Page 1
LR-IL-1
Hearing Loop Receiver with Lanyard
Configuration:
LR-IL-1 Hearing Loop Receiver with Lanyard
Product Overview:
The LR-IL-1 is a high quality audio hearing loop receiver which allows a non-hearing aid user to listen to the audio that is
being produced by the Hearing Loop system. The receiver also provides a visual as well as auditory confirmation allowing for
facility managers and system installers to check system performance.
Highlights:
Allows the user without a hearing aid to listen to hearing loop system using a pair of headphones
Essential for installers, venue managers and even organizers to check the induction loop system is working
Includes:
One (1) Hearing Loop Receiver with Lanyard
One (1) LA-366 High Capacity 9V Alkaline Battery for LR-IL-1
One (1) LA-164 Ear Speaker
One (1) User’s Guide
Product Specification: Hearing Loop Receiver with Lanyard
Audio
Frequency Response 85 Hz - 6 kHz ± 0.5 dB
Audio Output Power 110 dBA SPL at 16 Ohm Load
Distortion < 0.5% THD @ 1 kHz
Indicators
Battery Status Battery Condition OK when LED Illuminated
Power
Battery Type Alkaline
Battery Life Approximately 100 hrs.
Powered by TCPDF (www.tcpdf.org)
Nominal Voltage 9 VDC
Physical
Width 2.5 in. (63 mm)
Height 4 in. (102 mm)
Depth .87 in. (22 mm)
Shipping Weight 0.8 lbs. (0.4 kg)
Weight .31 lbs. (.14 kg)
Battery Size 9V
Listen Technologies Corporation * 14912 Heritage Crest Way * Bluffdale * Utah 84065-4818 U.S.A.
Hearing Loop Receiver with Lanyard Page 1 of 1
+1.801.233.8992 * +1.800.330.0891 North America * +1.801.233.8995 Fax
Listen Technologies Corporation All rights reserved 91407 - Created December 13, 2019
