This user guide has been designed to make understanding networking with the Notebook Adapter easier than
ever. Look for the following items when reading this User Guide:
This checkmark means there is a note of interest and is something you
should pay special attention to while using the Notebook Adapter.
This exclamation point means there is a caution or warning and is
something that could damage your property or the Notebook Adapter.
This question mark provides you with a reminder about something
you might need to do while using the Notebook Adapter.
In addition to these symbols, there are definitions for technical terms that are presented like this:
word: definition.
Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like
this:
Figure numbers and descriptions can also be found in the “List of Figures” section.
WPC54G-EU-LA_V3.1-UG-70130NC JL
Figure 0-1: Sample Figure Description
Wireless-G Notebook Adapter
Table of Contents
Chapter 1: Introduction1
Welcome1
What’s in this User Guide?1
Chapter 2: Planning your Wireless Network3
Network Topology3
Roaming3
Network Layout3
Chapter 3: Getting to Know the Wireless-G Notebook Adapter4
The LED Indicators4
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter5
Starting the Setup5
Connecting the Adapter7
Setting up the Adapter7
Chapter 5: Using the Wireless Network Monitor22
Accessing the Wireless Network Monitor22
Using the Wireless Network Monitor22
Link Information22
Site Survey25
Profiles27
Creating a New Profile28
Appendix A: Troubleshooting43
Common Problems and Solutions43
Frequently Asked Questions44
Figure 4-30: Wireless Security - RADIUS - EAP-TLS 19
Figure 4-31: Wireless Security - RADIUS - PEAP 19
Figure 4-32: Wireless Security - LEAP 20
Figure 4-33: LEAP Settings 20
Figure 4-34: Confirm New Settings 21
Figure 4-35: Congratulations Screen 21
Figure 5-1: Wireless Network Monitor Icon 22
Figure 5-2: Link Information 22
Figure 5-3: More Information - Wireless Network Status 23
Figure 5-4: More Information-Network Statistics 24
Figure 5-5: Site Survey 25
Figure 5-6: WEP Key Needed for Connection 25
Figure 5-7: WPA-Personal Needed for Connection 26
Figure 5-8: WPA2-Personal Needed for Connection 26
Figure 5-9: Profiles 27
Figure 5-10: Import a Profile 27
Figure 5-11: Export a Profile 27
Figure 5-12: Create a New Profile 28
Figure 5-13: Available Wireless Network 28
Figure 5-14: SecureEasySetup Screen 29
Figure 5-15: SecureEasySetup Logo 29
Figure 5-16: SecureEasySetup Logo Location 29
Figure 5-17: Congratulations 30
Figure 5-18: Available Wireless Network 30
Figure 5-19: WEP Key Needed for Connection 31
Figure 5-20: WPA-Personal Needed for Connection 31
Figure 5-21: WPA2-Personal Needed for Connection 32
Figure 5-22: Congratulations 32
Figure 5-23: Network Settings for New Profile 33
Figure 5-24: Wireless Mode for New Profile 33
Figure 5-25: Ad-Hoc Mode Settings for New Profile 34
Figure 5-26: Wireless Security - Disabled 34
Figure 5-27: Wireless Security - WEP for New Profile 35
Wireless-G Notebook Adapter
Figure 5-28: WEP Settings 35
Figure 5-29: Wireless Security - WPA-Personal for New Profile 36
Figure 5-30: WPA-Personal Settings 36
Figure 5-31: Wireless Security - WPA2-Personal for New Profile 37
Figure 5-32: WPA2-Personal Settings 37
Figure 5-33: Wireless Security - WPA-Enterprise Using EAP-TLS for New Profile 38
Figure 5-34: Wireless Security - WPA-Enterprise Using PEAP for New Profile 38
Figure 5-35: Wireless Security - WPA2-Enterprise Using EAP-TLS for New Profile 39
Figure 5-36: Wireless Security - WPA2-Enterprise Using PEAP for New Profile 39
Figure 5-37: Wireless Security - RADIUS Using EAP-TLS for New Profile 40
Figure 5-38: Wireless Security - RADIUS Using PEAP for New Profile 40
Figure 5-39: Wireless Security - LEAP for New Profile 41
Figure 5-40: LEAP Settings 41
Figure 5-41: Confirm New Settings for New Profile 42
Figure 5-42: Congratulations for New Profile 42
Wireless-G Notebook Adapter
Chapter 1: Introduction
Welcome
Thank you for choosing the Wireless-G Notebook Adapter. And now, with SecureEasySetup, setting up your
network and your Wireless-G Notebook Adapter is easier than ever.
Like all wireless products, the Adapter allows for greater range and mobility within your wireless network. This
Adapter communicates over the 802.11g wireless standard, up to 54 Mbps.
PCs equipped with wireless cards and adapters can communicate without cumbersome cables. By sharing the
same wireless settings, within their transmission radius, they form a wireless network.
The included Setup Wizard will walk you through configuring the Adapter to your network’s settings, step by step.
Then just slide it into your notebook's PC slot and enjoy network access with your notebook computer, while
retaining true mobility.
Once you’re connected, you can keep in touch via e-mail, access the Internet, and share files and other resources
such as printers and network storage with other computers on the network. At home, you can surf online or use
instant messaging to chat with friends while sitting out on the patio. Your wireless connection is protected by up
to 256-bit encryption.
You'll also be able to connect with any of the growing number of public wireless hotspots springing up in coffee
shops, airport lounges, hotels and convention centers.
Linksys recommends using the Setup Wizard on the Setup CD-ROM for first-time installation of the Adapter. You
can also refer to the instructions in this Guide to help you install and configure the Adapter. These instructions
should be all you need to get the most out of the Wireless-G Notebook Adapter.
What’s in this User Guide?
This user guide covers the steps for setting up and using the Wireless-G Notebook Adapter.
network: a series of computers or devices
connected for the purpose of data sharing,
storage, and/or transmission between users
bit: a binary digit
encryption: encoding data transmitted in a network
• Chapter 1: Introduction
This chapter describes the Adapter’s applications and this User Guide.
• Chapter 2: Planning Your Wireless Network
This chapter discusses a few of the basics about wireless networking.
Chapter 1: Introduction
Welcome
1
Wireless-G Notebook Adapter
• Chapter 3: Getting to Know the Wireless-G Notebook Adapter
This chapter describes the physical features of the Adapter.
• Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
This chapter instructs you on how to install and configure the Adapter.
• Chapter 5: Using the Wireless Network Monitor
This chapter show you how to use the Adapter’s Wireless Network Monitor.
• Appendix A: Troubleshooting
This appendix describes some problems and solutions, as well as frequently asked questions, regarding
installation and use of the Adapter.
• Appendix B: Wireless Security
This appendix discusses security issues regarding wireless networking and measures you can take to help
protect your wireless network.
• Appendix C: Windows Help
This appendix describes how you can use Windows Help for instructions about networking, such as installing
the TCP/IP protocol.
• Appendix D: Glossary
This appendix gives a brief glossary of terms frequently used in networking.
• Appendix E: Specifications
This appendix provides the Adapter’s technical specifications.
• Appendix F: Warranty Information
This appendix supplies the Adapter’s warranty information.
• Appendix G: Regulatory Information
This appendix supplies the Adapter’s regulatory information.
• Appendix H: Contact Information
This appendix provides contact information for a variety of Linksys resources, including Technical Support.
Chapter 1: Introduction
What’s in this User Guide?
2
Wireless-G Notebook Adapter
Chapter 2: Planning your Wireless Network
Network Topology
A wireless network is a group of computers, each equipped with one wireless adapter. Computers in a wireless
network must be configured to share the same radio channel. Several PCs equipped with wireless cards or
adapters can communicate with one another to form an ad-hoc network.
Linksys wireless adapters also provide users access to a wired network when using an access point or wireless
router. An integrated wireless and wired network is called an infrastructure network. Each wireless PC in an
infrastructure network can talk to any computer in a wired network infrastructure via the access point or wireless
router.
An infrastructure configuration extends the accessibility of a wireless PC to a wired network, and can double the
effective wireless transmission range for two wireless adapter PCs. Since an access point is able to forward data
within a network, the effective transmission range in an infrastructure network can be doubled.
Roaming
Infrastructure mode also supports roaming capabilities for mobile users. Roaming means that you can move your
wireless PC within your network and the access points will pick up the wireless PC's signal, providing that they
both share the same channel and SSID.
Before enabling you consider roaming, choose a feasible radio channel and optimum access point position.
Proper access point positioning combined with a clear radio signal will greatly enhance performance.
topology: the physical layout of a network
access point: a device that allows wireless-
equipped computers and other devices to
communicate with a wired network
ad-hoc: a group of wireless devices
communicating directly with each other (peerto-peer) without the use of an access point
infrastructure: a wireless network that is
bridged to a wired network via an access point
roaming: the ability to take a wireless device
from one access point's range to another without
losing the connection
ssid: your wireless network's name
Network Layout
Use the Wireless-G Notebook Adapter to add your computer to your network of Wireless-G and Wireless-B
products. When you wish to connect your wired network with your wireless network, network ports on access
points and wireless routers can be connected to any of Linksys's switches or routers.
With these, and many other, Linksys products, your networking options are limitless. Go to the Linksys website at
www.linksys.com/international for more information about wireless products.
Chapter 2: Planning your Wireless Network
Network Topology
3
Wireless-G Notebook Adapter
Chapter 3: Getting to Know the Wireless-G Notebook
Adapter
The LED Indicators
The Adapter's LEDs display information about network activity.
Figure 3-1: Front Panel
PowerGreen. The Power LED lights up when the Adapter is powered on.
LinkGreen. The Link LED lights up when the Adapter has an active connection.
Chapter 3: Getting to Know the Wireless-G Notebook Adapter
The LED Indicators
4
Wireless-G Notebook Adapter
Chapter 4: Setting up and Connecting the Wireless-G
Notebook Adapter
Starting the Setup
The Wireless-G Notebook Adapter Setup Wizard will guide you through the installation procedure. The Setup
Wizard will install the driver and Wireless Network Monitor, as well as connect and configure the Adapter.
IMPORTANT: Do not connect the Adapter until you are instructed to
do so or the setup will not work.
Insert the Setup Wizard CD-ROM into your CD-ROM drive. The Setup Wizard should run automatically, and the
Welcome screen should appear. If it does not, click the Start button and choose Run. In the field that appears,
enter D:\setup.exe (if “D” is the letter of your CD-ROM drive).
On the initial Welcome screen, the language of your computer’s operating system is selected. Click Next to
proceed in the current language. To use a different language, select it from the Language drop-down menu, and
then click Next.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Starting the Setup
Figure 4-1: Setup Wizard’s Welcome Screen
5
Wireless-G Notebook Adapter
A second Welcome screen will appear. You have the following choices:
Click Here to Start - Click the Click Here to Start button to begin the software installation process.
User Guide - Click the User Guide button to open the PDF file of this User Guide.
Exit - Click the Exit button to exit the Setup Wizard.
1. To install the Adapter, click the Click Here to Start button on the Welcome screen.
2. After reading the License Agreement, click the Next button if you agree and want to continue the installation,
or click the Cancel button to end the installation.
Figure 4-2: Click Here to Start
3. Windows will begin copying the files onto your PC.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Starting the Setup
Figure 4-3: Setup Wizard’s License Agreement
6
Wireless-G Notebook Adapter
Connecting the Adapter
1. Locate an available CardBus slot on your notebook PC.
2. With the connector pin end facing the CardBus slot and the label facing up, slide the Adapter into the CardBus
slot until it locks in place.
3. Windows 98 and Windows Me users may need to restart their PCs again when prompted to do so. The Power
LED should light up when the Adapter is installed correctly.
4. Windows will begin copying the driver files to your computer. If Windows asks you for the original Windows
CD-ROM, insert the CD-ROM, and direct Windows to its correct location (e.g., D:\).
5. Then, click Next.
Setting up the Adapter
The next screen to appear will be the Available Wireless Network screen.
This screen provides three options for setting up the Adapter.
Figure 4-4: Connecting the Adapter
• SecureEasySetup. This Adapter features SecureEasySetup. This means that you can set it up with just the
press of a button when connecting to wireless routers or access points that also feature SecureEasySetup.
Both devices on the network must feature SecureEasySetup for this to work.
• Available Wireless Network. (For most users.) Use this option if you already have a network set up with
devices that do not have SecureEasySetup. The networks available to this Adapter will be listed on this
screen. You can choose one of these networks and click the Connect button to connect to it. Click the
Refresh button to update the Available Wireless Network list.
• Manual Setup. If you are not taking advantage of SecureEasySetup and your network is not listed on this
screen, select Manual Setup to set up the adapter manually. This method of setting up the Adapter is
intended for Advanced Users only.
The setup for each option is described, step by step, under the appropriate heading on the following pages.
Click Exit to close the Setup Wizard, if you wish to set up the Adapter later.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Connecting the Adapter
Figure 4-5: Available Wireless Network
7
Wireless-G Notebook Adapter
SecureEasySetup
With SecureEasySetup, setting up the Adapter is as simple as pushing a couple of buttons. Before you press any
buttons, though, you should locate the SecureEasySetup button on the device you’re connecting the Adapter to,
such as a wireless router or access point.
1. Starting from the Available Wireless Network screen, click the SecureEasySetup button on the right hand
side.
2. You will be asked to locate the SecureEasySetup button on the device with which the Adapter will be
communicating. If you are not sure where to find this button, click Where can I find the button?.
This will walk you through a couple of screens to help you find the button, which is usually located on the
front of the wireless router or access point.
Figure 4-6: SecureEasySetup Screen
3. Press the Cisco logo or SecureEasySetup button on the wireless router or access point. When it turns white
and begins to flash, click the Next button on the Setup Wizard screen. The logo or button will stop flashing
on the wireless router or access point when the Adapter has been successfully added to the network. Repeat
this procedure for any additional SecureEasySetup device.
NOTE: You can only add one SecureEasySetup device at a time.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-7: SecureEasySetup Logo
Figure 4-8: SecureEasySetup Logo Location
8
Wireless-G Notebook Adapter
4. When SecureEasySetup is complete, you may save your configuration to a text file by clicking the Save
button, or print the configuration by clicking the Print button. Click Connect to Network to connect to your
network.
Congratulations! The setup is complete.
To check the link information, search for available wireless networks, or make additional configuration
changes, refer to Chapter 5: Using the Wireless Network Monitor.
Figure 4-9: SecureEasySetup Congratulations
Available Wireless Network
If you’re not setting up the Adapter with SecureEasySetup, another method for setting up the Adapter is with the
available networks listed on the Available Wireless Network screen. The available networks are listed in the table
on the center of the screen by SSID. Select the wireless network you wish to connect to and click the Connect
button. (If you do not see your network listed, you can click the Refresh button to bring the list up again.) If the
network utilizes wireless security, you will need to configure security on the Adapter. If not, you will be taken
directly to the Congratulations screen.
1. If you have wireless security enabled on your network, continue to step 2. If you don’t have wireless security
enabled, continue to step 3.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-10: Available Wireless Network
9
Wireless-G Notebook Adapter
2. If your network has the wireless security WEP (Wired Equivalent Privacy) enabled, this screen will appear.
Select 64-bit or 128-bit.
Then enter a passphrase or WEP key.
Passphrase - Enter a passphrase in the Passphrase field, so a WEP key is automatically generated. The
passphrase is case-sensitive and should not be longer than 16 alphanumeric characters. It must match the
passphrase of your other wireless network devices and is compatible with Linksys wireless products only. (If
you have any non-Linksys wireless products, enter the WEP key manually on those products.)
WEP Key - The WEP key you enter must match the WEP key of your wireless network. For 64-bit encryption,
enter exactly 10 hexadecimal characters. For 128-bit encryption, enter exactly 26 hexadecimal characters.
Valid hexadecimal characters are “0” to “9” and “A” to “F”.
Then click Connect and proceed to Step 3.
If your network has the wireless security WPA-Personal (Wi-Fi Protected Access) enabled, this screen will
appear.
Encryption - Select the type of algorithm you want to use, TKIP or AES, from the Encryption drop-down
menu.
Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.
