LINEAR TECHNOLOGY LTC2421, LTC2422 Technical data

FEATURES
1-/2-Channel 20-Bit µPower
No Latency ∆Σ
DESCRIPTIO
LTC2421/LTC2422
TM
ADCs in MSOP-10
U
20-Bit ADCs in Tiny MSOP-10 Packages
1- or 2-Channel Inputs
Single Supply 2.7V to 5.5V Operation
Low Supply Current (200µA) and Auto Shutdown
Automatic Channel Selection (Ping-Pong) (LTC2422)
No Latency: Digital Filter Settles in a Single Conversion Cycle
8ppm INL, No Missing Codes
4ppm Full-Scale Error
0.5ppm Offset
1.2ppm Noise
Zero Scale and Full Scale Set for Reference and Ground Sensing
Internal Oscillator—No External Components Required
110dB Min, 50Hz/60Hz Notch Filter
Reference Input Voltage: 0.1V to V
Live Zero—Extended Input Range Accommodates
CC
12.5% Overrange and Underrange
Pin Compatible with LTC2401/LTC2402
U
APPLICATIO S
Direct Temperature Measurement
Gas Analyzers
Strain Gauge Transducers
Instrumentation
Data Acquisition
Industrial Process Control
The LTC®2421/LTC2422 are 1- and 2-channel 2.7V to 5.5V micropower 20-bit analog-to-digital converters with an integrated oscillator, 8ppm INL and 1.2ppm RMS noise. These ultrasmall devices use delta-sigma technology and a new digital filter architecture that settles in a single cycle. This eliminates the latency found in conventional ∆Σ converters and simplifies multiplexed applications.
Through a single pin, the LTC2421/LTC2422 can be configured for better than 110dB rejection at 50Hz or 60Hz ±2%, or can be driven by an external oscillator for a user defined rejection frequency in the range 1Hz to 120Hz. The internal oscillator requires no external fre­quency setting components.
These converters accept an external reference voltage from 0.1V to VCC. With an extended input conversion range of –12.5% V ZS
), the LTC2421/LTC2422 smoothly resolve the off-
SET
to 112.5% V
REF
REF
(V
REF
= FS
SET
set and overrange problems of preceding sensors or signal conditioning circuits.
The LTC2421/LTC2422 communicate through a 2- or 3-wire digital interface that is compatible with SPI and MICROWIRETM protocols.
, LTC and LT are registered trademarks of Linear Technology Corporation.
No Latency ∆Σ is a trademark of Linear Technology Corporation. MICROWIRE is a trademark of National Semiconductor Corporation.
TYPICAL APPLICATIO
2.7V TO 5.5V
1µF
110
REFERENCE VOLTAGE
ZS
+ 0.1V TO V
SET
ANALOG INPUT RANGE
– 0.12V
SET
+ 0.12V
– ZS
SET
SET
TO
REF
REF
SET
– 100mV
ZS
(V
REF
SET
FS = FS
0V TO FS
CC
)
V
2
FS
3
CH1 SDO
4
CH0
5
ZS
CC
LTC2422
SET
SET
SCK
GND
F
O
CS
U
Pseudo Differential Bridge Digitizer
2.7V TO 5.5V
V
CC
= INTERNAL OSC/50Hz REJECTION = EXTERNAL CLOCK SOURCE = INTERNAL OSC/60Hz REJECTION
9
8
7
6
3-WIRE SPI INTERFACE
24212 TA01
1
V
CC
LTC2422
2
FS
SET
4
CH0
3
CH1
5
ZS
SET
GND
9
SCK
8
CS
F
O
7
10
3-WIRE SPI INTERFACE
INTERNAL OSCILLATOR 60Hz REJECTION
24012TA02
24212f
SDO
6
1
LTC2421/LTC2422
1 2 3 4 5
V
CC
FS
SET
CH1 CH0
ZS
SET
10 9 8 7 6
F
O
SCK SDO CS GND
TOP VIEW
MS10 PACKAGE
10-LEAD PLASTIC MSOP
WW
W
ABSOLUTE MAXIMUM RATINGS
U
(Notes 1, 2)
Supply Voltage (VCC) to GND.......................– 0.3V to 7V
Analog Input Voltage to GND ....... –0.3V to (VCC + 0.3V)
Reference Input Voltage to GND .. –0.3V to (VCC + 0.3V)
Digital Input Voltage to GND........ –0.3V to (VCC + 0.3V)
Digital Output Voltage to GND ..... –0.3V to (VCC + 0.3V)
UUW
PACKAGE/ORDER INFORMATION
TOP VIEW
10
1
V
CC
FS
2
SET
V
3
IN
NC
4
ZS
5
SET
MS10 PACKAGE
10-LEAD PLASTIC MSOP
T
= 125°C, θJA = 130°C/W
JMAX
F
O
SCK
9
SDO
8
CS
7
GND
6
Consult factory for parts specified with wider operating temperature ranges.
ORDER PART NUMBER
LTC2421CMS LTC2421IMS
MS10 PART MARKING
LTUX LTUY
Operating Temperature Range
LTC2421/LTC2422C ................................ 0°C to 70°C
LTC2421/LTC2422I ............................ –40°C to 85°C
Storage Temperature Range ................. –65°C to 150°C
Lead Temperature (Soldering, 10 sec).................. 300°C
ORDER PART NUMBER
LTC2422CMS LTC2422IMS
MS10 PART MARKING
T
= 125°C, θJA = 130°C/W
JMAX
LTUZ LTVA
U
CONVERTER CHARACTERISTICS
temperature range, otherwise specifications are at TA = 25°C. V
PARAMETER CONDITIONS MIN TYP MAX UNITS
Resolution 20 Bits No Missing Codes Resolution 0.1V FS Integral Nonlinearity FS
FS
SET SET
Offset Error 2.5V ≤ FS Offset Error Drift 2.5V ≤ FS Full-Scale Error 2.5V ≤ FS Full-Scale Error Drift 2.5V ≤ FS Total Unadjusted Error FS
FS
SET SET
Output Noise VIN = 0V (Note 13) 6 µV Normal Mode Rejection 60Hz ±2% (Note 7) 110 130 dB Normal Mode Rejection 50Hz ±2% (Note 8) 110 130 dB Power Supply Rejection, DC FS Power Supply Rejection, 60Hz ±2% FS Power Supply Rejection, 50Hz ±2% FS
SET
SET
SET
VCC, ZS
SET
= 2.5V, ZS = 5V, ZS
VCC, ZS
SET
VCC, ZS
SET
VCC, ZS
SET
VCC, ZS
SET
SET
= 2.5V, ZS = 5V, ZS
SET
= 2.5V, ZS = 2.5V, ZS = 2.5V, ZS
SET
= 0V (Note 6) 8 20 ppm of V
SET
= 0V 16 ppm of V
SET
SET
SET
The denotes specifications which apply over the full operating
= FS
REF
= 0V (Note 5) 20 Bits
SET
= 0V (Note 6) 4 10 ppm of V
= 0V 0.5 10 ppm of V
SET
= 0V 0.04 ppm of V
SET
= 0V 4 10 ppm of V
SET
= 0V 0.04 ppm of V
SET
= 0V 8 ppm of V
= 0V, VIN = 0V 100 dB = 0V, VIN = 0V, (Notes 7, 15) 110 dB = 0V, VIN = 0V, (Notes 8, 15) 110 dB
SET
– ZS
. (Notes 3, 4)
SET
REF
REF
REF REF
REF
/°C
REF
/°C
REF REF
RMS
2
24212f
LTC2421/LTC2422
UU
U
A ALOG I PUT A D REFERE CE
temperature range, otherwise specifications are at TA = 25°C. V
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
V
IN
FS
SET
ZS
SET
C
S(IN)
C
S(REF)
I
IN(LEAK)
I
REF(LEAK)
Input Voltage Range (Note 14) ZS Full-Scale Set Range 0.1 + ZS Zero-Scale Set Range 0FS Input Sampling Capacitance 1 pF Reference Sampling Capacitance 1.5 pF Input Leakage Current CS = V Reference Leakage Current V
U
CC
= 2.5V, CS = V
REF
The denotes specifications which apply over the full operating
REF
= FS
CC
SET
– ZS
. (Note 3)
SET
– 0.12V
SET
–100 1 100 nA
–100 1 100 nA
REF
SET
FS
+ 0.12V
SET
SET
V
CC
– 0.1 V
REF
V V
UU
DIGITAL I PUTS A D DIGITAL OUTPUTS
operating temperature range, otherwise specifications are at TA = 25°C. (Note 3)
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
V
IH
V
IL
V
IH
V
IL
I
IN
I
IN
C
IN
C
IN
V
OH
V
OL
V
OH
V
OL
I
OZ
High Level Input Voltage 2.7V ≤ VCC 5.5V 2.5 V CS, F
O
Low Level Input Voltage 4.5V ≤ VCC 5.5V 0.8 V CS, F
O
High Level Input Voltage 2.7V ≤ VCC 5.5V (Note 9) 2.5 V SCK 2.7V V
Low Level Input Voltage 4.5V ≤ VCC 5.5V (Note 9) 0.8 V SCK 2.7V V
Digital Input Current 0V ≤ VIN V CS, F
O
Digital Input Current 0V ≤ VIN VCC (Note 9) –10 10 µA SCK
Digital Input Capacitance 10 pF CS, F
O
Digital Input Capacitance (Note 9) 10 pF SCK
High Level Output Voltage IO = –800µA VCC – 0.5 V SDO
Low Level Output Voltage IO = 1.6mA 0.4 V SDO
High Level Output Voltage IO = –800µA (Note 10) VCC – 0.5 V SCK
Low Level Output Voltage IO = 1.6mA (Note 10) 0.4 V SCK
High-Z Output Leakage –10 10 µA SDO
2.7V VCC 3.3V 2.0 V
2.7V VCC 5.5V 0.6 V
The denotes specifications which apply over the full
3.3V (Note 9) 2.0 V
CC
5.5V (Note 9) 0.6 V
CC
CC
–10 10 µA
WU
POWER REQUIRE E TS
The denotes specifications which apply over the full operating temperature range, otherwise specifications are at TA = 25°C. (Note 3)
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
V
CC
I
CC
Supply Voltage 2.7 5.5 V Supply Current
Conversion Mode CS = 0V (Note 12) Sleep Mode CS = V
(Note 12) 20 30 µA
CC
200 300 µA
24212f
3
LTC2421/LTC2422
UW
TI I G CHARACTERISTICS
range, otherwise specifications are at TA = 25°C. (Note 3)
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
f
EOSC
t
HEO
t
LEO
t
CONV
f
ISCK
D
ISCK
f
ESCK
t
LESCK
t
HESCK
t
DOUT_ISCK
t
DOUT_ESCK
t
1
t
2
t
3
t
4
t
KQMAX
t
KQMIN
t
5
t
6
External Oscillator Frequency Range 2.56 307.2 kHz External Oscillator High Period 0.5 390 µs External Oscillator Low Period 0.5 390 µs Conversion Time FO = 0V 130.86 133.53 136.20 ms
Internal SCK Frequency Internal Oscillator (Note 10) 19.2 kHz
Internal SCK Duty Cycle (Note 10) 45 55 % External SCK Frequency Range (Note 9) 2000 kHz External SCK Low Period (Note 9) 250 ns External SCK High Period (Note 9) 250 ns Internal SCK 24-Bit Data Output Time Internal Oscillator (Notes 10, 12) 1.23 1.25 1.28 ms
External SCK 24-Bit Data Output Time (Note 9) 24/f CS ↓ to SDO Low Z 0 150 ns CS ↑ to SDO High Z 0 150 ns CS ↓ to SCK ↓ (Note 10) 0 150 ns CS ↓ to SCK ↑ (Note 9) 50 ns SCK ↓ to SDO Valid 200 ns SDO Hold After SCK (Note 5) 15 ns SCK Set-Up Before CS 50 ns SCK Hold After CS 50 ns
The denotes specifications which apply over the full operating temperature
= V
F
O
CC
External Oscillator (Note 11)
External Oscillator (Notes 10, 11) f
External Oscillator (Notes 10, 11)
157.03 160.23 163.44 ms
20510/f
192/f
(in kHz) ms
EOSC
/8 kHz
EOSC
(in kHz) ms
EOSC
(in kHz) ms
ESCK
Note 1: Absolute Maximum Ratings are those values beyond which the life of the device may be impaired.
