HDMI Fiber Extender
USER MANUAL LM-THF105H
1. Description
The HDMI Fiber optic extender provides extension of HDMI and 3D signals
long distances over one fiber optic cable, it supports high resolution up to
1080P, EDID copy, RS232 signal transmission and transmitter local output
function. The extender can use for a wide range of applications requiring long
distance transmission of high resolution with high quality by its good stability
and powerful security.
2. Features
Transmits HDMI video signals up to 2km-10km over one fiber optic
cable;
Support video resolution up to 1920*1080P@60Hz, 3D signal;
Support RS232 signal unidirectional transmission, baud rate
self-adaptive;
Support copy EDID, can match many kind display device;
Transmitter support one channel HDMI local output;
Receiver support two channel HDMI output;
Compliance with HDMI 1.3 and HDCP 1.2 standard;
High compatibility, can auto-match source and display device;
Built-in automatic adjustment system, make the image smooth, clear
and stable;
Built-in ESD protection system;
Simple to install, plug and play;
3. Specifications
Parameter
Description
Video
Standards
HDMI 1.3; HDCP 1.2
Maximum pixel
clock
165MHz
Maximum data rate
6.75Gbps
Resolution range
Up to 1920X1080P@60Hz
Connector
Female HDMI type A
Impedance
100Ω
RS232
Interface
DB9 socket
Signal direction
Unidirectional
Baud rate
Self-adaptive, Max：115200bps
Data bits
8
Optical
fiber
Interface
SFP model – LC connector
Fiber type
Single-mode
Wavelength
Single-mode 1310nm
Interface
bandwidth
10Gbps
Transmission
distance
Single-mode fiber: standard 2km；
maximum 10km
Other
Power supply
The power adapter: DC 5V/2A
Power dissipation
MAX 5W
Temperature
Operating: -5℃ ~ +70℃
Humidity
Operating: 5% ~ 90%
Dimension
165*80*30mm
The warranty
1 year free warranty
4. Panel
Transmitter:
Receiver:
Port name
Description
HDMI IN/OUT
HDMI signal input/output
EDID
EDID button, press 3 second to copy EDID of
display device
RS232
DB9 socket
DC/5V
Power adapter socket
Fiber
SFP model --- LC connector
LED indicator
Description
LINK
Optical fiber signal connection indicator
STA
Video signal connection indicator
PWR
System power indicator
5. Package list
HDMI optical fiber transmitter ………. 1 pc
HDMI optical fiber receiver ……………. 1 pc
Fiber optic module TX/RX ……………….1 set
Power adapter ………………………………..2 pcs
User manual ………………………………….. 1 pc
6. Installation
1. Connect the provided DC/5V power supplies to the power socket of the
transmitter and the receiver,
2. Connect an HDMI cable between the HDMI input port of transmitter and
the HDMI output port of the video source,
3. Connect the HDMI output port of receiver to the display device with HDMI
cable,
4. Connect the transmitter optical port to the receiver optical port using one
fiber optic cable.
7. Diagram
