Lithonia Lighting LIH1713 Specifications

Page 1

Catalog Number

Notes

FEATURES & SPECIFICATIONS

INTENDED USE

Provide s an LED lighting plat form to delive r general or task li ghting for resi dential and light co mmercial applications. Light engine delivers long life and excellent color to ensure a quality, low-maintenance light inst allation. Ideal f or use in bathroom s, lavatories, hallw ays, corridor s, stairways, u tility areas an d more.

CONSTRUCTION

The Traditional Round Vanity is constructed of an acrylic diﬀuser with housings available in brushed nickel and bronze ﬁnishes. The white acrylic diﬀuser provides even illumination and softens the appearance of the LEDs for improved aesthetics.

OPTICS

2' produce s 1300 lum ens, 3' produces 1900 lum ens, and 4' produces 2 500 lumens at 3000 K with 50,000 hours of li fe.

Extruded acrylic diﬀuser is of highly transmissive material to minimize LED image and provides highangle brig htness control.

ELECTRICAL

Long-li fe LEDs, coupled wit h a multivolt driver, prov ide extended se rvice life. Standa rd input = 9.5 watts, (1'); 18 watts, (2'); 26 watt s, (3'); 34 watts, (4'). Fixtur e is rated to deliver L70 pe rformance at 50,0 00 hours and opera tes at 120-277 volts.

Use with non-dimmable switches only.

LISTINGS

UL Listed to US a nd Canadian safe ty standards. L isted for damp loc ations. ENERGY STAR® certiﬁed.

WARRANTY

5-year limi ted warranty. Comp lete warranty te rms located at

www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx

NOTE: Act ual performan ce may diﬀer as a result o f end-user envir onment and applica tion. All values ar e design or typic al values, measure d under laborator y conditions at 2 5 °C. Speciﬁcations subject to change without notice.

Type

Decorative Indoor

Traditional Round

Vanity

VANITY LED

U.S. PATENT PENDING

SPECIFICATIONS 2FT 3FT 4FT

Length: 23-7/16 (595) 35 -1/4 (8 95) 47-1/16 (1195)

Weigh t: 7 (3.2) 9.7 (4. 4) 12.4 ( 5.6)

3000K Lum ens (LPW) 1363 (75) 2009 (77) 2670 (78)

4000K Lu mens (LPW) 1437 ( 79) 211 8 (81) 2815 (82)

All dimensions are inches (millimeters) unless otherwise indicated. Weights are pounds (kilograms).

ORDERING INFORMATION

Series Length Volta ge Color temperature CRI Finish

FMVTR L Traditional

Round Vanity

Replacement parts: Order as separate catal og number.

DFMVT RL 24IN 2' Traditional Round replacement diﬀuser DFMVTRL 36IN 3' Traditional Round replacement diﬀuser DFMVT RL 48IN 4' Traditional Round replacement diﬀuser

For shortest lead times, conﬁgure product using bolded options.

24IN 2' Nominal 36IN 3' Nominal 48IN 4' Nomina l

MVOLT MVOLT

(120V -277V )

40K 4000 K 35K 35 00 K 30K 3000 K 27K 270 0 K

90CRI >90 BN Brushed Nickel

Notes

1 60-d ay lead time for no n-stock co lor temperat ures; minimum 5 0 order quanti ty. 2 90-d ay lead time for no n-standa rd color temper atures; mini mum 50 order qua ntity. 3 60-d ay lead time for no n-stock ﬁn ishes; minimu m 50 order quanti ty.

Example: FMVTRL 36IN MVOLT 30K 90CRI BN

KR Chrome BZ Bronze

DECORATIVE INDOOR FMVTRL

Page 2

LED Vanity Traditional Round

PHOTOMETRICS

Distribution Curve Distribution Data Output Data Coeﬃcient of Utilization Illuminance Data at 30” Above Floor for a Single Luminaire

FMVTRL 48IN, 3000K LEDs, input watts: 33.3, delivered lumens: 2,551, LM/W=77, test no. LTL29645M, tested in accordance with IESNA LM 79-80.

180°

100 200 300 400 500 600 700 800

900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900

0° 20°

LIGHTING FACTS

90°

80°

60°

40°

°09°0°0°0

CP Summary

0° 90

0°

290

5°

309

288

15°

353

276

25°

395

254

35°

439

225

45°

478

188

55°

513

143

65°

536

75°

546

85°

547

492

Coefficients of Utilization

pf 20% pc 80% 70% 50% pw 70%50%30% 50%30%10% 50%30%10%

107

76 3 4 5

RCR

6 7 8

6 6

Zonal Lumen Summary

Zone Lumens % Lamp % Fixture 0° - 30° 0° - 40° 0° - 60° 0° - 90° 90° - 120° 90° - 130° 90° - 150° 90° - 180° 0° - 180°

231 390 758

1298

538

716 1035 1253 2551

9.1

15.3

29.7

50.9

21.1

28.1

40.6

49.1

100.0

9.1
