LINKSYS WPC54GV3 Users Manual

A Division of Cisco Systems, Inc.
®
2.4
Model No.
802.11g
WIRELESS
WPC54G V3
Wireless-G
Notebook Adapter
User Guide
with SpeedBooster
Wireless-G Notebook Adapter with SpeedBooster
Copyright and Trademarks
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2004 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
This User Guide
The User Guide to the Wireless-G Notebook Adapter with SpeedBooster has been designed to make understanding networking easier than ever. Look for the following items when reading this guide:
This checkmark means there is a note of interest and is something you should pay special attention to while using the Adapter.
This exclamation point means there is a caution or warning and is something that could damage your property or the Adapter.
This question mark provides you with a reminder about something you might need to do while using the Adapter.
In addition to these symbols, there are definitions for technical terms that are presented like this:
word: definition.
Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like this:
Figure numbers and descriptions can also be found in the "List of Figures" section in the “Table of Contents”.
WPC54GS-UG-40220NC BW
Figure 0-1: Sample Figure Description
Wireless-G Notebook Adapter with SpeedBooster
Table of Contents
Chapter 1: Introduction 1
Welcome 1 What’s in this Guide? 2
Chapter 2: Planning your Wireless Network 4
Network Topology 4 Roaming 4 Network Layout 5
Chapter 3: Getting to Know the Wireless-G Notebook Adapter 6
The LED Indicators 6
Chapter 4: Software Installation and Configuration 7
The Installation Procedure 8
Chapter 5: Hardware Installation 12
Connecting the Adapter 12
Chapter 6: Using the Wireless Network Monitor 13
Accessing the WLAN Monitor 13 Link Information 13 Site Survey 16 Profiles 17 Creating a New Profile 18
Appendix A: Troubleshooting 30
Common Problems and Solutions 30 Frequently Asked Questions 31
Appendix B: Wireless Security 34
Security Precautions 34 Security Threats Facing Wireless Networks 34
Appendix C: Windows Help 37 Appendix D: Glossary 38 Appendix E: Specifications 45 Appendix F: Warranty Information 46 Appendix G: Regulatory Information 47 Appendix H: Contact Information 49
Wireless-G Notebook Adapter with SpeedBooster
List of Figures
Figure 3-1: Front Panel 6 Figure 4-1: The Setup Wizard’s Welcome Screen 7 Figure 4-2: The Setup Wizard’s License Agreement 8 Figure 4-3: The Setup Wizard’s Wireless Mode Screen 8 Figure 4-4: The Setup Wizard’s Ad-Hoc Mode Screen 9 Figure 4-5: The Setup Wizard’s WEP Screen 9 Figure 4-6: The Setup Wizard’s WPA-PSK Screen 10 Figure 4-7: The Setup Wizard’s Check Settings Screen 10 Figure 4-8: The Setup Wizard’s Congratulations Screen 11 Figure 5-1: How the Adapter installs into your notebook 12 Figure 6-1: Link Information 13 Figure 6-2: More Information-Network Settings 14 Figure 6-3: More Information-Network Statistics 15 Figure 6-4: Site Survey 16 Figure 6-5: Profiles 17 Figure 6-6: Importing a Profile 17 Figure 6-7: Exporting a Profile 17 Figure 6-8: Creating a New Profile 18 Figure 6-9: Enter Profile Name 18 Figure 6-10: Wireless Mode for New Profile 19 Figure 6-11: Ad-Hoc Mode Settings 19 Figure 6-12: Netowork Settings 20 Figure 6-13: Wireless Security for New Profile 21 Figure 6-14: WEP Setting for New Profile 21 Figure 6-15: WPA-PSK Settings 22 Figure 6-16: TKIP Settings 22 Figure 6-17: WPA RADIUS Settings 23 Figure 6-18: Encryption Type 23 Figure 6-19: EAP-TLS Authentication 24 Figure 6-20: EAP-TTLS Authentication 24
Wireless-G Notebook Adapter with SpeedBooster
Figure 6-21: EAP-MD5 Authentication 25 Figure 6-22: EAP-PEAP Authentication 25 Figure 6-23: EAP-LEAP Authentication 25 Figure 6-24: RADIUS Settings 26 Figure 6-25: EAP-TLS Authentication 26 Figure 6-26: EAP-TTLS Authentication 27 Figure 6-27: EAP-MD5 Authentication 27 Figure 6-28: EAP-PEAP Authentication 28 Figure 6-29: LEAP Authentication 28 Figure 6-30: TKIP Settings 29 Figure 6-31: EAP-TLS Authentication 29
Wireless-G Notebook Adapter with SpeedBooster
Chapter 1: Introduction
Welcome
Thank you for choosing the Wireless-G Notebook Adapter with SpeedBooster. With this Adapter, your wireless networking experience will be faster and easier than ever.
