Listen Technologies LS-40-072 Data Sheet

LS-40-072
Listen Essentials Starter Stationary RF System (72 MHz)

Configuration:

LS-40-072 Listen Essentials Starter Stationary
RF System (72 MHz)

Product Overview:

Entry level system ideal for budget conscious venues. Solves frustrating but common sound problems caused by distance,
background noise, or poor room acoustics. The system meets the minimum requirements of the 2010 Americans with Disabilities
Act (ADA) standards for accessible design for venues with a seating capacity of less than 50. The system can be ordered only on
the 72 MHz frequency band, and can be customized if you need additional parts. Backed by Listen, this cost-effective solution
will enrich your customers' listening experience in lecture halls, public meeting rooms, playhouses, classrooms, centers for the
performing arts, and more.

Highlights:

• Ensures public venues meet new 2010 ADA requirements and deliver an enriched listening experience

• Easily switches between three different channels

• Economical price - backed by Listen's exceptional service and support

• Reliable clear sound quality - 62 dB SNR

• 30-day no obligation demonstrations available

• Limited Lifetime Warranty - buy with confidence

Includes:

One (1) LT-803-072-01 3-Channel RF Transmitter (72 MHz)
One (1) LA-106 Telescoping Top Mounted Antenna (72 MHz)
Two (2) LR-200-072 Standard 3-Channel RF Receiver (72 MHz)
Two (2) LA-164 Ear Speaker
Two (2) LA-166 Neck Loop
One (1) LPT-A107A-B Dual RCA to Dual RCA Cable 6.6 ft. (2 m)
Two (2) LA-361 High Capacity AA Alkaline Batteries (2)
One (1) LA-304 Assistive Listening Notification Signage Kit

Architectural Specification:

Furnish and install an RF wireless assistive listening system for use by the hearing-impaired. The assistive listening system (ALS)
shall be capable of broadcasting on 3 wide band channels and be frequency agile. The ALS system shall have 62 dB SNR or
greater, end-to-end. Receivers shall be frequency agile to 3 wide band frequencies set with a "channel select" switch. The receivers
will incorporate a stereo headset jack that allows the user to plug in either a mono or stereo headset and listen to audio normally.
The receivers shall incorporate automatic battery charging circuitry for recharging of Ni-MH batteries. The receivers and
transmitters shall offer a limited lifetime warranty. Listen Technologies Corporation LS-40-072 products are specified.

Listen Technologies Corporation * 14912 Heritage Crest Way * Bluffdale * Utah 84065-4818 U.S.A.

+1.801.233.8992 * +1.800.330.0891 North America * +1.801.233.8995 Fax

Listen Technologies Corporation All rights reserved 91407 - Created Feb. 20, 2015

Listen Essentials Starter Stationary RF System (72 MHz) Page 1

LS-40-072
Listen Essentials Starter Stationary RF System (72 MHz)

Product Specification:Listen Essentials Starter Stationary RF System (72 MHz)

Physical

Shipping Weight 7.0 (3.2)
