saving a Memory Position

Move the Table Top to the desired height (Chapter

9.3.1)

On the home screen, tap "Save", then "Sitting" or
"Standing" to save the position.

▸ The Memory Position has been saved

9.3.3 ADJUSTING THE TABLE
TOP TO A SAVED MEMORY
POSITION

This function allows you to move the Taple to to a saved

Memory Position.

2

1

Version A (Auto-Movement Disabled):

1

1

Fig. 11: Adjusting the Table Top to a Memory Position

On the home screen, tap and hold the Memory

Position you wish to move to

Keep holding until the Memory Position has

been reached

▸ Release to continue

1

LOGICLINK - MANUAL // PAGE 30

Version B (Auto-Movement Enabled):

INFO The Auto-Movement function is available only for Table Systems sold in US markets.

INFO If you press anywhere on the screen while the table moves to a Memory Position, the

Table Top will stop moving immediately. To continue, you must select the Memory
Position again.

CAUTION Risk of minor or moderate injury through unauthorized modications

The rmware is delivered with a deactivated auto-movement function. If you activate
this function, the grading of the safety functions according to EN ISO 13849-1 PL b,
Category B, are no longer valid, as the legal requirements in the standard are no longer
met.

• If you activate the function, perform a new risk new assessment to meet the higher
safety requirements (EN 60335-1). These cannot be met by LOGICDATA systems.

• LOGICDATA is not liable for injuries or damage caused by activating the double­click function

Go to the "Settings" Menu and enable Auto Movement

1

On the home screen, tap the Memory Position you wish to move to

2

Wait until the Memory Position has been reached

1

2

LOGICLINK - MANUAL // PAGE 31

10 ADDITIONAL INFORMATION

10.1 API

The LOGIClink API allows you to create customized applications using the LOGIClink. Contact LOGICDATA

for further details.

10.2 SOFTWARE-DEPENDENT FUNCTIONS

A full list of Software-Dependent Functions can be found in the Operating Manual of the installed Control

Box, or the DYNAMIC MOTION system Manual, depending on your chosen conguration.

10.3 DISASSEMBLY

To disassemble the LOGIClink, ensure that it has been disconnected from the mains. Then, follow the assem-

bly instructions in reverse order.

10.4 MAINTENANCE

The LOGIClink is maintenance-free for its entire service lifetime. To clean the LOGIClink, wipe the housing

with a soft, dry cloth.

WARNING Risk of death or serious injury through electric shocks and other hazards

Using LOGIClink alongside unauthorized spare or accessory parts may lead to death or
serious injury through electric shocks and other hazards.

• Only use accessory parts produced or approved by LOGICDATA

• Only use replacement parts produced or approved by LOGICDATA

• Only allow Skilled Persons to perform repairs or install accessory parts

• Contact customer services immediately if the system malfunctions

The use of unauthorized spare or accessory parts may cause system damage. Warranty
claims are void in this scenario.

10.5 TROUBLESHOOTING

A list of common problems and their solutions can be found in the Operating Manual of the installed Control

Box, or the DYNAMIC MOTION system Manual. Most problems with the LOGIClink can be xed by perform-

ing a Restart (Chapter 8.2). If you require further support, contact LOGICDATA.

10.6 DISPOSAL

All LOGIClink products are subject to the WEEE Directive2012/19/EU.

• Dispose of all components separately from household waste. Use designated collection

points or disposal companies authorized for this purpose

LOGICDATA
Electronic & Software Entwicklungs GmbH

Wirtschaftspark 18
8530 Deutschlandsberg
Austria

LOGICDATA North America, Inc.

Broadmoor Ave SE, Suite D
Grand Rapids MI
USA

Phone: [phone]
Fax: [phone]
Email: o[e-mail]
Internet: http://www.logicdata.net

www.logicdata.net

Phone: [phone]
Email: o[e-mail]
