lnfineon TLE 4296-2 DATA SHEET

Low Drop Voltage Regulator

Features

• Two versions: 3.3 V, 5.0 V

• Output voltage tolerance

• Very low drop voltage

• Output current: 30 mA

• Inhibit input

• Low quiescent current consumption

• Wide operation range: up to 45 V

• Wide temperature range: -40

• Output protected against short circuit

• Overtemperature protection

• Reverse polarity proof

• Very small SMD-Package P-SCT595-5

≤ ±4%

°C ≤ T

≤ 150 °C

j

TLE 4296-2

SCT 595

Functional Description

The TLE 4296-2 G is a monolithic integrated low-drop voltage regulator in the very small
SMD package P-SCT595-5. It is designed to supply e.g. microprocessor systems under
the severe conditions of automotive applications. Therefore the device is equipped with
additional protection functions against overload, short circuit and reverse polarity. At
overtemperature the regulator is automatically turned off by the integrated thermal
protection circuit.

Input voltages up to 40 V are regulated to

V

Q,nom

= 3.3 V (V33 version) or 5.0 V (V50
version). The output is able to drive a load of more than 30 mA while it regulates the
output voltage within a 4% accuracy. To save energy the device can be switched in
stand-by mode via an inhibit input which causes the current consumption to drop below
5

µA.

Type Ordering Code Package

TLE 4296-2 GV33 Q67006-A9608 P-SCT595-5
TLE 4296-2 GV50 Q67006-A9609 P-SCT595-5

Data Sheet 1 Rev. 1.0, 2004-01-01

TLE 4296-2

INH

GND

Ι

1

5

2

3

4

AEP02253

Figure 1 Pin Configuration (top view)

Table 1 Pin Definitions and Functions
Pin No. Symbol Function

1INH

Inhibit input; high level to turn IC on
2GNDGround; connected to pin 5
3IInput voltage

GND

Q

4QOutput voltage; must be blocked with a ceramic capacitor

C

≥ 3.3 µF, ESR ≤ 2 Ω

Q

5GNDGround; connected to pin 2

Data Sheet 2 Rev. 1.0, 2004-01-01

TLE 4296-2

Temperature

Control

3

Ι

Band-Gap-

Referenz

1

INH

Figure 2 Block Diagram

Saturation

Control and

Protection

Circuit

4

Q

+

2,5

GND

AEB02312

Data Sheet 3 Rev. 1.0, 2004-01-01

Table 2 Absolute Maximum Ratings

TLE 4296-2

-40

°C < T

< 150 °C

j

Parameter Symbol Limit Values Unit Remarks

Min. Max.

Input

Voltage
Current

V
I

I

I

-42 45 V –
––mA internally limited

Output

Voltage
Current

V
I

Q

Q

-0.3 30 V –
––mA internally limited

Inhibit

Voltage
Current
Current

V
I
I

INH

INH

INH

-42 45 V –

-500 * µA * internally limited

-5 5 mA -0.3 V < VI < 45 V;

t

< 1 ms

p

Temperatures

Junction temperature
Storage temperature

T

j

T

stg

-40 150 °C –

-50 150 °C –

Thermal Resistances

Junction pin
Junction ambient

R

thj-pin

1)

R

thja

– 30 K/W measured to pin 5
– 179 K/W zero airflow

zero heat sink area

1) Worst case regarding peak temperature.

Note: Maximum ratings are absolute ratings; exceeding any one of these values may

cause irreversible damage to the integrated circuit.

Data Sheet 4 Rev. 1.0, 2004-01-01

TLE 4296-2

Table 3 Operating Range
Parameter Symbol Limit Values Unit Remarks

Min. Max.

Input voltage

Inhibit voltage
Junction temperature

V
V
V
T

I

I

INH

j

4.0 45 V TLE 4296-2 GV33

5.5 45 V TLE 4296-2 GV50

-0.3 40 V –

-40 150 °C –

Data Sheet 5 Rev. 1.0, 2004-01-01

TLE 4296-2

Table 4 Electrical Characteristics

V

= 13.5 V; V

I

Parameter Symbol Limit Values Unit Test Condition

> +2.5 VQ; -40 °C < Tj < 150 °C; unless otherwise specified

INH

Min. Typ. Max.

Output voltage

V

V33 version

Output voltage

V

V50 version

Output current limitation

I

Drop voltage V
Output capacitor C

Current consumption

I

= II - I

q

Q

Current consumption

I

= II - I

q

Q

I

I

Q

Q

Q

dr

Q

3.17 3.30 3.43 V 1 mA < IQ < 30 mA

V

= 13.5 V

I

I

3.17 3.30 3.43 V

= 10 mA

Q

4.3 V <

V

< 40 V

I

4.80 5.00 5.20 V 1 mA < IQ < 30 mA

V

= 13.5 V

I

I

4.80 5.00 5.20 V

30 ––mA
– 0.25 0.30 V IQ = 20 mA

= 10 mA

Q

6 V <

1)

V

< 40 V

I

1)

