Page 1

Catalog

Number

Notes

FEATURES & SPECIFICATIONS

INTENDED USE — LBL LED wraparound provides a digital lighting platform to deliver general ambient

lighting f or surface-m ount application s. The LED system del ivers long life and e xcellent color to ensur e a qualit y, low-maint enance lighting ins tallation. Ideal f or closets, s torage rooms, hall ways, and oces.

CONSTRUCTION — Metal p arts are d ie formed f rom code- gauge ste el. Prismati c diuser is 10 0% acryl ic with sonically welded luminous ends. Continuous side anges on x ture body provide light trap and continuous diuser support to prevent accidental opening and simplify maintenance.

Finish: Five-stage iron phosphate pretreatment assures superior paint adhesion and rust resistance.

Painted pa rts nished wi th high-gloss, hi gh-reect ivity baked whi te polyester ename l (low VOC).

OPTICS — Curved prismatic diuser with linear side prisms and highly transmissive overlay minimizes lamp image and provides high-angle brightness control. Luminous end plates soften appearance for improved aesthetics.

ELECTRICAL — Long -life LED s, coupled w ith high- ecienc y driver s, provide e xtende d servic e life. 90% LED lumen mai ntenance at 60,000 ho urs (L90/60,000).

LED driver s deliver dimming f rom 0-10V control signal.

LISTINGS — CSA cert ied to U.S. and Canadi an standards. Dam p listed.

WARRANTY — 5-year limited warranty. Complete warranty terms located at:

www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx

Note: Act ual performa nce may dier as a resul t of end-user envir onment and applic ation.

All values are design or typical values, measured under laboratory conditions at 25 °C.

Specications subject to change without notice.

Type

Contractor Select

LBLED

Low-Prole Curved-Basket

LED Wraparound

2' and 4'

LED

Specications

Len gth: 24 (61.0)

48 (122.0)

Width: 10 (25.4)

Depth : 2-3/4 (7.0)

All dimensions are inches (centimeters) unless otherwise indicated.

ORDERING INFORMATION

Catalog number UPC Description Lumens

LBL2 LP835

LBL2 LP840

LBL4 LP835

LBL4 LP840

LBL4 347 LP835 190887856682 4' LED Wraparound 4,188 3500 K Patterned #12 acrylic 347 32 56 1

LBL4 347 LP840 190887856705 4' LED Wraparound 4,253 4000 K Patterned #12 acrylic 347 32 56 1

190887819380 2' LED Wraparound 2,014 3500 K Patterned #12 acrylic 120-277 17 112 1

190887819397 2' LED Wraparound 2,046 4000 K Patterned #12 acrylic 120-277 17 112 1

190887819199 4' LED Wraparound 4,188 3500 K Patterned #12 acrylic 120-277 32 56 1

190887819359 4' LED Wraparound 4,253 4000 K Patterned #12 acrylic 120-277 32 56 1

(25.4)

2-3/4

(7.0)

MOUNTING DATA Individual Installation —

Two single-stem hangers required. Row Installation — One hanger per xture plus one row required.

See LBL Congurable specication sheet for additional lumen packages and control options.

Color

temperature Lens type Voltage Wattage2Pallet qty

Standard

carton qty.

Notes

1. Product in stock.

2. All values are design or typical values, measured under laboratory conditions at 25°C.

LBL-LED-WRAPAROUND