Figure 4-11: WEP Key Needed for Connection
Figure 4-12: WPA - Personal Needed for Connection
Then click Connect and proceed to Step 3.
If your network has the wireless security WPA2-Personal (WPA2 is a stronger version of WPA) enabled, this
screen will appear.
Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.
Then click Connect and proceed to Step 3.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-13: WPA2 - Personal Needed for Connection
10
Wireless-G Notebook Adapter
3. After the software has been successfully installed, the Congratulations screen will appear. Click Connect to
Network to connect to your network. For more information about the Wireless Network Monitor, refer to
Chapter 5: Using the Wireless Network Monitor.
Congratulations! The Automatic Setup’s installation of the Wireless-G Notebook Adapter is complete.
To check the link information, search for available wireless networks, or make additional configuration
changes, proceed to Chapter 5: Using the Wireless Network Monitor.
Figure 4-14: Automatic Setup’s Congratulations
Manual Setup
If you are not taking advantage of SecureEasySetup and your network is not listed with the available networks,
you can use Manual Setup.
1. Click Manual Setup on the Available Wireless Network screen to set up the adapter manually.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-15: Available Wireless Network
11
Wireless-G Notebook Adapter
2. The Network Settings screen from the Wireless Network Monitor will appear. If your network has a router or
other DHCP server, click the radio button next to Obtain network settings automatically (DHCP).
If your network does not have a DHCP server, click the radio button next to Specify network settings. Enter
an IP Address, Subnet Mask, Default Gateway, and DNS addresses appropriate for your network. You must
specify the IP Address and Subnet Mask on this screen. If you are unsure about the Default Gateway and DNS
addresses, leave these fields empty.
IP Address - This IP Address must be unique to your network.
Subnet Mask - The Adapter’s Subnet Mask must be the same as your wired network’s Subnet Mask.
Default Gateway - Enter the IP address of your network’s Gateway here.
DNS 1 and DNS 2 - Enter the DNS address of your wired Ethernet network here.
Click the Next button to continue, or click the Back button to return to the previous screen.
3. The Wireless Mode screen shows a choice of two wireless modes. Click the Infrastructure Mode radio
button if you want to connect to a wireless router or access point. Click the Ad-Hoc Mode radio button if you
want to connect to another wireless device directly without using a wireless router or access point. Enter the
SSID for your network.
Figure 4-16: Network Settings
Infrastructure Mode - Use this mode if you want to connect to a wireless router or access point.
Ad-Hoc Mode - Use this mode if you want to connect to another wireless device directly without using a
wireless router or access point.
SSID - This is the wireless network name that must be used for all the devices in your wireless network. It is
case- sensitive and should be a unique name to help prevent others from entering your network.
Click the Next button to continue, or click the Back button to return to the previous screen.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-17: Wireless Mode
12
Wireless-G Notebook Adapter
4. If you chose Infrastructure Mode, go to Step 5 now. If you chose Ad-Hoc Mode, the Ad-Hoc Mode Settings
screen will appear.
Select the correct operating channel for your wireless network. The channel you choose should match the
channel set on the other devices in your wireless network. If you are unsure about which channel to use, keep
the default setting.
NOTE: Channels 12 and 13 are not available for Adapters sold in North, Central, and South
America. If you set the Adapter to channel 12 or 13, it will use channel 1 or 11 instead.
Click the Next button. Click the Back button to change any settings.
5. If your wireless network doesn’t have wireless security, select Disabled and then click the Next button to
continue. Proceed to Step 6.
If your wireless network has wireless security, select the method of security used: WEP, WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, RADIUS, or LEAP. WEP stands for Wired Equivalent
Privacy, and WPA stands for Wi-Fi Protected Access. WPA is a stronger security method than WEP. WPA2 is a
stronger version of WPA. RADIUS stands for Remote Authentication Dial-In User Service, and LEAP stands for
Lightweight Extensible Authentication Protocol. Click the Next button to continue or the Back button to return
to the previous screen.
Figure 4-18: Ad-Hoc Mode Settings
Proceed to the appropriate section for your security method: WEP, WPA-Personal, WPA2-Personal, WPAEnterprise, WPA2-Enterprise, RADIUS, or LEAP.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-19: Wireless Security - Disabled
13
Wireless-G Notebook Adapter
WEP
WEP - Select 64-bit or 128-bit encryption
Passphrase - Enter a passphrase in the Passphrase field, so a WEP key is automatically generated. It is case-
sensitive and should not be longer than 16 alphanumeric characters. This passphrase must match the
passphrase of your other wireless network devices and is compatible with Linksys wireless products only. (If
you have any non-Linksys wireless products, enter the WEP key manually on those products.)
WEP Key - The WEP key you enter must match the WEP key of your wireless network. For 64-bit encryption,
enter exactly 10 hexadecimal characters. For 128-bit encryption, enter exactly 26 hexadecimal characters.
Valid hexadecimal characters are “0” to “9” and “A” to “F”.
Advanced Users
TX Key - The default transmit key number is 1. If your network’s access point or wireless router uses transmit
key number 2, 3, or 4, select the appropriate number from the TX Key drop-down box.
Authentication -The default is set to Auto, so it will auto-detect for Shared Key or Open System
authentication. For Shared Key authentication, both the sender and the recipient share a WEP key for
authentication. For Open System authentication, the sender and the recipient do not share a WEP key for
authentication. If you are not sure which authentication method to select, keep the default, Auto.
Click the Next button to continue, or click the Back button to return to the previous screen.
Figure 4-20: Wireless Security - WEP
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-21: WEP Settings
14
Wireless-G Notebook Adapter
WPA-Personal
WPA-Personal offers two encryption methods, TKIP and AES, with dynamic encryption keys. Select TKIP or
AES for encryption. Then enter a Passphrase that is 8-63 characters in length.
Encryption - Select the type of algorithm you want to use, TKIP or AES, from the Encryption drop-down
menu.
Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.
Click the Next button to continue or the Back button to return to the previous screen.
Figure 4-22: Wireless Security - WPA-Personal
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-23: WPA-Personal Settings
15
Wireless-G Notebook Adapter
WPA2-Personal
WPA2-Personal offers AES with dynamic encryption keys. Enter a Passphrase that is 8-63 characters in
length.
Encryption - AES is automatically selected from the Encryption drop-down menu.
Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.
Click the Next button to continue or the Back button to return to the previous screen.
Figure 4-24: Wireless Security - WPA2-Personal
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-25: WPA2-Personal Settings
16
Wireless-G Notebook Adapter
WPA-Enterprise
WPA-Enterprise features WPA security used in coordination with a RADIUS server. (This should only be used
when a RADIUS server is connected to the Router.) WPA-Enterprise offers two authentication methods, EAPTLS and PEAP, as well as two encryption methods, TKIP and AES, with dynamic encryption keys.
Authentication - Select the authentication method your network is using, EAP-TLS or PEAP.
EAP-TLS
If you selected EAP-TLS, enter the login name of your wireless network in the Login Name field. Enter the
name of the authentication server in the Server Name field (this is optional). From the Certificate drop-down
menu, select the certificate you have installed to authenticate you on your wireless network. Select the type
of encryption, TKIP or AES, from the Encryption drop-down menu.
Click the Next button to continue or the Back button to return to the previous screen.
If you selected PEAP, enter the login name of your wireless network in the Login Name field. Enter the
password of your wireless network in the Password field. Enter the name of the authentication server in the
Server Name field (this is optional). From the Certificate drop-down menu, select the certificate you have
installed to authenticate you on your wireless network; if you want to use any certificate, keep the default
setting, Tru s t An y. Then select the authentication method used inside the PEAP tunnel. Select the type of
encryption, TKIP or AES, from the Encryption drop-down menu.
Click the Next button to continue or the Back button to return to the previous screen.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
WPA2-Enterprise features WPA2 security used in coordination with a RADIUS server. (This should only be used
when a RADIUS server is connected to the Router.) WPA2-Enterprise offers two authentication methods, EAPTLS and PEAP, as well as AES with dynamic encryption keys.
Authentication - Select the authentication method your network is using, EAP-TLS or PEAP.
EAP-TLS
If you selected EAP-TLS, enter the login name of your wireless network in the Login Name field. Enter the
name of the authentication server in the Server Name field (this is optional). From the Certificate drop-down
menu, select the certificate you have installed to authenticate you on your wireless network. AES is
automatically selected from the Encryption drop-down menu.
Click the Next button to continue or the Back button to return to the previous screen.
If you selected PEAP, enter the login name of your wireless network in the Login Name field. Enter the
password of your wireless network in the Password field. Enter the name of the authentication server in the
Server Name field (this is optional). From the Certificate drop-down menu, select the certificate you have
installed to authenticate you on your wireless network; if you want to use any certificate, keep the default
setting, Trust Any. Then select the authentication method used inside the PEAP tunnel. AES is automatically
selected from the Encryption drop-down menu.
Click the Next button to continue or the Back button to return to the previous screen.
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
RADIUS features use of a RADIUS server. (This should only be used when a RADIUS server is connected to the
Router.) RADIUS offers two authentication types: EAP-TLS and PEAP.
Authentication - Select the authentication method your network is using, EAP-TLS or PEAP.
EAP-TLS
If you selected EAP-TLS, enter the login name of your wireless network in the Login Name field. Enter the
name of the authentication server in the Server Name field (this is optional). From the Certificate drop-down
menu, select the certificate you have installed to authenticate you on your wireless network.
Click the Next button to continue or the Back button to return to the previous screen.
PEAP
If you selected PEAP, enter the login name of your wireless network in the Login Name field. Enter the
password of your wireless network in the Password field. Enter the name of the authentication server in the
Server Name field (this is optional). From the Certificate drop-down menu, select the certificate you have
installed to authenticate you on your wireless network; if you want to use any certificate, keep the default
setting, Trust Any. Then select the authentication method used inside the PEAP tunnel.
Click the Next button to continue or the Back button to return to the previous screen.
Figure 4-30: Wireless Security - RADIUS - EAP-TLS
Figure 4-31: Wireless Security - RADIUS - PEAP
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
19
Wireless-G Notebook Adapter
LEAP
If you selected LEAP, then enter the Username and Password that will authenticate you on your wireless
network.
Username - Enter the username used for authentication.
Password - Enter the password used for authentication.
Confirm - Enter the password again.
Click the Next button to continue, or click the Back button to return to the previous screen.
Figure 4-32: Wireless Security - LEAP
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-33: LEAP Settings
20
Wireless-G Notebook Adapter
6. The Confirm New Settings screen will appear next and show the new settings. To save the new settings, click
the Save button. To edit the new settings, click the Back button. To exit the Manual Setup through the
Wireless Network Monitor, click Exit.
7. The Congratulations screen will appear next. Click Connect to Network to implement the new settings
immediately and return to the Link Information screen. Click Return to Profiles Screen to keep the current
settings active and return to the Profiles screen.
Figure 4-34: Confirm New Settings
Congratulations! Your manual setup through the Wireless Network Monitor is complete.
To check the link information, search for available wireless networks, or make additional configuration
changes, proceed to “Chapter 5: Using the Wireless Network Monitor.”
Chapter 4: Setting up and Connecting the Wireless-G Notebook Adapter
Setting up the Adapter
Figure 4-35: Congratulations Screen
21
Wireless-G Notebook Adapter
Chapter 5: Using the Wireless Network Monitor
Use the Wireless Network Monitor to check the link information, search for available wireless networks, or create
profiles that hold different configuration settings.
Accessing the Wireless Network Monitor
After installing the Adapter, the Wireless Network Monitor icon will appear in the system tray of your computer. If
the Wireless Network Monitor is enabled, then the icon will be green. If the Wireless Network Monitor is disabled
or the Adapter is not connected, then the icon will be gray.
Figure 5-1: Wireless Network Monitor Icon
Using the Wireless Network Monitor
The opening screen of the Wireless Network Monitor is the Link Information screen. From this screen, you can
find out how strong the current wireless signal is and how good the connection’s quality is. You can also click the
More Information button to view additional status information about the current wireless connection. To search
for available wireless networks, click the Site Survey tab. To perform configuration changes or create connection
profiles, click the Profiles tab.
The SES button is available on all screens so you can add the device to a SES network at any time.
Link Information
The Link Information screen displays network mode, signal strength, and link quality information about the
current connection. It also provides a button to click for additional status information.
Ad-Hoc Mode or Infrastructure Mode - The screen indicates whether the Adapter is currently working in adhoc or infrastructure mode.
Signal Strength - The Signal Strength bar indicates signal strength.
Link Quality - The Link Quality bar indicates the quality of the wireless network connection.
Click the More Information button to view additional information about the wireless network connection on the
Wireless Network Status screen.
Chapter 5: Using the Wireless Network Monitor
Accessing the Wireless Network Monitor
Figure 5-2: Link Information
22
Wireless-G Notebook Adapter
Wireless Network Status
The Wireless Network Status screen provides information on your current network settings.
Status - This shows the status of the wireless network connection.
SSID - This is the unique name of the wireless network.
Wireless Mode - The mode of the wireless network currently in use is displayed here.
Transfer Rate - The data transfer rate of the current connection is shown here.
Channel - This is the channel to which the wireless network devices are set.
Security - The status of the wireless security feature is displayed here.
Authentication - This is your wireless network’s authentication method.
IP Address - The IP Address of the Adapter is displayed here.
Subnet Mask - The Subnet Mask of the Adapter is shown here.
Default Gateway - The Default Gateway address of the Adapter is displayed here.
DNS - This is the DNS address of the Adapter.
DHCP Client - This displays the Adapter’s status as a DHCP client.
MAC Address- The MAC address of the wireless network’s access point or wireless router is shown here.
Signal Strength - The Signal Strength bar indicates the signal strength.
Link Quality - The Link Quality bar indicates the quality of the wireless network connection.
Click the Statistics button to go to the Wireless Network Statistics screen. Click the Back button to return to the
initial Link Information screen. Click the Save to Profile button to save the currently active connection settings to
a profile.
Figure 5-3: More Information - Wireless Network Status
Chapter 5: Using the Wireless Network Monitor
Link Information
23
Wireless-G Notebook Adapter
Wireless Network Statistics
The Wireless Networks Statistics screen provides statistics on your current network settings.
Transmit Rate - This is the data transfer rate of the current connection. (In Auto mode, the Adapter dynamically
shifts to the fastest data transfer rate possible at any given time.)
Receive Rate - This is the rate at which data is received.
Packets Received - This shows the packets received by the Adapter, in real time, since connecting to the
wireless network or since the Refresh Statistics button was last pressed.
Packets Transmitted - This shows the packets transmitted from the Adapter, in real time, since connecting to
the wireless network or since the Refresh Statistics button was last pressed.
Noise Level - This shows the level of background noise affecting the wireless signal. A lower reading translates
into a higher quality signal.
Signal Strength - This is the intensity of the wireless signal received by the Adapter.
Driver Version - This shows the version of the Adapter’s driver.
Signal Strength - The Signal Strength bar indicates the signal strength.
Link Quality - The Link Quality bar indicates the quality of the wireless network connection.
Click the Back button to return to the initial Link Information screen. Click the Status button to go to the Wireless
Network Status screen. Click the Save to Profile button to save the currently active connection settings to a
profile. Click the Refresh button to reset the statistics.
Figure 5-4: More Information-Network Statistics
Chapter 5: Using the Wireless Network Monitor
Link Information
24
Wireless-G Notebook Adapter
Site Survey
The Site Survey screen displays a list of available networks in the table on the left. The table shows each
network’s SSID, Channel, and the quality of the wireless signal the Adapter is receiving. You may click SSID, CH
(Channel), or Signal, to sort by that field.
SSID - The SSID or unique name of the wireless network is displayed here.
CH - This is the channel that the network uses.
Signal - This is the percentage of signal strength, from 0 to 100%.
Site Information
For each network selected, the following settings are listed:
SSID - This the SSID or unique name of the wireless network.
Wireless Mode - This is the mode of the wireless network currently in use.
Channel - This is the channel to which the wireless network devices are set.
Security - The status of the wireless security feature is displayed here.
MAC Address- The MAC address of the wireless network’s access point is displayed here.
Refresh - Click the Refresh button to perform a new search for wireless devices.
