Link Win Technology SSB504R User Manual

User manual

Mobile phone

Model: SSB504R

Phone Overview

Get Started

Install the USIM/SIM Install the memory card

Remove the back cover Mount/Demount the battery

Basic Operations

Switch on

Touch and hold the Power button until the phone switches on.
Note: If you have enabled USIM/SIM locking in the Settings menu,
enter the correct PIN number upon power-on before you use the
phone.

Caution: Three consecutive attempts of entering an incorrect PIN will

lock the SIM card. If it is locked, use a PUK provided by the operator
to unlock it.

Switch off

Touch and hold the “Power button” until the Phone Options

screen displays. Tap " Power off ” to switch off the phone.

Unlock

Short press the “Power button” light up the screen, according to the
clues of the screen interface can be unlocked.

Touchscreen Usage

Use your fingers to perform operations directly on icons, buttons,
and the on-screen keypad.

Tap/Touch/Click
Tap the icon of an App to start it.

Touch & Hold

Touch and hold an item to display a pop-up menu of options. For

example, go to Address Book, touch and hold a contact on the
Address Book page, and a menu of options pops up.

Drag

Tap an item on the screen and drag it to another place.

Slide/Sweep

To sweep vertically or horizontally across the screen, you can view

apps, pictures, and webpages in a convenient manner.

Scroll

Similar to sweeping, but faster.

Pinch

Put two fingers on the screen to pinch in or out an item, such as a

webpage or picture.

Home Screen

1. Status bar: allows you to view status icons and notices, such as

signal, battery, current time and data service.

2. Notification bar: On the Home screen, tap the status bar and
drag it down to display the notification bar. Tap this bar. Then you
can view the notices. Touch the return button to switch back to the
previous page.

3. App icon: Tap an app to open it.

4. Main menu: allows you to enter the app main menu.

Phone Settings

To display the Settings menu, tap the Settings icon directly.

1.SIM card: In the Settings menu, choose SIM Card. You can then
manage your SIM cards on the pop-up page.

2. Network: In the Settings menu, select WLAN to configure your
radio network; or select Traffic usage to configure your mobile date
services; or select Mobile Network under More to configure data
services of your phone.

3. Sound: In the Settings menu, choose Sound. The allows you to

set the volume, enable/disable vibration during ringing, and select
ringtones for incoming calls and messages, as well as
enable/disable keypad touch sound effect, touch alert tone, and

screen lock tone

4. Display: allows you to configure the brightness, wallpaper,
automatic device rotation, sleep duration, and font size.

5. Security: In the Settings menu, choose Security. The Security
page allows you to set the screen locking mode and USIM/SIM
locking mode. App Permission: allows you to configure certain
permissions for an App and monitor their usage.

6. Anti-theft: allows you to remotely lock the phone or clear all data
of it.

7. Manage apps: In the Settings menu, choose Apps. Then you can
view or manage your apps.

Note: Disable or unload certain apps if available space is less than 100MB.

8. Message: On the Message page, tap the Menu button and

choose Settings. On the Message Settings page, you can
enable/disable report sending, create or select a message template,
and configure a message alert tone for each short or multimedia
message.

9. Call: To display the Call Settings page, choose Settings on the

Call page.

Shortcuts

On the Home screen, lightly drag down the Status bar. On the screen
top, a group of shortcuts are displayed, such as Settings, WLAN,
Bluetooth, Brightness, Ringtone Mode, flashlight and Airplane mode.
Tap any of them to open it quickly.

Widget

Android7.0 offers multiple ease-of-use widgets on the Home screen.
On this screen,Long press the screen and then the Widget tab, to
display the widget selection page. Tap and hold a desired widget to
be put on the Home screen, drag it left or right to locate it at a proper
place, and complete the Widget settings as prompted.

Move/Uninstall apps

1. Access the App main menu from the Home screen. On the ALL

App page, tap and hold an app to be put on the Home screen, and

drag it left or right to locate it at a proper place. In this way, a desktop
app is created.

2. On the All App page, tap and hold an app, and drag it to Uninstall
on the desktop. In this way, the app is removed from the phone.

Note: You are not allowed to uninstall basic apps of the phone.

3. On the All App page, tap and hold an app, and drag it to APP Info.

on the desktop. In this way, details about the app is displayed.

Call

This phone allows you to make or answer a call, initiate an
emergency call, and launch a multi-party call.
On the bottom left of the Home screen, tap the Dial-up icon. The
Dial-up page is displayed. Enter a phone number and choose
between card 1 and card 2 to make the call. When you enter the
number, the phone will automatically search among all contacts a
number that best matches the entered numerals, to facilitate your
operation.
During a call, tap Add a Call, and this call automatically switches to

Silent mode. Enter the number of another contact, tap Dial-up, and
the previous call automatically switches to On-hold mode. After the
second call is answered, tap Join. In this way, a teleconference is
established to achieve a multi-party talk.

Note: You need to subscribe to this service from your carrier before you
use it.

You are also allowed to initiate a call by selecting a phone number
from the list of contacts or the Message page.

Contacts

Tap Contacts to open it. The Contacts page offers management
functions. It allows you to view the list of contacts and related details,
make a call or send an SMS to a certain contact, and share the
contact.
Contact import: On the Contacts page, tap the Menu button, and
choose Import/Export to select a mode for importing or exporting a
contact.
Add a contact: On the lower right of the Contacts page, tap the Add

button to add a contact to your phone or USIM/SIM. Enter the name

and number, and tap Finish. In this way, a contact is created.
Contact list: On the Contacts page, tap the image of a contact.
Details about the contact is displayed. This allows you to quickly
make a call or send an SMS to the contact.
Search contact: On the Contacts page, tab Search, and enter

related information about a certain contact to search it among the
list of contacts.