Note 2: All voltage values are with respect to GND. Note 3: V
= 2.7 to 5.5V unless otherwise specified. Input source
CC
resistance = 0Ω. Note 4: Internal Conversion Clock source with the F
to GND or to V f
= 153600Hz unless otherwise specified.
EOSC
or to external conversion clock source with
CC
pin tied
O
Note 5: Guaranteed by design, not subject to test. Note 6: Integral nonlinearity is defined as the deviation of a code from
a straight line passing through the actual endpoints of the transfer curve. The deviation is measured from the center of the quantization band.
Note 7: FO = 0V (internal oscillator) or f
= 153600Hz ±2%
EOSC
(external oscillator). Note 8: F
= VCC (internal oscillator) or f
O
= 128000Hz ±2%
EOSC
(external oscillator).
Note 9: The converter is in external SCK mode of operation such that the SCK pin is used as digital input. The frequency of the clock signal driving SCK during the data output is f
and is expressed in kHz.
ESCK
Note 10: The converter is in internal SCK mode of operation such that the SCK pin is used as digital output. In this mode of operation, the SCK pin has a total equivalent load capacitance C
LOAD
= 20pF.
Note 11: The external oscillator is connected to the FO pin. The external oscillator frequency, f
, is expressed in kHz.
EOSC
Note 12: The converter uses the internal oscillator.
= 0V or FO = VCC.
F
O
Note 13: The output noise includes the contribution of the internal calibration operations.
= FS
Note 14: V
REF
SET
– ZS
to –0.3V and the maximum to V Note 15: VCC (DC) = 4.1V, VCC (AC) = 2.8V
. The minimum input voltage is limited
SET
+ 0.3V.
CC
.
P-P
24212f
4
UW
TYPICAL PERFOR A CE CHARACTERISTICS
Total Unadjusted Error (3V Supply) INL (3V Supply)
10
VCC = 3V
8
= 2.5V
V
REF
6 4 2 0
–2
ERROR (ppm)
–10
–4 –6 –8
0
TA = –55°C, –45°C, 25°C, 90°C
0.5 INPUT VOLTAGE (V)
1.0
1.5
Positive Extended Input Range Total Unadjusted Error (3V Supply)
VCC = 3V
8
= 2.5V
V
REF
6 4 2 0
–2
ERROR (ppm)
–4 –6 –8
–10
TA = –55°C, –45°C, 25°C, 90°C
2.50
2.55
2.60
INPUT VOLTAGE (V)
2.65 2.70
2.0
24212 G01
2.75102.80
24212 G04
2.5
10
VCC = 3V
8
= 2.5V
V
REF
6 4
2 0
–2
ERROR (ppm)
–4 –6 –8
–10
0
TA = –55°C, –45°C, 25°C, 90°C
0.5 INPUT VOLTAGE (V)
1.0
1.5
2.0
Total Unadjusted Error (5V Supply) INL (5V Supply)
10
VCC = 5V
8
V
= 5V
REF
6 4
2 0
–2
ERROR (ppm)
–4 –6 –8
–10
TA = –55°C, –45°C, 25°C, 90°C
1
0
2
INPUT VOLTAGE (V)
3
4
24212 G02
24212 G05
2.5
5
LTC2421/LTC2422
Negative Extended Input Range Total Unadjusted Error (3V Supply)
VCC = 3V
8
V
REF
6 4 2 0
–2
ERROR (ppm)
–4 –6 –8
–10
0
10
VCC = 5V
8
V
REF
6 4
2 0
–2
ERROR (ppm)
–4 –6 –8
–10
0
= 2.5V
–0.05
= 5V
TA = –55°C, –45°C, 25°C, 90°C
1
TA = 90°C
–0.15 –0.20
–0.10
INPUT VOLTAGE (V)
3
2
INPUT VOLTAGE (V)
TA = 25°C
TA = –45°C
TA = –55°C
–0.2510–0.30
4
24212 G03
5
24212 G06
Negative Extended Input Range Total Unadjusted Error (5V Supply)
VCC = 5V
8
V
REF
6 4 2 0
–2
ERROR (ppm)
–4 –6 –8
–10
0
= 5V
–0.05
–0.10 INPUT VOLTAGE (V)
TA = 25°C TA = 90°C TA = –45°C
–0.15 –0.20
TA = –55°C
–0.2510–0.30
24212 G07
Positive Extended Input Range Total Unadjusted Error (5V Supply)
VCC = 5V
8
= 5V
V
REF
6 4 2 0
–2
ERROR (ppm)
–4
–6
–10
–8
5.00
5.05
TA = 25°CTA = 90°C
5.15 5.20
5.10
INPUT VOLTAGE (V)
TA = –55°C
TA = –45°C
5.25105.30
24212 G08
Offset Error vs Reference Voltage
150
120
90
60
OFFSET ERROR (ppm)
30
0
1
0
REFERENCE VOLTAGE (V)
3
2
VCC = 5V
= 25°C
T
A
4
24212 G09
5
24212f
5
LTC2421/LTC2422
UW
TYPICAL PERFOR A CE CHARACTERISTICS
RMS Noise vs Reference Voltage Offset Error vs V
60
50
)
REF
40
30
20
RMS NOISE (ppm OF V
10
0
0
1234
REFERENCE VOLTAGE (V)
VCC = 5V
= 25°C
T
A
24212 G10
5
10
V
= 2.5V
REF
T
= 25°C
A
5
0
OFFSET ERROR (ppm)
–5
–10
2.7
3.2 3.7 4.2 4.7
CC
V
(V)
CC
5.2 5.5
24212 G11
RMS Noise vs V
10.0 V
= 2.5V
REF
T
= 25°C
A
7.5
5.0
RMS NOISE (ppm)
2.5
0
2.7
3.2 3.7 4.2 4.7
CC
VCC (V)
Noise Histogram RMS Noise vs Code Out Offset Error vs Temperature
350
VCC = 5
= 5
V
REF
300
= 0
V
IN
250
200
150
100
NUMBER OF READINGS
50
5.00 VCC = 5V
= 5V
V
REF
V
= 0.3V TO 5.3V
IN
= 25°C
T
A
3.75
2.50
RMS NOISE (ppm)
1.25
10
VCC = 5V
= 5V
V
REF
= 0V
V
IN
5
0
OFFSET ERROR (ppm)
–5
5.2 5.5
24212 G12
0
–2 0
26
OUTPUT CODE (ppm)
Full-Scale Error vs Temperature
10
VCC = 5V
= 5V
V
REF
= 5V
V
IN
5
0
–5
FULL-SCALE ERROR (ppm)
–10
–55
–30 –5 20 45
TEMPERATURE (°C)
4
24212 G13
70 95 120
24212 G16
0
0 7FFFF FFFFF
CODE OUT (HEX)
24212 G14
–10
–55
–30 –5 20 45
TEMPERATURE (°C)
Full-Scale Error vs Reference Voltage Full-Scale Error vs V
0
–25
–50
–75
–100
FULL-SCALE ERROR (ppm)
–125
–150
0
1234
REFERENCE VOLTAGE (V)
VCC = 5V
= V
V
IN
24212 G17
REF
5
10
V
= 2.5V
REF
= 2.5V
V
IN
= 25°C
T
A
5
0
–5
FULL-SCALE ERROR (ppm)
–10
2.7
3.2 3.7 4.2 4.7
70 95 120
24212 G15
CC
5.2 5.5
VCC (V)
24212 G18
24212f
6
UW
FREQUENCY AT VIN (Hz)
1
–120
REJECTION (dB)
–100
–80
–60
–40
–20
0
50 100 150 200
24212 G24
250
VCC = 5V V
REF
= 5V
V
IN
= 2.5V
F
O
= 0
INPUT FREQUENCY
0
–60
–40
0
24212 G27
–80
–100
fS/2 f
S
–120
–140
–20
REJECTION (dB)
TYPICAL PERFOR A CE CHARACTERISTICS
Conversion Current vs Temperature
230
220
210
200
190
180
SUPPLY CURRENT (µA)
170
160
150
–30 –5 45
–55
VCC = 5.5V
VCC = 4.1V
VCC = 2.7V
20
TEMPERATURE (°C)
70 95 120
24212 G19
Sleep Current vs Temperature
30
20
10
SUPPLY CURRENT (µA)
0
–30 –5 20 45
–55
VCC = 2.7V
VCC = 5V
TEMPERATURE (°C)
70 95 120
24212 G20
LTC2421/LTC2422
Rejection vs Frequency at V
0
VCC = 4.1V
= 0V
V
IN
–20
= 25°C
T
A
= 0
F
O
–40
–60
REJECTION (dB)
–80
–100
–120
1
100 10k 1M
FREQUENCY AT VCC (Hz)
CC
24212 G23
Rejection vs Frequency at V
–20
VCC = 4.1V V
= 0V
IN
= 25°C
T
A
–40
F
= 0
O
–60
–80
REJECTION (dB)
–100
–120
50
1
FREQUENCY AT VCC (Hz)
100
150
Rejection vs Frequency at V
–60
–70
–80
–90
–100
–110
REJECTION (dB)
–120
–130
–140
12–8–404812
INPUT FREQUENCY DEVIATION FROM NOTCH FREQUENCY (%)
200
CC
250
24212 G21
IN
24212 G25
Rejection vs Frequency at V
0
VCC = 4.1V
= 0V
V
IN
–20
= 25°C
T
A
= 0
F
O
–40
–60
REJECTION (dB)
–80
–100
–120
15200
15300 15350 15400
15250
FREQUENCY AT VCC (Hz)
Rejection vs Frequency at V
0
VCC = 5V
= 5V
V
REF
–20
= 2.5V
V
IN
= 0
F
O
–40
–60
REJECTION (dB)
–80
–100
–120
SAMPLE RATE = 15.36kHz ±2%
15100
15200 15300 15400 15500
FREQUENCY AT VIN (Hz)
CC
15450 15500
24212 G22
IN
24212 G26
Rejection vs Frequency at V
Rejection vs Frequency at V
IN
IN
24212f
7
LTC2421/LTC2422
UW
TYPICAL PERFOR A CE CHARACTERISTICS
INL vs Output Rate
20
VCC = 5V
= 5V
V
REF
= EXTERNAL
F
O
18
16
14
TUE RESOLUTION (BITS)
12
10
0
10
TA = –45°C
30
20
OUTPUT RATE (Hz)
TA = 25°C
40
50 60 70 80 90
TA = 90°C
100
24212 G28
