LITE ON TECHNOLOGY KB24RF002 User Manual

LiteON Technology

Operation Manual

Model : SK-7235-K
Customer : LITEON
Version : 0.3
Issue Date : 07.27.2009

SK-7235 2.4GHZ Keyboard Ver:0.3 <Confidential> 第 1 頁 共 16 頁

LiteON Technology

Table of Contents

1.General...........................................................................................................................................3

2. Mechanical Specifications............................................................................................................3

2.1 Dimensions and Weight..............................................................................................................3

3. Electrical Specification.................................................................................................................4

3.1 Power Consumption.............................................................................................................5

4. Radio Feature................................................................................................................................5

4.1 Operation procedure.............................................................................................................5

4.2 Radio feature........................................................................................................................6

SK-7235 2.4GHZ Keyboard Ver:0.3 <Confidential> 第 2 頁 共 16 頁

LiteON Technology

1.General

This is operation manual of SK-7235 series RF keyboard. It is a high quality
wireless 2.4GHz radio product with multi-channels, minimum 10m of operation range
for keyboard.

It offers a power saving design and with very low power consumption for
operation .

Product function includes standard keyboard function and WIN2000 hot key
function. .For normal operation, a USB RF dongle would be used as a RF receiver on
PC end.

2. Mechanical Specifications

Product Outline

Sk-7235 keyboard enclosure

2.1 Dimensions and Weight

1.Unpacked Dimensions and Weight

length(±3mm) width(±3mm) height(±3mm) weight(±0.1kg)

438 173 29 0.59

SK-7235 2.4GHZ Keyboard Ver:0.3 <Confidential> 第 3 頁 共 16 頁