3.3 ––µF ESR ≤ 2 Ω

at 10 kHz

q

q

– 25.2mAIQ < 30 mA

– 130 170 µA IQ < 0.1 mA;

T

< 85 °C

j

Quiescent current
(stand-by)

I

= II - I

q

Q

Quiescent current
(stand-by)

I

= II - I

q

Q

I

q

I

q

– 01µA V

T

– 05µA V

= 0.4 V;

INH

< 85 °C

j

= 0.4 V

INH

Data Sheet 6 Rev. 1.0, 2004-01-01

TLE 4296-2

Table 4 Electrical Characteristics (cont’d)

V

= 13.5 V; V

I

Parameter Symbol Limit Values Unit Test Condition

> +2.5 VQ; -40 °C < Tj < 150 °C; unless otherwise specified

INH

Min. Typ. Max.

Load regulation ∆V

Q

– 17 50 mV 1 mA < I

T

TLE 4296-2 GV50

– 14 40 mV 1 mA <

T

TLE 4296-2 GV33

Line regulation

Power Supply Ripple

∆V

Q

PSRR – 60 – dB f

Rejection

Logic Inhibit Input

Inhibit, Turn-on voltage
Inhibit, Turn-off voltage V
H-input current
L-input current

1) Measured when the output voltage VQ has dropped 100 mV from the nominal value.

V

INH, high

INH, low

I

INH, high

I

INH, low

– 10 25 mV VI = (V

to 36 V

I

Q

= 100 Hz;

r

V

––2.2 V VQ > 0.95 V

0.4 ––V VQ > 0.1 V
– 812µA V

-2 – 2 µA V

< 25 mA;

Q

= 25 °C

j

I

< 25 mA;

Q

= 25 °C

j

+ 0.5 V)

Q,nom

= 5 mA; Tj = 25 °C

= 0.5 Vpp

r

Q,nom

= 5 V

INH

= 0 V

INH

Data Sheet 7 Rev. 1.0, 2004-01-01

TLE 4296-2

V

Q

,nom

Inhibit

+ 0.5V to 45V

C

Ι

100 nF

INH

Ι

3

TLE 4296-2G

1

2,5

GND

Q

4

3.0V / 3.3V / 5.0V

C

Q

4.7 µF

e.g. TDK
C3216X7R1C475M

AES02313_4296-2

Figure 3 Application Circuit

Application Information

In the TLE 4296-2 G the output voltage is divided and compared to an internal reference
of 2.5 V typical. The regulation loop controls the output to achieve a stabilized output
voltage.

Figure 3 shows a typical application circuit. In order to maintain the stability of the control

loop the TLE 4296-2 G output requires an output capacitor
maximum permissible ESR of 2

C

capacitor for

, e.g. the TDK C3216X7R1C475M with a nominal capacitance of 4.7 µF.

Q

Ω. It is recommended to use a multi layer ceramic

C

of at least 3.3 µF with a

Q

Aluminum electrolytic as well as tantalum capacitors do not cover the required ESR
range over the full operating temperature range of -40

°C to 150 °C.

At the input of the regulator an input capacitor is necessary for compensating line
influences (100 nF ceramic capacitor recommended). A resistor of approx. 1
with

C

, can damp any oscillation occurring due the input inductivity and the input

I

Ω in series

capacitor. If the regulator is sourced via long input lines of several meters it is
recommended to place an additional electrolytic capacitor

≥ 47 µF at the input.

Data Sheet 8 Rev. 1.0, 2004-01-01

Typical Performance Characteristics

V

V

I

versus

Q

AED03349.VSD

V

= 5 V

INH

R

= 1 kΩ

L

Output Voltage
Input Voltage

10

V

V

Q

8

TLE 4296-2

Current Consumption Iq versus
Input Voltage

1000

µA

I

q

800

V

I

AED03347.VSD

V

= 5 V

INH

6

GV50

4

2

0

0

246810

GV33

V

V

I

600

400

200

R

= 1 kΩ

L

R

= 5 kΩ

L

0

0

10 20 30 40 50

V

V

I

Data Sheet 9 Rev. 1.0, 2004-01-01

Package Outlines

(0.13)

B

1.2

(0.4)

1)

(0.23)

0.6

+0.1

-0.05

1)

+0.1

-0.05

2.9
(2.2)

±0.2

(0.3)

0.3

0.95

+0.2

acc. to
DIN 6784

+0.1

-0.05

0.25 min

2.6 max

0.20

1.1 max

10˚max

M

A

0.1 max

+0.1

0.15

-0.06

TLE 4296-2

±0.1

1.6

10˚max

A

1.9

0.25MB

1)

Contour of slot depends on profile
of gull-wing lead form

Figure 4 P-SCT595-5 (Plastic Small Outline)

GPW05997

You can find all of our packages, sorts of packing and others in our
Infineon Internet Page “Products”: http://www.infineon.com/products.

SMD = Surface Mounted Device

Dimensions in mm

Data Sheet 10 Rev. 1.0, 2004-01-01