INL vs Output Rate
20
VCC = 3V
= 2.5V
V
REF
= EXTERNAL
F
O
18
16
TA = –45°C
14
TA = 25°C
TUE RESOLUTION (BITS)
12
10
102030
0
OUTPUT RATE (Hz)
40
UUU
PIN FUNCTIONS
VCC (Pin 1): Positive Supply Voltage. Bypass to GND (Pin␣ 6) with a 10µF tantalum capacitor in parallel with
0.1µF ceramic capacitor as close to the part as possible.
Resolution vs Output Rate
24
22
20
TA = 90°C
50 60 70 80 90
24212 G29
100
VCC = 5V
18
V
= 5V
REF
EFFECTIVE RESOLUTION (BITS)
= EXTERNAL
f
O
STANDARD DEVIATION OF 100 SAMPLES
16
0 7.5
25
50
OUTPUT RATE (Hz)
TA = 25°C
= 90°C
T
A
T
= –45°C
A
75
100
24212 G30
be connected directly to a ground plane through a mini­mum length trace or it should be the single-point-ground in a single-point grounding system.
FS
(Pin 2): Full-Scale Set Input. This pin defines the
SET
full-scale input value. When VIN = FS
, the ADC outputs
SET
full scale (FFFFFH). The total reference voltage is FS
SET
– ZS
SET
.
CH0, CH1 (Pins 4, 3): Analog Input Channels. The input voltage range is –0.125 • V V
> 2.5V, the input voltage range may be limited by the
REF
to 1.125 • V
REF
REF
. For
absolute maximum rating of – 0.3V to VCC + 0.3V. Conver­sions are performed alternately between CH0 and CH1 for the LTC2422. Pin 4 is a No Connect (NC) on the LTC2421.
ZS
(Pin 5): Zero-Scale Set Input. This pin defines the
SET
zero-scale input value. When VIN = ZS
, the ADC
SET
outputs zero scale (00000H). GND (Pin 6): Ground. Shared pin for analog ground,
digital ground, reference ground and signal ground. Should
CS (Pin 7): Active LOW Digital Input. A LOW on this pin enables the SDO digital output and wakes up the ADC. Following each conversion, the ADC automatically enters the Sleep mode and remains in this low power state as long as CS is HIGH. A LOW on CS wakes up the ADC. A LOW-to-HIGH transition on this pin disables the SDO digital output. A LOW-to-HIGH transition on CS during the Data Output transfer aborts the data transfer and starts a new conversion.
SDO (Pin 8): Three-State Digital Output. During the data output period, this pin is used for serial data output. When the chip select CS is HIGH (CS = VCC), the SDO pin is in a high impedance state. During the Conversion and Sleep periods, this pin can be used as a conversion status out­put. The conversion status can be observed by pulling CS LOW.
8
24212f
LTC2421/LTC2422
3.4k
SDO
24212 TC02
Hi-Z TO V
OL
VOH TO V
OL
VOL TO Hi-Z
C
LOAD
= 20pF
V
CC
U
UU
PIN FUNCTIONS
SCK (Pin 9): Bidirectional Digital Clock Pin. In the Internal Serial Clock Operation mode, SCK is used as digital output for the internal serial interface clock during the data output period. In the External Serial Clock Operation mode, SCK is used as digital input for the external serial interface. An internal pull-up current source is automatically activated in Internal Serial Clock Operation mode. The Serial Clock mode is determined by the level applied to SCK at power up and the falling edge of CS.
UU
W
FUNCTIONAL BLOCK DIAGRA
V
CC
GND
FO (Pin 10): Frequency Control Pin. Digital input that controls the ADC’s notch frequencies and conversion time. When the FO pin is connected to VCC (FO = VCC), the converter uses its internal oscillator and the digital filter’s first null is located at 50Hz. When the FO pin is connected to GND (FO = 0V), the converter uses its internal oscillator and the digital filter’s first null is located at 60Hz. When F is driven by an external clock signal with a frequency f
EOSC
O
, the converter uses this signal as its clock and the digital filter first null is located at a frequency f
OSCILLATOR
AUTOCALIBRATION
AND CONTROL
EOSC
INTERNAL
/2560.
(INT/EXT)
F
O
V
IN
V
REF
TEST CIRCUITS
SDO
DAC
3.4k
Hi-Z TO V
OH
VOL TO V
OH
VOH TO Hi-Z
C
LOAD
= 20pF
24212 TC01
ADC
DECIMATING FIR
SERIAL
INTERFACE
SDO
SCK
CS
24212 FD
24212f
9
LTC2421/LTC2422
CONVERT
SLEEP
DATA OUTPUT
24212 F02
0
1
CS AND
SCK
WUUU
APPLICATIO S I FOR ATIO
The LTC2421/LTC2422 are pin compatible with the LTC2401/LTC2402. The devices are designed to allow the user to incorporate either device in the same design with no modifications. While the LTC2421/LTC2422 output word length is 24 bits (as opposed to the 32-bit output of the LTC2401/LTC2402), its output clock timing can be identi­cal to the LTC2401/LTC2402. As shown in Figure 1, the LTC2421/LTC2422 data output is concluded on the falling edge of the 24th serial clock (SCK). In order to maintain drop-in compatibility with the LTC2401/LTC2402, it is possible to clock the LTC2421/LTC2422 with an additional 8 serial clock pulses. This results in 8 additional output bits which are always logic HIGH.
Converter Operation Cycle
The LTC2421/LTC2422 are low power, delta-sigma ana­log-to-digital converters with an easy to use 3-wire serial interface. Their operation is simple and made up of three states. The converter operating cycle begins with the con­version, followed by the sleep state and concluded with the data output (see Figure 2). The 3-wire interface consists of serial data output (SDO), a serial clock (SCK) and a chip select (CS).
Once CS is pulled LOW and SCK rising edge is applied, the device begins outputting the conversion result. There is no latency in the conversion result. The data output corre­sponds to the conversion just performed. This result is shifted out on the serial data out pin (SDO) under the control of the serial clock (SCK). Data is updated on the falling edge of SCK allowing the user to reliably latch data on the rising edge of SCK, see Figure 4. The data output state is concluded once 24 bits are read out of the ADC or when CS is brought HIGH. The device automatically initiates a new conversion and the cycle repeats.
Through timing control of the CS and SCK pins, the LTC2421/LTC2422 offer several flexible modes of opera­tion (internal or external SCK and free-running conver­sion modes). These various modes do not require program
ming configuration registers; moreover, they do not disturb the cyclic operation described above. These modes of operation are described in detail in the Serial Interface Timing Modes section.
Initially, the LTC2421/LTC2422 perform a conversion. Once the conversion is complete, the device enters the sleep state. While in this sleep state, power consumption is re­duced by an order of magnitude if CS is HIGH. The part remains in the sleep state as long as CS is logic HIGH. The conversion result is held indefinitely in a static shift regis­ter while the converter is in the sleep state.
