Page 1
Catalog
TM
(20.3)
9-1/4
(23.4)
Number
Notes
FEATURES & SPECIFICATIONS
INTENDED USE
Provides years of maintenance-free illumination for outdoor use in residential & commercial applications.
Ideal for applications such as lighting walkways and stairways for safety and security.
CONSTRUCTION
Cast-aluminum housing with corrosion-resistant paint in either dark bronze or white finish.
ADA compliant.
OPTICS
4000K CCT LEDs.
Polycarbonate lens protects the LED from moisture, dirt and other contaminants.
LUMEN MAINTENANCE: The LED will deliver 70% of its initial lumens at 50,000 hour average LED life. See
Lighting Facts label on page 2 for performance details.
ELECTRICAL
MVOLT driver operates on any line voltage from 120-277V
Operating temperature -30ºC to 40ºC.
1KV surge protection standard.
INSTALLATION
Surface mounts to universal junction box (provided by others).
LISTINGS
UL Listed to U.S. and Canadian safety standards for wet locations.
Tested in accordance with IESNA LM-79 and LM-80 standards.
WARRANTY — 5-ye ar limited warrant y. Complete warran ty terms locate d at
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
Actual p erformance may d iffer as a result of end -user environm ent and applicatio n.
All values ar e design or typic al values, measure d under laborator y conditions at 2 5 °C.
Note: Specifications subject to change without notice.
Type
Outdoor General Purpose
OLLWD & OLLWU
LED WALL CYLINDER LIGHT
Specifications
All dimensions are inches (centimeters)
3-11/16
(9.4)
4-5/16
(11.0)
ORDERING INFORMATION
For shortest lead times, configure products using bolded options.
Series Color temperature (CCT) Volta ge Finish
OLLWD LED Downlight
OLLWU LED Up & downligh t
40K 4000K
MVOLT 120V -277V
120 120V
1
DDB Dark bronze
WH White
5-7/8
(15.0)
3-11/16
(9.4)
4-5/16
(11.0)
5-7/8
8
(15.0)
Example: OLLWD LED P1 40K MVOLT DDB
Notes
1 Only available with OLLWU and in DDB.
DECORATIVE INDOOR & OUTDOOR OLLWD-OLLWU
Page 2
OLLWD & OLLWU LED Wall Cylinder Light
PHOTOMETRICS
To see complete photometric reports or download .ies files for this product,visit Lithonia Lighting’s Outdoor LED homepage
Tested in accordance with IESNA LM-79 and LM-80 standards.
OLLWD
OLLWU
OLLWD
OLLWD-OLLWU
DECORATIVE INDOOR & OUTDOOR: One Lithonia Way Conyers, GA 30012 Phone: 1-800-279-8041 www.lithonia.com © 2012-2017 Acuity Brands Lighting, Inc. All rights reserved. Rev. 02/27/17
OLLWU
