LA-317
4-Unit Portable RF Product Charging/Carrying Case
Configuration:
LA-317-01 4-Unit Portable RF Product
Charging/Carrying Case (North America)*
LA-317-02 4-Unit Portable RF Product
Charging/Carrying Case (Asia, UK)*
LA-317-03 4-Unit Portable RF Product
Charging/Carrying Case (Euro)*
LA-317-04 4-Unit Portable RF Product
Charging/Carrying Case (Australia)*
*01, 02, 03, and 04 designation refers to
international plug type (type B, G, C, and I) for
the power supply.
Product Overview:
Designed and built to conveniently store and charge up to four (4) Listen RF portable devices (LT-700, LR-200, LR-300,
LR-400, or LR-500), the LA-317 is perfect for temporary or mobile systems. The case features individual earphone storage
slots for easy cord management, a large pocket for storing the power supply and accessories, and a rugged, durable design.
Highlights:
Secure storage slots for up to four (4) Listen RF devices
Automatically turns off power to each unit once it is fully charged
Individual earphone storage slots and a large accessory pocket for carrying and stowing the power supply, headsets,
and more
Sturdy, durable construction that can stand up to frequent use
Includes a shoulder strap for easy carrying
Includes:
One (1) LA-317 4-Unit Portable RF Product Charging/Carrying Case
One (1) Shoulder Strap
One (1) Power Supply
Product Specification: 4-Unit Portable RF Product Charging/Carrying Case
Listen Technologies Corporation * 14912 Heritage Crest Way * Bluffdale * Utah 84065-4818 U.S.A.
4-Unit Portable RF Product Charging/Carrying Case Page 1 of 2
+1.801.233.8992 * +1.800.330.0891 North America * +1.801.233.8995 Fax
Listen Technologies Corporation All rights reserved 91407 - Created March 9, 2018
LA-317
4-Unit Portable RF Product Charging/Carrying Case
Product Specification: 4-Unit Portable RF Product Charging/Carrying Case
Power
Power Supply Input 100-240 VAC 50-60 Hz, 1200 mA
Power Supply Output 7.5 VDC, 4 A, 30 W
Power Cord Length 12 ft. (3.7 m) with line cord
Physical
Color Grey
Material Lockable hard case, interior foam
Shipping Weight 5.0 lbs. (2.3 kg)
Dimensions (H x W x D) 7.5 x 11.8 x 3.75 in. (19 x 30 x 9.5 cm)
Weight 2.6 lbs. (1.2 kg)
Shoulder Strap Length Adjustable 33 to 53 in. (83 to 135 cm)
Compliance
Power Supply Compliance UL, CE, GS, TÜV, RoHS
Safety RoHS
