Link Win Technology MP5184G User Manual





User manual

Mobile phone

Model: MP5184G

LUSH MINT

Phone Overview

Get Started

Install the USIM/SIM Install the
memory card

Remove the back cover Mount/Demount
the battery

Basic Operations

Switch on

Touch and hold the Power button until the phone
switches on.
Note: If you have enabled USIM/SIM locking in the
Settings menu, enter the correct PIN number upon
power-on before you use the phone.

Caution: Three consecutive attempts of entering an

incorrect PIN will lock the SIM card. If it is locked,
use a PUK provided by the operator to unlock it.

Switch off

Touch and hold the “Power button” until the Phone

Options screen displays. Tap " Power off ” to switch
off the phone.

Unlock

Short press the “Power button” light up the screen,
according to the clues of the screen interface can be
unlocked.

Touchscreen Usage

Use your fingers to perform operations directly on
icons, buttons, and the on-screen keypad.

Tap/Touch/Click
Tap the icon of an App to start it.

Touch & Hold

Touch and hold an item to display a pop-up menu of

options. For example, go to Address Book, touch
and hold a contact on the Address Book page, and a
menu of options pops up.

Drag

Tap an item on the screen and drag it to another place.

Slide/Sweep

To sweep vertically or horizontally across the screen,

you can view apps, pictures, and webpages in a
convenient manner.

Scroll

Similar to sweeping, but faster.

Pinch

Put two fingers on the screen to pinch in or out a n it em,

such as a webpage or picture.

Home Screen

1. Status bar: allows you to view status icons and

notices, such as signal, battery, current time and data
service.

2. Notification bar: On the Home screen, tap the
status bar and drag it down to display the notification
bar. Tap this bar. Then you can v iew the notices. Touch
the return button to switch back to the previous page.

3. App icon: Tap an app to open it.

4. Main menu: allows you to enter the app main m enu.

Phone Settings

To display the Settings menu, tap the Settings icon
directly.

1.SIM card: In the Settings menu, choose SIM Card.
You can then manage your SIM cards on the pop-up
page.

2. Network: In the Settings menu, select WLAN to
configure your radio network; or select Traffic usage
to configure your mobile date services; or select
Mobile Network under More to configure da ta
services of your phone.

3. Sound: In the Settings menu, choose Sound. The

allows you to set the volume, enable/disable vibration
during ringing, and select ringtones for incoming calls
and messages, as well as enable/disable key pad to uch
sound effect, touch alert tone, and screen lock tone

4. Display: allows you to configure the brightness,

wallpaper, automatic device rotation, sleep duration,
and font size.

5. Security: In the Settings menu, choose Security.

The Security page allows you to set the screen locking
mode and USIM/SIM locking mode. App Permission:
allows you to configure certain permissions for an App
and monitor their usage.

6. Anti-theft: allows you to remotely lock the phone or

clear all data of it.

7. Manage apps: In the Settings menu, choose Apps.

Then you can view or manage your apps.

Note: Disable or unload certain apps if available space is less
than 100MB.

8. Message: On the Message page, tap the Menu

button and choose Settings. On the Message Settings
page, you can enable/disable report sending, create or
select a message template, and configure a message
alert tone for each short or multimedia message.

9. Call: To display the Call Settings page, choose

Settings on the Call page.

Shortcuts

On the Home screen, lightly drag down the Status bar.
On the screen top, a group of shortcuts are displayed,
such as Settings, WLAN, Bluetooth, Brightness,
Ringtone Mode, flashlight and Air pl a ne m ode . Tap any
of them to open it quickly.

Widget

Android7.0 offers multiple ease-of-use widgets on the
Home screen.
On this screen, Long press the screen and then the
Widget tab, to display the widget selection page. Tap
and hold a desired widget to be put on the Home
screen, drag it left or right to locate it at a proper place,
and complete the Widget settings as prompted.

Move/Uninstall apps

1. Access the App main menu from the Home screen.

On the ALL App page, tap and hold a n app t o be put o n
the Home screen, and drag it left or right to locate it at
a proper place. In this way, a desktop app is created.

