Thank you for choosing the Fly 9 Neckband Bluetooth Earphones developed by Linklike To
better use this product, please read the Quick Start Guide carefully before use and properly
manage it.
PRODUCT SPECIFICATIONS
Bluetooth version
User Manual
Fly 9 Neckband Bluetooth Earphones
L
Bluetooth chip
Transmission range
Charging time
Music play time/Talk time
Standby time
HOW TO USE IMPORTANT SAFETY INFORMATIONHOW TO CHARGE
Turn on : In power off mode, press and hold the middle button for 2 seconds, and there will be
an English voice prompt of ‘power on’ . The red and blue LEDs will flash for 1 second.
Turn off : In any mode,press and hold the middle button for 3 seconds, and there will be an
English voice prompt of ‘power off’ . The red and blue LEDs will flash for 1 second.
Volume up/down : Short press once for voice up and down. When sounds become maximum
or minimum, it will have voice prompt.
Answer/End call : Short press middle button once for answering or ending.
Reject call : Press and hold the middle button for 2 second in the call ring status .
Play /Pause: Short press middle button once for playing/pausing music.
Previous/Next : In playing music, press and hold volume +/- for 2 second.
Clear paired list : Long press the plus and reduce buttons of sound volume for 5 seconds at the
same time, the red and blue lights flash for three times simultaneously.
Using Micro USB cable and plug in the charging port to charge .Low battery (talking time less
than 10 minutes) : there will be a voice prompt ‘battery low’and prompt once per minute ,when
battery power lower than 3.1V, it will be shut down automatically. Charging : the white light on
steadily (It can not turn on when charging).
Fully charged : the blue light stays on steadily in LED.
5.0
QCC3003
About 10m
About 2.5h
About 15h
About 480h
Speaker size
Frequency range
Neck line length
Sensitivity
Impedance
Battery Capacity
6mm
20~20000Hz
300mm
105±3dB
32Ω
Li-Polymer Battery
3.7V/250mAh
EU DECLARATION OF CONFORMITYUSER GUIDE
Hereby, Lilai (Shenzhen) Technology Co., Ltd declares that the radio equipment of Linklike Fly
9 neckband Bluetooth earphones are in compliance with Directive 2014/53/EU. The full text of
the EU declaration of conformity is available at the following internet
address:http://www.linklike-audio.com/
●
Don't remove or replace the Battery,including sensitive electronic components, including a
battery,and can be damaged or cause injury if dropped, burned, punctured, crushed,
disassembled, or if exposed to excessive heat or liquid.Don't use damaged batteries and
electronic components.
●
Dispoal and recycling information
Don't treat the product and battery as a household waste or into a fire. When you decide to
dispose of the product and its battery, please follow the local environmental laws to handle
the battery to avoid an explosion.
Medical device interference
●
The product contains components and radios that emit electromagnetic fields and also
contains magnets. These electromagnetic fields and magnets may interfere with pacemakers,defibrillators, or other medical devices. Maintain a safe distance of separation
between your medical device and product.Consult your physician and medical device
manufacturer for information specific to your medical device. Stop using product if you
suspect it is interfering with your pacemaker, defibrillator, or any other medical device.
CAUTION
Use the Bluetooth Earphone in the environment with the temperature
between-10℃ and 40℃.
The product shall only be connected to a USB interface of version USB2.0 or
higher and that the connection to a power USB is prohibited.
For Battery: Risk of explosion battery is replaced by an incorrect type, dispose of
used batteries according to the instructions.
To prevent possible hearing damage, do not listen at high volume levels for long
periods.
●
Listen Responsibly
To avoid hearing impairment, please make sure to turn down the volume of the music
player before connecting the earphones. After putting the earphones into/onto the ears,
turn up the volume gradually until to a comfortable listening level. Noise level is measured
in de- cibels (db). Exposure to 85db or higher noise will lead to gradual hearing impairment.
Please supervise your usage and the hearing impairment is a function of loudness against
time. The louder the sound is, the shorter you can be exposed. The softer the sound is, the
longer you can listen.
PRODUCT INFORMATION
Fly 9 Neckband Bluetooth Earphones
Ear support
①
ABS plastic front and back the cavity
②
Volume up/Next track
③
Turn on/Turn off/Answer
④
/End call/Reject call/Play/Pause
Volume down/Previous trackNext track
⑤
LED (White light /Blue light)
⑥
The USB connector
⑦
Battery
⑧
Neck line
⑨
FCC WARNNING
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
●
Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
●
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
●
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
HOW TO CONNECT
In off mode, long press the center button for 5 seconds to get the headphone into pairing
1.
status with an English voice prompt ‘power on’. During the pairing process, the red and
blue lights flash by turns. The headphone will automatically shut down if pairing fails
within 5 minutes.
2.
Turn on the Bluetooth on your mobile phone, then search the Bluetooth device.
3.
Choose Bluetooth device named ‘UiiSii BN80 ‘and enter pairing password ‘0000’ to
connect with it. When voice notice “connected” indicate connected successful, The red
and blue lights flashe twice every 4 seconds in connected status.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
●
This device may not cause harmful interference
●
This device must accept any interference received, including interference that may
cause undesired operation.
