MANUAL FOR
CARETTA BUGGY
Edition 1 – 2016-02-02
Caretta Buggy Edition 1 p. 1
NOTE! THE MANUFACTURER IS SOLELY RESPONSIBLE ONLY FOR THE EQUIPMENT
PURCHASED FROM A DIRECT REPRESENTATIVE OF LIW CARE TECHNOLOGY, OR IN
SPECIALIZED MEDICAL SHOPS REPRESENTING LIW CARE TECHNOLOGY IN POLAND.
Caretta Buggy Edition 1 p. 2
Table of content:
1. Introduction ..................................................................................................................................... 3
2. General safety standards................................................................................................................. 4
3. Indications for product use ............................................................................................................ 5
4. Weight and dimensions ................................................................................................................... 6
5. Basic structure of the Caretta Buggy ............................................................................................... 9
6. Detailed assembly steps of the Caretta Buggy .............................................................................. 11
7. Installation of additional adapters ................................................................................................ 13
8. Chest supports installation ............................................................................................................ 14
9. Folding the stroller ........................................................................................................................ 15
10. Removing the wheels ................................................................................................................ 17
10.1 Removing the front wheels ....................................................................................................... 17
10.2 Removing the rear wheels ......................................................................................................... 18
11. Moving the Caretta Buggy stroller around ................................................................................ 18
12. Detailed description of adjustment and structure of the Caretta Buggy .................................. 19
12.1 Parking brake ............................................................................................................................. 19
12.2 Backrest adjustment .................................................................................................................. 19
12.3 Pushing handle adjustment ....................................................................................................... 20
12.4 Seat angle adjustment ............................................................................................................... 20
12.5 Seat depth adjustment .............................................................................................................. 21
12.6 Footrest height adjustment ....................................................................................................... 22
12.7 Chest supports adjustments adjustment .................................................................................. 23
12.8 Head supports adjustment ........................................................................................................ 24
12.9 Footrest angle adjustment ........................................................................................................ 24
12.10 Footrest supports angle adjustment ..................................................................................... 25
12.11 Adjusting the foot-rest platforms .......................................................................................... 25
13. Cleaning and maintenance ........................................................................................................ 26
14. Warranty/Service ...................................................................................................................... 27
15. Identification plate .................................................................................................................... 27
16. Symbols meaning ...................................................................................................................... 28
17. Compliance with the safety requirements for medical devices ............................................... 28
WARRANTY CARD .................................................................................................................................. 29
Caretta Buggy Edition 1 p. 3
1. Introduction
Developed and created by LIW Care Technology, first-class Pediatric Pushchair Caretta Buggy
(hereinafter referred to as the buggy), is designed to transport children up to 55 kg. It is designed to
facilitate the daily care of children who need transport, whose diseases enable their self-sufficient
movement as well as the correct sitting and standing. Buggy Caretta medical device is designed for
children with paralysis and triplegia or tetra- plegia; with diplegia, hemiplegia or hemiparesis. We did
our best to make this Caretta Buggy Pediatric Pushchair really easy to operate, to provide stability,
with the ability to adapt to the body shape.
We are aware of the fact that assuming sitting position by a disabled person is a very
important element of psychomotor development and the opportunity for comfortable and safe
movement in open space has a huge, positive impact on patients and their caregivers alike. That is
why, we have Caretta Buggy, which was designed to be easy to use and to dismantle. The buggy may
be used both indoors and outdoors.
We pay special attention to high quality of our products, that is why we would like you to
read these user instructions thoroughly – this will ensure a safe use of this product, it will affect its
efficiency and it will allow you to fully exploit the advantages of this Caretta Buggy.
Keep these instructions in a safe place, so that they are available if required. These
instructions are intended to be read by persons responsible for taking care of disabled children.
