About the Network Mediaplayer
Your Loewe TV set is equipped with the Network Mediaplayer. This allows
you to play back multimedia contents (photos, music files, videos) that are
english
saved on a data medium on your home network and are made available via
a media server (also see page 16). The Network Mediaplayer can access
various types of storage media on the network for this purpose (e.g. PCs,
Network Attached Storages (NAS)).
You can connect your TV set either wired (Ethernet, PowerLine) or also via
a wireless radio connection (WLAN) to your home network. The TV set has
wireless connections via an internal WLAN antenna. To operate it when there
is bad reception there is an additional antenna included (not with Connect 32).
You will find connection examples on page 5 on the right.
The Network Mediaplayer supports UPnP AV standard.
You will find more detailed information in the technical data on page 16
and in the glossary from page 17.
All photos, albums and album graphics shown in these operating instructions
are just examples.
Help for problems with home network
Because of the wide variety of configurations of home networks, Loewe
cannot provide support for PC hardware and software or network
components.
For support with configuration of and maintaining network connections,
storage media, media server software and network devices, such as
routers (positions 4, 5 and 8 in the connection examples on page 5)
please contact the administrator of your network and/ or the specialist
retailer.
Access to the MediaNetwork
Start the MediaNetwork using the Assist+ menu.
Go to Assist+ menu.
56 Mark MediaNetwork,
OK confirm.
Selection of menu items
Use the arrow buttons 5634 to move the marker on
the user interface.
Use the OK button to select or adopt the object you have
currently marked.
Use the 7 button to go back up a level respectively.
With the END button you return from any item in the
menu overview to the media selection (page 8).
This screen symbol shows you that the required operating
function is currently not available.
Exit MediaNetwork
Go to Assist+ menu and select another function (see
above).
Or:
Press TV or RADIO button to change to the corresponding
- 4
type of operation.
Or:
Press END button in the media selection (page 8)
to change to the last previously active type of operation
(TV, radio).
Connectivity
C
Initial installation
1
3
2
4
567
8
1
7
213
4
556
7
8
9
9
Connecting TV set and home network
Network socket on Loewe TV set
Wired connection between TV set and home network with
a network cable (available from specialist retailers)
LAN switch / router
PC
WLAN antenna inside device
Additional antenna (optional, see below)
Example of wired connection
english
Example of wireless connection
WLAN router
Connectivity display (see page 7)
Connecting up the additional antenna
(not with Connect 32)
If your TV set should not recognise a wireless router despite it being set
up correctly, then it may help to mount the additional antenna supplied
on to the set.
Screw the antenna on to the thread available for it (connection is under
a flap on the back of the TV set on the right looking at the set from
behind).
Align the antenna to optimise the reception.
5 -
Initial installation
Select Network Interface
Activate
Wired
Wireless (with wireless router)
OK
OK
Select a wireless router
Activate Rescan
WLAN-Router_1
WLAN-Router_2
OK
OK
Please enter password
Adopt Password
Delete password
Delete last positionSelect character
a..z → A..Z
12378_ky&
0 1 2 3 4 5 6 7 8 9
a b c ed f g h i j
k l m n o p q r s t
u v w x y z ! ? ( )
@
#
$
%
&
^
*
`
{
}
_ - ~ + = | / \ [ ]
: ;
” ‘
,
. < >
OK
Initial installation
The first time MediaNetwork is called up, initial installation is started.
Select Network Interface
english
Select wireless router
- 6
Here you enter whether you want to connect your TV
set Wired via cable or Wireless (with wireless router) to
your home network. You will find connection examples
on page 5.
56 Select Network Interface.
OK Activate.
➠ If you select Wired then initial installation is continued
with the menu item Select IP address assignment
method (page 7).
If you have selected Wireless (with wireless router), then
the TV set starts to search for wireless routers.
56 Select required WLAN router.
OK Activate.
As soon as is displayed, you can go back one
installation step by pressing this button.
If your router is not found the first time, then you can
press the red button to Rescan for routers. If there are
any problems making a wireless connection, it can help
to install the additional antenna on the TV set (see page 5).
Please also refer to the information on wireless connections on page 15.
Enter WLAN password
If your network has an encryption then it is necessary to
enter the password that allows access to the network.
A screen keyboard will appear to enter the password.
Arrow buttons: Mark characters.
Function of coloured buttons:
Blue: Select character.
