LS-45-072
Listen Classic Level II Stationary RF System (72 MHz)
Configuration:
LS-45-072 Listen Classic Level II Stationary RF
System (72 MHz)
Product Overview:
For larger venues, the LS-45 Classic Level II Stationary RF System makes it easy to install and operate a compliant assistive
listening setup in no time. Designed for use in larger venues, the LS-45 provides a coverage range of up to 1,500 ft (457.2
m) with 17 wide-band digital channels. The included LR-300 receivers are digitally tuned to ensure a strong, reliable signal at
all times, and each receiver benefits from our Super Quiet Companding Technology that offers 20 dB less noise than
competitors’ receivers. The transmitter is compatible with nearly any audio source thanks to universal inputs, and the
package includes everything needed to meet compliance requirements right away.
The LS-45 is available for the 72 MHz band only.
Highlights:
Ensures public venues deliver an enriched listening experience while meeting new legislative requirements for
assistive listening
Superior audio quality – 80 dB signal-to-noise ratio (SNR), setting the industry’s sound quality standard
Offers 17 wide band 100% digital channels – Listen receivers are digitally-tuned so the transmission won’t drift
Long transmission range ensures coverage for the entire venue
Includes:
One (1) LT-800-072-01 RF Transmitter (72 MHz)
One (1) LA-122 Universal Antenna Kit (72 MHz and 216 MHz)
One (1) LA-326 Universal Rack Mounting Kit
Four (4) LR-300-072 Portable Digital RF Receiver (72 MHz)
Four (4) LA-164 Ear Speaker
Two (2) Neck Loop
One (1) LPT-A107A-B Dual RCA to Dual RCA Cable 6.t ft. (2 m)
Four (4) LA-361 High Capacity AA Alkaline Batteries (2)
One (1) LA-304 Assistive Listening Notification Signage Kit
Product Specification: Listen Classic Level II Stationary RF System (72 MHz)
Physical
Shipping Weight 24.0 (10.3)