Caretta Buggy Edition 1 p. 4
2. General safety standards
For LIW Care Technology Sp. z o. o., the most important thing is to protect the patients who
use our equipment. For ensuring the safety of Caretta Buggy users, the following recommendations
should be adopted:
1. Please read the Instructions before the first use. In case any questions or doubts should arise,
please contact your dealer or the manufacturer. Contact details are available via our website:
www.liwcare.pl
2. Please make sure that all the information, tips and warnings contained in these chapters are
fully understood.
3. Never leave your child in the buggy unattended.
4. Improper use of the buggy may endanger human health and it may cause injuries.
5. While using and operating the buggy as well as during its setting and adjusting the
mechanisms, you should pay close attention to moving parts which create risk of trapping the
body in holes or between the elements. After every single adjustment, you must stabilize its
position by carefully tightening screws and ensure that all the components are correctly
positioned and locked.
6. If the child is in a buggy, make sure it is properly secured by belts and a vest.
7. The Caretta Buggy can be used by one person at a time.
8. It is forbidden to transport the baby in the Caretta Buggy while using the public and private
transport, ie. bus, tram, trolley bus, train.
9. It is forbidden to transport the baby in the Caretta Buggy while driving a car – the seat of the
buggy is not a car seat. The child cannot stay in the seat while driving.
10. In the backseat there is a pocket with all the tools that are needed to carry out the
adjustments: allen wrench no. 4.
11. It is forbidden to drive up and drive the buggy down stairs with both the child and without
the child.
Caretta Buggy Edition 1 p. 5
In these instructions for LIW Care Technology Sp. z o. o. products, you will find information
marked with „NOTE!” symbol. It is used to the draw reader’s particular attention to the text. It looks
as follows:
NOTE! THE SYMBOL IS USED TO DRAW THE READER’S ATTENTION TO THE TEXT
WHICH IS MARKED WITH THIS SYMBOL. FAILURE TO COMPLY WITH THE
INSTRUCTIONS MAY ENDANGER THE HEALTH AND SAFETY OF THE USER OR IT
MAY DAMAGE THE PRODUCT.
3. Indications for product use
Caretta Buggy medical device is designed for children suffering paralysis and triplegia or
tetraplegia; from diplegia, hemiplegia or hemiparesis.
It is recommended for children who have been diagnosed with:
• cerebral palsy (paralysis cerebralis infantium),
• muscular dystrophies,
• paralysis,
• spina bifida,
• myelomeningocele,
• spinal injury,
• traumatic brain injury,
• strokes,
• other diseases with paresis, paralysis, locomotory disabilities enabling their
self-sufficient movement.
Caretta Buggy Edition 1 p. 6
4. Weight and dimensions
Caretta Buggy Edition 1 p. 7
Caretta Buggy Edition 1 p. 8
No.
Dimension
Dimension
symbol
Dimension [cm]
1
Pelvic support spacing (seat width)
SW
32
2
Seat depth
SD
36-42-48
3
Turning angle
TA
+1 ÷ -23⁰
4
Back height
BH
55 ÷ 75
5
Back-support angle
BA
0⁰ ÷ 120⁰
6
Chest supports length
LH
12 ÷ 42
7
Chest supports spacing
LR
17 ÷ 30
8
Head supports spacing
HR
12 ÷ 21
9
Footrests height
FH
27 ÷ 37
10
Footrest length
FL
23
11
Footrest angle adjustment
FA
0⁰÷ 90⁰
12
Footrest assembly angle
FA1
-20⁰÷ 20⁰
13
Base length
BL
113
14
Base width
BW
64
15
Wheel diameter (front)
WDF
19
16
Wheel diameter (rear)
WDR
31
17
Handle height
HH
70 ÷ 113
18
Height of the buggy when folded without wheels
HH1
52
19
Width of the buggy when folded without wheels
BW1
61
20
Length of the buggy when folded without wheels
BL1
94
21
Height of the buggy when folded with wheels
HH2
57
22
Width of the buggy when folded with wheels
BW2
63
