Logic 3 PSP 535 User Manual

PSP535U

INSTRUCTION MANUAL

33 Northfield Industrial Estate, Beresford Avenue, Wembley

HA0 1NW, UK

Tel: -[phone]

Fax: - [phone]

[e-mail]

www.logic3.com

Logic3 is a trademark of Logic3 International Ltd. Wembley, U.K.

All other trademarks, copyrights and trade names are registered properties of their respective owners

PSP 535

Setup

1

3

4

2

6

Contents

Carrying
Pouch

Line in
Cable

PSP

5

35

Line-in Conne

ctio

n

Line-in

Power

5

7

DC IN LINE IN

Connections

AA

AA

OR

P

O

W

E

R

H

O

L

D

CD

MP3

MD

MiniDisc

AC
Adaptor

CAUTION

1 2

PSP Sound System - PSP535 User Manual

Thank you for purchasing the Logic3 Sound System for use with the PSP, the latest in
our long and established range of speakers. As with all Logic3 products, this has been
built to the highest manufacturing standards, to bring you the very latest and advanced
technology available.

The PSP Sound System offers a complete solution to listen, recharge. It produces hi-fi
quality sound from the combination of a sub-woofer, dynamic tweeter speakers and
a 3D surround sound processor. The compact portable unit measures only 280 x 105
x 38mm and weighs only 550g. The Sound System can be powered by an AC Mains
Adaptor (supplied) or 4xAA Batteries (Not Included). By using the line-in port, the
Sound System can used whilst holding the PSP in your hands or be used in conjunc­tion with a number of other portable audio devices such as MiniDisc, MP3 Players or
Portable CD Players.

Contents

• PSP Sound System

• AC Adaptor, 100V – 240V AC. 5V 2.5A DC

• 1.2m - 3.5mm to 3.5mm Stereo Line In Cable

• Nylon Carry Case and Storage

Setup

Please follow the steps on the quick start guide to set up the PSP535

1) Remove the Clear Plastic Protective Cover, being careful to not damage the
speakers or sub woofer

2) Fold down the Sub woofer unit

3) Insert the AC Adaptor (supplied) or 4 x AA Batteries (Ensure that the batteries are
inserted as indicated inside the battery compartments on the rear of the Sound
System, to avoid potential damage)

4) Switch on your PSP, press the Power button on the Sound System and adjust the
volume to desired level

5) Insert PSP

6) Replace the Clear Plastic Protective Cover on the rear of the PSP535 to act as a
support for the PSP

7) The PSP Sound System can also be used whilst the PSP is being used in your
hands using the Line In Cable

ENGLISH

3

Speaker Controls

1. Power On/Off button

a. Push the button once to switch on the Sound System. The Blue LED’s will illuminate

when the Sound System is turned on.
b. Push the button again to switch off the Sound System.
c. If the unit is unused for about 2 minutes, then the Sound System will automatically

turn off to preserve power.

2. Volume Controls

a. Press the Up or Down Arrows to adjust the Sound System sound level.

3. 3D button

a. Push the 3D button to enrich the sound with a wider effect. The sound will appear to sur

-

round you. (The Volume level may need to turned down to avoid sound distortion.)
b. Push the button again to return to the normal stereo sound effect.

Recharging the PSP

To recharge the PSP ensure that Sound System is connected to the AC Adaptor the
PSP will recharge automatically

Line-In

The Sound System also offers the facility to allow portable audio devices such as MP3,
Mini-Disc and Portable CD Players to be connected for use as a speaker system. Con­nect the 3.5mm Line In Cable to the Headphone socket on the device and connect the
other end to the Line–In socket to the rear of Sound System.

Should you have any connection or setup problems with the please contact our
Technical Support Hotline on [phone] – National call rates apply or E-mail
[e-mail]

System Specifications

Total continuous power: 12W RMS (6W + 3Wx2)
Satellite speakers: 3Watts/channel @ 6 ohms
@10% THD + N @20~20kHz
Subwoofer: 6Watts 6 ohms
Frequency Response: 100 Hz ~ 20 kHz
Signal to Noise Ratio: @ 1 kHz input > 60 dB
Speaker Drivers: Two 2” full range neodymium
Micro drivers + 3” speaker

ENGLISH

4