Yellow: Delete last position.
Red: Delete complete password from the input line.
Green: Switch from small to capital letters and vice
versa.
OK Adopt Password.
➠ The WLAN code may not exceed a maximum length
of 32 characters. Umlauts (German characters ä, ö, ü)
are generally not supported.
➠ If you do not know the WLAN key, contact your
network administrator.
➠ Supported encryption types: page 16.
Initial installation
Network Setting
Adopt
Adopt the following settings?
Network mode : Wireless
SSID : WLAN-Router_1
IP address : 192.168.1.123
Subnet mask : 255.255.255.0
OK
Select IP Address Assignment Method
Activate
Automatic (DHCP)
Input Static IP Address
OK
OK
Set Device IP Address
Adopt
IP Address 192.168.1.123_
OK
Input digits
Delete address
Delete last position
-
Input “.“
0
9
EPG
Select Server
Activate Rescan
Media-Server 1
Media-Server 2
OK
OK
Select IP address assignment method
56 Select IP address and subnet mask Assignment
method.
OK Activate.
Automatic (DHCP): IP address and subnet mask are
automatically issued by a DHCP server on your home
network.
➠ A DHCP server has to be set up on a device on the
network (e.g. WLAN router).
Input Static IP Address: IP address and subnet mask are
entered manually.
Network Setting
Afterwards you will see a summary of the settings.
OK Adopt settings.
english
Backwards step by step for changes.
Select Server
If there is more than one media server in your home
network, you also have to select the server from which
you want to draw the data.
56 Select Server.
Digit buttons: Input digits of IP address.
EPG: Enter dots.
Function of coloured buttons:
OK Activate.
If your required media server should not be found the
first time, then you can press the red button to Rescan
for media servers.
Yellow: Delete last position.
Red: Delete address.
OK: Adopt IP address.
➠ Proceed in the same way with the subsequent entry
of the subnet mask.
Connectivity display
After successful initial installation, the media selection opens up
(page 8) and the Connectivity display on the left of the TV set lights
up. The Connectivity display can, if required, be switched off via the
MediaNetwork menu (page 9).
7 -
Operating convenience
END
INFO
MENU
Order by...
Open folder
MediaNetwork
Change view
OK
Music
Video
END
INFO
MENU
Order by...
View picture
MediaNetwork
Go to page...
Slide showChange viewPage↑/↓(1/5)
OK
P+
P–
LOEWE_2...LOEWE_1... LOEWE_3... LOEWE_4...Back
LOEWE_5...
Photo\LOEWE_2_highres 47 Title(s)
LOEWE_7...LOEWE_6... LOEWE_8... LOEWE_9...
END
INFO
MENU
Order by...
View picture
MediaNetwork
Go to page...
Slide showChange viewPage↑/↓(1/5)
OK
P+
P–
OK
Back
LOEWE_1_highres
LOEWE_2_highres
LOEWE_3_highres
LOEWE_4_highres
LOEWE_5_highres
LOEWE_6_highres
LOEWE_7_highres
LOEWE_8_highres
LOEWE_9_highres
LOEWE_A_highres
LOEWE_B_highres
Photo\LOEWE_2_highres 47 Title(s)
Media selection
english
The Network Mediaplayer starts with the media selection. Select the
media type you want.
Select media type
34 Select required media folder,
OK confirm and go to the respective overview.
Photo operation: see page 10.
Video operation: see page 11.
Music operation: see page 12.
Exit Network Mediaplayer
END: Exit Network Mediaplayer for last previously active
mode (TV, Radio).
Function of coloured buttons in the media selection
Green button: Order by...
Change order objects displayed (folders or files).
➠ The sorting options available depend on the media server
that you are using.
Yellow button: Change view
Switches between preview and list view:
Example: Photo operation, preview
- 8
Example: Photo operation, list view
Blue button: Go to page...
Alternatively to going through pages with P+/P- you can
also go directly to the individual pages on the overview. On
the Go to page... overview the first title on each page
respectively is shown.
➠ Only available if there are more objects than can be
displayed.
➠ The number of pages depends on the view selected
(preview or list). You can see the number at the bottom
on the left.
Operating convenience
MediaNetwork menu
END
INFO
No
Background play Yes
MediaNetwork LED On
Photo info Off
Slide show interval 5 Sec.