23
Length of the buggy when folded with wheels
BL2
97
24
Maximum user’s weight
55 kg
25
Weight of the buggy
23 kg
Caretta Buggy Edition 1 p. 9
5. Basic structure of the Caretta Buggy
Fig. 1 General layout of the stroller
5.1 Standard equipment
1. Pushing handle
2. Back rest
3. Seat
4. Stroller frame
5. Front wheels, back wheels
6. Parking brake
7. Rear shock absorbers
8. Foot rest
9. Five points safety belt
10. Side windshields
11. Bag
12. Adapters along the backrest
13. Protective cover for the handle pipes
Caretta Buggy Edition 1 p. 10
5.2 Additional equipment (available on customer’s request)
1. Canopy
2. Cushion tapered seat
3. Sleeping bag
4. Headrest
5. Adjustable belts
6. Hip pelottes
7. Protective cover for seat pipes
8. Accesories bag
Caretta Buggy Edition 1 p. 11
6. Detailed assembly steps of the Caretta Buggy
For the safety reasons, the stroller is delivered in parts, including: frame with a seat, wheels,
windshields and back part with, or without the head stabilizer. In order to assemble the stroller, you
shall follow the steps below:
STEP 1: Remove any protective film layers from the elements of the buggy, and place the frame as
shown on Fig. 2.
STEP 2: Install the front wheels by pushing the bolts into the frame holes. Once the bolts are pushed
in, a click may be heard when the wheels are properly installed; once this happens they have no
chance of falling out.
Fig. 2 Stroller frame, along with the seat
STEP 3: Install the wheels on the bolt of the rear suspension element. Push the wheels until you hear
the lock click.
Fig. 3 Stroller frame, along with the wheels
Caretta Buggy Edition 1 p. 12
STEP 4: Press the black handle at the back of the frame, and then adjust the back part, so that a
proper rest angle is achieved.
Fig. 4 Stroller with the back rest deployed
STEP 5: In order to properly install the windshield, first place the wind shield in socket 1. Then turn it
around and lock it in clasp 2.
Fig. 5 Stroller with the windshields installed
1
2
Caretta Buggy Edition 1 p. 13
STEP 6: Push the stroller handle up, until the frame locks in place.
Fig. 6 - Fully assembled stroller
7. Installation of additional adapters
Prolonged backrest installation
Press clamp no. 1 and then slide the tubes no. 2 onto the protruding elements of the rest,
until you hear a click. After the assembly is completed, slide on the No. 3 material.
Fig. 7 Back rest with an adapter
1
1 2 3
Caretta Buggy Edition 1 p. 14
Head supports (head stabilizers) installation
Press clamp no. 1 and then slide the head support onto the protruding elements of the
rest, until you hear a click.
Fig. 8 Back rest with an head supports
8. Chest supports installation
Press the clamp No. 1 and then insert the chest support into the hole, until it clicks in its place.
Fig. 9 Chest supports installation
1
1
1
Caretta Buggy Edition 1 p. 15
9. Folding the stroller
STEP 1: Set the tilt angle to the horizontal position (press the red handle at the back of the back rest.)
Fig. 10 Tilt angle adjustment
STEP 2: Remove the chest supports (chest stabilizers). Press the clamp no. 1 and remove the support
from its socket.
Fig. 11 Chest supports dismantling
1
Caretta Buggy Edition 1 p. 16
STEP 3: Dismantle the windshields. Press the red button on the side of the back rest and remove the
windshields.
Fig. 12 Windshields dismantling
STEP 4: Pull the release elements and turn the handle to fold the stroller frame.
Fig. 13 Collapsing the framework
Caretta Buggy Edition 1 p. 17
STEP 5: Pull the handle used to adjust the back rest angle and push the rest forward.
Fig. 14 Collapsing the back rest
10. Removing the wheels
10.1 Removing the front wheels
Press the black plastic button from the top and then pull the front wheel to remove it.