2. On the All App page, tap and hold an app, and drag
it to Uninstall on the desktop. In this way, the app is
removed from the phone.

Note: You are not allowed to uninstall basic apps of the phone.

3. On the All App page, tap and hold an app, and drag
it to APP Info. on the desktop. In this way, details
about the app is displayed.

Call

This phone allows you to make or answer a call, initiate
an emergency call, and launch a multi-party call.
On the bottom left of the Home screen, tap the Dial-up
icon. The Dial-up page is displayed. Enter a phone
number and choose between card 1 and card 2 to
make the call. When you enter the number, the phone
will automatically search among all contacts a number
that best matches the entered numerals, to facilitate
your operation.
During a call, tap Add a Call, and this call automatically

switches to Silent mode. Enter the number of
another contact, tap Dial-up, and the previous call
automatically switches to On-hold mode. After the
second call is answered, tap Join. In this way, a
teleconference is established to achieve a
multi-party talk.

Note: You need to subscribe to this service from your carrier
before you use it.

You are also allowed to initiate a call by selecting a
phone number from the list of contacts or the Message
page.

Contacts

Tap Contacts to open it. The Contacts page offers
management functions. It allows you to view the list of
contacts and related details, make a call or send an
SMS to a certain contact, and share the contact.
Contact import: On the Contacts page, tap the Menu
button, and choose Import/Export to select a mode for
importing or exporting a contact.
Add a contact: On the lower right of the Contacts

page, tap the Add button to add a contact to your
phone or USIM/SIM. Enter the name and number,
and tap Finish. In this way, a contact is created.

Contact list: On the Contacts page, tap the image of a
contact. Details about the contact is displayed. This
allows you to quickly make a call or send an SMS to
the contact.
Search contact: On the Contacts page, tab Search,

and enter related information about a certain contact
to search it among the list of contacts.

Message

Ta b Mess age on the d esktop. Then you ca n cr eate an d
send an SMS or MMS.
New message: Tap the Add icon on the upper right of
the Message page. The message creating page is
displayed. Enter the name or phone number of the
target contact into the Recipient bar. The phone will
automatically search among the list of contacts for one
that best matches the entered info. (You can also
select the contact from the list of contacts or groups.)
Input method: Tap the text editing zone to invoke the

keypad. Long press the space bar to switch your

input method.
Send: After an SMS is complete, tap Send and choose
between card 1 and card 2 for sending the SMS.

Browser

Tap Browser to open it. The Browser page allows you

to access and manage WAP and WWW webpages.
During a browse, tap the Menu button, choose
Bookmark to display the Bookmark list. In addition,
tapping the Menu button helps save the webpage that
you are viewing to the Bookmark.
Tap the Menu button during a webpage browse: also
allows you to share the webpage, search on the
webpage, and view history records.
Add a webpage bookmark to desktop: On the
Bookmark page, tap and hold a bookmark, and choose
“Add shortcut to the Home screen”. In this way, you
can add frequently used webpages to the desktop for
future access.
Browser settings: Tap the Menu button and choose
Settings. The Browser Settings page allows you to
configure the browser as desired, such as common
content settings and privacy & security settings.
Advanced settings allows for resetting to default
settings.

E-mail

Tap E-mail to open it. The E-mail page is display. On

this page, you can send and receive an e-mail via the

phone.
For the first time you use this function, enter your
e-mail account and password to set up an account.
You can also set more accounts for ease of uniform
management of all mails.

Gallery

Gallery saves and manages all pictures obtained via

the camera, Internet, and the MMS received.
On the Home screen, tap Gallery to open it. The
Gallery page is displayed. It supports management of
all pictures.
Open a picture and then click the share button at the

top. In this way, the picture is shared via the
Bluetooth, message, and mail.