Select / search media server
Change network
Device information
Network mode Wireless
SSID WLAN-Router 1
IP address 192.168.1.123
Subnet mask 255.255.255.0
WLAN signal level
max. WLAN transfer rate 17 Mbit/sec
active WLAN channel 1
WLAN MAC address 00:0F:65:02:81:19
Server Name Media-Server
MediaNetwork menu
END
INFO
No
Background play Yes
MediaNetwork LED On
Photo info Off
Slide show interval 5 Sec.
Select / search media server
Change network
MediaNetwork menu
Open MediaNetwork menu.
Call Device information (see right hand column).
56 Select menu item.
34 or
OK Adopt settings.
Exit MediaNetwork menu
Explanation of setting options in the MediaNetwork menu
Background
Media-
Network LED
Photo Info
Slide show
interval
Select / search
media server
Change
network
Select Yes to continue to play back music files that were
play
being played back even if you are no longer in the music
view (e.g. as background music for a slide show in photo
operation).
Select whether the Connectivity display on the left
of the TV set is to light up when there is a connection.
Select On, to always have the photo information (file
name and number of files in folder) shown with Full
screen display or Slide show (photo operation see
page 10).
Select how long each picture is to be shown for during
a slide show. The display time can be 2, 3, 5, 10, 30 and
60 seconds.
In the current network you can rescan for a media
server, for example if a new server has been added.
Here you can designate a new network, e.g. change from
wired to wireless.
Device information
Open Device information.
This window provides you all information about your network connection
that is currently active.
Explanation of display items
Network
IP address
Subnet mask
WLAN signal
max. WLAN
transfer rate
active WLAN
channel
WLAN MAC
address
Server Name
Shows the type of connection (wired or wireless).
mode
SSID
(only appears with wireless connection)
The name of your network.
The SSID of your wireless home network must be visibly
transmitted, as otherwise the network will not be
recognised.
Your current IP address.
Your current subnet mask.
(only appears with wireless connection)
level
Display of current strength of reception: The more fields
that are filled white, the better the reception.
(only appears with wireless connection)
Shows you the maximum amount of data can be
transmitted wirelessly per second.
(only appears with wireless connection)
Shows you which of the total of 13 WLAN channels is being
used for radio transmission between TV set and router.
(only appears with wireless connection)
Provides the MAC address of the WLAN component of
your TV set that is secured in the hardware.
The name of your media server.
9 -
english
Operating convenience
END
INFO
MENU
Order by...
Open folder
MediaNetwork
Change view
OK
Music
Video
2 / 47 <Loewe_2_highres> Slide show
Media overview – photo operation
➠ Media selection is shown (page 8).
english
34 Select folder with photos,
OK open folder.
➠ The name of the folder depends on your media server
setting (in example picture: Photo).
5634Select required sub-folder,
OK open folder. If required, repeat.
P+/P- Page up / down.
OK View marked picture in full screen mode.
MENU: Open MediaNetwork menu (page 9).
Green button: Order by...
Change order of objects displayed (folders or files).
➠ The sorting options available depend on the media server
that you are using.
Yellow button: Change view
Switches between preview and list view.
Blue button: Go to page...
Alternatively to going through pages with P+/P- you can
also go directly to the individual pages on the overview. On
the Go to page... overview, the first title on each page
respectively is shown.
➠ Only available if there are more objects than can be
displayed.
➠ The number of pages depends on the view selected
(preview or list). You can see the number at the bottom
on the left.
Full screen mode
Slide show
➠ A picture has been selected in the photo overview.
OK Go to / close full screen mode.
Show previous / next picture.
INFO: Show / hide context information (e.g. recording
date, camera model used, picture format etc.).
END: Temporarily show / hide file names and number of
files in the folder.
➠ Permanent display of this information can be set in the
MediaNetwork menu (page 9).
PLAY button: Start slide show.
➠ from photo overview: Start slide show with marked
picture.
➠
in full screen mode: Start slide show with displayed
picture.
PAUSE button: Pause slide show.
PLAY button: Continue slide show.
STOP button: Stop slide show and return to overview.
- 10
Operating convenience
END
INFO
MENU
Order by...
Open folder
MediaNetwork
Change view
OK
Video
Photo Music Video
<Toskana_Video1>
Status Repeat
Off
0:12:39
0:06:20
0:00:00
Media overview – video operation
➠ Media selection is shown (page 8).