Connect - To connect to one of the networks on the list, select the wireless network, and click the Connect
button. If the network has encryption enabled, then you will see a new screen appear.
If the network has the wireless security WEP encryption enabled, then you will see the WEP Key Needed for Connection screen. Select the appropriate level of WEP encryption, 64-bit or 128-bit). Then enter the network’s
Passphrase or WEP Key. Click the Connect button. To cancel the connection, click the Cancel button.
Figure 5-5: Site Survey
Chapter 5: Using the Wireless Network Monitor
Site Survey
Figure 5-6: WEP Key Needed for Connection
25
Wireless-G Notebook Adapter
If the network has the wireless security WPA-Personal security enabled, then you will see the WPA-Personal
Needed for Connection screen. Select the appropriate encryption type, TKIP or AES. Enter the network’s
Passphrase or pre-shared key in the Passphrase field. Then click the Connect button. To cancel the connection,
click the Cancel button.
If the network has the wireless security WPA2-Personal security enabled, then you will see the WPA2-Personal Needed for Connection screen. Enter the network’s Passphrase or pre-shared key in the Passphrase field. Then
click the Connect button. To cancel the connection, click the Cancel button.
Figure 5-7: WPA-Personal Needed for Connection
Chapter 5: Using the Wireless Network Monitor
Site Survey
Figure 5-8: WPA2-Personal Needed for Connection
26
Wireless-G Notebook Adapter
Profiles
The Profiles screen lets you save different configuration profiles for different network setups. The table on the left
displays a list of available profiles with their profile names and SSIDs.
Profile - The name of the profile is displayed here.
SSID - The SSID or unique name of the wireless network is displayed here.
Profile Information
For each profile selected, the following are listed:
Wireless Mode - This is the mode of the wireless network currently in use.
Transfer Rate - The data transfer rate of the current connection is shown here.
Channel - This is the channel to which the wireless network devices are set.
Security - The status of the wireless security feature is displayed here.
Authentication - The authentication setting for the network is shown here.
Connect - To connect to a wireless network using a specific profile, select the profile, and click the Connect
button.
New - Click the New button to create a new profile. See the next section, “Creating a New Profile,” for detailed
instructions.
Edit - Select the profile you want to change, and then click the Edit button.
Import - Click the Import button to import a profile that has been saved in another location. Select the appropriate file, and click the Open button.
Export - Select the profile you want to save in a different location, and click the Export button. Direct Windows to the appropriate folder, and click the Save button.
NOTE: If you want to export more than one profile, you have to export them one at a time.
Delete - Select the profile you want to delete, and then click the Delete button.
Figure 5-9: Profiles
Figure 5-10: Import a Profile
Figure 5-11: Export a Profile
Chapter 5: Using the Wireless Network Monitor
Profiles
27
Wireless-G Notebook Adapter
Creating a New Profile
On the Profiles screen, click the New button to create a new profile. Enter a name for the new profile, and click
the OK button. Click the Cancel button to return to the Profiles screen without entering a name.
The Available Wireless Network screen will appear. This screen provides three options for setting up the Adapter
• SecureEasySetup. This Adapter features SecureEasySetup. This means that you can set it up with just the
press of a button when connecting to wireless routers or access points that also feature SecureEasySetup.
Both point on the network must feature SecureEasySetup for this to work.
• Available Networks. (For most users.) Use this option if you already have a network set up with devices that
do not have SecureEasySetup. The networks available to this Adapter will be listed on this screen. You can
choose one of these networks and click the Connect button to connect to it. Click the Refresh button to
update the Available Wireless Network list.
• Manual Setup. If you are not taking advantage of SecureEasySetup and your network is not listed on this
screen, select Manual Setup to set up the adapter manually. This method of setting up the Adapter is
intended for Advanced Users only.
The setup for each option is described, step by step, under the appropriate heading on the following pages.
Click Exit to close the Setup Wizard.
Figure 5-12: Create a New Profile
Figure 5-13: Available Wireless Network
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
28
Wireless-G Notebook Adapter
SecureEasySetup
With SecureEasySetup, setting up the Adapter is as simple as pushing a couple of buttons. Before you press any
buttons, though, you should locate the SecureEasySetup button on the device you’re connecting the Adapter to,
such as a wireless router or access point.
1. Starting from the Available Wireless Network screen, click the SecureEasySetup button on the right hand
side.
2. You will be asked to locate the SecureEasySetup button on the device with which the Adapter will be
communicating. If you are not sure where to find this button, click Where can I find the button?.
This will walk you through a couple of screens to help you find the button, which is usually located on the
front of the wireless router or access point.
3. Press the Cisco logo or SecureEasySetup button on the wireless router or access point. When it turns white
and begins to flash, click the Next button on the Setup Wizard screen. The logo or button will stop flashing on
the wireless router or access point when the Adapter has been successfully added to the network. Repeat
this procedure for any additional SecureEasySetup device.
Figure 5-14: SecureEasySetup Screen
Figure 5-15: SecureEasySetup Logo
NOTE: You can only add one SecureEasySetup device at a time.
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-16: SecureEasySetup Logo Location
29
Wireless-G Notebook Adapter
4. When SecureEasySetup is complete, you may save your configuration to a text file by clicking the Save
button, or print the configuration by clicking the Print button. Click Connect to Network to connect to your
network.
Congratulations! The setup is complete.
Available Networks
If you’re not setting up the Adapter with SecureEasySetup, another method for setting up the Adapter is with the
available networks listed on the Available Wireless Network screen. The available networks are listed in the table
on the center of the screen by SSID. Select the wireless network you wish to connect to and click the Connect
button. (If you do not see your network listed, you can click the Refresh button to bring the list up again.) If the
network utilizes wireless security, you will need to configure security on the Adapter. If not, you will be taken
directly to the Congratulations screen.
Figure 5-17: Congratulations
1. If you have wireless security enabled on your network, continue to step 2. If you don’t have wireless security
enabled, continue to step 3.
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-18: Available Wireless Network
30
Wireless-G Notebook Adapter
2. If your network has the wireless security WEP (Wired Equivalent Privacy) enabled, this screen will appear.
Select 64-bit or 128-bit.
Then enter a passphrase or WEP key.
Passphrase - Enter a passphrase in the Passphrase field, so a WEP key is automatically generated. The
passphrase is case-sensitive and should not be longer than 16 alphanumeric characters. It must match the
passphrase of your other wireless network devices and is compatible with Linksys wireless products only. (If
you have any non-Linksys wireless products, enter the WEP key manually on those products.)
WEP Key - The WEP key you enter must match the WEP key of your wireless network. For 64-bit encryption,
enter exactly 10 hexadecimal characters. For 128-bit encryption, enter exactly 26 hexadecimal characters.
Valid hexadecimal characters are “0” to “9” and “A” to “F”.
Then click Connect.
If your network has the wireless security WPA-Personal (Wi-Fi Protected Access) enabled, this screen will
appear.
Encryption - Select the type of algorithm you want to use, TKIP or AES, from the Encryption drop-down
menu.
Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.
Then click Connect.
Figure 5-19: WEP Key Needed for Connection
Figure 5-20: WPA-Personal Needed for Connection
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
31
Wireless-G Notebook Adapter
If your network has the wireless security WPA2-Personal (the stronger version of Wi-Fi Protected Access)
enabled, this screen will appear.
Encryption - AES is automatically selected from the Encryption drop-down menu.
Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.
Then click Connect.
3. After the software has been successfully installed, the Congratulations screen will appear. Click Connect to
Network to connect to your network.
Figure 5-21: WPA2-Personal Needed for Connection
Congratulations! The setup is complete.
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-22: Congratulations
32
Wireless-G Notebook Adapter
Manual Setup
1. The Network Settings screen will appear. If your network has a router or other DHCP server, click the radio
button next to Obtain network settings automatically (DHCP).
If your network does not have a DHCP server, click the radio button next to Specify network settings. Enter
an IP Address, Subnet Mask, Default Gateway, and DNS addresses appropriate for your network. You must
specify the IP Address and Subnet Mask on this screen. If you are unsure about the Default Gateway and DNS
addresses, leave these fields empty.
IP Address - This IP Address must be unique to your network.
Subnet Mask - The Adapter’s Subnet Mask must be the same as your wired network’s Subnet Mask.
Default Gateway - Enter the IP address of your network’s Gateway here.
DNS 1 and DNS 2 - Enter the DNS address of your wired Ethernet network here.
Click the Next button to continue, or click the Back button to return to the previous screen.
2. The Wireless Mode screen shows a choice of two wireless modes. Click the Infrastructure Mode radio
button if you want to connect to a wireless router or access point. Click the Ad-Hoc Mode radio button if you
want to connect to another wireless device directly without using a wireless router or access point. Enter the
SSID for your network.
Infrastructure Mode - Use this mode if you want to connect to a wireless router or access point.
Ad-Hoc Mode - Use this mode if you want to connect to another wireless device directly without using a
wireless router or access point.
SSID - This is the wireless network name that must be used for all the devices in your wireless network. It is
case- sensitive and should be a unique name to help prevent others from entering your network.
Click the Next button to continue or the Back button to return to the previous screen.
Figure 5-23: Network Settings for New Profile
Figure 5-24: Wireless Mode for New Profile
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
33
Wireless-G Notebook Adapter
3. If you chose Infrastructure Mode, go to Step 4 now. If you chose Ad-Hoc Mode, the Ad-Hoc Mode Settings
screen will appear.
Select the correct operating channel for your wireless network. The channel you choose should match the
channel set on the other devices in your wireless network. If you are unsure about which channel to use, keep
the default setting.
NOTE: Channels 12 and 13 are not available for Adapters sold in North, Central, and South
America. If you set the Adapter to channel 12 or 13, it will use channel 1 or 11 instead.
Click the Next button. Click the Back button to change any settings.
4. If your wireless network doesn’t have wireless security, select Disabled and then click the Next button to
continue. Proceed to Step 5.
If your wireless network has wireless security, select the method of security used: WEP, WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, RADIUS, or LEAP. WEP stands for Wired Equivalent
Privacy, and WPA stands for Wi-Fi Protected Access. WPA is a stronger security method than WEP. WPA2 is a
stronger version of WPA. RADIUS stands for Remote Authentication Dial-In User Service, and LEAP stands for
Lightweight Extensible Authentication Protocol. Click the Next button to continue or the Back button to return
to the previous screen.
Figure 5-25: Ad-Hoc Mode Settings for New Profile
Proceed to the appropriate section for your security method: WEP, WPA-Personal, WPA2-Personal, WPAEnterprise, WPA2-Enterprise, RADIUS, or LEAP.
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-26: Wireless Security - Disabled
34
Wireless-G Notebook Adapter
WEP
WEP - Select 64-bit or 128-bit encryption
Passphrase - Enter a passphrase in the Passphrase field, so a WEP key is automatically generated. It is case-
sensitive and should not be longer than 16 alphanumeric characters. This passphrase must match the
passphrase of your other wireless network devices and is compatible with Linksys wireless products only. (If
you have any non-Linksys wireless products, enter the WEP key manually on those products.)
WEP Key - The WEP key you enter must match the WEP key of your wireless network. For 64-bit encryption,
enter exactly 10 hexadecimal characters. For 128-bit encryption, enter exactly 26 hexadecimal characters.
Valid hexadecimal characters are “0” to “9” and “A” to “F”.
Advanced Users
TX Key - The default transmit key number is 1. If your network’s access point or wireless router uses transmit
key number 2, 3, or 4, select the appropriate number from the TX Key drop-down box.
Authentication -The default is set to Auto, so it will auto-detect for Shared Key or Open System
authentication. For Shared Key authentication, both the sender and the recipient share a WEP key for
authentication. For Open System authentication, the sender and the recipient do not share a WEP key for
authentication. If you are not sure which authentication method to select, keep the default, Auto.
Click the Next button to continue, or click the Back button to return to the previous screen.
Figure 5-27: Wireless Security - WEP for New Profile
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-28: WEP Settings
35
Wireless-G Notebook Adapter
WPA-Personal
WPA-Personal offers two encryption methods, TKIP and AES, with dynamic encryption keys. Select TKIP or
AES for encryption. Then enter a Passphrase that is 8-63 characters in length.
Encryption - Select the type of algorithm you want to use, TKIP or AES, from the Encryption drop-down
menu.
Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.
Click the Next button to continue or the Back button to return to the previous screen.
Figure 5-29: Wireless Security - WPA-Personal for
New Profile
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-30: WPA-Personal Settings
36
Wireless-G Notebook Adapter
WPA2-Personal
WPA2-Personal offers AES with dynamic encryption keys. Enter a Passphrase that is 8-63 characters in
length.
Encryption - AES is automatically selected from the Encryption drop-down menu.
Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.
Click the Next button to continue or the Back button to return to the previous screen.
Figure 5-31: Wireless Security - WPA2-Personal for
New Profile
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-32: WPA2-Personal Settings
37
Wireless-G Notebook Adapter
WPA-Enterprise
WPA-Enterprise features WPA security used in coordination with a RADIUS server. (This should only be used
when a RADIUS server is connected to the Router.) WPA-Enterprise offers two authentication methods, EAPTLS and PEAP, as well as two encryption methods, TKIP and AES, with dynamic encryption keys.
Authentication - Select the authentication method your network is using, EAP-TLS or PEAP.
EAP-TLS
If you selected EAP-TLS, enter the login name of your wireless network in the Login Name field. Enter the
name of the authentication server in the Server Name field (this is optional). From the Certificate drop-down
menu, select the certificate you have installed to authenticate you on your wireless network. Select the type
of encryption, TKIP or AES, from the Encryption drop-down menu.
Click the Next button to continue or the Back button to return to the previous screen.
PEAP
If you selected PEAP, enter the login name of your wireless network in the Login Name field. Enter the
password of your wireless network in the Password field. Enter the name of the authentication server in the
Server Name field (this is optional). From the Certificate drop-down menu, select the certificate you have
installed to authenticate you on your wireless network; if you want to use any certificate, keep the default
setting, Trust Any. Then select the authentication method used inside the PEAP tunnel. Select the type of
encryption, TKIP or AES, from the Encryption drop-down menu.
Figure 5-33: Wireless Security - WPA-Enterprise Using
EAP-TLS for New Profile
Figure 5-34: Wireless Security - WPA-Enterprise Using
PEAP for New Profile
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
38
Wireless-G Notebook Adapter
WPA2-Enterprise
WPA2-Enterprise features WPA2 security used in coordination with a RADIUS server. (This should only be used
when a RADIUS server is connected to the Router.) WPA2-Enterprise offers two authentication methods, EAPTLS and PEAP, as well as AES with dynamic encryption keys.
Authentication - Select the authentication method your network is using, EAP-TLS or PEAP.
EAP-TLS
If you selected EAP-TLS, enter the login name of your wireless network in the Login Name field. Enter the
name of the authentication server in the Server Name field (this is optional). From the Certificate drop-down
menu, select the certificate you have installed to authenticate you on your wireless network. AES is
automatically selected from the Encryption drop-down menu.
Click the Next button to continue or the Back button to return to the previous screen.
PEAP
Figure 5-35: Wireless Security - WPA2-Enterprise Using
EAP-TLS for New Profile
If you selected PEAP, enter the login name of your wireless network in the Login Name field. Enter the
password of your wireless network in the Password field. Enter the name of the authentication server in the
Server Name field (this is optional). From the Certificate drop-down menu, select the certificate you have
installed to authenticate you on your wireless network; if you want to use any certificate, keep the default
setting, Trust Any. Then select the authentication method used inside the PEAP tunnel. AES is automatically
selected from the Encryption drop-down menu.
Click the Next button to continue or the Back button to return to the previous screen.
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-36: Wireless Security - WPA2-Enterprise Using
PEAP for New Profile
39
Wireless-G Notebook Adapter
RADIUS
RADIUS features use of a RADIUS server. (This should only be used when a RADIUS server is connected to the
Router.) RADIUS offers two authentication types: EAP-TLS and PEAP.
Authentication - Select the authentication method your network is using, EAP-TLS or PEAP.