Fig. 15 Removing the front wheels
Caretta Buggy Edition 1 p. 18
10.2 Removing the rear wheels
Press the metal pin in the rear wheel, then pull to remove it.
Fig. 16 Removing the back wheels
11. Moving the Caretta Buggy stroller around
For safety reasons, the collapsed stroller needs to be carried while held by its frame.
Fig. 17 Proper way to carry the stroller
Caretta Buggy Edition 1 p. 19
12. Detailed description of adjustment and structure of the Caretta Buggy
NOTE! After each adjustment, one needs to ensure that all of the adjustment
elements are properly placed and secured.
12.1 Parking brake
Fig. 18 Parking brake
The back wheels are locked by the lever at the back bar of the framework. By pressing the
lever, we block the back wheels. Unlocking is realized by lifting the lever up. Fig. 18
NOTE! The brake status needs to be regularly assessed. Dirt and mud need to
be periodically cleaned.
NOTE! Be cautious, when going over a threshold.
12.2 Backrest adjustment
Fig. 19 Backrest
Press the black lever installed on the back part of the seat, and by manipulating that lever
adjust the back rest angle, within the range between 90⁰ ÷ 113⁰ Fig. 19.
Caretta Buggy Edition 1 p. 20
12.3 Pushing handle adjustment
Fig. 20 Pushing handle
Press both adjustment buttons simultaneously, set a proper height for the handle. Once it is
set, move it up and down, until you hear the lock click. Fig. 20. There is an option of adjusting the
height at which the pushing handle is placed, within the range from 70 to 113 centimeters from the
ground.
NOTE! You shall remember that every item you place on the handle has a significant
impact on the stroller’s stability.
12.4 Seat angle adjustment
Fig. 21 Seat angle adjustment
Holding the seat, press the red release lever (Fig. 21), setting the desired angle within the
range between +1⁰ and -23⁰ Fig. 21.
Caretta Buggy Edition 1 p. 21
NOTE! Due to the wide scope of possible adjustment, when you regulate the seat
angle and the back rest, there is an option of setting a position in which the child’s head
is beneath the pelvis line. Using such position is prohibited, since it may lead to child
being choked.
12.5 Seat depth adjustment
Fig. 22 a
STEP 1: Press the blockade under the seat.
Fig. 22 b
STEP 2: Extend the pipe which supports the footrest.
Fig. 22 c
STEP 3: Install additional belt and install the seat upholstery element.
Caretta Buggy Edition 1 p. 22
12.6 Footrest height adjustment
Fig. 23 Footrest height adjustment
Press the locking button and then pull the pipe, setting a proper height for the footrest. The
adjustment range is between 27 and 37 cm.
NOTE! The footrest is used to rest the feet on, the child should not stand on that
element.
Caretta Buggy Edition 1 p. 23
12.7 Chest supports adjustments adjustment
Fig. 24 - Chest support width and height adjustment
Loosen the knobs and then adjust the height and width of the chest supports. Right and left
support may be set asymmetrically.
Breast pelottes can be rotated upto 180⁰ degrees in order to increase the control range.
For this function, unscrew the clamping knobs, turn pelottes and then screw back in the clamping
knobs.
Caretta Buggy Edition 1 p. 24
12.8 Head supports adjustment
Fig. 25 Head supports width adjustment
Unscrew the 6 rotary knobs. Adjust the height of the headrest and width of head pelottes.
After adjusting, tighten the adjustment knobs. Head pelottes can be set asymmetrically.
12.9 Footrest angle adjustment
Fig. 26 Footrest angle adjustment
Loosen the lower adjustment screws, set a proper angle, lock these screws again. Fig. 26. It is
possible to adjust the footrest angle, within the range between -20⁰ ÷ 20⁰.