34 Select folder with videos,
OK open folder.
➠ The name of the folder depends on your media server
setting (in example picture: Video).
5634Select required sub-folder,
OK open folder. If required, repeat.
P+/P- Page up / down.
MENU: Open MediaNetwork menu (page 9).
Green button: Order by...
Change order objects displayed (folders or files).
➠ The sorting options available depend on the media server
that you are using.
Yellow button: Change view
Switches between preview and list view.
Blue button: Go to page...
Alternatively to going through pages with P+/P- you can
also go directly to the individual pages on the overview. On
the Go to page... overview the first title on each page respec-
tively is shown.
➠ Only available if there are more objects than can be
displayed.
➠ The number of pages depends on the view selected
(preview or list). You can see the number at the bottom
on the left.
Play back video files
PLAY button or
OK Play marked file.
Green button: Set playback mode:
Repeat title / Repeat all / Repeat off.
A message on the corresponding playback mode is shown
briefly at the bottom edge of the picture.
INFO: Display information on video played.
END: Show video status bar.
The status bar provides you with further information
about the current playback.
Status
Playback (), pause () or wind ( or ).
Repeat
Shows whether one Title or All are being repeated or
whether repeat is switched Off.
The bar on the right hand side shows you how far the
video has been played.
PAUSE button: Pause current playback.
PLAY button: Continue playback.
STOP button: Stop current playback and return to
Wind
You can wind/rewind videos to search for desired
scenes.
Rewind at double speed.
Press again for 4 times speed.
Wind at double speed.
Press again for 4 times speed.
OK Continue playing at the marked position.
END: Abort search and continue playing at the starting
english
overview.
point of the winding process.
11 -
Operating convenience
END
INFO
MENU
Order by...
Open folder
MediaNetwork
Change view
OK
Music
Photo Music Video
END
INFO
MENU
Screen off/on
Play back
MediaNetwork
Random on/off
Repeat title/all/offPage↑/↓
OK
P+
P–
Status Repeat Random
Title Off
005. 02 Elton John - Dark Diamond
OK
001. (I Wish I Knew How It Would Feel To Be) Free...
002. (You Can Keep On) Fallin’ Forever And Ever
003. (You Make Me Feel Like) A Natural Woman
004. 01 Elton John - The Emperors New Clothes
005. 02 Elton John - Dark Diamond
006. 03 Elton John - Look Ma No Hands
007. 04 Elton John - American Triangle
008. 05 Elton John - Original Sin
009. 06 Elton John - Birds
00:00
02:13
04:26
Media overview – music operation
➠ Media selection is shown (page 8).
english
- 12
34 Select folder with music files,
OK open folder.
➠ The name of the folder depends on your media server
setting (in example picture: Music).
5634Select required sub-folder,
OK open folder. If required, repeat.
P+/P- Page up / down.
MENU: Open MediaNetwork menu (page 9).
Green button: Order by...
Change order objects displayed (folders or files).
➠ The sorting options available depend on the media server
that you are using.
Yellow button: Change view
Switches between preview and list view.
Blue button: Go to page...
Alternatively to going through pages with P+/P- you can
also go directly to the individual pages on the overview. On
the Go to page... overview the first title on each page
respectively is shown.
➠ Only available if there are more objects than can be
displayed.
➠ The number of pages depends on the view selected
(preview or list). You can see the number at the bottom
on the left.
Playback of music files
PLAY button or
OK Play marked file.
Press again to jump to the start of the file.
PAUSE button: Pause current playback.
PLAY button: Continue playback.
STOP button: Stop current playback and return to
overview.
Playback previous / next title.
INFO: Display information on marked music file
(Metadata).
Function of coloured buttons during music playback
Red: Switch Screen off/on.
Green: Repeat individual Title / All titles /
Repeat Off.
Yellow: Random on/off.
➠ Random and Repeat are mutually exclusive.
➠ In the additional information (metadata) of a music file, graphics can
be stored as an album cover. If there are such graphics available for
the piece currently being played, then this connection is shown in
the picture.
Music playback – List view with album cover
Operating convenience
Status Repeat Random
Title Off
OK
001. (I Wish I Knew How It Would Feel To Be) Free...