EAP-TLS
If you selected EAP-TLS, enter the login name of your wireless network in the Login Name field. Enter the
name of the authentication server in the Server Name field (this is optional). From the Certificate drop-down
menu, select the certificate you have installed to authenticate you on your wireless network.
Click the Next button to continue or the Back button to return to the previous screen.
PEAP
If you selected PEAP, enter the login name of your wireless network in the Login Name field. Enter the
password of your wireless network in the Password field. Enter the name of the authentication server in the
Server Name field (this is optional). From the Certificate drop-down menu, select the certificate you have
installed to authenticate you on your wireless network; if you want to use any certificate, keep the default
setting, Trust Any. Then select the authentication method used inside the PEAP tunnel.
Click the Next button to continue or the Back button to return to the previous screen.
Figure 5-37: Wireless Security - RADIUS Using EAP-TLS
for New Profile
Figure 5-38: Wireless Security - RADIUS Using PEAP for
New Profile
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
40
Wireless-G Notebook Adapter
LEAP
If you selected LEAP, then enter the Username and Password that will authenticate you on your wireless
network.
Username - Enter the username used for authentication.
Password - Enter the password used for authentication.
Confirm - Enter the password again.
Click the Next button to continue, or click the Back button to return to the previous screen.
Figure 5-39: Wireless Security - LEAP for New Profile
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-40: LEAP Settings
41
Wireless-G Notebook Adapter
4. The Confirm New Settings screen will appear next and show the new settings. To save the new settings, click
the Save button. To edit the new settings, click the Back button. To exit the Wireless Network Monitor, click
Exit.
5. The Congratulations screen will appear next. Click Connect to Network to implement the new settings
immediately and return to the Link Information screen. Click Return to Profiles Screen to keep the current
settings active and return to the Profiles screen.
Figure 5-41: Confirm New Settings for New Profile
You have successfully created a connection profile.
Chapter 5: Using the Wireless Network Monitor
Creating a New Profile
Figure 5-42: Congratulations for New Profile
42
Wireless-G Notebook Adapter
Appendix A: Troubleshooting
This appendix consists of two parts: “Common Problems and Solutions” and “Frequently Asked Questions.” This
appendix provides solutions to problems that may occur during the installation and operation of the Wireless-G
Notebook Adapter. Read the description below to solve your problems. If you can't find an answer here, check the
Linksys website at www.linksys.com/international.
Common Problems and Solutions
1. My computer does not recognize the Wireless-G Notebook Adapter.
Make sure that the Wireless-G Notebook Adapter is properly inserted into the CardBus slot.
2. The Wireless-G Notebook Adapter does not work properly.
Reinsert the Wireless-G Notebook Adapter into the notebook’s CardBus port.
For Windows 98SE or Me, right-click on My Computer, and select Properties. Select the Device Manager
tab, and click on the Network Adapter. You will find the Wireless-G Notebook Adapter if it is installed
successfully. If you see a yellow exclamation mark, the resources may be conflicting and you must follow the
steps below:
• Uninstall the driver software from your PC.
• Restart your PC and repeat the hardware and software installation as specified in this User Guide.
3. I cannot communicate with the other computers linked via Ethernet in the Infrastructure
configuration.
Make sure that the notebook is powered on.
Make sure that the Wireless-G Notebook Adapter is configured with the same SSID and security settings as
the other computers in the Infrastructure configuration.
Appendix A: Troubleshooting
Common Problems and Solutions
43
Wireless-G Notebook Adapter
Frequently Asked Questions
Can I run an application from a remote computer over the wireless network?
This will depend on whether or not the application is designed to be used over a network. Consult the
application’s user guide to determine if it supports operation over a network.
Can I play computer games with other members of the wireless network?
Yes, as long as the game supports multiple players over a LAN (local area network). Refer to the game’s user
guide for more information.
What is the IEEE 802.11g standard?
It is one of the IEEE standards for wireless networks. The 802.11g standard allows wireless networking hardware
from different manufacturers to communicate, provided that the hardware complies with the 802.11g standard.
The 802.11g standard states a maximum data transfer rate of 54Mbps and an operating frequency of 2.4GHz.
What is the IEEE 802.11b standard?
It is one of the IEEE standards for wireless networks. The 802.11b standard allows wireless networking hardware
from different manufacturers to communicate, provided that the hardware complies with the 802.11b standard.
The 802.11b standard states a maximum data transfer rate of 11Mbps and an operating frequency of 2.4GHz.
What IEEE 802.11g features are supported?
The product supports the following IEEE 802.11g functions:
• CSMA/CA plus Acknowledge protocol
• OFDM protocol
• Multi-Channel Roaming
• Automatic Rate Selection
• RTS/CTS feature
• Fragmentation
• Power Management
What IEEE 802.11b features are supported?
The product supports the following IEEE 802.11b functions:
When a wireless network is set to ad-hoc mode, the wireless-equipped computers are configured to
communicate directly with each other. This type of network will not communicate with any wired network.
What is infrastructure mode?
When a wireless network is set to infrastructure mode, the wireless network is configured to communicate with a
wired network through a wireless access point.
What is roaming?
Roaming is the ability of a portable computer user to communicate continuously while moving freely throughout
an area greater than that covered by a single access point. Before using the roaming function, the workstation
must make sure that it is the same channel number with the access point of dedicated coverage area.
To achieve true seamless connectivity, the wireless LAN must incorporate a number of different functions. Each
node and access point, for example, must always acknowledge receipt of each message. Each node must
maintain contact with the wireless network even when not actually transmitting data. Achieving these functions
simultaneously requires a dynamic RF networking technology that links access points and nodes. In such a
system, the user’s end node undertakes a search for the best possible access to the system. First, it evaluates
such factors as signal strength and quality, as well as the message load currently being carried by each access
point and the distance of each access point to the wired backbone. Based on that information, the node next
selects the right access point and registers its address. Communications between end node and host computer
can then be transmitted up and down the backbone.
As the user moves on, the end node’s RF transmitter regularly checks the system to determine whether it is in
touch with the original access point or whether it should seek a new one. When a node no longer receives
acknowledgment from its original access point, it undertakes a new search. Upon finding a new access point, it
then re-registers, and the communication process continues.
What is ISM band?
The FCC and their counterparts outside of the U.S. have set aside bandwidth for unlicensed use in the ISM
(Industrial, Scientific and Medical) band. Spectrum in the vicinity of 2.4 GHz, in particular, is being made available
worldwide. This presents a truly revolutionary opportunity to place convenient high-speed wireless capabilities in
the hands of users around the globe.
What is Spread Spectrum?
Spread Spectrum technology is a wideband radio frequency technique developed by the military for use in
reliable, secure, mission-critical communications systems. It is designed to trade off bandwidth efficiency for
reliability, integrity, and security. In other words, more bandwidth is consumed than in the case of narrowband
transmission, but the trade-off produces a signal that is, in effect, louder and thus easier to detect, provided that
the receiver knows the parameters of the spread-spectrum signal being broadcast. If a receiver is not tuned to
the right frequency, a spread-spectrum signal looks like background noise. There are two main alternatives,
Direct Sequence Spread Spectrum (DSSS) and Frequency Hopping Spread Spectrum (FHSS).
What is DSSS? What is FHSS? And what are their differences?
Frequency-Hopping Spread-Spectrum (FHSS) uses a narrowband carrier that changes frequency in a pattern that
is known to both transmitter and receiver. Properly synchronized, the net effect is to maintain a single logical
channel. To an unintended receiver, FHSS appears to be short-duration impulse noise. Direct-Sequence SpreadSpectrum (DSSS) generates a redundant bit pattern for each bit to be transmitted. This bit pattern is called a chip
(or chipping code). The longer the chip, the greater the probability that the original data can be recovered. Even if
one or more bits in the chip are damaged during transmission, statistical techniques embedded in the radio can
recover the original data without the need for retransmission. To an unintended receiver, DSSS appears as low
power wideband noise and is rejected (ignored) by most narrowband receivers.
Linksys wants to make wireless networking as safe and easy for you as possible. The current generation of
Linksys products provide several network security features, but they require specific action on your part for
implementation. So, keep the following in mind whenever you are setting up or using your wireless network.
Security Precautions
The following is a complete list of security precautions to take (at least steps 1 through 5 should be followed):
1. Change the default SSID.
2. Disable SSID Broadcast.
3. Change the default password for the Administrator account.
4. Enable MAC Address Filtering.
5. Change the SSID periodically.
6. Use the highest encryption algorithm possible. Use WPA if it is available. Please note that this may reduce
your network performance.
7. Change the WEP encryption keys periodically.
For information on implementing these security features, refer to “Chapter 5: Configuring the Wireless-N
Broadband Router.”
Security Threats Facing Wireless Networks
Wireless networks are easy to find. Hackers know that in order to join a wireless network, wireless networking
products first listen for “beacon messages”. These messages can be easily decrypted and contain much of the
network’s information, such as the network’s SSID (Service Set Identifier). Here are the steps you can take:
Change the administrator’s password regularly. With every wireless networking device you use, keep in mind
that network settings (SSID, WEP keys, etc.) are stored in its firmware. Your network administrator is the only
person who can change network settings. If a hacker gets a hold of the administrator’s password, he, too, can
change those settings. So, make it harder for a hacker to get that information. Change the administrator’s
password regularly.
NOTE: Some of these security features are
available only through the network router or
access point. Refer to the router or access point’s
documentation for more information.
47
Wireless-G Notebook Adapter
SSID. There are several things to keep in mind about the SSID:
1. Disable Broadcast
2. Make it unique
3. Change it often
Most wireless networking devices will give you the option of broadcasting the SSID. While this option may be
more convenient, it allows anyone to log into your wireless network. This includes hackers. So, don’t broadcast
the SSID.
Wireless networking products come with a default SSID set by the factory. (The Linksys default SSID is “linksys”.)
Hackers know these defaults and can check these against your network. Change your SSID to something unique
and not something related to your company or the networking products you use.
Change your SSID regularly so that any hackers who have gained access to your wireless network will have to
start from the beginning in trying to break in.
MAC Addresses. Enable MAC Address filtering. MAC Address filtering will allow you to provide access to only
those wireless nodes with certain MAC Addresses. This makes it harder for a hacker to access your network with
a random MAC Address.
WEP Encryption. Wired Equivalent Privacy (WEP) is often looked upon as a cure-all for wireless security
concerns. This is overstating WEP’s ability. Again, this can only provide enough security to make a hacker’s job
more difficult.
There are several ways that WEP can be maximized:
1. Use the highest level of encryption possible
2. Use “Shared Key” authentication
3. Change your WEP key regularly
WPA. Wi-Fi Protected Access (WPA) is the newest and best available standard in Wi-Fi security. WPA2 is the
newer version of Wi-Fi Protected Access with stronger encryption than WPA. WPA and WPA2 gives you a choice of
two encryption methods: TKIP (Temporal Key Integrity Protocol), which incorporates Message Integrity Code (MIC)
to provide protection against hackers, and AES (Advanced Encryption System), which utilizes a symmetric 128Bit block data encryption. (AES is stronger than TKIP.)
IMPORTANT: Always remember that each device
in your wireless network MUST use the same
security method and key, or else your wireless
network will not function properly.
48
Wireless-G Notebook Adapter
WPA-Enterprise and WPA2-Enterprise use a RADIUS (Remote Authentication Dial-In User Service) server for
authentication. RADIUS uses a RADIUS server and WEP encryption.
WPA/WPA2-Personal. Select the type of algorithm, TKIP or AES, and enter a password in the Pre-shared Key
field of 8-63 characters. Enter a Key Renewal period time between 0 and 99,999 seconds, which instructs the
Router or other device how often it should change the encryption keys.
WPA/WPA2-Enterprise. This method is WPA or WPA2 used in coordination with a RADIUS server. Enter the IP
address and port number of the RADIUS server. Then enter the key shared between the Router and its RADIUS
server. Then enter a Key Renewal period, which instructs the Router or other device how often it should
change the encryption keys.
RADIUS. This method is WEP used in coordination with a RADIUS server. Enter the IP address and port
number of the RADIUS server. Then enter the key shared between the Router and its RADIUS server. Enter the
WEP settings.
Implementing encryption may have a negative impact on your network’s performance, but if you are transmitting
sensitive data over your network, encryption should be used.
These security recommendations should help keep your mind at ease while you are enjoying the most flexible
and convenient technology Linksys has to offer.
Almost all wireless products require Microsoft Windows. Windows is the most used operating system in the world
and comes with many features that help make networking easier. These features can be accessed through
Windows Help and are described in this appendix.
TCP/IP
Before a computer can communicate with an access point or wireless router, TCP/IP must be enabled. TCP/IP is a
set of instructions, or protocol, all PCs follow to communicate over a network. This is true for wireless networks
as well. Your PCs will not be able to utilize wireless networking without having TCP/IP enabled. Windows Help
provides complete instructions on enabling TCP/IP.
Shared Resources
If you wish to share printers, folder, or files over your network, Windows Help provides complete instructions on
utilizing shared resources.
Network Neighborhood/My Network Places
Other PCs on your network will appear under Network Neighborhood or My Network Places (depending upon the
version of Windows you're running). Windows Help provides complete instructions on adding PCs to your
network.
Appendix C: Windows Help
50
Wireless-G Notebook Adapter
Appendix D: Glossary
This glossary contains some basic networking terms you may come across when using this product. For more
advanced terms, see the complete Linksys glossary at http://www.linksys.com/glossary.
Access Point - A device that allows wireless-equipped computers and other devices to communicate with a
wired network. Also used to expand the range of a wireless network.
Ad-hoc - A group of wireless devices communicating directly with each other (peer-to-peer) without the use of
an access point.
AES (Advanced Encryption Standard) - An encryption method that supports these key sizes: 128-bit, 192-bit,
and 256-bit.
Bandwidth - The transmission capacity of a given device or network.
Bit - A binary digit.
Boot - To start a device and cause it to start executing instructions.
Broadband - An always-on, fast Internet connection.
Browser - An application program that provides a way to look at and interact with all the information on the
World Wide Web.
Byte - A unit of data that is usually eight bits long
Cable Modem - A device that connects a computer to the cable television network, which in turn connects to the
Internet.
Daisy Chain - A method used to connect devices in a series, one after the other.
DDNS (Dynamic Domain Name System) - Allows the hosting of a website, FTP server, or e-mail server with a
fixed domain name (e.g., www.xyz.com) and a dynamic IP address.
Default Gateway - A device that forwards Internet traffic from your local area network.
DHCP (Dynamic Host Configuration Protocol) - A networking protocol that allows administrators to assign
temporary IP addresses to network computers by “leasing” an IP address to a user for a limited amount of time,
instead of assigning permanent IP addresses.
Appendix D: Glossary
51
Wireless-G Notebook Adapter
DMZ (Demilitarized Zone) - Removes the Router's firewall protection from one PC, allowing it to be “seen” from
the Internet.
DNS (Domain Name Server) - The IP address of your ISP's server, which translates the names of websites into IP
addresses.
Domain - A specific name for a network of computers.
Download - To receive a file transmitted over a network.
DSL (Digital Subscriber Line) - An always-on broadband connection over traditional phone lines.
Dynamic IP Address - A temporary IP address assigned by a DHCP server.
EAP (Extensible Authentication Protocol) - A general authentication protocol used to control network access.
Many specific authentication methods work within this framework.
Encryption - Encoding data transmitted in a network.
Ethernet - IEEE standard network protocol that specifies how data is placed on and retrieved from a common
transmission medium.
Firewall - A set of related programs located at a network gateway server that protects the resources of a
network from users from other networks.
Firmware - The programming code that runs a networking device.
FTP (File Transfer Protocol) - A protocol used to transfer files over a TCP/IP network.
Full Duplex - The ability of a networking device to receive and transmit data simultaneously.
Gateway - A device that interconnects networks with different, incompatible communications protocols.
Half Duplex - Data transmission that can occur in two directions over a single line, but only one direction at a
time.
HTTP (HyperText Transport Protocol) - The communications protocol used to connect to servers on the World
Wide Web.
Infrastructure - A wireless network that is bridged to a wired network via an access point.
IP (Internet Protocol) - A protocol used to send data over a network.
