LITE ON TECHNOLOGY CX8703LB User Manual
JukeBlox Networked Media Module
CX Series
Datasheet
Complete audio networking system on a small module
•
• Integrated Ethernet + USB 2.0
• WiFi-certified 802.11b/g
• Built-in strip antenna
Optional 2X Diversity Antenna
•
• Glueless audio, video and control ports
• FCC certified
• Ideal for enabling network and USB audio playback for iPod docks, audio
systems, AV Receivers, active speaker systems, internet radios, network
playback adaptors
SMSC CX Module Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
Copyright © 2012 SMSC or its subsidiaries. All rights reserved.
Circuit diagrams and other information relating to SMSC products are included as a means of illustrating typical applications. Consequently, complete information sufficient for
construction purposes is not necessarily given. Although the information has been checked and is believed to be accurate, no responsibility is assumed for inaccuracies. SMSC
reserves the right to make changes to specifications and product descriptions at any time without notice. Contact your local SMSC sales office to obtain the latest specifications
before placing your product order. The provision of this information does not convey to the purchaser of the described semiconductor devices any licenses under any patent
rights or other intellectual property rights of SMSC or others. All sales are expressly conditional on your agreement to the terms and conditions of the most recently dated
version of SMSC's standard Terms of Sale Agreement dated before the date of your order (the "Terms of Sale Agreement"). The pro duct may contain design defects or errors
known as anomalies which may cause the product's functions to deviate from published specifications. Anomaly sheets are available upon request. SMSC products are not
designed, intended, authorized or warranted for use in any life support or other application where product failure could cause or contribute to pe rsonal injury or severe property
damage. Any and all such uses without prior written approval of an Officer of SMSC and furthe r te sting and/or modificati on will b e f ully at the risk of the customer. Copi es of this
document or other SMSC literature, as well as the Terms of Sale Agreement, may be obtained by visiting SMSC’s website at http://www.smsc.com. SMSC is a registered
trademark of Standard Microsystems Corporation (“SMSC”). Product names and company names are the trademarks of their respective holders.
The Microchip name and logo, and the Microchip logo are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.
SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARRANTIES, INCLUDING WITHOUT LIMITATION ANY AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND AGAINST INFRINGEMENT AND THE LIKE, AND ANY AND ALL WARRANTIES ARISING FROM ANY COURSE
OF DEALING OR USAGE OF TRADE. IN NO EVENT SHALL SMSC BE LIABLE FOR ANY DIRECT, INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR
CONSEQUENTIAL DAMAGES; OR FOR LOST DATA, PROFITS, SAVINGS OR REVENUES OF ANY KIND; REGARDLESS OF THE FORM OF ACTION, WHETHER
BASED ON CONTRACT; TORT; NEGLIGENCE OF SMSC OR OTHERS; STRICT LIABILITY; BREACH OF WARRANTY; OR OTHERWISE ; WHETHER OR NOT ANY
REMEDY OF BUYER IS HELD TO HAVE FAILED OF ITS ESSENTIAL PURPOSE, AND WHETHER OR NOT SMSC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
SMSC CX Module 2 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
Table of Contents
INTRODUCTION...............................................................................................................4
1
2 BLOCK DIAGRAM.............................................................................................................4
3 BOARD PICTURES............................................................................................................5
3.1 TOP VIEW OF CX MODULE................................. .................................................................. 5
3.2 BOTTOM VIEW OF CX MODULE........................................... ................................................... 6
3.2.1 CX Module Bottom View w/64-pin Low Density Connector ...........................................6
3.2.2 CX Module Bottom View w/120-pin Media Connector .................................. ................ 6
3.3 PRODUCTION MODULE WITH TOP AND RF SHIELDS IN PLACE – T OP VIEW.............................................7
3.4 PRODUCTION MODULE WITH 64-PIN CONNECTOR OPTION – SIDE VIEW ..............................................7
3.5E
3.6 PRODUCTION MODULE WITH BOTTOM SHIELD (PART NUMBERS WITH A “B” AFTER THE CONFIGURATION LETTER)9
4 ORDERING GUIDE .........................................................................................................10
4.1 PART NUMBER SYNTAX ............................................................................................... ...... 10
5 ELECTRICAL SPECIFICATIONS....................................................................................... 11
5.1 ABSOLUTE MAXIMUM RATINGS ............................................................................................ 12
5.2 OPERATING CONDITIONS................................................................................................... 12
5.3 WIFI SPECIFICATION (CX870 ONLY).................................................................................... 13
6 REGULATORY COMPLIANCE AND QUALITY ....................................................................14
6.1 ROHS........................................................................................................................ 16
6.2 ENVIRONMENTAL TEST.................................................................................................. .... 16
6.3 ESD AND TRANSIENT TEST (APPLIES TO LAN AND USB EXTERNAL CONNECTIONS ONLY)......................... 16
6.4 MAGNETIC FIELD TEST ..................................................................................................... 16
6.5MTBF ........................................................................................................................ 16
6.6 MECHANICAL SPECIFICATIONS.......................................... ................................................... 16