002. (You Can Keep On) Fallin’ Forever And Ever
003. (You Make Me Feel Like) A Natural Woman
004. 01 Elton John - The Emperors New Clothes
005. 02 Elton John - Dark Diamond
006. 03 Elton John - Look Ma No Hands
007. 04 Elton John - American Triangle
008. 05 Elton John - Original Sin
009. 06 Elton John - Birds
00:00
02:13
04:26
Status bar
The status bar below the music file list provides you with further
information on the current playback.
Status
Playback (), pause () or stop ().
Repeat
Random
The bar on the right shows you how far playback of the file has
progressed.
Internet radio
Several media servers give you the option of making internet radio
programmes available apart from multimedia contents (e.g. TwonkyMedia,
see section Media server software on page 16).
Internet Radio programmes that are available are also shown in the
Music folder of the media overview. The precise name of the folder
or file depends on the setting of the media server and on the Internet
Radio station.
Shows whether one Title or All are being repeated or
whether repeat is switched Off.
Shows whether Random has been activated.
english
13 -
Troubleshooting
Problem Possible cause Remedy
The TV set is not getting any connection to
the server. On the main screen Connect is
english
shown and the Connectivity display does not
light up.
Your TV set does not have an IP assigned
to it despite required type of IP assignment
Automatic (DHCP).
a) No connection to the media server.
b) On your PC with Windows XP several media
servers run at the same time, e.g. Windows
Media Player (WMP) 11 and TwonkyMedia
(also see page 16).
a) No DHCP server is working on your
network.
b) With an encrypted wireless connection,
you have entered the key incorrectly.
a) Check whether the media server is switched
on.
Press OK to make a new attempt at
connecting.
Check the connection using the PING
command. To do this, in the entry request on
your PC, enter the command ping.exe,
followed by the IP address of your TV set. You
will find the current IP address in the Device
information (see page 9). Example:
ping.exe 192.168.1.123
If the data packages are not transferred, then
there is a problem with the network.
With a wired connection:
Check the arrangement of the cables.
With a wireless connection:
Check your wireless router. Attach the
additional antenna to the TV set (page 5).
b) If there are several media servers, they can
impede each other. For example, when
working with TwonkyMedia close file release
by WMP11.
a) Set up a DHCP server.
Assign a fixed IP address for the TV set.
b) Select Change network in the MediaNetwork
menu. Rescan for routers using the red
coloured buttons. Then correctly enter the
WLAN key for your router.
Despite video or music file being played back,
no sound can be heard.
- 14
a) The TV set is set to mute or the volume has
been turned down too far.
b) An audio device that does not exist or that
is not connected is registered in the TV
menu under Connections → Sound
components (e.g. HiFi/AV amplifier).
a) Increase the volume by pressing the V+ button
on your remote control. This will also cancel
any mute setting.
b) Connect up the audio device and switch it on.
In the Sound components wizard change back
to TV speakers.
Troubleshooting
Problem Possible cause Remedy
Although the file is visible on the media server,
it is not shown in the Network Mediaplayer.
A media file that is displayed can not be
played back.
Characters contained in the WLAN key are not
shown on the input screen (page 6).
The code for your wireless network contains
more characters than can be entered in the
Please enter password dialog box (page 6).
When searching for wireless routers, no device
is found.
If with wireless operation there should be any interference such as disruptions during playback or slow reactions by devices to commands, you could
try the following:
- Keep at least three metres distance from microwave ovens, bluetooth devices, mobile telephones and Wi-Fi compatible devices such as printers
and PDAs.
- Change the active channel on the WLAN router.
Notes on high definition films
High definition film material (HD films) from format 720p upwards (resolution 1280 x 720 or higher) should be played back via a wired connection.
If there is a wireless connection, then technical limitations (e.g. fault liability, bandwidth limitations) can cause disruptions in the playback right up
to a complete breakdown of the playback.
The file is not being made available by your
media server.
The format of the file is not supported (see
also limitations in section File formats supported
on page 16).
The device only supports the characters shown
(ASCII standard).
The device only supports WLAN codes with up
to 32 characters.
The router is not ready for wireless
communication.
Change your media server. Read up about this
in the section "Media server software" on
page 16.
No remedy.
Change the WLAN key of the router.
Change the WLAN key of the router.
Check your wireless router.
Try to make the connection again a few
minutes later.
english
15 -
Other
Technical specifications
File formats supported
Pictures: JPG, PNG, BMP
english
➠ Picture files may generally not exceed a size of 6MB.
