FEATURES & SPECIFICATIONS
INTENDED USE SBL LED wraparound provides a digital lighting platform to deliver general ambient
lighting f or surface -mount appl ications. The S BL provides a sim ilar look to that of a n existing flu orescent
wrap with all of the excellent benefits of LED: energy savings, long life, and maintenance savings. Ideal
for closets, storage rooms, and offices.
CONSTRUCTION Linear side prisms control brightness, pyramidal bottom prisms minimize lamp
image. Continuous side flanges on fixture body provide light trap and continuous diffuser support to
prevent accidental opening and simplify maintenance. Full depth, white enamel end plates.
Die-fo rmed from code gau ge cold-rolled st eel. Channel cover snaps i nto place without th e use of tools.
Full end cap f actory inst alled to reduce job s ite labor.
OPTICS The tra nslucent white di ffuser reduce s glare and pixil ation without i mpacting p erformanc e.
ELECTRICAL Long -life LED s, coupled w ith high- efficienc y driver s, provide e xtende d servic e life. 90%
LED lumen mai ntenance at 60,000 ho urs (L90/60,000).
LED drivers deliver dimming from 0-10V control signal.
LISTINGS CSA cert ified to U.S. and Canadia n standards. Damp l isted.
WARRANTY — 5-ye ar limited warrant y. Complete warran ty terms locate d at:
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
Note: Act ual performa nce may differ as a resul t of end-user envir onment and applic ation.
All values ar e design or typic al values, measure d under laborator y conditions at 2 5 °C.
Specifications subject to change without notice.
Type
Contractor Select
SB LED Square-Basket
Wraparound
2' and 4'
LED
A
M
B
L
M
I
E
D
DIMENSIONS
All dimensions are inches (centimeters) unless otherwise noted.
Narrow Body
2' or 4' lengths
Specifications
Length: 24 (61.0)
48 (122.0)
Width: 8-5/8 (21.9)
Depth: 2-5/8 (6.7)
ORDERING INFORMATION
Catalog number UPC Description Lumens Color temperature Voltage Wattage Pallet qty Standard carton qty.
1
SBL2 LP835
SBL2 LP840
SBL4 LP835
SBL4 LP840
SBL4 347 LP835
SBL4 347 LP840
1
1
1
2
2
190887819458 2' LED Wraparound 1,937 3500 K 120-277 17 140 1
190887819489 2' LED Wraparound 1,967 4000 K 120-277 17 140 1
190887819410 4' LED Wraparound 3,933 3500 K 120-277 32 70 1
190887819434 4' LED Wraparound 3,994 4000 K 120-277 32 70 1
190887855692 4' LED Wraparound 3,933 3500 K 347 32 70 1
190887856675 4' LED Wraparound 3,994 4000 K 347 32 70 1
8-5/8
2-5/
(6.7)
MOUNTING DATA
Individual Installation
Two single-stem hangers required.
Row Installation
One hanger per fixture plus one row required.
Please se e SBL Configurable spe cification shee t for additional o ptions and lumen pac kages.
Notes
1 Product in stock.
2 Non-stock standard manufac turing lead times apply.
Step-d own transfo rmer will not fi t in SBL2.
SB LEDWRAPAROUND
CONTRACTOR SELECT / LED: One Lithonia Way Conyers, GA 30012 Phone: 800-858-7763 Fax: 770-929-8789 www.lithonia.com © 2015-2017 Acuity Brands Lighting, Inc. All rights reserved. Rev. 03/13/17