CS
SCK
EOC = 0
SDO
EOC = 1
CONVERSION SLEEP
Figure 1. LTC2421/LTC2422 Compatible Timing with the LTC2401/LTC2402
Figure 2. LTC2421/LTC2422 State Transition Diagram
8 8 8 8 (OPTIONAL)
DATA OUT
4 STATUS BITS 20 DATA BITS
DATA OUTPUT
EOC = 1
LAST 8 BITS ALWAYS 1
CONVERSION
24212 F01
24212f
10
WUUU
APPLICATIO S I FOR ATIO
LTC2421/LTC2422
Conversion Clock
A major advantage delta-sigma converters offer over con­ventional type converters is an on-chip digital filter (com­monly known as Sinc or Comb filter). For high resolution, low frequency applications, this filter is typically designed to reject line frequencies of 50Hz or 60Hz plus their har­monics. In order to reject these frequencies in excess of 110dB, a highly accurate conversion clock is required. The LTC2421/LTC2422 incorporate an on-chip highly accu­rate oscillator. This eliminates the need for external fre­quency setting components such as crystals or oscilla­tors. Clocked by the on-chip oscillator, the LTC2421/ LTC2422 reject line frequencies (50Hz or 60Hz ±2%) a minimum of 110dB.
Ease of Use
The LTC2421/LTC2422 data output has no latency, filter settling or redundant data associated with the conver­sion cycle. There is a one-to-one correspondence be­tween the conversion and the output data. Therefore, multiplexing an analog input voltage is easy.
The LTC2421/LTC2422 perform offset and full-scale cali­brations every conversion cycle. This calibration is trans­parent to the user and has no effect on the cyclic operation described above. The advantage of continuous calibration is extreme stability of offset and full-scale readings with respect to time, supply voltage change and temperature drift.
Power-Up Sequence
above. The first conversion result following POR is accu­rate within the specifications of the device.
Reference Voltage Range
The LTC2421/LTC2422 can accept a reference voltage = FS
SET
– ZS
)
from 0V to VCC. The converter output
SET
(V
REF
noise is determined by the thermal noise of the front-end circuits, and as such, its value in microvolts is nearly con­stant with reference voltage. A decrease in reference volt­age will not significantly improve the converter’s effective resolution. On the other hand, a reduced reference voltage will improve the overall converter INL performance. The recommended range for the LTC2421/LTC2422 voltage reference is 100mV to VCC.
Input Voltage Range
The converter is able to accommodate system level offset and gain errors as well as system level overrange situa­tions due to its extended input range, see Figure 3. The LTC2421/LTC2422 convert input signals within the ex­tended input range of –0.125 • V (V
= FS
REF
For large values of V
SET
– ZS
SET
REF
).
(V
= FS
REF
to 1.125 • V
REF
– ZS
SET
SET
),
REF
this range is limited by the absolute maximum voltage range of –0.3V to (VCC + 0.3V). Beyond this range, the input ESD protection devices begin to turn on and the errors due to the input leakage current increase rapidly.
Input signals applied to VIN may extend below ground by –300mV and above VCC by 300mV. In order to limit any
The LTC2421/LTC2422 automatically enter an internal reset state when the power supply voltage VCC drops below approximately 2.2V. This feature guarantees the integrity of the conversion result and of the serial interface mode selection which is performed at the initial power-up. (See the 2-wire I/O sections in the Serial Interface Timing Modes section.)
When the VCC voltage rises above this critical threshold, the converter creates an internal power-on-reset (POR) signal with duration of approximately 0.5ms. The POR signal clears all internal registers. Following the POR sig­nal, the LTC2421/LTC2422 start a normal conversion cycle and follows the normal succession of states described
FS
ZS
VCC + 0.3V
+ 0.12V
SET
– 0.12V
SET
REF
FS
SET
NORMAL
INPUT
RANGE
ZS
SET
REF
–0.3V
Figure 3. LTC2421/LTC2422 Input Range
= FS
(V
REF
SET
– ZS
EXTENDED
INPUT
RANGE
)
SET
ABSOLUTE MAXIMUM
INPUT
RANGE
24212 F03
24212f
11
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
fault current, a resistor of up to 5k may be added in series with the VIN pin without affecting the performance of the device. In the physical layout, it is important to maintain the parasitic capacitance of the connection between this series resistance and the VIN pin as low as possible; there­fore, the resistor should be located as close as practical to the VIN pin. The effect of the series resistance on the con­verter accuracy can be evaluated from the curves pre­sented in the Analog Input/Reference Current section. In addition, a series resistor will introduce a temperature de­pendent offset error due to the input leakage current. A 1nA input leakage current will develop a 1ppm offset error on a 5k resistor if V
= 5V. This error has a very strong
REF
temperature dependency.
Output Data Format
The LTC2421/LTC2422 serial output data stream is 24 bits long. The first 4 bits represent status information indicat­ing the sign, selected channel, input range and conversion state. The next 20 bits are the conversion result, MSB first.
Bit 23 (first output bit) is the end of conversion (EOC) indicator. This bit is available at the SDO pin during the conversion and sleep states whenever the CS pin is LOW. This bit is HIGH during the conversion and goes LOW when the conversion is complete.
Bit 22 (second output bit) for the LTC2422, this bit is LOW if the last conversion was performed on CH0 and HIGH for CH1. This bit is always LOW for the LTC2421.
Bit 21 (third output bit) is the conversion result sign indi­cator (SIG). If VIN is >0, this bit is HIGH. If VIN is <0, this bit is LOW. The sign bit changes state during the zero code.
Bit 20 (fourth output bit) is the extended input range (EXR) indicator. If the input is within the normal input range
0␣ ≤␣VIN V normal input range, VIN > V
, this bit is LOW. If the input is outside the
REF
or VIN < 0, this bit is HIGH.
REF
The function of these bits is summarized in Table 1.
Table 1. LTC2421/LTC2422 Status Bits
Input Range EOC CH0/CH1 SIG EXR
VIN > V
REF
0 < VIN V VIN = 0+/0 VIN < 0 0 *0/1 0 1 *Bit 22 displays the channel number for the LTC2422. Bit 22 is always
0 for the LTC2421
REF
Bit 23 Bit 22 Bit 21 Bit 20
0 *0/1 1 1 0 *0/1 1 0 0 *0/1 1/0 0
Bit 19 (fifth output bit) is the most significant bit (MSB). Bits 19-0 are the 20-bit conversion result MSB first. Bit 0 is the least significant bit (LSB). Data is shifted out of the SDO pin under control of the serial
clock (SCK), see Figure 4. Whenever CS is HIGH, SDO remains high impedance and any SCK clock pulses are ignored by the internal data out shift register.
In order to shift the conversion result out of the device, CS must first be driven LOW. EOC is seen at the SDO pin of the device once CS is pulled LOW. EOC changes real time from HIGH to LOW at the completion of a conversion. This sig­nal may be used as an interrupt for an external microcon­troller. Bit 23 (EOC) can be captured on the first rising edge of SCK. Bit 22 is shifted out of the device on the first falling edge of SCK. The final data bit (Bit 0) is shifted out on the falling edge of the 23rd SCK and may be latched on the rising edge of the 24th SCK pulse. On the falling edge of the 24th SCK pulse, SDO goes HIGH indicating a new conver­sion cycle has been initiated. This bit serves as EOC (Bit
23) for the next conversion cycle. Table 2 summarizes the output data format.
12
CS
BIT 23
SDO
Hi-Z
SCK
EOC
1 2 3 4 5 192024
SLEEP DATA OUTPUT CONVERSION
BIT 20BIT 21BIT 22
MSBEXTSIGCH0/CH1
Figure 4. Output Data Timing
BIT 0BIT 19 BIT 4
LSB
20
24212 F04
24212f
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
Table 2. LTC2421/LTC2422 Output Data Format
Bit 23 Bit 22* Bit 21 Bit 20 Bit 19 Bit 18 Bit 17 Bit 16 Bit 15 Bit 0
Input Voltage EOC CH0/CH1 SIG EXR MSB LSB
VIN > 9/8 • V 9/8 • V V
REF
V
REF
3/4V 3/4V 1/2V 1/2V 1/4V 1/4V 0+/0 –1LSB 0 CH0/CH1 0111 1 11...1 –1/8 • V VIN < –1/8 • V *Bit 22 is always 0 for the LTC2421 **The sign bit changes state during the 0 code.
REF
REF
+ 1LSB 0 CH0/CH1 1100 0 00...0
+ 1LSB 0 CH0/CH1 1011 0 00...0
REF
REF
+ 1LSB 0 CH0/CH1 1010 0 00...0
REF
REF
+ 1LSB 0 CH0/CH1 1001 0 00...0
REF
REF
REF
REF
0 CH0/CH1 1100 0 11...1 0 CH0/CH1 1100 0 11...1
0 CH0/CH1 1011 1 11...1
0 CH0/CH1 1010 1 11...1
0 CH0/CH1 1001 1 11...1
0 CH0/CH1 1000 1 11...1 0 CH0/CH1 1/0** 0 0 0 0 0 0 ... 0
0 CH0/CH1 0111 1 00...0 0 CH0/CH1 0111 1 00...0
As long as the voltage on the VIN pin is maintained within the –0.3V to (VCC + 0.3V) absolute maximum operating range, a conversion result is generated for any input value from –0.125 • V greater than 1.125 • V to the value corresponding to 1.125 • V ages below – 0.125 • V to the value corresponding to –0.125 • V
to 1.125 • V
REF
, the conversion result is clamped
REF
, the conversion result is clamped
REF
For input voltages
REF.
. For input volt-
REF
.
REF
Frequency Rejection Selection (FO Pin Connection)
The LTC2421/LTC2422 internal oscillator provides better than 110dB normal mode rejection at the line frequency and all its harmonics for 50Hz ±2% or 60Hz ±2%. For 60Hz rejection, FO (Pin 10) should be connected to GND (Pin 6) while for 50Hz rejection the FO pin should be con­nected to V
(Pin␣ 1).