➠ Photos in Bitmap format (BMP) are supported if not
compressed in 8 bit and 24 bit (not RLE) and only in Windows
format.
➠ Photos in Progressive JPEG format may not exceed a resolution
of 1024x768 pixels.
Music: MP3, WAV (without ADPCM), WMA 8/9 (compressed), LPCM, AAC-LC
Video: MPEG 1/2/4, WMV 9/HD, DivX® Video, Xvid
➠ This device can not play back any DRM protected contents.
➠ In individual cases it is possible that media files can not be played back
due to the numerous available technical design and editing options.
Ethernet (wired network)
Standards supported: 10 Mbit/s Ethernet (10Base-T), 100 Mbit/s Fast Ethernet
(100Base-T)
WLAN (wireless network)
Standards supported:
IEEE 802.11b and 802.11g
Frequency range used:
2400-2483.5 MHz
Types of encoding that are supported:
WEP 64 and 128 Bit (ASCII and HEX), WPA PSK and TKIP (max. 32
characters), WPA2 AES (max. 32 characters)
Supported home network standard
Universal Plug and Play Audio / Video (UPnP AV)
Media server software
To play multimedia contents you will need media server software which
makes the appropriate files available to you. Handling individual files
depends on the technical properties and also on the media server
software used.
On our homepage at www.loewe-int.de you can download a test version of
the TwonkyMedia Media server. With your TV set you have simultaneously
acquired the option if obtaining a free license for this media server.
Alternatively to that, you can also use other media software such as the
Windows Media Player (WMP) as of version 11.
For communication with your PC, certain port addresses of the network
connection are required. They may not be blocked by a firewall if there
is one, otherwise this could cause serious connection errors.
Windows Media Player 11 requires the port addresses 1900 and the block
of 10280 up to and including 10284 (all for UDP) as well as 2869 and
10243 (both for TCP). For TwonkyMedia the port addresses 1030, 1900
and 9080 (all for UDP) and 9000 (for TCP) must be available.
Other ports to be kept free depend on the operating system you are
using.
Contact your network administrator about configuring the firewall.
Legal notices
The screen font "LoeweL2700" is based on the "Tavmjong Bah Arev
(tavmjong.free.fr)" font, which in turn is based on "Bitstream Vera".
Bitstream Vera is a trademark of Bitstream Inc.
This set contains a software which is based partly on the work of the
Independent JPEG Group.
DivX and the corresponding DivX logos are registered trademarks of
DivX, Inc
Masthead
Loewe Opta GmbH
Industriestraße 11
D-96317 Kronach
www.loewe.de
All rights including translation, technical modifications and errors
reserved.
This equipment is in compliance with the essential requirements and other relevant provisions
of Directive 1999/5/EU. It may be operated in all countries in the EU (with the exception of Bulgaria) and also
in Iceland, Norway and Switzerland.
In France and Italy it may only be used indoors.
- 16
Printed in Germany
Date of issue 08/08-5.0 FP
ID: V80205.0
© Loewe Opta GmbH, Kronach
Glossary
A
Administrator: Person who administers the network, i.e. takes care of
setting up and maintaining all components belonging to the network.
AVI: Abbreviation for Audio Video Interleave, a video container file format
developed by Microsoft. A single AVI video file can contain several audio,
video and text data streams (thus the name container format).
B
BMP: Abbreviation for Bitmap, a grid graphics format designed for
Microsoft Windows and OS/2 that is wide spread and therefore
supported by almost every popular graphics software package without
any problems.
C
Channel (WLAN): The channel is a certain part of the WLAN frequency
band. Devices that want to communicate with each other have to use the
same WLAN channel. In Europe the WLAN frequency band is currently
divided into 13 channels.
Client: Also referred to as network client; describes an end device such
as your TV set that is connected to the network and gets data from a
(media) server to make it accessible to the user.
D
DHCP: Abbreviation for Dynamic Host Configuration Protocol. DHCP
allows automatic assignment of IP addresses with the aid of a DHCP
server.
DHCP server: Network service which takes care of automatic assignment
of IP addresses to clients.
DivX: Video Codec which allows even large files to be relatively highly
compressed in their file size without having to tolerate important quality
losses.
DRM: Digital Rights Management. Processes to control copyright
protected data. To be used correctly, DRM protected contents require
not only a DRM capable device but also the possession of a license
issued by the provider (to be paid for).