Caretta Buggy Edition 1 p. 25
12.10 Footrest supports angle adjustment
Fig. 27 Footrest supports angle adjustment
Press both adjustment buttons simultaneously. Once it is set, move it up and down, until you
hear the lock click. It is possible to regulate the footrest support angle within the range between:
0 - 90⁰.
12.11 Adjusting the foot-rest platforms
Fig. 28 Adjusting the foot-rest platforms
Unscrew the four screws that secure the platform. Slide the platform at a suitable distance.
After adjustment tighten the screws.
Caretta Buggy Edition 1 p. 26
13. Cleaning and maintenance
Caretta Buggy Stroller is a mechanical device, with its frame made out of steel and
aluminium. The frame is powder-coated. Foam - sponge inserts are attached to the metal structure
of the device. The foam elements are covered with textile material covers. None of the Buggy’s
external layers cause skin irritation. Caretta Buggy stroller, as any other medical device, shall be kept
clean and shall be used in line with the manufacturer’s guidelines.
The paint coating and plastic covers should be cleaned with a damp cloth. It is
permissible to use mild detergents. Dust removal shall be carried out mechanically,
or with the use of a soft brush.
The cover should be washed by hand, or in a washing machine, however the water
temperature shall not exceed 30 degrees Celsius. When washing, one should use
washing solutions certified by the Polish National Institute of Hygiene, for use with
delicate products, in a quantity specified on the packaging.
It is permissible to clean the foam - sponge inserts with a damp cloth and a mild
detergent. After this procedure is carried out, thoroughly dry the insert in room
temperature.
NOTE! BEFORE YOU USE THE CARETTA BUGGY STROLLER AGAIN, THE UPHOLSTERY
SHALL BE DRY.
You should systematically take care of the frame, remove the dirt and mud from the
moving parts.
Please, do not use strong (corrosive) detergents and their derivatives.
One shall avoid prolonged sunlight exposure. Before you get child seated, please
check the seat temperature.
NOTE! CARETTA BUGGY STROLLER SHALL UNDERGO MAINTENANCE AT LEAST
ANNUALLY. MAINTENANCE WORKS SHOULD BE CARRIED OUT BY A QUALIFIED
MAINTENANCE TECHNICIAN. WHEN YOU CARRY OUT THE MAINTENANCE PROCEDURES,
THE SAFETY OF THE BUGGY SHOULD BE REVIEWED - MOVING ELEMENTS, CLASPS AND
ADJUSTMENT MECHANISMS SHALL BE INSPECTED. PERIODIC MAINTENANCE ALLOWS
FOR LONG TERM OPERATION, WITHOUT ANY MAJOR PROBLEMS.
Caretta Buggy Edition 1 p. 27
14. Warranty/Service
Should you notice any faults or defects, you should stop using the buggy immediately and
contact your dealer or manufacturer. Defective unit must be protected against enlarging the area of
damage. Never attempt to disassemble or repair the product. Do not replace original parts with the
ones coming from a source other than the manufacturer recommends.
If the user decides not to continue using the product it is bound to its disposal in accordance with
the applicable environmental regulations.
The economic lifetime of the product is five years.
The manufacturer provides post – warranty service. Contact details:
LIW Care Technology Sp. z o.o., ul. Golfowa 7, 94-406 Łódź, Poland.
biuro@liwcare.pl
Current contact details are available on: www.liwcare.pl
Warranty terms are specified in the warranty card, which is an integral part of this statement.
The warranty card is available on the last page of this document.
15. Identification plate
Caretta Buggy Edition 1 p. 28
16. Symbols meaning
Manufacturer’s name and date of manufacture
Serial Number
User’s permissible weight
Note! Follow product instructions
Avoid contact with water
Unlocking direction
Movement direction
Mark of conformity in accordance with EU Directive 93/42 EEC Annex. VII,
concerning medical devices
17. Compliance with the safety requirements for medical devices
Caretta Buggy meets the essential requirements of the MDD 93/42 EEC + 2007/47 / EC for medical
devices.