CC
The selection of 50Hz or 60Hz rejection can also be made by driving FO to an appropriate logic level. A selection change during the sleep or data output states will not disturb the converter operation. If the selection is made during the conversion state, the result of the conversion in progress may be outside specifications but the following conversions will not be affected.
When a fundamental rejection frequency different from 50Hz or 60Hz is required or when the converter must be synchronized with an outside source, the LTC2421/ LTC2422 can operate with an external conversion clock. The converter automatically detects the presence of an external clock signal at the FO pin and turns off the internal oscillator. The frequency f
of the external signal must
EOSC
be at least 2560Hz (1Hz notch frequency) to be detected. The external clock signal duty cycle is not significant as long as the minimum and maximum specifications for the high and low periods t
HEO
and t
are observed.
LEO
While operating with an external conversion clock of a frequency f 110dB normal mode rejection in a frequency range f
, the LTC2421/LTC2422 provide better than
EOSC
EOSC
/
2560 ±4% and its harmonics. The normal mode rejection as a function of the input frequency deviation from f
EOSC
/
2560 is shown in Figure 5. Whenever an external clock is not present at the FO pin, the
converter automatically activates its internal oscillator and enters the Internal Conversion Clock mode. The LTC2421/ LTC2422 operation will not be disturbed if the change of conversion clock source occurs during the sleep state or during the data output state while the converter uses an
24212f
13
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
–60
–70
–80
–90
–100
–110
REJECTION (dB)
–120
–130
–140
12–8–404812
INPUT FREQUENCY DEVIATION FROM NOTCH FREQUENCY (%)
24212 F05
Figure 5. LTC2421/LTC2422 Normal Mode Rejection When Using an External Oscillator of Frequency f
EOSC
external serial clock. If the change occurs during the con­version state, the result of the conversion in progress may be outside specifications but the following conversions will not be affected. If the change occurs during the data output state and the converter is in the Internal SCK mode, the serial clock duty cycle may be affected but the serial data stream will remain valid.
Table 3 summarizes the duration of each state as a func­tion of FO.
SERIAL INTERFACE
synchronous 3-wire interface. During the conversion and sleep states, this interface can be used to assess the con­verter status and during the data output state, it is used to read the conversion result.
Serial Clock Input/Output (SCK)
The serial clock signal present on SCK (Pin 9) is used to synchronize the data transfer. Each bit of data is shifted out the SDO pin on the falling edge of the serial clock.
In the Internal SCK mode of operation, the SCK pin is an output and the LTC2421/LTC2422 create their own serial clock by dividing the internal conversion clock by 8. In the External SCK mode of operation, the SCK pin is used as input. The internal or external SCK mode is selected on power-up and then reselected every time a HIGH-to-LOW transition is detected at the CS pin. If SCK is HIGH or floating at power-up or during this transition, the con­verter enters the internal SCK mode. If SCK is LOW at power-up or during this transition, the converter enters the external SCK mode.
Serial Data Output (SDO)
The serial data output pin, SDO (Pin 8), drives the serial data during the data output state. In addition, the SDO pin is used as an end of conversion indicator during the con­version and sleep states.
The LTC2421/LTC2422 transmit the conversion results and receives the start of conversion command through a
Table 3. LTC2421/LTC2422 State Duration
State Operating Mode Duration
CONVERT Internal Oscillator FO = LOW 133ms
(60Hz Rejection) FO = HIGH 160ms
(50Hz Rejection)
External Oscillator FO = External Oscillator 20510/f
with Frequency f
/2560 Rejection)
(f
EOSC
SLEEP As Long As CS = HIGH Until CS = 0 and SCK DATA OUTPUT Internal Serial Clock FO = LOW/HIGH As Long As CS = LOW But Not Longer Than 1.28ms
(Internal Oscillator) (24 SCK cycles) FO = External Oscillator with As Long As CS = LOW But Not Longer Than 192/f
Frequency f
External Serial Clock with As Long As CS = LOW But Not Longer Than 24/f Frequency f
kHz (24 SCK cycles)
SCK
EOSC
When CS (Pin 7) is HIGH, the SDO driver is switched to a high impedance state. This allows sharing the serial
s
kHz
EOSC
kHz (24 SCK cycles)
EOSC
SCK
EOSC
ms
14
ms
24212f
WUUU
APPLICATIO S I FOR ATIO
LTC2421/LTC2422
interface with other devices. If CS is LOW during the con­vert or sleep state, SDO will output EOC. If CS is LOW during the conversion phase, the EOC bit appears HIGH on the SDO pin. Once the conversion is complete, EOC goes LOW. The device remains in the sleep state until the first rising edge of SCK occurs while CS = 0. While in the sleep state, the device is in a LOW power state if CS is HIGH.
Chip Select Input (CS)
The active LOW chip select, CS (Pin 7), is used to test the conversion status and to enable the data output transfer as described in the previous sections.
In addition, the CS signal can be used to trigger a new conversion cycle before the entire serial data transfer has been completed. The LTC2421/LTC2422 will abort any serial data transfer in progress and start a new conversion cycle anytime a LOW-to-HIGH transition is detected at the CS pin after the converter has entered the data output state (i.e., after the first rising edge of SCK occurs with CS = 0).
Finally, CS can be used to control the free-running modes of operation, see Serial Interface Timing Modes section. Grounding CS will force the ADC to continuously convert at the maximum output rate selected by FO. Tying a ca­pacitor to CS will reduce the output rate and power dissi­pation by a factor proportional to the capacitor’s value, see Figures 13 to 15.
SERIAL INTERFACE TIMING MODES
The LTC2421/LTC2422’s 3-wire interface is SPI and MICROWIRE compatible. This interface offers several flexible modes of operation. These include internal/exter­nal serial clock, 2- or 3-wire I/O, single cycle conversion and autostart. The following sections describe each of
these serial interface timing modes in detail. In all these cases, the converter can use the internal oscillator (FO = LOW or FO = HIGH) or an external oscillator connected to the FO pin. Refer to Table 4 for a summary.
External Serial Clock, Single Cycle Operation (SPI/MICROWIRE Compatible)
This timing mode uses an external serial clock to shift out the conversion result and a CS signal to monitor and con­trol the state of the conversion cycle, see Figure 6.
The serial clock mode is selected on the falling edge of CS. To select the external serial clock mode, the serial clock pin (SCK) must be LOW during each CS falling edge.
The serial data output pin (SDO) is Hi-Z as long as CS is HIGH. At any time during the conversion cycle, CS may be pulled LOW in order to monitor the state of the converter. While CS is LOW, EOC is output to the SDO pin. EOC = 1 while a conversion is in progress and EOC = 0 if the device is in the sleep state. Independent of CS, the device auto­matically enters the sleep state once the conversion is complete. While in the sleep state, power is reduced an order of magnitude if CS is HIGH.
When the device is in the sleep state (EOC = 0), its conversion result is held in an internal static shift register. The device remains in the sleep state until the first rising edge of SCK is seen while CS is LOW. Data is shifted out the SDO pin on each falling edge of SCK. This enables external circuitry to latch the output on the rising edge of SCK. EOC can be latched on the first rising edge of SCK and the last bit of the conversion result can be latched on the 24th rising edge of SCK. On the 24th falling edge of SCK, the device begins a new conversion. SDO goes HIGH (EOC = 1) indicating a conversion is in progress.
Table 4. LTC2421/LTC2422 Interface Timing Modes
Conversion Data Connection
SCK Cycle Output and
Configuration Source Control Control Waveforms
External SCK, Single Cycle Conversion External CS and SCK CS and SCK Figures 6, 7 External SCK, 2-Wire I/O External SCK SCK Figure 8 Internal SCK, Single Cycle Conversion Internal CS CS ↓ Figures 9, 10 Internal SCK, 2-Wire I/O, Continuous Conversion Internal Continuous Internal Figure 11 Internal SCK, Autostart Conversion Internal C
EXT
Internal Figure 12
15
24212f
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
At the conclusion of the data cycle, CS may remain LOW and EOC monitored as an end-of-conversion interrupt. Alternatively, CS may be driven HIGH setting SDO to Hi-Z. As described above, CS may be pulled LOW at any time in order to monitor the conversion status.
Typically, CS remains LOW during the data output state. However, the data output state may be aborted by pulling
2.7V TO 5.5V
1µF
110
SET
TO
REF
2
CC
3
4
)
5
EXRSIG
SDO
REFERENCE VOLTAGE
+ 0.1V TO V
ZS
SET
ANALOG INPUT RANGE
– 0.12V
ZS
SET
REF
FS
+ 0.12V
SET
(V
= FS
– ZS
REF
SET
0V TO FS
CS
TEST EOCTEST EOC
BIT 23
EOC CH0/CH1
SET
– 100mV
CS HIGH anytime between the first rising edge and the 24th falling edge of SCK, see Figure 7. On the rising edge of CS, the device aborts the data output state and imme­diately initiates a new conversion. This is useful for sys­tems not requiring all 24 bits of output data, aborting an invalid conversion cycle or synchronizing the start of a conversion.