6.7 MODULE QUALITY........................................................................................................... 16
7 BOARD DIMENSIONS AND WEIGHT............................................................................... 17
7.1 TOP & BOTTOM VIEW OF CX870 MODULE WITHOUT BOTTOM SHIELD............................................... 17
7.2 SIDE VIEW OF CX870 MODULE WITHOUT BOTTOM SHIELD ........................................................... 18
7.3 3D VIEW OF CX870 MODULE WITHOUT BOTTOM SHIELD............................................................. 19
7.4 MODULE WEIGHT ........................................................................................................... 20
8 CONNECTORS AND CONNECTIONS ............................... .. .. .. .. ......................... .. .. .. .. .. ......20
8.1 WLAN UFL ANTENNA CONNECTOR (OPTIONAL)........................................................................ 20
8.2 MODULE CONNECTORS ............................................................................................... ...... 20
9 APPLICATION GUIDELINES...........................................................................................28
9.1 POWER SUPPLY SEQUENCI NG AND RESET TIMING ....................................................................... 28
9.2 RF CONSIDERATIONS ........................................................................................ .............. 29
10 REVISION CONTROL.................................................................................................... 30
11 APPENDIX 1: CERTIFICATION NOTICES......................................................................39
XAMPLE PRODUCTION MODULE SHOWING SOLDERED
3.6.1 Including J3 Low Density 64-pin connector – Bottom View........................................... 9
3.6.2 Including J2 High Density 120-pin connector – Bottom View........................................9
6.0.1 Antenna Considerations.............................. ........................ ......................... ............ 15
6.0.2 CX Power Settings Used For Modular Approval............................................................ 16
7.1.1 Top & Bottom View of CX Module with Bottom Shield........................................ ........ 17
7.2.1 Side View of CX Module with Bottom Shield except CX870-3JB ........................ .. .. .. .... 18
7.2.2 Side View of CX870 Module with Bottom Shield part number CX870-3JB only .............. 19
8.2.1 Pin Descriptions ................................................................................................... 21
8.2.2 Connector PIN Assignments................................................................................... 26
8.2.3 GPIO Assignments................................... .. .. .... .. .. .... .. .. .. .... .. .. ... .... .. .. .. .... .. .. .. .... .. .. 28
9.1.1Power up, Reset and Power Down Timing................................................................ 29
RF S
..................................................... 8
HIELD
SMSC CX Module 3 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
1 Introduction
The CX-series module is a single-board networked media player module, based on SMSC’s DM870A and DM875
media processors, and enables fast product developments with Ethernet, USB and optional WiFi connectivity. The
module connects to standard legacy components in various audio, video/LCD and control formats.
2 Block Diagram
JukeBlox Networked Media Module – CX Series
RJ-45
Transformer
Type-A
Display
SD-Card
CCIR-656
A/D, D/A
S/PDIF
Host
Controller/
LCD setup
+
USB
Apple Coprocessor
3.3V
1.2V
1.9V
Reset In
3x6bit RGB
4/8bit MMC
Video Out
Audio I/O
SPI Ctrl.
GPIO
Ethernet
Transceiver
I2C
PWM DAC
UART
JTAG
DM870A
RST
RMII
USB
LCD
SSM
I2C
DAC
AV
Ports
UART
JTAG
SPI
GPIO
or
DM875
Flash
Mem.
Bus
802.11
RF Amp. ANT
Ext.
Antenna
Antenna
NAND-Flash
256 Mbit
SDRAM
NOR-Flash
2.4 GHz RF
transceiver
switch
PCB
Ext.
Antenna
24.000 MHz
PCB
Antenna
Note: Choice of antenna is a build option, see Ordering Guide.
SMSC CX Module 4 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
3 Board Pictures
Please note that all production modules include the RF and top shield. The below top view has the shields
temporarily removed to show the components. Also, please note that the 64-pin connector mounted on the module is
the male gender.
3.1 Top View of CX Module
802.11b/g
front-end
PCB antenna
PCB antenna
External Antenna
Connectors
SMSC processor
Ethernet PHY
SDRAM
SMSC CX Module 5 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
3.2 Bottom View of CX Module
3.2.1 CX Module Bottom View w/64-pin Low Density Connector
LCD connector
Low density
connector
LCD
connector
3.2.2 CX Module Bottom View w/120-pin Media Connector
FLASH
FLASH
Media
connector
SMSC CX Module 6 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
3.3 Production Module with Top and RF shields in
place – Top View
3.4 Production Module with 64-pin Connector Option –
Side View
SMSC CX Module 7 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
3.5 Example Production Module Showing Soldered RF
Shield
SMSC CX Module 8 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
3.6 Production Module with Bottom Shield (Part
Numbers with a “B” after the configuration letter)
3.6.1 Including J3 Low Density 64-pin connector – Bottom View
3.6.2 Including J2 High Density 120-pin connector – Bottom
View
SMSC CX Module 9 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
4 Ordering Guide
Internal
PCB
Diversity
Part Number Status SMSC ICs
CX870-3A
CX870-3B
CX870-3D
CX870-3DS CO % DM870A+T6201 X X X X X X X
CX870-3F
CX870-3G
CX870-3H
CX870-3I
CX870-3J O DM870A+T6201 X X X X X X
CX870-3K
CX870-3BB
CX870-3HB
CX870-3IB
CX870-3JB
CX870-3KB
CX780-3LB
CX870-3MB
CX875-3PB
CO DM870A+T6201 X (X)* X X X X X X X
O DM870A+T6201 X X X X X X X
CO DM870A+T6201 X X X X X X X
O DM870A+T6201 X X X X X X X
O
O DM870A+T6201 X X X X X X X
O DM870A+T6201 X X X X X X
CO
SA DM870A+T6201 X X X X X X X X
SA
SA DM870A+T6201 X X X X X X X
SA
CA
CA
CA
SA
DM870A+T6201 X
DM870A+T6201 X
DM870A+T6201
DM870A+T6201
DM870A+T6201 X
DM870A+T6201 X
DM870A+T6201 X
DM875+T6201
Antennas
Ext. Diversity
Antennas (UFL
One
Ant.