Message

Tab Message on the desktop. Then you can create and send an
SMS or MMS.
New message: Tap the Add icon on the upper right of the Message
page. The message creating page is displayed. Enter the name or
phone number of the target contact into the Recipient bar. The
phone will automatically search among the list of contacts for one
that best matches the entered info. (You can also select the contact
from the list of contacts or groups.)
Input method: Tap the text editing zone to invoke the keypad. Long

press the space bar to switch your input method.
Send: After an SMS is complete, tap Send and choose between
card 1 and card 2 for sending the SMS.

Browser

Tap Browser to open it. The Browser page allows you to access and

manage WAP and WWW webpages.
During a browse, tap the Menu button, choose Bookmark to display
the Bookmark list. In addition, tapping the Menu button helps save
the webpage that you are viewing to the Bookmark.
Tap the Menu button during a webpage browse: also allows you to
share the webpage, search on the webpage, and view history
records.
Add a webpage bookmark to desktop: On the Bookmark page, tap
and hold a bookmark, and choose “Add shortcut to the Home
screen”. In this way, you can add frequently used webpages to the
desktop for future access.

Browser settings: Tap the Menu button and choose Settings. The
Browser Settings page allows you to configure the browser as
desired, such as common content settings and privacy & security
settings. Advanced settings allows for resetting to default settings.

E-mail

Tap E-mail to open it. The E-mail page is display. On this page, you

can send and receive an e-mail via the phone.
For the first time you use this function, enter your e-mail account and
password to set up an account. You can also set more accounts for
ease of uniform management of all mails.

Gallery

Gallery saves and manages all pictures obtained via the camera,

Internet, and the MMS received.
On the Home screen, tap Gallery to open it. The Gallery page is
displayed. It supports management of all pictures.
Open a picture and then click the share button at the top. In this way,

the picture is shared via the Bluetooth, message, and mail.

Clock

Tap Clock to open it. The Clock page is displayed.
Set clock: Tap the alarm clock on the upper left. The Alarm Clock
page is displayed.
Add clock: On the Alarm clock page, tap “+” on the top to add an
alarm. Edit the alarm time and tap Finish. When editing the alarm
time, select Hour before Minute. For example, in the 12-hour format,
select 8 as the hour and 0 as the minute, and select a.m.

Multimedia Function

The phone also supports many multimedia functions, such as

camera, music, and recorder. Tap any icon of theirs to open any

one of them.

Manage File

This function allows you to copy, paste, share and delete a file stored
on the SD card or other memory cards.

Search

On the Home screen, Tap Google, and enter keywords. In this way,

you can search for a webpage, app, contact, and music. The result
will be displayed below the search bar.

Voice Search

In the network-connected state, tab Voice Search, and speak to the

microphone what you want to search, such as weather and other
information.

Play Store

This store allows you to download the latest Android apps,
games, music, movies, TV programs, books, and magazines to
your phone.

Troubleshooting

To save time and avoid unnecessary cost, please conduct the
following checks before contacting our after-sale personnel:

1. Unable to turn on the phone: Check whether you have tapped
and hold the Power button for over two seconds. Check whether the
battery is in good contact. If not, remove the battery, reinstall it, and
turn on the phone again. Check whether the battery runs out. If yes,
charge it.

2. Poor signal: It is possibly because of where you are, for example,
on the basement or near a high-rise, that deteriorates the
reachability of radio waves. Please move to someplace with better
signal reachability.

3. Echo or noise: The network trunk line of certain carriers may be

in poor quality. Please tap the hang-up icon and redial, so that you
may switch to another trunk line with better quality.

4. Unable to charge the battery: Your battery may fail. Please

contact the dealer.

5.SIM card error: The metal surface of the SIM card is dirty. Rub the

metal contact terminals with a clean dry cloth.
The SIM card is not installed properly. Install it again as specified in

the user manual.

The SIM card breaks down. Contact the network service provider.

6. Unable to enter anything into Phone Book: This is possible

because that your phone book memory is full. Please delete
needless data from Contacts.

FCC Statement

Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions (1)this device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.

SAR Information Statement

Your Mobile phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF

energy for the general population. The guidelines are based on
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed
to assure the safety of all persons, regardless of age and health. The
exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted
with the phone transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is determined at the
highest certified power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is because the
phone is designed to operate at multiple power levels so as to use
only the power required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the power
output. Before a phone model is available for sale to the public, it
must be tested and certified to the FCC that it does not exceed the
limit established by the government adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g., at
the ear and worn on the body) as required by the FCC for each
model. The highest SAR value for this model phone when tested for
use at the ear is 0.53W/Kg and when worn on the body, as described
in this user guide, is 0.59W/Kg (Body-worn measurements differ
among phone models, depending upon available accessories and
FCC requirements). The maximum scaled SAR in hotspot mode is

0.61W/Kg. While there may be differences between the SAR levels
of various phones and at various positions, they all meet the
government requirement for safe exposure. The FCC has granted an
Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on file with the
FCC and can be found under the Display Grant section of
http://www.fcc.gov/ oet/fccid after searching on
FCC ID: 2AQ4G-SSB504R
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications Industry Association

(CTIA) web-site at http://www.wow-com.com. * In the United States
and Canada, the SAR limit for mobile phones used by the public is

1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in
measurements.
