LA-390
RG-8 50 Ohm Preassembled Coaxial Cable (Per ft./.3 m)
Product Overview:
Order the exact amount of cable needed for your pre-designed RF or IR assistive listening system with the LA-390
preassembled cable. Each order comes with both BNC connectors attached to our RG-8 cable cut to the desired length. A
minimum order requirement of 15.2 m (50 ft.) applies.
Highlights:
Ordered in custom lengths (minimum of 50 ft.)
Pre-cut and assembled to your desired specifications
RG-8 cable and BNC connectors made for use with RF and IR system installations
Includes:
One (1) RG-8 50 Ohm Preassembled Coaxial Cable (Per ft.)
Product Specification: RG-8 50 Ohm Preassembled Coaxial Cable (Per ft./.3 m)
Physical
Material Conductor: Twisted Bare CopperShield: Braided Bare Copper
Diameter Conductor: 0.12 in. (3 mm)Insulation: 0.28 in. (7 mm)Overall: 0.39 in. (10 mm)
Cable Type RG-8/U Low Loss 50 Ohm
Gauge 11 AWG
Weight Per ft.: 4 oz. (113 g)
Number of Conductors 1