Clock

Tap Clock to open it. The Clock page is displayed.
Set clock: Tap the alarm clock on the upper left. The
Alarm Clock page is displayed.
Add clock: On the Alarm clock page, tap “+” on the top
to add an alarm. Edit the alarm time and tap Finish.
When editing the alarm time, select Hour before
Minute. For example, in the 12-hour for mat, select 8 as
the hour and 0 as the minute, and select a.m.

Multimedia Function

The phone also supports many multimedia functions,

such as camera, music, and recorder. Tap any icon

of theirs to open any one of them.

Manage File

This function allows you to copy, paste, share and
delete a file stored on the SD card or other memory
cards.

Search

On the Home screen, Tap Google, and enter keywords.

In this way, you can search for a webpage, app,
contact, and music. The result will be displayed below
the search bar.

Voice Search

In the network-connected state, tab Voice Search, and

speak to the microphone what you want to search,
such as weather and other information.

Play Store

This store allows you to download the latest
Android apps, games, music, movies, TV
programs, books, and magazines to your phone.

Troubleshooting

To save time and avoid unnecessary cost, please
conduct the following checks before contacting our
after-sale personnel:

1. Unable to turn on the phone: Check whether you
have tapped and hold the Power button for over two
seconds. Check whether the battery is in good contact.
If not, remove the battery, reinstall it, and turn on the
phone again. Check whether the battery runs out. If
yes, charge it.

2. Poor signal: It is possibly because of where y ou are,

for example, on the basement or near a high-r ise, tha t
deteriorates the reachability of radio waves. Please
move to someplace with better signal reachability.

3. Echo or noise: The network trunk line of certain
carriers may be in poor quality. Please tap the hang-up
icon and redial, so that you may switch to another trunk
line with better quality.

4. Unable to charge the battery: Your battery may fail.
Please contact the dealer.

5.SIM card error: The metal surface of the SIM card is
dirty. Rub the metal contact terminals with a clean dry
cloth.
The SIM card is not installed properly. Install it again as

specified in the user manual.
The SIM card breaks down. Contact the network
service provider.

6. Unable to enter anything into Phone Book: This
is possible because that your phone book memory is
full. Please delete needless data from Contacts.

FCC Statement

Changes or modifications not expressly approved by
the party responsible for compliance could void the

user's authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and
receiver.

-- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

-- Consult the dealer or an experienced radio/TV
technician for help
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions
(1)this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.

SAR Information Statement

Your Mobile phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radiofreque ncy (RF)
energy set by the Federal Communications
Commission of the U.S. Government. These limits are
part of comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines are based on st andards th at
were developed by independent scientific
organizations through periodic and thorough
evaluation of scientific studies. The standards include
a substantial safety margin designed to assure the
safety of all persons, regardless of ag e an d h ealth. The
exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the
FCC is 1.6 W/kg. * Tests for SAR are conducted with
the phone transmitting at its highest certified pow er
level in all tested frequency bands. Although the SAR
is determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
Before a phone model is availabl e for sal e to the public,
it must be tested and certified to the FCC that it does
not exceed the limit established by the government
adopted requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the ear
and worn on the body) as required by the FC C for each
model. The highest SAR value for this model phone
when tested for use at the ear is 0.5W/Kg and when
worn on the body, as described in this user guide, is

0.6W/Kg (Body-worn measurements differ among
phone models, depending upon available accessories
and FCC requirements). The maximum scaled SAR in
hotspot mode is 0.61W/Kg. While there may be
differences between the SAR levels of various phones
and at various positions, they all meet the government
requirement for safe exposure. The FCC has granted
an Equipment Authorization for this model phone with
all reported SAR levels evaluated as in compliance
with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of
http://www.fcc.gov/ oet/fccid after searching on
FCC ID: 2AQ4G-MP5184G Additional information on
Specific Absorption Rates (SAR) can be found on the
Cellular Telecommunications Industry Association
(CTIA) web-site at http://www.wow-com.com. * In the
United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kg (W/kg)

averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give
additional protection for the public and to account for
any variations in measurements.
The SAR test distance is 10mm.