Appendix D: Glossary
52
Wireless-G Notebook Adapter
IP Address - The address used to identify a computer or device on a network.
IPCONFIG - A Windows 2000 and XP utility that displays the IP address for a particular networking device.
IPSec (Internet Protocol Security) - A VPN protocol used to implement secure exchange of packets at the IP layer.
ISP (Internet Service Provider) - A company that provides access to the Internet.
LAN - The computers and networking products that make up your local network.
MAC (Media Access Control) Address - The unique address that a manufacturer assigns to each networking
device.
Mbps (MegaBits Per Second) - One million bits per second; a unit of measurement for data transmission.
NAT (Network Address Translation) - NAT technology translates IP addresses of a local area network to a different
IP address for the Internet.
Network - A series of computers or devices connected for the purpose of data sharing, storage, and/or
transmission between users.
Packet - A unit of data sent over a network.
Passphrase - Used much like a password, a passphrase simplifies the WEP encryption process by automatically
generating the WEP encryption keys for Linksys products.
Ping (Packet INternet Groper) - An Internet utility used to determine whether a particular IP address is online.
POP3 (Post Office Protocol 3) - A standard mail server commonly used on the Internet.
Port - The connection point on a computer or networking device used for plugging in cables or adapters.
Power over Ethernet (PoE) - A technology enabling an Ethernet network cable to deliver both data and power.
PPPoE (Point to Point Protocol over E
thernet) - A type of broadband connection that provides authentication
(username and password) in addition to data transport.
PPTP (Point-to-Point Tunneling Protocol) - A VPN protocol that allows the Point to Point Protocol (PPP) to be
tunneled through an IP network. This protocol is also used as a type of broadband connection in Europe.
RADIUS (Remote Authentication Dial-In User Service) - A protocol that uses an authentication server to control
network access.
Appendix D: Glossary
53
Wireless-G Notebook Adapter
RJ-45 (Registered Jack-45) - An Ethernet connector that holds up to eight wires.
Roaming - The ability to take a wireless device from one access point's range to another without losing the
connection.
Router - A networking device that connects multiple networks together.
Server - Any computer whose function in a network is to provide user access to files, printing, communications,
and other services.
SMTP (Simple Mail Transfer Protocol) - The standard e-mail protocol on the Internet.
SNMP (Simple Network Management Protocol) - A widely used network monitoring and control protocol.
SPI (Stateful Packet Inspection) Firewall - A technology that inspects incoming packets of information before
allowing them to enter the network.
SSID (Service Set IDentifier) - Your wireless network's name.
Static IP Address - A fixed address assigned to a computer or device that is connected to a network.
Static Routing - Forwarding data in a network via a fixed path.
Subnet Mask - An address code that determines the size of the network.
Switch - 1. A data switch that connects computing devices to host computers, allowing a large number of
devices to share a limited number of ports. 2. A device for making, breaking, or changing the connections in an
electrical circuit.
TCP (Transmission Control Protocol) - A network protocol for transmitting data that requires acknowledgement
from the recipient of data sent.
TCP/IP (Transmission Control Protocol/Internet Protocol) - A set of instructions PCs use to communicate over a
network.
Telnet - A user command and TCP/IP protocol used for accessing remote PCs.
TFTP (Trivial File Transfer Protocol) - A version of the TCP/IP FTP protocol that has no directory or password
capability.
Throughput - The amount of data moved successfully from one node to another in a given time period.
Appendix D: Glossary
54
Wireless-G Notebook Adapter
TKIP (Temporal Key Integrity Protocol) - a wireless encryption protocol that provides dynamic encryption keys for
each packet transmitted.
Topology - The physical layout of a network.
TX Rate - Transmission Rate.
Upgrade - To replace existing software or firmware with a newer version.
Upload - To transmit a file over a network.
URL (Uniform Resource Locator) - The address of a file located on the Internet.
VPN (Virtual Private Network) - A security measure to protect data as it leaves one network and goes to another
over the Internet.
WAN (Wide Area Network)- The Internet.
WEP (Wired Equivalent Privacy) - A method of encrypting network data transmitted on a wireless network for
greater security.
WLAN (Wireless Local Area Network) - A group of computers and associated devices that communicate with
each other wirelessly.
WPA (Wi-Fi Protected Access) - a wireless security protocol using TKIP (Temporal Key Integrity Protocol)
encryption, which can be used in conjunction with a RADIUS server.
Appendix D: Glossary
55
Wireless-G Notebook Adapter
Appendix E: Specifications
StandardsIEEE 802.11g, IEEE 802.11b, CardBus
Channels11 Channels (most of North, Central, and South America)
Linksys warrants to You that, for a period of three years (the “Warranty Period”), your Linksys Product will be substantially
free of defects in materials and workmanship under normal use. Your exclusive remedy and Linksys' entire liability under
this warranty will be for Linksys at its option to repair or replace the Product or refund Your purchase price less any rebates.
This limited warranty extends only to the original purchaser.
If the Product proves defective during the Warranty Period call Linksys Technical Support in order to obtain a Return
Authorization Number, if applicable. BE SURE TO HAVE YOUR PROOF OF PURCHASE ON HAND WHEN CALLING. If You are
requested to return the Product, mark the Return Authorization Number clearly on the outside of the package and include a
copy of your original proof of purchase. RETURN REQUESTS CANNOT BE PROCESSED WITHOUT PROOF OF PURCHASE. You
are responsible for shipping defective Products to Linksys. Linksys pays for UPS Ground shipping from Linksys back to You
only. Customers located outside of the United States of America and Canada are responsible for all shipping and handling
charges.
ALL IMPLIED WARRANTIES AND CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED
TO THE DURATION OF THE WARRANTY PERIOD. ALL OTHER EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF NON-INFRINGEMENT, ARE DISCLAIMED. Some jurisdictions do not
allow limitations on how long an implied warranty lasts, so the above limitation may not apply to You. This warranty gives
You specific legal rights, and You may also have other rights which vary by jurisdiction.
This warranty does not apply if the Product (a) has been altered, except by Linksys, (b) has not been installed, operated,
repaired, or maintained in accordance with instructions supplied by Linksys, or (c) has been subjected to abnormal physical
or electrical stress, misuse, negligence, or accident. In addition, due to the continual development of new techniques for
intruding upon and attacking networks, Linksys does not warrant that the Product will be free of vulnerability to intrusion or
attack.
TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT WILL LINKSYS BE LIABLE FOR ANY LOST DATA, REVENUE OR PROFIT,
OR FOR SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES, REGARDLESS OF THE THEORY OF
LIABILITY (INCLUDING NEGLIGENCE), ARISING OUT OF OR RELATED TO THE USE OF OR INABILITY TO USE THE PRODUCT
(INCLUDING ANY SOFTWARE), EVEN IF LINKSYS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT
WILL LINKSYS’ LIABILITY EXCEED THE AMOUNT PAID BY YOU FOR THE PRODUCT. The foregoing limitations will apply even if
any warranty or remedy provided under this Agreement fails of its essential purpose. Some jurisdictions do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to You.
This Warranty is valid and may be processed only in the country of purchase.
Please direct all inquiries to: Linksys, P.O. Box 18558, Irvine, CA 92623.
Appendix F: Warranty Information
57
Wireless-G Notebook Adapter
Appendix G: Regulatory Information
FCC Statement
This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment or devices
• Connect the equipment to an outlet other than the receiver's
• Consult a dealer or an experienced radio/TV technician for assistance
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body.
Safety Notices
Caution: To reduce the risk of fire, use only No.26 AWG or larger telecommunication line cord.
Do not use this product near water, for example, in a wet basement or near a swimming pool.
Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning.
Industry Canada (Canada)
This device complies with Industry Canada ICES-003 and RSS210 rules.
Cet appareil est conforme aux normes NMB003 et RSS210 d'Industrie Canada.
Appendix G: Regulatory Information
58
Wireless-G Notebook Adapter
IC Statement
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including interference that may cause undesired operation of the device.
Règlement d’Industry Canada
Le fonctionnement est soumis aux conditions suivantes :
1. Ce périphérique ne doit pas causer d'interférences;
2. Ce périphérique doit accepter toutes les interférences reçues, y compris celles qui risquent d'entraîner un
fonctionnement indésirable.
Appendix G: Regulatory Information
59
Wireless-G Notebook Adapter
Compliance Information for 2,4-GHz and 5-GHz Wireless Products Relevant to the EU and Other Countries
Following the EU Directive 1999/5/EC (R&TTE Directive)
Declaration of Conformity with Regard to the EU Directive 1999/5/EC (R&TTE Directive)
Appendix G: Regulatory Information
60
Wireless-G Notebook Adapter
NOTE: For all products, the Declaration of Conformity (DofC) is available through one or more of these options:
•A pdf file is included on the product's CD.
•A print copy is included with the product.
•A pdf file is available on the product's webpage. Visit www.linksys.com/international and select your country or
region. Then select your product.
If you need any other technical documentation, see the “Technical Documents on www.linksys.com/international”
section, as shown later in this appendix.
The following standards were applied during the assessment of the product against the requirements of the Directive
1999/5/EC:
• Radio: EN 300 328 and/or EN 301 893 as applicable
• EMC: EN 301 489-1, EN 301 489-17
• Safety: EN 60950 and either EN 50385 or EN 50371
Dynamic Frequency Selection (DFS) and Transmit Power Control (TPC) are required for operation in the 5 GHz band.
DFS: The equipment meets the DFS requirements as defined in ETSI EN 301 893. This feature is required by the regulations
to avoid interference with Radio Location Services (radars).
TPC: For operation in the 5 GHz band, the maximum power level is 3 dB or more below the applicable limit. As such, TPC is
not required. Nevertheless, you can further reduce the power output if you wish to do so. For more information about
changing the power output settings, refer to your product’s documentation on its CD or www.linksys.com/international.
CE Marking
For the Linksys Wireless-N, -G, -B, and/or -A products, the following CE mark, notified body number (where applicable),
and class 2 identifier are added to the equipment.
ororor
Check the CE label on the product to find out which notified body was involved during the assessment.
Appendix G: Regulatory Information
61
Wireless-G Notebook Adapter
National Restrictions
This product may be used in all EU countries (and other countries following the EU directive 1999/5/EC) without any
limitation except for the countries mentioned below:
Ce produit peut être utilisé dans tous les pays de l’UE (et dans tous les pays ayant transposés la directive 1999/5/CE) sans
aucune limitation, excepté pour les pays mentionnés ci-dessous:
Questo prodotto è utilizzabile in tutte i paesi EU (ed in tutti gli altri paesi che seguono le direttive EU 1999/5/EC) senza
nessuna limitazione, eccetto per i paesii menzionati di seguito:
Das Produkt kann in allen EU Staaten ohne Einschränkungen eingesetzt werden (sowie in anderen Staaten die der EU
Direktive 1999/5/CE folgen) mit Außnahme der folgenden aufgeführten Staaten:
In the majority of the EU and other European countries, the 2,4- and 5-GHz bands have been made available for the use of
wireless local area networks (LANs). Table 1 provides an overview of the regulatory requirements applicable for the
2,4- and 5-GHz bands.
Later in this document you will find an overview of countries in which additional restrictions or requirements or both are
applicable.
The requirements for any country may evolve. Linksys recommends that you check with the local authorities for the latest
status of their national regulations for both the 2,4- and 5-GHz wireless LANs.
Table 1: Overview of Regulatory Requirements for Wireless LANs
Frequency Band (MHz)Max Power Level
(EIRP) (mW)
2400-2483.5100X
5150-5350
5470-5725
†
†
200X
1000X
Indoor
ONLY
Indoor &
Outdoor
† Dynamic Frequency Selection and Transmit Power Control are required in the frequency ranges of 5250-5350 MHz and
5470-5725 MHz.
Appendix G: Regulatory Information
62
Wireless-G Notebook Adapter
The following countries have restrictions and/or requirements in addition to those given in Table 1:
Denmark
In Denmark, the band 5150 - 5350 MHz is also allowed for outdoor usage.
I Danmark må frekvensbåndet 5150 - 5350 også anvendes udendørs.
France
For 2,4 GHz, the output power is restricted to 10 mW eirp when the product is used outdoors in the band
2454 - 2483,5 MHz. There are no restrictions when used in other parts of the 2,4 GHz band. Check http://www.arcep.fr/ for
more details.
Pour la bande 2,4 GHz, la puissance est limitée à 10 mW en p.i.r.e. pour les équipements utilisés en extérieur dans la bande
2454 - 2483,5 MHz. Il n'y a pas de restrictions pour des utilisations dans d'autres parties de la bande 2,4 GHz. Consultez
http://www.arcep.fr/ pour de plus amples détails.
Table 2: Applicable Power Levels in France
LocationFrequency Range (MHz)Power (EIRP)
Indoor (No restrictions)2400-2483.5100 mW (20 dBm)
Outdoor2400-2454
2454-2483.5
100 mW (20 dBm)
10 mW (10 dBm)
Italy
This product meets the National Radio Interface and the requirements specified in the National Frequency Allocation Table
for Italy. Unless this 2,4-GHz wireless LAN product is operating within the boundaries of the owner’s property, its use
requires a “general authorization”. Please check http://www.comunicazioni.it/it/ for more details.
Questo prodotto è conforme alla specifiche di Interfaccia Radio Nazionali e rispetta il Piano Nazionale di ripartizione delle
frequenze in Italia. Se non viene installato all’interno del proprio fondo, l’utilizzo di prodotti Wireless LAN a 2,4 GHz richiede
una “Autorizzazione Generale”. Consultare http://www.comunicazioni.it/it/ per maggiori dettagli.
Appendix G: Regulatory Information
63
Wireless-G Notebook Adapter
Latvia
The outdoor usage of the 2,4 GHz band requires an authorization from the Electronic Communications Office. Please check
http://www.esd.lv for more details.
Notes: (1) Although Norway, Switzerland and Liechtenstein are not EU member states, the EU Directive 1999/5/EC has also
been implemented in those countries.
(2) The regulatory limits for maximum output power are specified in eirp. The eirp level of a device can be calculated by
adding the gain of the antenna used (specified in dBi) to the output power available at the connector (specified in dBm).
Product Usage Restrictions
This product is designed for indoor usage only. Outdoor usage is not recommended, unless otherwise noted.
2,4 GHz Restrictions
This product is designed for use with the standard, integral or dedicated (external) antenna(s) that is/are shipped together
with the equipment. However, some applications may require the antenna(s), if removable, to be separated from the
product and installed remotely from the device by using extension cables. For these applications, Linksys offers an R-SMA
extension cable (AC9SMA) and an R-TNC extension cable (AC9TNC). Both of these cables are 9 meters long and have a
cable loss (attenuation) of 5 dB. To compensate for the attenuation, Linksys also offers higher gain antennas, the HGA7S
(with R-SMA connector) and HGA7T (with R-TNC connector). These antennas have a gain of 7 dBi and may only be used
with either the R-SMA or R-TNC extension cable.
Combinations of extension cables and antennas resulting in a radiated power level exceeding 100 mW EIRP are illegal.
Power Output of Your Device
To comply with your country’s regulations, you may have to change the power output of your wireless device. Proceed to
the appropriate section for your device.
NOTE: The power output setting may not be available on all wireless products. For more information, refer to the
documentation on your product’s CD or at http://www.linksys.com/international.
Appendix G: Regulatory Information
64
Wireless-G Notebook Adapter
Wireless Adapters
For wireless adapters operating in the 2,4-GHz band, the typical radiated output power is 18 dBm EIRP, while the maximum
radiated output power will not exceed 20 dBm (100 mW) EIRP. For wireless adapters operating in the 5-GHz band, the
typical radiated output power is 20 dBm EIRP, while the maximum radiated output power will not exceed 23 dBm (200 mW)
EIRP. If you need to alter your wireless adapter’s power output, follow the appropriate instructions for your computer’s
operating system:
Windows XP
1. Double-click the Wireless icon in your desktop’s system tray.
2. Open the Wireless Network Connection window.
3. Click the Properties button.
4. Select the General tab, and click the Configure button.
5. In the Properties window, click the Advanced tab.
6. Select Power Output.
7. From the pull-down menu on the right, select the adapter’s power output percentage.
Windows 2000
1. Open the Control Panel.
2. Double-click Network and Dial-Up Connections.
3. Select your current wireless connection, and select Properties.
4. From the Properties screen, click the Configure button.
5. Click the Advanced tab, and select Power Output.
6. From the pull-down menu on the right, select the adapter’s power setting.
If your computer is running Windows Millennium or 98, then refer to Windows Help for instructions on how to access the
advanced settings of a network adapter.