V
CC
= INTERNAL OSC/50Hz REJECTION
V
FS
CH1 SDO
CH0
ZS
F
CC
O
LTC2422
SET
SET
9
SCK
8
7
CS
6
GND
MSB LSB
= EXTERNAL CLOCK SOURCE = INTERNAL OSC/60Hz REJECTION
3-WIRE SERIAL I/O
BIT 0BIT 4BIT 19 BIT 18BIT 20BIT 21BIT 22
20
TEST EOC
Hi-ZHi-ZHi-Z
SCK
(EXTERNAL)
CONVERSION
SDO
SCK
(EXTERNAL)
SLEEP DATA OUTPUT CONVERSION
24212 F06
Figure 6. External Serial Clock, Single Cycle Operation
2.7V TO 5.5V
1µF
110
V
REFERENCE VOLTAGE
ZS
+ 0.1V TO V
SET
ANALOG INPUT RANGE
– 0.12V
ZS
SET
REF
FS
+ 0.12V
SET
(V
= FS
– ZS
REF
SET
0V TO FS
CS
BIT 0
EOC
TEST EOC TEST EOC
Hi-Z
CONVERSIONSLEEP SLEEP
DATA OUTPUT
– 100mV
SET
Hi-Z Hi-ZHi-Z
2
CC
3
TO
4
REF
)
SET
5
BIT 23
EOC CH0/CH1
FS
CH1 SDO
ZS
CC
SET
CH0
SET
LTC2422
SCK
GND
F
O
9
8
7
CS
6
3-WIRE SERIAL I/O
DATA OUTPUT
V
CC
= INTERNAL OSC/50Hz REJECTION = EXTERNAL CLOCK SOURCE = INTERNAL OSC/60Hz REJECTION
MSBEXRSIG
BIT 8BIT 19 BIT 9BIT 20BIT 21BIT 22
TEST EOC
CONVERSION
24212 F07
16
Figure 7. External Serial Clock, Reduced Data Output Length
24212f
WUUU
APPLICATIO S I FOR ATIO
LTC2421/LTC2422
External Serial Clock, 2-Wire I/O
This timing mode utilizes a 2-wire serial I/O interface. The conversion result is shifted out of the device by an exter­nally generated serial clock (SCK) signal, see Figure 8. CS may be permanently tied to ground (Pin 6), simplifying the user interface or isolation barrier.
The external serial clock mode is selected at the end of the power-on reset (POR) cycle. The POR cycle is concluded approximately 0.5ms after VCC exceeds 2.2V. The level applied to SCK at this time determines if SCK is internal or external. SCK must be driven LOW prior to the end of POR in order to enter the external serial clock timing mode.
Since CS is tied LOW, the end-of-conversion (EOC) can be continuously monitored at the SDO pin during the convert and sleep states. EOC may be used as an inter­rupt to an external controller indicating the conversion result is ready. EOC = 1 while the conversion is in progress and EOC = 0 once the conversion enters the low power sleep state. On the falling edge of EOC, the conversion result is loaded into an internal static shift register. The device remains in the sleep state until the first rising edge of SCK. Data is shifted out the SDO pin on each falling edge of SCK enabling external circuitry to latch data on the rising edge of SCK. EOC can be latched on the first rising edge of SCK. On the 24th falling edge of SCK, SDO
goes HIGH (EOC = 1) indicating a new conversion has begun.
Internal Serial Clock, Single Cycle Operation
This timing mode uses an internal serial clock to shift out the conversion result and a CS signal to monitor and con­trol the state of the conversion cycle, see Figure 9.
In order to select the internal serial clock timing mode, the serial clock pin (SCK) must be floating (Hi-Z) or pulled HIGH prior to the falling edge of CS. The device will not enter the internal serial clock mode if SCK is driven LOW on the falling edge of CS. An internal weak pull-up resistor is active on the SCK pin during the falling edge of CS; therefore, the internal serial clock timing mode is auto­matically selected if SCK is not externally driven.
The serial data output pin (SDO) is Hi-Z as long as CS is HIGH. At any time during the conversion cycle, CS may be pulled LOW in order to monitor the state of the converter. Once CS is pulled LOW, SCK goes LOW and EOC is output to the SDO pin. EOC = 1 while a conversion is in progress and EOC = 0 if the device is in the sleep state.
When testing EOC, if the conversion is complete (EOC = 0), the device will exit the sleep state and enter the data output state if CS remains LOW. In order to prevent the device from exiting the low power sleep state, CS must be pulled
SDO
SCK
(EXTERNAL)
CS
CONVERSION
2.7V TO 5.5V
1µF
110
V
SET
TO
REF
CC
)
2
FS
3
CH1 SDO
4
CH0
5
ZS
REFERENCE VOLTAGE
+ 0.1V TO V
ZS
SET
ANALOG INPUT RANGE
– 0.12V
ZS
SET
REF
+ 0.12V
FS
SET
(V
= FS
– ZS
REF
SET
SET
– 100mV
0V TO FS
BIT 23
EOC CH0/CH1
SLEEP DATA OUTPUT CONVERSION
CC
LTC2422
SET
SET
F
O
9
SCK
8
7
CS
6
GND
MSBEXRSIG
V
CC
= INTERNAL OSC/50Hz REJECTION = EXTERNAL CLOCK SOURCE = INTERNAL OSC/60Hz REJECTION
2-WIRE SERIAL I/O
BIT 4BIT 19 BIT 18BIT 20BIT 21BIT 22
BIT 0
LSB
20
Figure 8. External Serial Clock, CS = 0 Operation
17
24212 F08
24212f
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
REFERENCE VOLTAGE
ZS
SET
ANALOG INPUT RANGE
ZS
– 0.12V
SET
FS
SET
(V
= FS
REF
0V TO FS
<t
EOCtest
CS
+ 0.1V TO V
REF
+ 0.12V
– ZS
SET
SET
– 100mV
SET
2.7V TO 5.5V
1µF
110
TO
REF
CC
)
V
2
FS
3
CH1 SDO
4
5
ZS
CC
LTC2422
SET
CH0
SET
SCK
GND
F
O
CS
V
CC
V
CC
= INTERNAL OSC/50Hz REJECTION = EXTERNAL CLOCK SOURCE = INTERNAL OSC/60Hz REJECTION
9
8
7
6
10k
SDO
SCK
(INTERNAL)
TEST EOC
Hi-Z Hi-Z Hi-Z Hi-Z
BIT 23
EOC CH0/CH1
SLEEP DATA OUTPUT CONVERSIONCONVERSION
Figure 9. Internal Serial Clock, Single Cycle Operation
HIGH before the first rising edge of SCK. In the internal SCK timing mode, SCK goes HIGH and the device begins outputting data at time t (if EOC = 0) or t
after EOC goes LOW (if CS is LOW
EOCtest
during the falling edge of EOC). The value of t
after the falling edge of CS
EOCtest
EOCtest
is 23µs
if the device is using its internal oscillator (F0 = logic LOW or HIGH). If FO is driven by an external oscillator of fre­quency f HIGH before time t
EOSC
, then t
EOCtest
EOCtest
is 3.6/f
. If CS is pulled
EOSC
, the device remains in the sleep state. The conversion result is held in the internal static shift register.
If CS remains LOW longer than t
, the first rising
EOCtest
edge of SCK will occur and the conversion result is serially shifted out of the SDO pin. The data output cycle begins on this first rising edge of SCK and concludes after the
24th rising edge. Data is shifted out the SDO pin on each falling edge of SCK. The internally generated serial clock is output to the SCK pin. This signal may be used to shift the con­version result into external circuitry. EOC can be latched on the first rising edge of SCK and the last bit of the con­version result on the 24th
rising edge, SDO goes HIGH (EOC = 1), SCK stays
24th
rising edge of SCK. After the
HIGH, and a new conversion starts. Typically, CS remains LOW during the data output state.
However, the data output state may be aborted by pulling
BIT 19 BIT 18BIT 20BIT 21BIT 22
MSBEXRSIG
CS HIGH anytime between the first and
BIT 4
BIT 0
LSB
24th
20
TEST EOC
24212 F09
rising edge of SCK, see Figure 10. On the rising edge of CS, the device aborts the data output state and immediately initiates a new conversion. This is useful for systems not requiring all 24 bits of output data, aborting an invalid conversion cycle, or synchronizing the start of a conversion. If CS is pulled HIGH while the converter is driving SCK LOW, the internal pull-up is not available to restore SCK to a logic HIGH state. This will cause the device to exit the internal serial clock mode on the next falling edge of CS. This can be avoided by adding an external 10k pull-up resistor to the SCK pin or by never pulling CS HIGH when SCK is LOW.
Whenever SCK is LOW, the LTC2421/LTC2422’s internal pull-up at pin SCK is disabled. Normally, SCK is not exter­nally driven if the device is in the internal SCK timing mode. However, certain applications may require an external driver on SCK. If this driver goes Hi-Z after outputting a LOW signal, the LTC2421/LTC2422’s internal pull-up remains disabled. Hence, SCK remains LOW. On the next falling edge of CS, the device is switched to the external SCK timing mode. By adding an external 10k pull-up resistor to SCK, this pin goes HIGH once the external driver goes Hi-Z. On the next CS falling edge, the device will remain in the internal SCK timing mode.
24212f
18
WUUU
APPLICATIO S I FOR ATIO
REFERENCE VOLTAGE
ZS
ANALOG INPUT RANGE
ZS
SET
FS
(V
= FS
REF
0V TO FS
+ 0.1V TO V
SET
– 0.12V
+ 0.12V
SET
SET
SET
REF
– ZS
– 100mV
2.7V TO 5.5V
1µF
110
SET
TO
REF
CC
)
V
2
FS
3
CH1 SDO
4
CH0
5
ZS
CC
LTC2422
SET
SET
F
SCK
CS
GND
LTC2421/LTC2422
V
CC
V
CC
= INTERNAL OSC/50Hz REJECTION
O
9
8
7
6
= EXTERNAL CLOCK SOURCE = INTERNAL OSC/60Hz REJECTION
10k
SDO
SCK
(INTERNAL)
>t
EOCtest
CS
BIT 0
EOC
Hi-Z Hi-Z Hi-Z Hi-Z Hi-Z
DATA OUTPUT
<t
EOCtest
TEST EOCTEST EOC
BIT 23
EOC CH0/CH1
SLEEP DATA OUTPUT
Figure 10. Internal Serial Clock, Reduced Data Output Length
A similar situation may occur during the sleep state when CS is pulsed HIGH-LOW-HIGH in order to test the conver­sion status. If the device is in the sleep state (EOC = 0), SCK will go LOW. Once CS goes HIGH (within the time period defined above as t
), the internal pull-up is activated.