E
Ethernet: Cable linked data net technology for local networks (LANs). Also
covers standards for e.g. plug connectors and transfer speeds.
H
Host: Computer that the server services are provided from, i.e. that makes
data available. Refer also to media server.
I
ID3 tags: Additional information on MP3 files. Here you can save
information on the artist, title, album and album cover. This data is then
processed by the PC using an ID3 tag editor.
IP address: IP addresses (Internet Protocol Addresses) are used to identify
devices in an Internet Protocol (IP) network. IP addresses are made up of
four groups of numbers of three digits each.
J
JPEG/JPG: Joint Photographic Experts Group. A body that has developed
a standardised process for compressing digital images. This process JPEG
(abbreviated to JPG) that was named after the body is a wide spread
graphics format for photos.
L
LAN: Abbreviation for Local Area Network. Mainly used as a name for
networks with cabling (Ethernet).
M
MAC address: Hardware address of a network adapter, e.g. the network
card in the PC. It is permanently assigned by the manufacturer and is
used to uniquely identify devices in networks.
Mbit/sec: Information about the transfer rate in networks in megabits,
i.e. millions of characters per second. With WLAN, the maximum speed
is 11 (IEEE 802.11b) or respectively 54 (IEEE 802.11g) Mbit/sec, in wired
nets 10 Mbit/sec or 100 Mbit/sec (Fast Ethernet).
Media server: Stands for the device which multimedia contents are stored
on, but is also the name for the service provided by the device that makes
this data available to the network.
MP3: Data format for compressed audio data.
Multimedia contents: Videos, music files and photos are grouped together
under this term.
N
NAS: Abbreviation for Network Attached Storage. The term describes
a hard disk which is independently linked to the network (i.e. without
a PC).
Network Mediaplayer: The technology in your Loewe TV set which
presents multimedia contents on the screen for you.
english
17 -
Glossary
P
PNG: Abbreviation for Portable Network Graphics, a freely available grid
graphics format for loss-free compression.
Port: A port is part of a network address (or also IP address). It allows
english
assignment of data packages to various services which are running on
one device under the same network address.
PSK: Stands in connection with WLAN encoding for Pre-Shared Key.
Clients, who want to connect up to a wireless network secured with
PSK have to know this key.
R
Router: Device for connecting up several networks, e.g. home network
and Internet.
S
Switch: Device for connecting several computers to a network.
U
UPnP AV: Abbreviation for Universal Plug and Play Audio / Video. Is used
to control network devices from all manufacturers. Has become a wide
spread standard for home networking.
W
WEP: Abbreviation for Wired Equivalent Privacy. Former standard process
in the WLAN encryption, now outdated.
Wired network: see LAN.
Wireless network: see WLAN.
WLAN: Abbreviation for Wireless Local Area Network. Also abbreviated
as wireless network.
WMA: Abbreviation for Windows Media Audio, Microsoft own audio data
format. As with MP3 files, the content is compressed here as well.
WMV: Abbreviation for Windows Media Video, Microsoft own video
data format.
WPA: Abbreviation for Wi-Fi Protected Access. Replaced WEP as standard
encryption for wireless networks.
- 18
Index
A
Additional antenna 4, 5
C
Coloured buttons 8
D
Device information 9
Active WLAN channel 9
IP address 9
Max. WLAN transfer rate 9
Network mode 9
Server Name 9
SSID 9
Subnet mask 9
WLAN MAC address 9
WLAN signal level 9
E
Enter WLAN key 6
I
Initial installation 5
Internal WLAN antenna 4, 5
IP address 7
M
MediaNetwork 4
Access 4
Exit 4
Selection of menu items 4
MediaNetwork menu 9
Background play 9
Change network 9
MediaNetwork LED 9
Photo Info 9
Select / search media server 9
Slide show interval 9
Multimedia contents 4
Music operation 12
N
NAS 4
Network connection
Wired 4, 5
Wireless 4, 5
Network Setting 7
P
PC 4
Photo operation 10
Full screen mode 10
Slide show 10
R
Remote control 3
S
Select IP address assignment method 7
Select Network Interface 6
Select server 7
Select wireless router 6
Subnet mask 7
U
UPnP 4
V
Video operation 11
english
19 -
- 20
21 -
- 22
Loading...
