Page 1
LITHIUM
POWER INC
,
,
®
Lithium replacement battery
for iRobot® Roomba
500, 600, 700, 800, 900 series
and Scooba® 450
Quick Start Card
®
Page 2
1
Please register product warranty at www.Lithium
PowerInc.com/customer-service.php.
Please refer to iRobot Roomba and iRobot Scooba’s
2
manual for battery installation. Please charge the
battery for 8 hours before the first use.
Our batteries are designed with a sleep-mode that
3
deactivates the battery after a period of inactivity in
order to provide a longer operating time and longer
battery life. It may be necessary to reactivate the
battery before use.
If your Roomba or Scooba 450 fails to operate OR
4
displays a rapid flashing charge light, please refer to
the following steps below to reactivate the battery.
Roomba: Please place the Roomba onto the
charging dock with the power outlet plugged in and
restart the Roomba. For instructions on restarting
your Roomba, please refer to the iRobot Roomba’s
manual. The procedure varies between models.
For example:
500 and 600 series - press and hold down “spot”
and “dock” buttons for 10 seconds.
Page 1 of 3
Page 3
700 and 800 series - press and hold down “clean”
button for 10 seconds until the display reads ”rSt”
for reset.
900 series - press and hold down “clean” button for
10 seconds until all indicators illuminate.
Scooba 450: Install the battery and connect the
power source directly into the Scooba. Please do not
use the charging dock for this procedure. Restart the
Scooba by pressing and holding down the “info ( i )”
and “room size” buttons for 10 seconds.
Scooba 450 requires changing the water tank and
5
recharging after 45 minutes of use. If you wish to
keep the Scooba 450 operating without recharging,
please refer to the following steps:
a) Press and hold down “info ( i )”, “Clean” and
“room size” buttons for 10 seconds until the battery
indicator flashes.
b) Press “room size” button for 5 times.
c) Press “room size” button once again to select the
size you want.
d) Press “Clean” button to begin cleaning.
Page 2 of 3
Page 4
LITHIUM
POWER INC
,
®
6
Due to Lithium Power’s long lasting lithium
technology, battery light signal values have changed.
For a reference on operating time remaining, please
refer to the table below.
Light Color Time Remaining
Solid Green (fully charged) 3 - 4 Hours
Orange 1.5 - 2 Hours
Red 1 - 1.5 Hours
Please note, iRobot Roomba will stop operating after
7
cleaning cycle is completed regardless of power
remaining. If you wish to keep your iRobot Roomba
operating until no power remains, turn off the dock.
8
If the dock is left on, iRobot Roomba will automatical-
ly return to charge after battery light signal turns red.
Thank you very much for choosing our product and
services. If you need any further assistance, please contact
the Lithium Power Customer Service department by E mail
Last longer, clean better.
iRobot®, Roomba®, Scooba® are trademarks of iRobot Corporation.
© 2016 Lithium Power Inc. All rights reserved.
,
Page 3 of 3