Caretta Buggy, in accordance with Annex IX of the MDD 93/42 EEC is non-invasive non-active I class
medical device according to rule 1.
The Declaration of Conformity for this product can be found in manufacturer's Sales Department.
Caretta Buggy Edition 1 p. 29
WARRANTY CARD
Warranty terms:
1. Manufacturer of medical device - LIW Care Technology Sp. o.o (ul. Golfowa 7, 94-406 Łódź, Poland) ensures that the company sells an operative
device, free from construction, installation, material defects, et c., and that the device will remain free from such defects during the warranty period. This
warranty does not cover usefulness of the product for the Buyer purposes.
2. LIW Care Technology Sp. z o. o. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial purchase date.
3. The only proof of warranty is this warranty card, issued by the Seller to the Buyer. To t ransfer warranty entitlements, you need to transfer the
possession of this warranty card.
4. In case of finding any faults or defects during the w arranty period - the manufacturer will remedy the defect at his own cost. If parts are replaced, t he
removed part shall become the property of the LIW Care Technology Sp. z o. o. and shall not be returned to the warranty user.
5. Under the war ranty, the user is obliged to report physical product defect during the war ranty period via a form on our website: www.liwcare.pl,
following prior logging to the "customer zone" by post LIW Care Technology Sp. z o. o. or by phone: +48 42 212-35-18
6. Under the warranty, the user is obliged to deliver the equipment with warranty card and along with the original document of purchase (VAT invoice or
receipt) at the expense of the manufacturer to his seat . when there is no receipt, the initial purchase date (the start of the warranty period) shall be the
date of manufacture.
7. This warranty does not cover:
waste elements and destroyed or damaged parts due to improper use (in particular, but not exclusively due to improper instructions issued or
under unfavorable conditions), or improper storage of the product,
damage caused by any alterations or additions to the device made by the user or a third parties,
damage caused by improper cleaning or maintenance of the product made by the user or a third party,
damage caused by normal wear and tear or normal aging of the product,
damage caused by user’s lack of negligence (particularly, but not exclusively, in maintenance and cleaning of the product),
damage caused by force majeure,
damage caused by external events (pollutions, mechanical and water damage).
8. The warranty is valid exclusively in Poland.
9. The warranty does not include does not include regulation and adjustment during the warranty period, because they do not constitute a product
defect.
10. In order to qualify for the above warranty, you need to deliver the product which is securely enclosed in packaging to the manufacturer. To do that,
use the original packaging. If the user do not deliver the product In the original packaging, his replacement packaging must satisfy the following
requirements: solid box with intact walls, separate protection for each component, cushioning material, strong tape used for wrapping, as well as sender
address or receiver (LIW Care Technology Sp. z o. o). address.
LIW Care Technology Sp. z o. o. shall not be held liable for product damage caused by insufficient packaging.
11. Warranty Repair or replacement will be made as far as possible within 30 days from the proper delivery of the product by the warranty user to LIW
Care Technology Sp. z o. o
12. After warranty repair, the product will be delivered at the expense of LIW Care Technology Sp. z o. o., to the supplied address. In the event when
a correctly addressed package is not collected, the warranty user is obliged to shall bear all costs related to the product transport and its storage.
13. Quality warranty granted by LIW Care Technology Sp. z o. o. does not affect any legal rights of the Buyer.
Thank you for choosing our product. We wish you success in therapy with our equipment.
NOTE!
KEEP THE WARRANTY CARD IN A SAFE PLACE
LIW Care Technology Sp. z o. o. will require providing this document before accepting the warranty repair.
Product name/Type ……………………….......................Serial number:…………………………………………………………………..
Sold-by date:………………………………………………………… Stamp and signature of the Seller: …………… …………………………………
No.
Date of repair
request
Procedures
Repair completion
date
Stamp and signature of the
technician
1
2
3
4
Loading...
