BI-HJ023-825US/L1990
Specification
Product Type: Transformer
Model: DT-5000VA
Power: 5000VA
Input and Output Voltage: 220V/110V
Current: 6.82A
Frequency: 50HZ-60HZ
Insulation Grade: B Grade
Operating Temperature: -5-400C
Short Circuit Protection: Yes
Temperature Protection: Yes
Power Phase: Single-phase
Efficiency: 95%
Cooling Mode: Natural Cooling
Cooling Form: Dry Type
Renewal Form: Auto Transfer
Intimate Form: Ring
Shape Structure: Horizontal
Plug: US
Application
This transformer can be used for a wide range of imported appliances, including air conditioners,
refrigerators, washing machines, computers, televisions, electric fans, etc.
Product Size: 27.5*22*20cm/10.8*8.7*7.9inch
Package Size: 31.8*26.5*22.5cm/12.5*10.4*8.6inch
Net Weight: 11.7kg/25.8lbs
Gross Weight: 12kg/26.5lbs
How to Use
1. Determine the input and output voltage.
2. For 220V input and 110V output, please select 220V with the button on the back of the machine;
for 110V input and 220V output, please select 110V.
3. Please select the corresponding output voltage interface on the front of the machine and connect it
to the appliance.
Package Included
1*Transformer
Notes
1. Generally speaking, transformers have electrical energy loss, so you must choose a transformer
that is more than 20% higher than the power of the appliance. In other words, when the power of the
appliance is 1600w, it is better to choose a 2000w transformer; when it is 900w, a 2000w transformer
is also recommended.
2. If your appliances come with motors, such as air conditioners, refrigerators, high-speed blenders,
etc., you should choose a transformer that is more than 30% higher than the power of the appliances.
3. To ensure safety, please energize the machine for 15 minutes before the first use. If there are no
abnormalities, you can connect the appliances for further use.
4. Although the transformer has a heat dissipation function, please pay attention to the ventilation.
And avoid using it in an environment of high humidity and high temperature. Keep it away from
flammable and explosive materials. There is a heat dissipation window on the side, so please do not
have objects blocking the surface. After using the machine, don't forget to cut off the power.
5. For 220V appliances used in the United States, you should first convert the local 110V voltage to
220V, and then connect it to the appliances.
6. Please allow the slight color difference caused by the shooting light and 1-3cm error due to
manual measurement, and make sure you do not mind before you order.