Like all wireless products, the Adapter allows for greater range and mobility within your wireless network. This adapter communicates over the 54Mbps 802.11g wireless standard, which is almost five times faster than
802.11b. But since they share the same 2.4GHz radio band, the Adapter can also communicate with the widely used 11Mbps 802.11b standard.
PCs equipped with wireless cards and adapters can communicate without cumbersome cables. By sharing the same wireless settings, within their transmission radius, they form a wireless network.
network: a series of computers or devices connected for the purpose of data sharing, storage, and/or transmission between users.
adapter: a device that adds network functionality to your PC.
The included Setup Wizard will walk you through configuring the adapter to your network's settings, step by step. Then just slide it into your notebook's PC Card slot and enjoy network access with your notebook computer, while retaining true mobility.
Once you're connected, you can keep in touch with your e-mail, access the Internet, and share files and other resources such as printers and network storage with other computers on the network. At home, you can surf the web or use instant messaging to chat with friends while sitting out on the patio. Your wireless connection is protected by up to 128-bit WEP encryption.
You'll also be able to connect with any of the growing number of public wireless hotspots springing up in coffee shops, airport lounges, hotels and convention centers. And as those hotspots upgrade to the new high-speed Wireless-G standard, you'll be ready to take advantage of the increased speeds.
Get connected to current-standard 802.11b networks today, and be prepared for the future with the Wireless-G Notebook Adapter with SpeedBooster from Linksys.
Chapter 1: Introduction Welcome
802.11b: an IEEE wireless networking standard that specifies a maximum data transfer rate of 11Mbps and an operating frequency of 2.4GHz.
802.11g an IEEE wireless networking standard that specifies a maximum data transfer rate of 54Mbps and an operating frequency of 2.4GHz.
1
Wireless-G Notebook Adapter with SpeedBooster
What’s in this Guide?
This user guide covers the steps for setting up and using the Wireless-G Notebook Adapter with SpeedBooster.
• Chapter 1: Introduction This chapter describes the Adapter’s applications and this User Guide.
• Chapter 2: Planning Your Wireless Network This chapter discusses a few of the basics about wireless networking.
• Chapter 3: Getting to Know the Wireless-G Notebook Adapter This chapter describes the physical features of the Adapter.
• Chapter 4: Software Installation and Configuration This chapter instructs you on how to install the Adapter’s Setup Wizard and Configure the Adapter
• Chapter 5: Hardware Installation This chapter shows you how to connect the Adapter to your PC.
• Chapter 6: Using the WLAN Monitor This chapter show you how to use the Adapter’s WLAN Monitor.
• Appendix A: Troubleshooting This appendix describes some problems and solutions, as well as frequently asked questions, regarding installation and use of the Adapter.
• Appendix B: Wireless Security This appendix discusses security issues regarding wireless networking and measures you can take to help protect your wireless network.
• Appendix C: Windows Help This appendix describes how you can use Windows Help for instructions about networking, such as installing the TCP/IP protocol.
• Appendix D: Glossary This appendix gives a brief glossary of terms frequently used in networking.
• Appendix E: Specifications This appendix provides the Adapter’s technical specifications.
• Appendix F: Warranty Information This appendix supplies the Adapter’s warranty information.
Chapter 1: Introduction What’s in this Guide?
2
Wireless-G Notebook Adapter with SpeedBooster
• Appendix G: Regulatory Information This appendix supplies the Adapter’s regulatory information.
• Appendix H: Contact Information This appendix provides contact information for a variety of Linksys resources, including Technical Support.
Chapter 1: Introduction What’s in this Guide?
3
Wireless-G Notebook Adapter with SpeedBooster
Chapter 2: Planning your Wireless Network
Network Topology
A wireless network is a group of computers, each equipped with one wireless adapter. Computers in a wireless network must be configured to share the same radio channel. Several PCs equipped with wireless cards or adapters can communicate with one another to form an ad-hoc network.
Linksys wireless adapters also provide users access to a wired network when using an access point or wireless router. An integrated wireless and wired network is called an infrastructure network. Each wireless PC in an infrastructure network can talk to any computer in a wired network infrastructure via the access point or wireless router.
An infrastructure configuration extends the accessibility of a wireless PC to a wired network, and can double the effective wireless transmission range for two wireless adapter PCs. Since an access point is able to forward data within a network, the effective transmission range in an infrastructure network can be doubled.
Roaming
Infrastructure mode also supports roaming capabilities for mobile users. Roaming means that you can move your wireless PC within your network and the access points will pick up the wireless PC's signal, providing that they both share the same channel and SSID.
topology: the physical layout of a network.
ad-hoc: a group of wireless devices
communicating directly with each other (peer­to-peer) without the use of an access point.
infrastructure: a wireless network that is bridged to a wired network via an access point.
roaming: the ability to take a wireless device from one access point's range to another without losing the connection.
Before enabling you consider roaming, choose a feasible radio channel and optimum access point position. Proper access point positioning combined with a clear radio signal will greatly enhance performance.
Chapter 2: Planning your Wireless Network Network Topology
ssid: your wireless network's name.
4
