LITHE PRO SERIES
TM
WIFI CEILING SPEAKER
ULTIMATE CONNECTIVITY.
Designed explicitly to be top of the Lithe Audio integrated speaker range. This award winning in-ceiling active
offering delivers leading features such as WiSA integration for Dolby Atmos systems, PoE power delivery for the
convenience of easy installation and the most comprehensive set of wireless & wired connectivity options.
PoE Ethernet Optical
TM
EXPANDABLE
HARDWARE
The Pro series features an interchangable chipset.
which means the hardware can be upgraded as
new technologies emerge and keep your Pro at the
forefront of technology.
ALL-IN-ONE
SYSTEM
PoE
WIRELESS ATMOS.
2X AUDIO QUALITY
WiSA transmits 24bits at 48kHz/96kHz, that’s
twice the quality of CD audio.
NEARLY ZERO LATENCY
Less than 1/10th the latency of a Bluetooth
audio device means no visible lip sync.
PERFECT SYNC
All speakers in the system are certified
to be synchronized within 1/1,000,000 of a
second even when using all eight channels.
SCALEABLE & SEAMLESS
Automatically recognizes audio
configurations from 2.0 to 7.1 and even 5.1.2
Optical
Ethernet
Fast Fix
SOUND SEND
Turn Your Smart TV into the Centre of Your
Home Cinema. Wirelessly Connect to Any WiSA
Certified Speakers. Connects to TV via
HDMI ARC and eARC.
TM
Woven Fiber
Glass Cone
Titanium
Tweeter
“We work forward from what our customer’s
needs are, not backwards from what technology
allows. The result is the exciting PRO Series
with unparalleled connectivity and
upgradeable hardware”
Chief Design Engineer
Po E
++
“PoE POWERED WITH WISA CONNECTIVITY,
THE FUTURE OF CEILING SPEAKERS IS HERE”
Power directly from the network cabling infrastructure the all-in-one Pro Series uses the latest
standard: IEEE 802.3bt to deliver up to 70W of power to each speaker.
PATENTED PENDING.
SPECIFICATIONS / FEATURES
AR
PoE
70W
POWER VIA:
LIGHTING
CIRCUIT
OR OR
OPTICAL
OPEN YOUR PHONE
CAMERA & SCAN
PLUG
CONNECT SECOND SPEAKER
VIA SPEAKER CABLE
ETHERNET
THE QR CODE FOR
AUGMENTED REALITY
Dimensions
CONNECT UP TO
230mm
30
WI-FI SPEAKERS FOR
(9’)
g
grille
diameter
MULTI ROOM
OR PARTY MODE
110mm
(4.3’)
ceiling
depth
WORKS WITH IOS, ANDROID
& WINDOWS
TM
WORKS WITH
VOICE CONTROL
210mm (8’) hole cut out
(template supplied)
Speaker Grille: 230mm
Depth with PoE addon: 140mm
required
Features Connectivity
Wireless & Wired Connection
Works in both the 5GHz and 2.4GHz Wi-Fi
spectrum or can be hardwired via ethernet
cable for a hardwired data connection
All-In-One System
Amplifier & comprehensive connectivity
options all built-in, just add power from your
lighting circuit or simply plug in to socket or PoE.
High Res Audio
192kHz / 24 bits delivers superb sound quality
with pin-sharp clarity
Built-In AirPlay 2 & Google Chromecast
Fully certified, wirelessly stream from any mobile
or tablet directly to the speaker
Expandable Hardware
Designed to grow as new technologies emerge
and evolve the interchangeable hardware is
upgradeable to ensure your system is at the
forefront of audio connectivity
WiSA certified
the dolby atmos in ceiling solution for any Wisa
home cinema setup.
Speaker Spec
RMS Power: 60W RMS (2x 30W)
Impedance: 8 Ohms nominal
Sound Quality THD+N<0.009%, 55Hz-20kHz (+/- 3dB)
Sensitivity (1W/1m): 90dB
Line In (Optical), auto-detecting
Type: Class D (Digital)
Audio Compression: 192Khz/24bits
Woofer: 6.5” Woven Glass Fiber cone /
Polypropylene Cone (IP44)
Tweeter: 0.75” Titanium Cone
Power Input Supply : 100 - 240V, 50/60Hz / 2A
Transformer Output Supply : DC24V / 2.5A
IP rating: IP44 (Bathroom models only)
Operating Temperature 0º to 40º C (32º to 104º F)
Storage Temperature -20º to 70º C (4º to 158º F)
Standby power: 1.3W / 0.02A
Connected power: 1.5W / 0.03A
Playing Music: 2.8W - 10.5W / 0.03A - 0.09A
Wi-Fi certified 2.4Ghz / 5Ghz (802.11a/b/g/n/ac)
Apple AirPlay 2 certified
Google ChromeCast certified
Works with Alexa
Spotify connect certified
Bluetooth
Optical
Ethernet Connection In / Out
DLNA/uPnP connections
Access digital music storage using NAS drive
Control4 - SDDP
What’s in the box
Pro Series Bluetooth & Wi-Fi Ceiling Speaker
Power cord
Instruction manual
SKU Codes
06500 Pro Wi-Fi Ceiling Speaker (Single)
06510 Pro Wi-Fi Ceiling Speaker (Pair)
06501 Pro IP44 Bathroom Wi-Fi (Single)
06511 Pro IP44 Bathroom Wi-Fi (Pair)
06514 Pro Wi-Fi Ceiling Speaker With PoE (Single)
06515 Pro Wi-Fi Ceiling Speaker With PoE (Pair)
06520 PoE Adaptor Module
06521 WiSA Module Bolt on
06530 WiSA Sound Send Transmitter
06512 Pro Ceiling Speaker (1 Pair) & 1 WiSA Module
(Atmos .2 kit)
06513 Pro Ceiling Speaker (2 Pairs) & 2 WiSA
Modules (Atmos .4 kit)
litheaudio.com/pro-series
Visit our website or open your phone camera and scan the QR code to visit our product page
