O-90 AirTight Access Point / Sensor

Quick Start Guide

Package Contents

You should have received the following components in your O-90 package.

x 2

O-90

x 1

Mounting Accessories

x 4 x 4

x 4

x 1

Mounting the O-90

Wall Mount: AirTight logo facing away from the wall

Pole Mount: AirTight logo facing away from the wall

Getting the O-90 Online

Step 1: Power up

Plug one end of the Ethernet cable into the PoE switch or injector and plug the other
end into the LAN1 (PoE) on the O-90. Make sure the PoE source you are using is
turned ON.

Step 2: Connect to the network

As you are using PoE, the O-90 should already be connected to your network.

Step 3: Check the LED status

Wait for a few minutes till the
Power (PWR) LED and LAN1 (PoE) LED
turn solid GREEN, which indicates that
the O-90 is online and operational.
