MX3-4
Audio Everywhere 4 Channel Wi-Fi Server
Product Overview:
The MX3-4, our four-input wireless assistive listening system, is an excellent option for restaurants, sports bars, and
additional spaces where multiple audio sources are needed. Thanks to seamless integration with each user’s smartphone or
mobile device, the costs associated with installing and operating a streaming audio system are much lower, and the listening
experience is ideal for everyone. Additionally, the MX3-4 uses a minimal amount of bandwidth from your existing wireless
internet service, meaning there is virtually no effect on speed or signal strength. The Audio Everywhere from Listen
Technologies cloud server interface makes updates and other service options simple and fast.
*Custom solutions available upon request to accommodate more channels/users, email [email protected] for
information.
Highlights:
•Plug & Play Installation
•Ultra-Low Latency
•Uses Existing Wireless Network
Includes: One (1) Audio Everywhere 4 Channel Wi-Fi Server
Product Specification: Audio Everywhere 4 Channel Wi-Fi Server
Interconnections
Ethernet RJ45: 100 BaseT or 1000 BaseT (gigabit)
Analog 35mm
Power Supply
Connector DC Barrel Connector
Input Voltage 100-240 VAC, 50-60Hz
Output Voltage 5 VDC
Current 1.2 A
Power 6W
Countries North American, UK, EU, AUS
Servers
IP Address DHCP, Static, Reserved
Prioritization QoS/ToS
C Users 150 (per server)
Max Channels 4 mono
WAP Support 802.11n or better w/WMM enabled
Frequency 2.4 GHz & 5 GHz
Bandwidth Use >175 kbps
App Support iOS/Android
Cloud Service Yes
Listen Technologies Corporation * 14912 Heritage Crest Way * Bluffdale * Utah 84065-4818 U.S.A.
Audio Everywhere 4 Channel Wi-Fi Server Page 1 of 2
+1.801.233.8992 * +1.800.330.0891 North America * +1.801.233.8995 Fax
Listen Technologies Corporation All rights reserved 91407 - Created December 21, 2017
Page 2
MX3-4
Audio Everywhere 4 Channel Wi-Fi Server
Product Specification: Audio Everywhere 4 Channel Wi-Fi Server
Regulatory FCC, CE, RoHS
Warranty 3 years
Multiple servers may be used to increase
the number of channels.
Physical
Dimensions (H x W x D) 45mm x 483mm x 155mm (1.77in x 19.02in x 6.1in)
Weight 2.2 kg (4.85 lbs)
Rack Space 1RU
Audio Everywhere from Listen servers are
cloud managed with customizable in-app
functions which support welcome
messages, videos, sliding banners, pdf
documents, offers and supports portable
smart iOS and Android devices.