EOCtest
For a heavy capacitive load on the SCK pin, the internal pull-up may not be adequate to return SCK to a HIGH level before CS goes low again. This is not a concern under normal conditions where CS remains LOW after detecting EOC = 0. This situation is easily overcome by adding an external 10k pull-up resistor to the SCK pin.
Internal Serial Clock, 2-Wire I/O, Continuous Conversion
This timing mode uses a 2-wire, all output (SCK and SDO) interface. The conversion result is shifted out of the device by an internally generated serial clock (SCK) signal, see Figure 11. CS may be permanently tied to ground (Pin 6), simplifying the user interface or isolation barrier.
The internal serial clock mode is selected at the end of the power-on reset (POR) cycle. The POR cycle is concluded approximately 0.5ms after VCC exceeds 2.2V. An internal
CONVERSIONCONVERSIONSLEEP
TEST EOC
24212 F10
BIT 19 BIT 18BIT 20BIT 21BIT 22
MSBEXRSIG
BIT 8
weak pull-up is active during the POR cycle; therefore, the internal serial clock timing mode is automatically selected if SCK is not externally driven LOW (if SCK is loaded such that the internal pull-up cannot pull the pin HIGH, the ex­ternal SCK mode will be selected).
During the conversion, the SCK and the serial data output pin (SDO) are HIGH (EOC = 1). Once the conversion is complete, SCK and SDO go LOW (EOC = 0) indicating the conversion has finished and the device has entered the sleep state. The part remains in the sleep state a minimum amount of time (1/2 the internal SCK period) then imme­diately begins outputting data. The data output cycle begins on the first rising edge of SCK and ends after the 24th rising edge. Data is shifted out the SDO pin on each falling edge of SCK. The internally generated serial clock is out­put to the SCK pin. This signal may be used to shift the conversion result into external circuitry. EOC can be latched on the first rising edge of SCK and the last bit of the conversion result can be latched on the 24th rising edge of SCK. After the 24th rising edge, SDO goes HIGH (EOC = 1) indicating a new conversion is in progress. SCK remains HIGH during the conversion.
24212f
19
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
2.7V TO 5.5V
1µF
110
SET
TO
REF
2
CC
3
4
)
5
MSBEXRSIG
SDO
SCK
(INTERNAL)
REFERENCE VOLTAGE
ZS
+ 0.1V TO V
SET
ANALOG INPUT RANGE
ZS
– 0.12V
SET
(V
REF
0V TO FS
CS
BIT 23
EOC CH0/CH1
SLEEP
FS = FS
SET
+ 0.12V
– ZS
SET
SET
REF
– 100mV
Figure 11. Internal Serial Clock, Continuous Operation
Internal Serial Clock, Autostart Conversion
This timing mode is identical to the internal serial clock, 2-wire I/O described above with one additional feature. Instead of grounding CS, an external timing capacitor is tied to CS.
While the conversion is in progress, the CS pin is held HIGH by an internal weak pull-up. Once the conversion is complete, the device enters the low power sleep state and an internal 25nA current source begins discharging the capacitor tied to CS, see Figure 12. The time the converter spends in the sleep state is determined by the value of the external timing capacitor, see Figures 13 and 14. Once the voltage at CS falls below an internal threshold (1.4V), the device automatically begins outputting data. The data out­put cycle begins on the first rising edge of SCK and ends on the
24th
rising edge. Data is shifted out the SDO pin on each falling edge of SCK. The internally generated serial clock is output to the SCK pin. This signal may be used to shift the conversion result into external circuitry. After the 24th rising edge, CS is pulled HIGH and a new conversion is immediately started. This is useful in applications re­quiring periodic monitoring and ultralow power. Figure 15 shows the average supply current as a function of capaci­tance on CS.
V
LSB
CC
10k
20
24212 F11
V
CC
= INTERNAL OSC/50Hz REJECTION
V
FS
CH1 SDO
CH0
ZS
F
CC
SET
O
LTC2422
SET
DATA OUTPUT CONVERSIONCONVERSION
I
t should be noticed that the external capacitor discharge
SCK
GND
9
8
7
CS
6
= EXTERNAL CLOCK SOURCE = INTERNAL OSC/60Hz REJECTION
BIT 4 BIT 0BIT 19 BIT 18BIT 20BIT 21BIT 22
current is kept very small in order to decrease the con­verter power dissipation in the sleep state. In the autostart mode, the analog voltage on the CS pin cannot be observed without disturbing the converter operation using a regular oscilloscope probe. When using this con­figuration, it is important to minimize the external leakage current at the CS pin by using a low leakage external ca­pacitor and properly cleaning the PCB surface.
The internal serial clock mode is selected every time the voltage on the CS pin crosses an internal threshold volt­age. An internal weak pull-up at the SCK pin is active while CS is discharging; therefore, the internal serial clock tim­ing mode is automatically selected if SCK is floating. It is important to ensure there are no external drivers pulling SCK LOW while CS is discharging.
DIGITAL SIGNAL LEVELS
The LTC2421/LTC2422’s digital interface is easy to use. Its digital inputs (FO, CS and SCK in External SCK mode of operation) accept standard TTL/CMOS logic levels and the internal hysteresis receivers can tolerate edge rates as slow as 100µs. However, some considerations are re
quired
24212f
20
WUUU
APPLICATIO S I FOR ATIO
REFERENCE VOLTAGE
+ 0.1V TO V
ZS
SET
ANALOG INPUT RANGE
– 0.12V
ZS
SET
+ 0.12V
FS
SET
(V
= FS
REF
SET
0V TO FS
V
CC
CS
GND
– ZS
SET
2.7V TO 5.5V
1µF
TO
REF
REF
SET
– 100mV
110
V
CC
2
FS
CC
3
CH1 SDO
4
)
CH0
5
ZS
LTC2422
SET
SET
SCK
GND
F
O
9
8
7
CS
6
LTC2421/LTC2422
V
CC
= INTERNAL OSC/50Hz REJECTION = EXTERNAL CLOCK SOURCE = INTERNAL OSC/60Hz REJECTION
C
EXT
V
CC
10k
(SEC)
SAMPLE
t
7
6
5
4
3
2
1
0
SDO
SCK
(INTERNAL)
VCC = 5V
10 100 100000
1
CAPACITANCE ON CS (pF)
1000 10000
V
BIT 23
EOC
SLEEP
DATA OUTPUT CONVERSIONCONVERSION
Figure 12. Internal Serial Clock, Autostart Operation
300
CC
24212 F13
= 3V
)
RMS
SUPPLY CURRENT (µA
250
200
150
100
50
0
1
VCC = 5V
VCC = 3V
10 100 1000 10000
CAPACITANCE ON CS (pF)
BIT 21BIT 22
SIG
100000
24212 F15
)
RMS
SUPPLY CURRENT (µA
300
250
200
150
100
BIT 0
Hi-ZHi-Z
2420 F12
VCC = 5V
VCC = 3V
50
0
1
10 100 1000 10000
CAPACITANCE ON CS (pF)
100000
24212 F15
Figure 13. CS Capacitance vs t
SAMPLE
Figure 14. CS Capacitance vs Output Rate
to take advantage of exceptional accuracy and low supply current.
The digital output signals (SDO and SCK in Internal SCK mode of operation) are less of a concern because they are not generally active during the conversion state.
Figure 15. CS Capacitance vs Supply Current
In order to preserve the LTC2421/LTC2422’s accuracy, it is very important to minimize the ground path impedance which may appear in series with the input and/or reference signal and to reduce the current which may flow through this path. The GND pin should be connected to a low
24212f
21
LTC2421/LTC2422
V
REF
V
IN
V
CC
R
SW
5k
AVERAGE INPUT CURRENT:
I
IN
= 0.25(VIN – 0.5 • V
REF
)fC
EQ
I
REF(LEAK)
I
REF(LEAK)
V
CC
R
SW
5k
C
EQ
1pF (TYP)
R
SW
5k
I
IN(LEAK)
I
IN
24212 F16
I
IN(LEAK)
SWITCHING FREQUENCY f = 153.6kHz FOR INTERNAL OSCILLATOR (f
O
= LOGIC LOW OR HIGH)
f = f
EOSC
FOR EXTERNAL OSCILLATORS
GND
WUUU
APPLICATIO S I FOR ATIO
resis
tance ground plane through a minimum length trace. The use of multiple via holes is recommended to further reduce the connection resistance.
In an alternative configuration, the GND pin of the con­verter can be the single-point-ground in a single point grounding system. The input signal ground, the reference signal ground, the digital drivers ground (usually the digi­tal ground) and the power supply ground (the analog ground) should be connected in a star configuration with the common point located as close to the GND pin as possible.
The power supply current during the conversion state should be kept to a minimum. This is achieved by restrict­ing the number of digital signal transitions occurring dur­ing this period.
While a digital input signal is in the range 0.5V to (VCC␣ –␣ 0.5V), the CMOS input receiver draws additional current from the power supply. It should be noted that, when any one of the digital input signals (FO, CS and SCK in External SCK mode of operation) is within this range, the LTC2421/LTC2422 power supply current may increase even if the signal in question is at a valid logic level. For micropower operation and in order to minimize the poten­tial errors due to additional ground pin current, it is recom­mended to drive all digital input signals to full CMOS levels [VIL < 0.4V and VOH > (VCC – 0.4V)].
Parallel termination near the LTC2421/LTC2422 pin will eliminate this problem but will increase the driver power dissipation. A series resistor between 27 and 56 placed near the driver or near the LTC2421/LTC2422 pin will also eliminate this problem without additional power dissipa­tion. The actual resistor value depends upon the trace impedance and connection topology.
Driving the Input and Reference
The analog input and reference of the typical delta-sigma analog-to-digital converter are applied to a switched ca­pacitor network. This network consists of capacitors switch­ing between the analog input (VIN), ZS (Pin 2). The result is small current spikes seen at both V and V
. A simplified input equivalent circuit is shown in
REF
(Pin 5) and FS
SET
SET
IN
Figure 16. The key to understanding the effects of this dynamic input
current is based on a simple first order RC time constant model. Using the internal oscillator, the LTC2421/ LTC2422’s internal switched capacitor network is clocked at 153,600Hz corresponding to a 6.5µs sampling period. Fourteen time constants are required each time a capacitor is switched in order to achieve 1ppm settling accuracy.