Appendix G: Regulatory Information
65
Wireless-G Notebook Adapter
Wireless Access Points, Routers, or Other Wireless Products
If you have a different wireless product, use its Web-based Utility to configure its power output setting (refer to the
product’s documentation for more information).
Technical Documents on www.linksys.com/international
Follow these steps to access technical documents:
1. Enter http://www.linksys.com/international in your web browser.
2. Select the country or region in which you live.
3. Click the Products tab.
4. Select the appropriate product category.
5. Select the product sub-category, if necessary.
6. Select the product.
7. Select the type of documentation you want from the More Information section. The document will open in PDF format if
you have Adobe Acrobat installed on your computer.
NOTE: If you have questions regarding the compliance of this product or you cannot find the information you need,
please contact your local sales office or visit http://www.linksys.com/international for more details.
Appendix G: Regulatory Information
66
Wireless-G Notebook Adapter
User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste Electric and Electronic
Equipment (WEEE)
This document contains important information for users with regards to the proper disposal and recycling of Linksys
products. Consumers are required to comply with this notice for all electronic products bearing the following symbol:
Appendix G: Regulatory Information
67
Wireless-G Notebook Adapter
Appendix G: Regulatory Information
68
Wireless-G Notebook Adapter
Appendix G: Regulatory Information
69
Wireless-G Notebook Adapter
Appendix G: Regulatory Information
70
Wireless-G Notebook Adapter
For more information, visit www.linksys.com.
Appendix G: Regulatory Information
71
Wireless-G Notebook Adapter
Appendix H: Contact Information
Need to contact Linksys?
Visit us online for information on the latest products and updates to your existing products at:
http://www.linksys.com/international
If you experience problems with any Linksys product, you can e-mail us at:
In EuropeE-mail Address
Austriasupport.at@linksys.com
Belgiumsupport.be@linksys.com
Czech Republicsupport.cz@linksys.com
Denmarksupport.dk@linksys.com
Finlandsupport.fi@linksys.com
Francesupport.fr@linksys.com
Germanysupport.de@linksys.com
Greecesupport.gr@linksys.com (English only)
Hungarysupport.hu@linksys.com
Irelandsupport.ie@linksys.com
Italysupport.it@linksys.com
Netherlandssupport.nl@linksys.com
Norwaysupport.no@linksys.com
Polandsupport.pl@linksys.com
Portugalsupport.pt@linksys.com
Russiasupport.ru@linksys.com
Spainsupport.es@linksys.com
Swedensupport.se@linksys.com
Appendix H: Contact Information
72
Wireless-G Notebook Adapter
In EuropeE-mail Address
Switzerlandsupport.ch@linksys.com
Turkeysupport.tk@linksys.com
United Kingdomsupport.uk@linksys.com
Outside of EuropeE-mail Address
Asia Pacificasiasupport@linksys.com (English only)
Latin Americasupport.portuguese@linksys.com or support.spanish@linksys.com
Middle East & Africasupport.mea@linksys.com (English only)
South Africasupport.ze@linksys.com (English only)
UAEsupport.ae@linksys.com (English only)
U.S. and Canadasupport@linksys.com
Note: For some countries, support may be available only in English.
Ziel dieses Benutzerhandbuchs ist, Ihnen den Einstieg in den Netzwerkbetrieb mit dem Notebook-Adapter noch
einfacher zu machen. Achten Sie beim Lesen dieses Benutzerhandbuchs auf folgende Symbole:
Dieses Häkchen kennzeichnet einen Hinweis, den Sie bei Verwendung des
Notebook-Adapters besonders beachten sollten.
Dieses Ausrufezeichen kennzeichnet eine Warnung und weist darauf hin,
dass unter bestimmten Umständen Schäden an Ihrem Eigentum oder am
Notebook-Adapter verursacht werden können.
Dieses Fragezeichen dient als Erinnerung an bestimmte Schritte, die bei
Verwendung des Notebook-Adapters durchzuführen sind.
Zusätzlich zu diesen Symbolen finden Sie auch Definitionen für technische Begriffe, die in folgender Form
dargestellt werden:
Wort: Definition.
Alle Abbildungen (Diagramme, Bildschirmdarstellungen und andere Bilder) sind mit einer Abbildungsnummer und
einer Kurzbeschreibung versehen (siehe folgendes Beispiel):
Abbildung 0-1: Beschreibung der Beispielabbildung
Die Abbildungsnummern und die zugehörigen Kurzbeschreibungen finden Sie auch unter
„Abbildungsverzeichnis“.
WPC54G-DE_V3.1-UG-70130NC JL
Wireless-G Notebook-Adapter
Inhalt
Kapitel 1: Einführung1
Willkommen1
Inhalt dieses Benutzerhandbuchs2
Kapitel 2: Planen des Wireless-Netzwerks4
Netzwerktopologie4
Roaming4
Netzwerkanordnung4
Kapitel 3: Beschreibung des Wireless-G Notebook-Adapters5
LED-Anzeigen5
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters6
Starten der Einrichtung6
Anschließen des Adapters8
Einrichten des Adapters8
Kapitel 5: Verwenden des Wireless-Netzwerkmonitors23
Zugreifen auf den Wireless-Netzwerkmonitor23
Verwenden des Wireless-Netzwerkmonitors23
Verbindungsdaten23
Netzwerksuche26
Profile28
Erstellen eines neuen Profils29
Anhang A: Fehlerbehebung44
Behebung häufig auftretender Probleme44
Häufig gestellte Fragen45
Anhang B: Wireless-Sicherheit48
Vorsichtsmaßnahmen48
Sicherheitsrisiken bei Wireless-Netzwerken48
Abbildung 3-1: Vorderseite 5
Abbildung 4-1: Begrüßungsfenster des Setup-Assistenten 6
Abbildung 4-2: „Click Here to Start“ (Klicken Sie hier, um zu starten) 7
Abbildung 4-3: Lizenzvereinbarung des Setup-Assistenten 7
Abbildung 4-4: „Connecting the Adapter“ (Anschließen des Adapters) 8
Abbildung 4-5: „Available Wireless Network“ (Verfügbares Wireless-Netzwerk) 8
Abbildung 4-6: SecureEasySetup-Fenster 9
Abbildung 4-7: SecureEasySetup-Logo 9
Abbildung 4-8: Position des SecureEasySetup-Logos 9
Abbildung 4-9: SecureEasySetup – Glückwunschfenster 10
Abbildung 4-10: „Available Wireless Network“ (Verfügbares Wireless-Netzwerk) 10
Abbildung 4-11: „WEP Key Needed for Connection“ (WEP-Schlüssel für Verbindung erforderlich) 11
Abbildung 4-12: „WPA - Personal Needed for Connection“ (WPA-Personal für Verbindung erforderlich) 11
Abbildung 4-13: „WPA2 - Personal Needed for Connection“ (WPA2-Personal für Verbindung erforderlich) 11
Abbildung 4-14: Glückwunschfenster der automatischen Einrichtung 12
Abbildung 4-15: „Available Wireless Network“ (Verfügbares Wireless-Netzwerk) 12
Abbildung 4-16: „Network Settings“ (Netzwerkeinstellungen) 13
Abbildung 4-17: „Wireless Mode“ (Wireless-Modus) 13
Abbildung 4-18: „Ad-Hoc Mode Settings“ (Einstellungen für den Ad-Hoc-Modus) 14
Abbildung 4-19: „Wireless Security“ (Wireless-Sicherheit) – „Disabled“ (Deaktiviert) 14
Abbildung 4-20: „Wireless Security“ (Wireless-Sicherheit) - „WEP“ 15
Abbildung 4-21: WEP-Einstellungen 15
Abbildung 4-22: „Wireless Security“ (Wireless-Sicherheit) – „WPA-Personal“ 16
Abbildung 4-23: Einstellungen für WPA-Personal 16
Abbildung 4-24: „Wireless Security“ (Wireless-Sicherheit) – „WPA2-Personal“ 17
Abbildung 4-25: Einstellungen für WPA2-Personal 17
Abbildung 4-26: „Wireless Security“ (Wireless-Sicherheit) – „WPA-Enterprise“ – „EAP-TLS“ 18
Abbildung 4-27: „Wireless Security“ (Wireless-Sicherheit) – „WPA-Enterprise“ – „PEAP“ 18
Abbildung 4-28: „Wireless Security“ (Wireless-Sicherheit) – „WPA-Enterprise“ – „EAP_TLS“ 19
Abbildung 4-29: „Wireless Security“ (Wireless-Sicherheit) – „WPA-Enterprise“ – Auswahl von PEAP 19
Abbildung 4-30: „Wireless Security“ (Wireless-Sicherheit) – „RADIUS“ – „EAP-TLS“ 20
Wireless-G Notebook-Adapter
Abbildung 4-31: „Wireless Security“ (Wireless-Sicherheit) – „RADIUS“ – „PEAP“ 20
Abbildung 4-32: „Wireless Security“ (Wireless-Sicherheit) – „LEAP“ 21
Abbildung 4-33: Einstellungen für „LEAP“ 21
Abbildung 4-34: „Confirm New Settings“ (Neue Einstellungen bestätigen) 22
Abbildung 4-35: Glückwunschfenster 22
Abbildung 5-1: Symbol für den Wireless-Netzwerkmonitor 23
Abbildung 5-2: „Link Information“ (Verbindungsdaten) 23
Abbildung 5-3: Weitere Informationen: „Wireless Network Status“ (Status des Wireless-Netzwerks) 24
Abbildung 5-4: Weitere Informationen: Netzwerkstatistiken 25
Abbildung 5-5: „Site Survey“ (Netzwerksuche) 26
Abbildung 5-6: „WEP Key Needed for Connection“ (WEP-Schlüssel für Verbindung erforderlich) 26
Abbildung 5-7: „WPA-Personal Needed for Connection“ (WPA-Personal für Verbindung erforderlich) 27
Abbildung 5-8: „WPA2-Personal Needed for Connection“ (WPA2-Personal für Verbindung erforderlich) 27
Abbildung 5-9: „Profiles“ (Profile) 28
Abbildung 5-10: Importieren eines Profils 28
Abbildung 5-11: Exportieren eines Profils 29
Abbildung 5-12: Erstellen eines neuen Profils 29
Abbildung 5-13: „Available Wireless Network“ (Verfügbares Wireless-Netzwerk) 29
Abbildung 5-14: SecureEasySetup-Fenster 30
Abbildung 5-15: SecureEasySetup-Logo 30
Abbildung 5-16: Position des SecureEasySetup-Logos 30
Abbildung 5-17: Glückwunschfenster 31
Abbildung 5-18: „Available Wireless Network“ (Verfügbares Wireless-Netzwerk) 31
Abbildung 5-19: „WEP Key Needed for Connection“ (WEP-Schlüssel für Verbindung erforderlich) 32
Abbildung 5-20: „WPA-Personal Needed for Connection“ (WPA-Personal für Verbindung erforderlich) 32
Abbildung 5-21: „WPA2-Personal Needed for Connection“ (WPA2-Personal für Verbindung erforderlich) 33
Abbildung 5-22: „Congratulations“ (Gratulation) 33
Abbildung 5-23: Netzwerkeinstellungen für neues Profil 34
Abbildung 5-24: Wireless-Modus für neues Profil 34
Abbildung 5-25: Einstellungen für den Ad-Hoc-Modus für neues Profil 35
Abbildung 5-26: „Wireless Security“ (Wireless-Sicherheit) – „Disabled“ (Deaktiviert) 35
Abbildung 5-27: „Wireless Security“ (Wireless-Sicherheit): WEP für neues Profil 36
Abbildung 5-28: WEP-Einstellungen 36
Abbildung 5-29: „Wireless Security“ (Wireless-Sicherheit) – WPA-Personal für neues Profil 37
Wireless-G Notebook-Adapter
Abbildung 5-30: Einstellungen für WPA-Personal 37
Abbildung 5-31: „Wireless Security“ (Wireless-Sicherheit) – WPA2-Personal für neues Profil 38
Abbildung 5-32: Einstellungen für WPA2-Personal 38
Abbildung 5-33: „Wireless Security“ (Wireless-Sicherheit) – WPA-Enterprise unter Verwendung von EAP-TLS für neues Profil 39
Abbildung 5-34: „Wireless Security“ (Wireless-Sicherheit) – WPA-Enterprise unter Verwendung von PEAP für neues Profil 39
Abbildung 5-35: „Wireless Security“ (Wireless-Sicherheit) – WPA2-Enterprise unter Verwendung von EAP-TLS für neues Profil 40
Abbildung 5-36: „Wireless Security“ (Wireless-Sicherheit) – WPA2-Enterprise unter Verwendung von PEAP für neues Profil 40
Abbildung 5-37: „Wireless Security“ (Wireless-Sicherheit) – RADIUS unter Verwendung von EAP-TLS für neues Profil 41
Abbildung 5-38: „Wireless Security“ (Wireless-Sicherheit) – RADIUS unter Verwendung von PEAP für neues Profil 41
Abbildung 5-39: „Wireless Security“ (Wireless-Sicherheit) – LEAP für neues Profil 42
Abbildung 5-40: Einstellungen für „LEAP“ 42
Abbildung 5-41: Neue Einstellungen für neues Profil bestätigen 43
Abbildung 5-42: Glückwunschfenster zum neu erstellten Profil 43
Wireless-G Notebook-Adapter
Kapitel 1: Einführung
Willkommen
Vielen Dank, dass Sie sich für einen Wireless-G Notebook-Adapter entschieden haben. Mit SecureEasySetup ist
die Einrichtung Ihres Netzwerks und Ihres Wireless-G Notebook-Adapters einfacher als je zuvor.
Wie alle Wireless-Produkte ermöglicht dieser Adapter größere Reichweiten und mehr Mobilität in Ihrem WirelessNetzwerk. Der Adapter kommuniziert über den Wireless-Standard 802.11g (bis zu 54 Mbit/s).
Mit Wireless-Karten und -Adaptern ausgerüstete PCs können ganz ohne lästige Kabel kommunizieren. Sie
verwenden innerhalb des Übertragungsradius dieselben Wireless-Einstellungen und bilden so ein WirelessNetzwerk.
Der Setup-Assistent führt Sie Schritt für Schritt durch die Konfiguration des Adapters mit den Einstellungen Ihres
Netzwerks. Stecken Sie den Adapter einfach in den PC-Steckplatz Ihres Notebooks, und schon haben Sie von
Ihrem Notebook-Computer aus Zugriff auf das Netzwerk – und Sie bleiben dabei uneingeschränkt mobil.
Sobald Sie den Adapter angeschlossen haben, können Sie auf Ihre E-Mails und das Internet zugreifen und
Dateien und andere Ressourcen wie beispielsweise Drucker und Netzwerkspeicherplatz mit anderen Computern
im Netzwerk gemeinsam nutzen. Und zu Hause auf der Terrasse steht Ihnen das Internet und Instant Messaging
zum Chatten mit Freunden zur Verfügung. Ihre Wireless-Verbindung wird durch Verschlüsselung mit bis zu
256 Bit geschützt.
Sie können sich auch mit einem der zahlreichen öffentlichen „Wireless-Hot Spots“ verbinden, von denen immer
mehr in Cafés, auf Flughäfen, in Hotels und in Konferenzzentren eingerichtet werden.
Linksys empfiehlt die Verwendung des Setup-Assistenten auf der Installations-CD-ROM zur erstmaligen
Installation des Adapters. Zusätzlich können Sie zur Installation und Konfiguration des Adpaters auch die in
diesem Handbuch aufgeführten Anleitungsschritte befolgen. Diese enthalten alle Informationen, die Sie
benötigen, um den Wireless-G Notebook-Adapter optimal zu verwenden.