X
X
X
X
X
X
X
Conn.)+
Two
Ant.
Ethernet
X X
X X
X X X
X X
X X
X X X
X X X
X X
USB
Host
Low
density
64-pin
Conn.
Hi
density
120-pin
Conn.
Hi
density
32MB
LCD
SDRAM
Conn.
X X X
X X X
X X X X
X X X X
X X X X
X X X X
X X X X
X X X X
16MB
SDRAM
8MB
SDRAM
1Gb
NAND
8MB
NOR
Top
Module
Shield
Note: Please note that the Apple Authentication Coprocessor will not be provided on the CX module. The Apple Authentication
Coprocessor should be provided on the product motherboard, connected to the SDA, SCL signals from the CX module.
Shaded rows indicate Custom or Obsolete configuration - NOT TO BE USED FOR NEW/STANDARD MP DESIGNS.
Note:
Status code:
C - Custom | S - Standard | O - Obsolete | A - Available
* Connector on board, but requires board modification to enable the connector.
+ The position of the X in the One Ant. column indicates that there is one external antenna connector provided. The position of the X
in the Two Ant. column indicates that there are two external antenna connectors provided. Do not use a module which has two
external antenna connectors with only one external antenna connected. Leaving one antenna socket open will degrade WiFi
performance. SMSC recommends always using modules with two external antennas for best performance.
% The CX870-3DS is the same as CX870-3D, except that the RF shield is soldered in place.
Bottom
Module
Shield
4.1 Part Number Syntax
SMSC CX Module 10 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
5 Electrical Specifications
Parameter State Model Voltage Symbol min. typ. max. Units
Power Supply Input Voltage
VIN
Logic Input high voltage VIH 1.7 5.5 V
Logic Input low voltage VIL -0.3 0.7 V
Logic Input threshold voltage VIT 1.29 1.39 1.5 V
Schmitt-trigger input low to
high threshold voltage
Schmitt-trigger input high to
low threshold voltage
V
1.58 1.65 1.71 V
IT+
0.95 1.01 1.06 V
V
IT-
Logic Output high voltage VOH 2.4 V
Logic Output low voltage VOL 0.4 V
Logic Low-level output
current
(V
=0.4V)
OL
Logic High-level output
current
(V
=2.4V)
OH
Reset State
I
-9.6 -15.6 -19.3 mA
OL
I
11.1 22.5 35.3 mA
OH
3.3 I3.3 60 78 mA
1.2 I1.2 32 42 mA
1.9 I1.9 18 23 mA
3.3 I3.3 185 241 mA
1.2 I1.2 337 438 mA
Current Consumption
Operating in
idle state
CX870
1.9 I1.9 257 334 mA
Playback over
WiFi high mips
& rate
condition
3.3 I3.3 240 312 mA
1.2 I1.2 347 451 mA
1.9 I1.9 258 335 mA
Note: The maximum current values are 30% larger than the typical values. The maximum
values are intended to be used for power supply sizing calculations.
3.0
1.08
1.8
3.3
1.2
1.9
3.6
1.32
2.0
V
V
V
SMSC CX Module 11 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
JukeBlox Networked Media Modules – CX Series
Datasheet
5.1 Absolute Maximum Ratings
Parameter Component Min Max Units
3.3V Supply Voltage -0.5 4.6 V
1.2V Supply Voltage -0.5 1.8 V
1.9V Supply Voltage -0.5 2.2 V
Logic Input Voltage -0.5 6 V
Logic Output Voltage
Main
5.2 Operating Conditions
Parameter Min Max Units
Operating Temperature 0 +70 °C
Operating Humidity 10 90 (non condensing) %RH
Storage Temperature -10 +75 °C
Storage Humidity 10 95 (non condensing) %RH
Storage Temperature Cycle Test 24 hrs -10 +75 °C
-0.5 4.6 V
SMSC CX Module 12 Revision 2.8 (09-30-12)
SMSC CONFIDENTIAL
Loading...