Netzwerk: Mehrere Computer oder Geräte, die miteinander
verbunden sind, damit Benutzer Daten an andere Benutzer
übertragen und Daten gemeinsam nutzen und speichern können.
Bit: Eine binäre Informationseinheit.
Verschlüsselung: Die Codierung von Daten, die über ein
Netzwerk übertragen werden.
Kapitel 1: Einführung
Willkommen
1
Wireless-G Notebook-Adapter
Inhalt dieses Benutzerhandbuchs
In diesem Benutzerhandbuch sind die zur Installation und Verwendung des Wireless-G Notebook-Adapters
erforderlichen Schritte aufgeführt.
• Kapitel 1: Einführung
In diesem Kapitel werden die Anwendungen des Adapters sowie dieses Benutzerhandbuch beschrieben.
• Kapitel 2: Planen des Wireless-Netzwerks
In diesem Kapitel werden einige der Grundlagen des Wireless-Netzwerkbetriebs erläutert.
• Kapitel 3: Beschreibung des Wireless-G Notebook-Adapters
In diesem Kapitel werden die physischen Merkmale des Adapters beschrieben.
• Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Dieses Kapitel enthält Anleitungen zur Installation und Konfiguration des Adapters.
• Kapitel 5: Verwenden des Wireless-Netzwerkmonitors
In diesem Kapitel wird beschrieben, wie Sie den Wireless-Netzwerkmonitor des Adapters verwenden.
• Anhang A: Fehlerbehebung
In diesem Anhang werden einige Probleme und Lösungsansätze sowie häufig gestellte Fragen in
Zusammenhang mit der Installation und Verwendung des Adapters erörtert.
• Anhang B: Wireless-Sicherheit
In diesem Anhang werden Sicherheitsfragen erläutert, die den Wireless-Netzwerkbetrieb betreffen, sowie
Maßnahmen aufgezeigt, mit denen Sie Ihr Wireless-Netzwerk schützen können.
• Anhang C: Windows-Hilfe
In diesem Anhang wird beschrieben, wie Sie in der Windows-Hilfe Anleitungen und Informationen zum
Netzwerkbetrieb finden, wie beispielsweise zur Installation des TCP/IP-Protokolls.
• Anhang D: Glossar
In diesem Anhang finden Sie ein kurzes Glossar mit häufig verwendeten Begriffen aus dem Bereich
Netzwerkbetrieb.
• Anhang E: Spezifikationen
In diesem Anhang sind die technischen Spezifikationen des Adapters aufgeführt.
• Anhang F: Garantieinformationen
Dieser Anhang enthält die Garantieinformationen für den Adapter.
Kapitel 1: Einführung
Inhalt dieses Benutzerhandbuchs
2
Wireless-G Notebook-Adapter
• Anhang G: Zulassungsinformationen
Dieser Anhang enthält die für den Adapter geltenden Zulassungsinformationen.
• Anhang H: Kontaktinformationen
In diesem Anhang finden Sie Kontaktinformationen zu einer Reihe von Linksys-Ressourcen, darunter auch
zum technischen Support.
Kapitel 1: Einführung
Inhalt dieses Benutzerhandbuchs
3
Wireless-G Notebook-Adapter
Kapitel 2: Planen des Wireless-Netzwerks
Netzwerktopologie
Top ologie: Die physische Anordnung eines Netzwerks.
Bei einem Wireless-Netzwerk handelt es sich um eine Gruppe von Computern, die jeweils über einen WirelessAdapter verfügen. Computer in einem Wireless-Netzwerk müssen so konfiguriert sein, dass sie denselben
Funkkanal verwenden. Es können mehrere PCs, die über Wireless-Karten oder -Adapter verfügen, miteinander
kommunizieren und so ein Ad-Hoc-Netzwerk bilden.
Mit Wireless-Adaptern von Linksys erhalten Benutzer bei Verwendung eines Access Points oder eines WirelessRouters außerdem Zugang zu Wired-Netzwerken. Ein integriertes Wireless-Netzwerk und Wired-Netzwerk wird
als Infrastrukturnetzwerk bezeichnet. Wireless-PCs können in einem Infrastrukturnetzwerk über einen Access
Point oder einen Wireless-Router mit jedem beliebigen Computer in einer Wired-Netzwerkinfrastruktur
kommunizieren.
Mit einer Infrastrukturkonfiguration erweitern Sie nicht nur die Zugriffsmöglichkeiten von Wireless-PCs auf
Wired-Netzwerke, Sie können den effektiven Wireless-Übertragungsbereich außerdem für zwei WirelessAdapter-PCs verdoppeln. Da mit einem Access Point Daten innerhalb eines Netzwerks weitergeleitet werden
können, kann der Übertragungsbereich in einem Infrastrukturnetzwerk verdoppelt werden.
Access Point: Ein Gerät, über das Computer und andere Geräte
mit Wireless-Funktionalität mit einem Wired-Netzwerk
kommunizieren können.
Ad-Hoc: Eine Gruppe von Wireless-Geräten, die direkt und ohne
Access Point miteinander kommunizieren (Peer-to-Peer).
Infrastruktur: Ein Wireless-Netzwerk, das über einen
Access Point mit einem Wired-Netzwerk verbunden ist.
Roaming
Der Infrastrukturmodus unterstützt auch Roaming-Funktionen für mobile Benutzer. Roaming bedeutet, dass Sie
Ihren Wireless-PC innerhalb Ihres Netzwerks verschieben können und der Access Point das Signal des WirelessPCs aufnimmt, vorausgesetzt, beide verwenden dieselben Kanäle und SSIDs.
Bevor Sie die Roaming-Funktion aktivieren, wählen Sie einen geeigneten Funkkanal sowie einen optimalen
Standort für Ihren Access Point aus. Mit einer geeigneten Positionierung des Access Points und einem klaren
Funksignal erreichen Sie eine erhebliche Leistungssteigerung.
Netzwerkanordnung
Mit dem Wireless-G Notebook-Adapter können Sie Ihren Computer in Ihr Netzwerk aus Wireless-G- und WirelessB-Produkten einbinden. Wenn Sie Ihr Wireless-Netzwerk mit Ihrem Wired-Netzwerk verbinden möchten, können
Sie die Netzwerk-Ports der Access Points und der Wireless-Router mit jedem beliebigen Switch oder Router von
Linksys verbinden.
Mit diesen und zahlreichen weiteren Linksys Produkten stehen Ihnen grenzenlose Möglichkeiten für Ihren
Netzwerkbetrieb zur Verfügung. Weitere Informationen zu Wireless-Produkten finden Sie auf der Website von
Linksys unter www.linksys.com/international.
Kapitel 2: Planen des Wireless-Netzwerks
Netzwerktopologie
Roaming: Die Möglichkeit, mit einem Wireless-Gerät aus einem
Access Point-Bereich in einen anderen zu wechseln, ohne die
Verbindung zu unterbrechen.
SSID: Der Name Ihres Wireless-Netzwerks.
4
Wireless-G Notebook-Adapter
Kapitel 3: Beschreibung des Wireless-G
Notebook-Adapters
LED-Anzeigen
Auf den LEDs werden Informationen über die Netzwerkaktivität des Netzwerkadapters angezeigt.
Figure 3-1: Vorderseite
Power (Netzstrom)Grün. Die LED für den Netzstrom leuchtet auf, wenn der Adapter eingeschaltet wird.
Link (Verbindung)Grün. Die LED für die Verbindung leuchtet auf, wenn der Adapter über eine aktive
Verbindung verfügt.
Kapitel 3: Beschreibung des Wireless-G Notebook-Adapters
LED-Anzeigen
5
Wireless-G Notebook-Adapter
Kapitel 4: Einrichten und Anschließen des Wireless-G
Notebook-Adapters
Starten der Einrichtung
Der Setup-Assistent für den Wireless-G Notebook-Adapter führt Sie durch den Installationsvorgang. Der SetupAssistent führt die Installation des Treibers und des Wireless-Netzwerkmonitors sowie den Anschluss und die
Konfiguration des Adapters durch.
WICHTIG: Stellen Sie die Verbindung mit dem Adapter erst dann her, wenn
Sie dazu aufgefordert werden. Andernfalls schlägt die Installation fehl.
Legen Sie die Setup-Assistenten-CD-ROM in Ihr CD-ROM-Laufwerk ein. Der Setup-Assistent sollte automatisch
gestartet und das Fenster Welcome (Willkommen) angezeigt werden. Ist dies nicht der Fall, klicken Sie auf die
Schaltfläche Start, und wählen Sie Ausführen aus. Geben Sie im daraufhin angezeigten Feld D:\setup.exe ein
(wobei „D“ für den Buchstaben Ihres CD-ROM-Laufwerks steht).
Im ersten Fenster Welcome (Willkommen) wird die Sprache des Betriebssystems Ihres Computers ausgewählt.
Klicken Sie auf Next (Weiter), um in der aktuellen Sprache fortzufahren. Wenn Sie eine andere Sprache
verwenden möchten, wählen Sie diese aus dem Dropdown-Menü Language (Sprache) aus, und klicken Sie
anschließend auf Next (Weiter).
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Starten der Einrichtung
Abbildung 4-1: Begrüßungsfenster
des Setup-Assistenten
6
Wireless-G Notebook-Adapter
Ein zweites Begrüßungsfenster wird angezeigt. Es stehen Ihnen folgende Optionen zur Verfügung:
Click Here to Start (Klicken Sie hier, um zu starten): Klicken Sie auf diese Schaltfläche, um den
Installationsvorgang für die Software zu starten.
User Guide (Benutzerhandbuch): Klicken Sie auf die Schaltfläche User Guide (Benutzerhandbuch), um das
Benutzerhandbuch als PDF-Datei zu öffnen.
Exit (Beenden): Klicken Sie auf die Schaltfläche Exit (Beenden), um den Setup-Assistenten zu beenden.
1. Um den Adapter zu installieren, klicken Sie im Fenster Welcome (Willkommen) auf die Schaltfläche Click Here to Start (Klicken Sie hier, um zu starten).
2. Nachdem Sie die Lizenzvereinbarung gelesen haben, klicken Sie auf die Schaltfläche Next (Weiter), wenn Sie
zustimmen und mit der Installation fortfahren möchten, oder Sie klicken auf die Schaltfläche Cancel
(Abbrechen), um den Installationsvorgang zu beenden.
Abbildung 4-2: „Click Here to Start“
(Klicken Sie hier, um zu starten)
3. Windows beginnt, die Dateien auf Ihren PC zu kopieren.
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Starten der Einrichtung
Abbildung 4-3: Lizenzvereinbarung
des Setup-Assistenten
7
Wireless-G Notebook-Adapter
Anschließen des Adapters
1. Suchen Sie nach einem verfügbaren CardBus-Steckplatz auf Ihrem Notebook.
2. Stecken Sie den Adapter mit der Pin-Seite des Steckers (Etikett nach oben) in den CardBus-Steckplatz, bis er
einrastet.
3. Benutzer von Windows 98 und Windows ME werden u. U. aufgefordert, ihren PC neu zu starten. Sobald der
Adapter korrekt installiert ist, sollte die Netzstrom-LED leuchten.
4. Windows beginnt mit dem Kopieren der Treiberdateien auf den Computer. Legen Sie bei Aufforderung die
Original-Windows-CD-ROM ein, und geben Sie den entsprechenden Speicherort an (z. B. D:\).
5. Klicken Sie anschließend auf Next (Weiter).
Einrichten des Adapters
Als nächster Schritt wird das Fenster Available Wireless Network (Verfügbares Wireless-Netzwerk) angezeigt.
Dieses Fenster enthält drei Optionen zur Einrichtung des Adapters.
• SecureEasySetup: Bei diesem Adapter steht die Funktion für SecureEasySetup zur Verfügung. Das bedeutet,
dass Sie den Adapter einfach durch Drücken einer Taste einrichten können, wenn Sie diesen an Wireless-Router
oder Access Points anschließen, die auch über die Funktion für SecureEasySetup verfügen. Beide
Netzwerkgeräte müssen über die Funktion für SecureEasySetup verfügen, damit diese ausgeführt werden kann.
• Available Wireless Network (Verfügbares Wireless-Netzwerk): (Für die meisten Benutzer.) Verwenden Sie
diese Option bei Netzwerken mit Geräten, die nicht über SecureEasySetup verfügen. Die für diesen Adapter
verfügbaren Netzwerke werden in diesem Fenster aufgeführt. Wählen Sie eines dieser Netzwerke aus, und klicken
Sie auf die Schaltfläche Connect (Verbinden), um eine Verbindung mit dem Netzwerk herzustellen. Klicken Sie auf
die Schaltfläche Refresh (Aktualisieren), um die Liste der verfügbaren Wireless-Netzwerke zu aktualisieren.
• Manual Setup (Manuelles Einrichten): Wenn Sie die Vorteile von SecureEasySetup nicht nutzen möchten, oder
Ihr Netzwerk in diesem Fenster nicht aufgeführt ist, wählen Sie die Option Manual Setup (Manuelles Einrichten)
aus, um den Adapter manuell einzurichten. Diese Methode zum Einrichten des Adapters ist nur für Benutzer mit
fortgeschrittenen Kenntnissen geeignet.
Die Einrichtungsmethode für die einzelnen Optionen wird schrittweise unter den entsprechenden Überschriften auf
den folgenden Seiten beschrieben.
Wenn Sie den Adapter später einrichten möchten, klicken Sie auf Exit (Beenden), um den Setup-Assistenten zu
beenden.
Abbildung 4-4: „Connecting the Adapter“
(Anschließen des Adapters)
Abbildung 4-5: „Available Wireless Network“
(Verfügbares Wireless-Netzwerk)
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Anschließen des Adapters
8
Wireless-G Notebook-Adapter
SecureEasySetup
Mit SecureEasySetup kann der Adapter einfach und schnell durch Drücken einiger Tasten eingerichtet werden.
Bevor Sie aber eine Taste drücken, sollten Sie zunächst auf dem Gerät, an das Sie den Adapter anschließen
(z. B. Wireless-Router oder Access Point), nach der Taste SecureEasySetup suchen.
1. Wenn Sie vom Fenster Available Wireless Network (Verfügbares Wireless-Netzwerk) aus starten, klicken Sie
rechts auf die Schaltfläche SecureEasySetup.
2. Sie werden dazu aufgefordert, die Taste SecureEasySetup auf dem Gerät zu suchen, mit dem der Adapter
verbunden wird. Wenn Sie sich nicht sicher sind, wo Sie diese Taste finden, klicken Sie auf Where can I find the button? (Wo finde ich diese Taste?).
In den daraufhin angezeigten Fenstern erhalten Sie Informationen zur Position der Taste, die sich in der Regel
an der Vorderseite des Wireless-Routers oder des Access Points befindet.
Abbildung 4-6: SecureEasySetup-Fenster
3. Drücken Sie auf dem Wireless-Router oder Access Point auf das Cisco Logo oder die SecureEasySetupTaste. Sobald das Logo oder die Taste weiß blinkt, klicken Sie im Fenster Setup Wizard (Setup-Assistent) auf
die Schaltfläche Next (Weiter). Das Logo oder die Taste auf dem Wireless-Router oder Access Point hört auf
zu blinken, sobald der Adapter erfolgreich dem Netzwerk hinzugefügt wurde. Wiederholen Sie diesen Vorgang
für alle weiteren SecureEasySetup-Geräte.
HINWEIS: Sie können jeweils nur ein SecureEasySetup-Gerät
hinzufügen.
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Einrichten des Adapters
Abbildung 4-7: SecureEasySetup-Logo
Abbildung 4-8: Position des SecureEasySetup-Logos
9
Wireless-G Notebook-Adapter
4. Nach Abschluss des SecureEasySetup-Vorgangs können Sie Ihre Konfiguration als Textdatei speichern,
indem Sie auf die Schaltfläche Save (Speichern) klicken; oder klicken Sie auf die Schaltfläche Print
(Drucken), um die Konfiguration zu drucken. Klicken Sie auf Connect to Network (Mit Netzwerk verbinden),
um eine Verbindung zu Ihrem Netzwerk herzustellen.
Gratulation! Die Einrichtung ist abgeschlossen.
Wenn Sie die Verbindungsdaten überprüfen, nach verfügbaren Wireless-Netzwerken suchen
oder weitere Änderungen an der Konfiguration vornehmen möchten, fahren Sie mit
„Kapitel 5: Verwenden des Wireless-Netzwerkmonitors“ fort.
Wenn Sie den Adapter nicht mit SecureEasySetup einrichten, können Sie diesen mithilfe der verfügbaren
Netzwerke, die im Fenster Available Wireless Network (Verfügbares Wireless-Netzwerk) angezeigt werden,
einrichten. Die verfügbaren Netzwerke werden in der Tabelle in der Mitte des Fensters nach SSID aufgeführt.
Wählen Sie das Wireless-Netzwerk aus, zu dem Sie eine Verbindung herstellen möchten, und klicken Sie auf die
Schaltfläche Connect (Verbinden). Wenn Ihr Netzwerk nicht in der Liste aufgeführt ist, klicken Sie auf die
Schaltfläche Refresh (Aktualisieren), um die Liste zu aktualisieren. Wenn im Netzwerk eine WirelessSicherheitsmethode verwendet wird, müssen Sie die Sicherheit auf dem Adapter konfigurieren. Andernfalls
werden Sie direkt zum Fenster Congratulations (Gratulation) geführt.
1. Wenn Sie für das Netzwerk Wireless-Sicherheit aktiviert haben, fahren Sie mit Schritt 2 fort. Wenn Sie für das
Netzwerk keine Wireless-Sicherheit aktiviert haben, fahren Sie mit Schritt 3 fort.
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Einrichten des Adapters
Abbildung 4-10: „Available Wireless Network“
(Verfügbares Wireless-Netzwerk)
10
Wireless-G Notebook-Adapter
2. Wenn für Ihr Netzwerk die Wireless-Sicherheitsfunktion WEP (Wired Equivalent Privacy) aktiviert ist, wird
nebenstehendes Fenster angezeigt. Wählen Sie 64-bit (64-Bit) oder 128-bit (128-Bit) aus.
Geben Sie anschließend eine Passphrase oder einen WEP-Schlüssel ein.
Passphrase: Geben Sie eine Passphrase in das Feld Passphrase ein, sodass automatisch ein WEP-Schlüssel
generiert wird. Bei der Passphrase wird zwischen Groß- und Kleinschreibung unterschieden. Die Länge von
16 alphanumerischen Zeichen darf nicht überschritten werden. Sie muss mit der Passphrase Ihrer anderen
Wireless-Netzwerkgeräte übereinstimmen und ist nur mit Wireless-Produkten von Linksys kompatibel. (Wenn
Sie Wireless-Produkte anderer Anbieter verwenden, geben Sie den WEP-Schlüssel bei den entsprechenden
Produkten manuell ein.)
WEP Key (WEP-Schlüssel): Der eingegebene WEP-Schlüssel muss mit dem WEP-Schlüssel Ihres WirelessNetzwerks übereinstimmen. Geben Sie für die 64-Bit-Verschlüsselung genau 10 hexadezimale Zeichen ein.
Geben Sie für die 128-Bit-Verschlüsselung genau 26 hexadezimale Zeichen ein. Gültige hexadezimale
Zeichen sind Zeichen von „0“ bis „9“ und von „A“ bis „F“.
Klicken Sie anschließend auf Connect (Verbinden), und fahren Sie mit Schritt 3 fort.
Wenn für Ihr Netzwerk die Wireless-Sicherheitsmethode WPA-Personal (Wi-Fi Protected Access) aktiviert ist,
wird dieses Fenster angezeigt.
Encryption (Verschlüsselung): Wählen Sie den gewünschten Algorithmus (TKIP oder AES) aus dem
Dropdown-Menü Encryption (Verschlüsselung) aus.
Passphrase: Geben Sie eine Passphrase (auch als vorläufiger gemeinsamer Schlüssel bezeichnet) mit einer
Länge von 8 bis 63 Zeichen in das Feld Passphrase ein. Je länger und komplexer Ihre Passphrase ist, desto
sicherer ist Ihr Netzwerk.
Abbildung 4-11: „WEP Key Needed for Connection“
(WEP-Schlüssel für Verbindung erforderlich)
Abbildung 4-12: „WPA - Personal Needed for Connection“
(WPA-Personal für Verbindung erforderlich)
Klicken Sie anschließend auf Connect (Verbinden), und fahren Sie mit Schritt 3 fort.
Wenn für Ihr Netzwerk die Wireless-Sicherheitsmethode WPA2-Personal (WPA2 ist eine leistungsstärkere
Version von WPA) aktiviert ist, wird dieses Fenster angezeigt.
Passphrase: Geben Sie eine Passphrase (auch als vorläufiger gemeinsamer Schlüssel bezeichnet) mit einer
Länge von 8 bis 63 Zeichen in das Feld Passphrase ein. Je länger und komplexer Ihre Passphrase ist, desto
sicherer ist Ihr Netzwerk.
Klicken Sie anschließend auf Connect (Verbinden), und fahren Sie mit Schritt 3 fort.
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Einrichten des Adapters
Abbildung 4-13: „WPA2 - Personal Needed for Connection“
(WPA2-Personal für Verbindung erforderlich)
11
Wireless-G Notebook-Adapter
3. Nach der erfolgreichen Installation der Software wird das Glückwunschfenster angezeigt. Klicken Sie auf
Connect to Network (Mit Netzwerk verbinden), um eine Verbindung zu Ihrem Netzwerk herzustellen. Weitere
Informationen zum Wireless-Netzwerkmonitor finden Sie in „Kapitel 5: Verwenden des Wireless-
Netzwerkmonitors“.
Gratulation! Die Installation des Wireless-G Notebook-Adapters
mithilfe der automatischen Einrichtung ist hiermit abgeschlossen.
Wenn Sie die Verbindungsdaten überprüfen, nach verfügbaren Wireless-Netzwerken
suchen oder weitere Änderungen an der Konfiguration vornehmen möchten,
fahren Sie mit „Kapitel 5: Verwenden des Wireless-Netzwerkmonitors“ fort.
Abbildung 4-14: Glückwunschfenster der
automatischen Einrichtung
Manuelles Einrichten
Wenn Sie die Vorteile von SecureEasySetup nicht nutzen möchten oder Ihr Netzwerk nicht unter den verfügbaren
Wireless-Netzwerken aufgeführt ist, können Sie die Option Manual Setup (Manuelles Einrichten) verwenden.
1. Klicken Sie im Fenster Available Wireless Network (Verfügbares Wireless-Netzwerk) auf Manual Setup
(Manuelles Einrichten), um den Adapter manuell einzurichten.
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Einrichten des Adapters
Abbildung 4-15: „Available Wireless Network“
(Verfügbares Wireless-Netzwerk)
12
Wireless-G Notebook-Adapter
2. Das Fenster Network Settings (Netzwerkeinstellungen) des Wireless-Netzwerkmonitors wird angezeigt. Wenn
Ihr Netzwerk über einen Router oder einen anderen DHCP-Server verfügt, klicken Sie auf die
Optionsschaltfläche neben Obtain network settings automatically (DHCP) (Netzwerkeinstellungen
automatisch beziehen (DHCP)).
Wenn Ihr Netzwerk über keinen DHCP-Server verfügt, klicken Sie auf die Optionsschaltfläche neben Specify network settings (Netzwerkeinstellungen angeben). Geben Sie eine IP-Adresse, eine Subnetzmaske, ein
Standard-Gateway und die DNS-Adressen ein, die für Ihr Netzwerk geeignet sind. In diesem Fenster ist die
Angabe der IP-Adresse und der Subnetzmaske obligatorisch. Wenn Sie sich nicht sicher sind, welches die
korrekten Einstellungen für das Standard-Gateway und die DNS-Adressen sind, lassen Sie diese Felder leer.
IP Address (IP-Adresse): Diese IP-Adresse muss im Netzwerk eindeutig sein.
Subnet Mask (Subnetzmaske): Die Subnetzmaske des Adapters muss mit der Subnetzmaske Ihres Wired-
Netzwerks übereinstimmen.
Default Gateway (Standard-Gateway): Geben Sie hier die IP-Adresse des Gateways Ihres Netzwerks ein.
DNS 1 und DNS 2: Geben Sie die DNS-Adresse Ihres Wired-Ethernet-Netzwerks hier ein.
Klicken Sie auf die Schaltfläche Next (Weiter), um fortzufahren, oder klicken Sie auf die Schaltfläche Back
(Zurück), um zum vorherigen Fenster zurückzukehren.
3. Im Fenster Wireless Mode (Wireless-Modus) stehen zwei Modi für den Wireless-Betrieb zur Auswahl. Klicken Sie
auf die Optionsschaltfläche Infrastructure Mode (Infrastrukturmodus), wenn Sie eine Verbindung zu einem
Wireless-Router oder Access Point herstellen möchten. Klicken Sie auf die Optionsschaltfläche Ad-Hoc Mode
(Ad-Hoc-Modus), wenn Sie eine direkte Verbindung zu einem anderen Wireless-Gerät ohne Verwendung eines
Wireless-Routers oder Access Points herstellen möchten. Geben Sie die SSID für Ihr Netzwerk ein.
Infrastructure Mode (Infrastrukturmodus): Verwenden Sie diesen Modus, wenn Sie eine Verbindung zu einem
Wireless-Router oder Access Point herstellen möchten.
Ad-Hoc Mode (Ad-Hoc-Modus): Verwenden Sie diesen Modus, wenn Sie eine direkte Verbindung zu einem
anderen Wireless-Gerät ohne Verwendung eines Wireless-Routers oder Access Points herstellen möchten.
SSID: Hierbei handelt es sich um den Netzwerknamen, der für alle Geräte im Netzwerk verwendet werden
muss. Bei diesem Namen ist neben der Groß- und Kleinschreibung zu beachten, dass er eindeutig sein sollte,
um zu vermeiden, dass andere auf Ihr Netzwerk zugreifen können.
Abbildung 4-16: „Network Settings“
(Netzwerkeinstellungen)
Abbildung 4-17: „Wireless Mode“ (Wireless-Modus)
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Einrichten des Adapters
13
Wireless-G Notebook-Adapter
Klicken Sie auf die Schaltfläche Next (Weiter), um fortzufahren, oder klicken Sie auf die Schaltfläche Back
(Zurück), um zum vorherigen Fenster zurückzukehren.
4. Wenn Sie die Option Infrastructure Mode (Infrastrukturmodus) ausgewählt haben, fahren Sie jetzt mit
Schritt 5 fort. Wenn Sie die Option Ad-Hoc Mode (Ad-Hoc-Modus) ausgewählt haben, wird das Fenster
Ad-Hoc Mode Settings (Einstellungen für Ad-Hoc-Modus) angezeigt.
Wählen Sie den korrekten Betriebskanal für Ihr Wireless-Netzwerk aus. Der von Ihnen angegebene Kanal muss
mit dem Kanal übereinstimmen, den Sie auf den anderen Geräten Ihres Wireless-Netzwerks eingestellt haben.
Wenn Sie nicht sicher sind, welchen Kanal Sie verwenden sollen, behalten Sie die Standardeinstellung bei.
HINWEIS: Die Kanäle 12 und 13 sind nicht für Adapter verfügbar, die in Nord-, Mittel- und
Südamerika erhältlich sind. Wenn der Adapter auf Kanal 12 oder Kanal 13 eingestellt wird,
werden stattdessen die Kanäle 1 und 11 verwendet.
Klicken Sie auf Next (Weiter). Klicken Sie auf die Schaltfläche Back (Zurück), falls Sie die vorgenommenen
Einstellungen ändern möchten.
Abbildung 4-18: „Ad-Hoc Mode Settings“
(Einstellungen für den Ad-Hoc-Modus)
5. Wenn Ihr Wireless-Netzwerk über keine Wireless-Sicherheitsmethode verfügt, wählen Sie Disabled
(Deaktiviert) aus, und klicken Sie dann auf die Schaltfläche Next (Weiter), um fortzufahren. Fahren Sie mit
Schritt 6 fort.
Wenn in Ihrem Wireless-Netzwerk eine Wireless-Sicherheitsmethode aktiviert ist, wählen Sie die
entsprechende Methode aus: WEP, WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, RADIUS oder LEAP. WEP ist die Abkürzung für Wired Equivalent Privacy und WPA für Wi-Fi Protected Access.
Bei WPA handelt es sich um einen höheren Sicherheitsstandard als bei WEP. WPA2 ist eine leistungsstärkere
Version von WPA. RADIUS ist die Abkürzung für Remote Authentication Dial-In User Service und LEAP für
Lightweight Extensible Authentication Protocol. Klicken Sie auf die Schaltfläche Next (Weiter), um
fortzufahren oder auf die Schaltfläche Back (Zurück), um zum vorherigen Fenster zurückzukehren.
Fahren Sie mit den entsprechenden Anweisungen für die gewünschte Sicherheitsmethode fort: WEP,
WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, RADIUS oder LEAP.
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Einrichten des Adapters
Abbildung 4-19: „Wireless Security“ (Wireless-
Sicherheit) – „Disabled“ (Deaktiviert)
14
Wireless-G Notebook-Adapter
WEP
WEP: Wählen Sie aus dem Dropdown-Menü die 64-Bit- oder die 128-Bit-Verschlüsselung aus.
Passphrase: Geben Sie eine Passphrase in das Feld Passphrase ein, sodass automatisch ein WEP-Schlüssel
generiert wird. Hierbei wird zwischen Groß- und Kleinschreibung unterschieden. Die Länge von 16
alphanumerischen Zeichen darf nicht überschritten werden. Diese Passphrase muss mit der Passphrase Ihrer
anderen Wireless-Netzwerkgeräte übereinstimmen und ist nur mit Wireless-Produkten von Linksys
kompatibel. (Wenn Sie Wireless-Produkte anderer Anbieter verwenden, geben Sie den WEP-Schlüssel bei den
entsprechenden Produkten manuell ein.)
WEP Key (WEP-Schlüssel): Der eingegebene WEP-Schlüssel muss mit dem WEP-Schlüssel Ihres WirelessNetzwerks übereinstimmen. Geben Sie für die 64-Bit-Verschlüsselung genau 10 hexadezimale Zeichen ein.
Geben Sie für die 128-Bit-Verschlüsselung genau 26 hexadezimale Zeichen ein. Gültige hexadezimale
Zeichen sind Zeichen von „0“ bis „9“ und von „A“ bis „F“.
Benutzer mit fortgeschrittenen Kenntnissen
TX Key (Übertragungsschlüssel): Die Standardnummer des Übertragungsschlüssels ist 1. Wenn der Access
Point bzw. der Wireless-Router Ihres Netzwerks die Nummern 2, 3 oder 4 als Übertragungsschlüssel verwendet,
wählen Sie die entsprechende Nummer aus dem Dropdown-Menü TX Key (Übertragungsschlüssel) aus.
Authentication (Authentifizierung): Standardmäßig ist die Option Auto (Automatisch) ausgewählt, wobei die
Authentifizierungsmethoden Shared Key (Gemeinsamer Schlüssel) bzw. Open System (Offenes System)
automatisch erkannt werden. Shared Key (Gemeinsamer Schlüssel) bedeutet, dass Absender und Empfänger
einen gemeinsamen WEP-Schlüssel zur Authentifizierung verwenden. Bei Open System (Offenes System)
verwenden Absender und Empfänger keinen gemeinsamen WEP-Schlüssel zur Authentifizierung. Wenn Sie
sich nicht sicher sind, welche Authentifizierungsmethode Sie wählen sollen, behalten Sie die
Standardeinstellung Auto (Automatisch) bei.
Abbildung 4-20: „Wireless Security“
(Wireless-Sicherheit) - „WEP“
Klicken Sie auf die Schaltfläche Next (Weiter), um fortzufahren, oder klicken Sie auf die Schaltfläche Back
(Zurück), um zum vorherigen Fenster zurückzukehren.
Kapitel 4: Einrichten und Anschließen des Wireless-G Notebook-Adapters
Einrichten des Adapters
Abbildung 4-21: WEP-Einstellungen
15
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