Therefore, the equivalent time constant at VIN and V
REF
should be less than 6.5µs/14 = 460ns in order to achieve 1ppm accuracy.
Severe ground pin current disturbances can also occur due to the undershoot of fast digital input signals. Under­shoot and overshoot can occur because of the imped­ance mismatch at the converter pin when the transition time of an external control signal is less than twice the propagation delay from the driver to LTC2421/LTC2422. For reference, on a regular FR-4 board, signal propaga­tion velocity is approximately 183ps/inch for internal traces and 170ps/inch for surface traces. Thus, a driver generating a control signal with a minimum transition time of 1ns must be connected to the converter pin through a trace shorter than 2.5 inches. This problem becomes particularly difficult when shared control lines are used and multiple reflections may occur. The solution is to carefully terminate all transmission lines close to their characteristic impedance.
22
Figure 16. LTC2421/LTC2422 Equivalent Analog Input Circuit
24212f
WUUU
APPLICATIO S I FOR ATIO
LTC2421/LTC2422
Input Current (VIN)
If complete settling occurs on the input, conversion re­sults will be uneffected by the dynamic input current. If the settling is incomplete, it does not degrade the linearity performance of the device. It simply results in an offset/ full-scale shift, see Figure 17. To simplify the analysis of input dynamic current, two separate cases are assumed: large capacitance at VIN (CIN > 0.01µF) and small capaci- tance at VIN (CIN < 0.01µF).
TUE
ZS
SET
SOURCE
V
IN
Figure 17. Offset/Full-Scale Shift
R
SOURCE
INTPUT
SIGNAL
C
IN
C
PAR
20pF
V
IN
LTC2421/
LTC2422
24212 F17
FS
SET
24212 F17
If the total capacitance at VIN (see Figure 18) is small (<0.01µF), relatively large external source resistances (up to 80k for 20pF parasitic capacitance) can be tolerated without any offset/full-scale error. Figures 19 and 20 show a family of offset and full-scale error curves for various small valued input capacitors (CIN < 0.01µF) as a function of input source resistance.
For large input capacitor values (CIN > 0.01µF), the input spikes are averaged by the capacitor into a DC current. The gain shift becomes a linear function of input source resis­tance independent of input capacitance, see Figures 21 and 22. The equivalent input impedance is 16.6M. This results in ±150nA of input dynamic current at the extreme values of VIN (VIN = 0V and VIN = V
, when V
REF
REF
= 5V).
This corresponds to a 0.3ppm shift in offset and full-scale readings for every 10 of input source resistance.
35
30
25
20
15
10
OFFSET ERROR (ppm)
5
0
CIN = 22µF C
= 10µF
IN
= 1µF
C
IN
C
= 0.1µF
IN
C
= 0.01µF
IN
= 0.001µF
C
IN
VCC = 5V V
= 5V
REF
= 0V
V
IN
T
= 25°C
A
200 400 1000
0
R
SOURCE
600 800
()
24212 F20
Figure 18. An RC Network at V
50
VCC = 5V
= 5V
V
REF
= 0V
V
IN
40
= 25°C
T
A
30
20
OFFSET ERROR (ppm)
10
0
1
CIN = 100pF
C
IN
C
10
CIN = 0pF
= 1000pF
= 0.01µF
IN
100 R
SOURCE
Figure 19. Offset vs R
1k
()
SOURCE
IN
10k
100k
24212 F19
(Small C)
Figure 20. Offset vs R
5
0
–5
–10
–15
–20
–25
FULL-SCALE ERROR (ppm)
–30
–35
CIN = 22µF
= 10µF
C
IN
= 1µF
C
IN
C
= 0.1µF
IN
= 0.01µF
C
IN
= 0.001µF
C
IN
200 400 800
0
R
SOURCE
SOURCE
600
()
Figure 21. Full-Scale Error vs R
(Large C)
VCC = 5V
= 5V
V
REF
V
= 0V
IN
= 25°C
T
A
24212 F21
SOURCE
1000
(Large C)
24212f
23
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
10
0
–10
C
= 0pF
IN
–20
–30
FULL-SCALE ERROR (ppm)
–40
–50
1
CIN = 100pF
= 1000pF
C
IN
VCC = 5V V
REF
= 5V
V
IN
= 25°C
T
A
CIN = 0.01µF
= 5V
10 100 1k 10k
R
SOURCE
()
100k
24212 F22
60
50
40
30
20
10
FULL-SCALE ERROR (ppm)
0
–10
C
= 22µF
VREF
= 10µF
C
VREF
= 1µF
C
VREF
= 0.1µF
C
VREF
= 0.01µF
C
VREF
= 0.001µF
C
VREF
VCC = 5V
= 5V
V
REF
= 5V
V
IN
= 25°C
T
A
200 400 1000
0
RESISTANCE AT V
600 800
()
REF
24212 F23
Figure 22. Full-Scale Error vs R
SOURCE
(Small C)
In addition to the input current spikes, the input ESD pro­tection diodes have a temperature dependent leakage cur­rent. This leakage current, nominally 1nA (±100nA max), results in a fixed offset shift of 10µV for a 10k source resistance.
The effect of input leakage current is evident for CIN = 0 in Figures 19 and 22. A leakage current of 3nA results in a 150µV (30ppm) error for a 50k source resistance. As R
SOURCE
gets larger, the switched capacitor input current
begins to dominate.
Reference Current (V
REF
)
Similar to the analog input, the reference input has a dy­namic input current. This current has negligible effect on the offset. However, the reference current at VIN = V
REF
is similar to the input current at full-scale. For large values of reference capacitance (C
> 0.01µF), the full-scale er-
VREF
ror shift is 0.03ppm/ of external reference resistance independent of the capacitance at V the capacitance tied to V
is small (C
REF
, see Figure 23. If
REF
< 0.01µF), an
VREF
input resistance of up to 80k (20pF parasitic capacitance at V
) may be tolerated, see Figure 24.
REF
Unlike the analog input, the integral nonlinearity of the device can be degraded with excessive external RC time constants tied to the reference input. If the capacitance at node V
is small (C
REF
< 0.01µF), the reference input
VREF
can tolerate large external resistances without reduction in INL, see Figure 25. If the external capacitance is large (C
> 0.01µF), the linearity will be degraded by
VREF
Figure 23. Full-Scale Error vs R
500
VCC = 5V
= 5V
V
REF
400
V
= 5V
IN
= 25°C
T
A
300
200
100
0
FULL-SCALE ERROR (ppm)
–100
–200
10 100 100k
1
RESISTANCE AT V
C
C
VREF
C
VREF
VREF
= 1000pF
= 100pF
= 0.01µF
1k 10k
REF
C
()
VREF
Figure 24. Full-Scale Error vs R
50
VCC = 5V
= 5V
V
REF
40
= 25°C
T
A
30
20
10
INL ERROR (ppm)
0
–10
–20
1
Figure 25. INL Error vs R
C
= 1000pF
VREF
C
= 100pF
VREF
C
= 0.01µF
VREF
C
VREF
10 100 100k
RESISTANCE AT V
1k 10k
()
REF
VREF
(Large C)
VREF
= 0pF
24212 F24
(Small C)
VREF
= 0pF
24212 F25
(Small C)
24212f
24
WUUU
APPLICATIO S I FOR ATIO
LTC2421/LTC2422
0.015ppm/ independent of capacitance at V
REF
, see
Figure 26. In addition to the dynamic reference current, the V
REF
ESD
protection diodes have a temperature dependent leakage current. This leakage current, nominally 1nA (±10nA max), results in a fixed full-scale shift of 10µV for a 10k source resistance.
10
–2
INL ERROR (ppm)
–4 –6 –8
–10
C
= 22µF
8 6 4 2 0
VREF
= 10µF
C
VREF
C
= 1µF
VREF
= 0.1µF
C
VREF
= 0.01µF
C
VREF
C
= 0.001µF
VREF
200 400 1000
0
RESISTANCE AT V
600 800
REF
()
VCC = 5V
= 5V
V
REF
= 25°C
T
A
24212 F26
0
–20
–40
–60
–80
REJECTION (dB)
–100
–120
–140
0
fS/2 f
INPUT FREQUENCY
S
24212 F27
Figure 27. Sinc4 Filter Rejection
The modulator contained within the LTC2421/LTC2422 can handle large-signal level perturbations without satu­rating. Signal levels up to 40% of V
do not saturate the
REF
analog modulator. These signals are limited by the input ESD protection to 300mV below ground and 300mV above VCC.
Figure 26. INL Error vs R
(Large C)
VREF
ANTIALIASING
One of the advantages delta-sigma ADCs offer over con­ventional ADCs is on-chip digital filtering. Combined with a large oversampling ratio, the LTC2421/LTC2422 signifi­cantly simplify antialiasing filter requirements.
The digital filter provides very high rejection except at integer multiples of the modulator sampling frequency (fS), see Figure 27. The modulator sampling frequency is 256 • FO, where FO is the notch frequency (typically 50Hz or 60Hz). The bandwidth of signals not rejected by the digital filter is narrow (0.2%) compared to the band­width of the frequencies rejected.
As a result of the oversampling ratio (256) and the digital filter, minimal (if any) antialias filtering is required in front of the LTC2421/LTC2422. If passive RC components are placed in front of the LTC2421/LTC2422, the input dy­namic current should be considered (see Input Current section). In cases where large effective RC time constants are used, an external buffer amplifier may be required to minimize the effects of input dynamic current.
Simple Basic Program for Interfacing to the LTC2421/LTC2422
DTR
V
REF
LTC2421
V
IN
LTC2422
GND
”TINY.BAS V1.0 Copyright (C) 2000 by J. A. Dutra and LTC, All rights reseved' NOTE this program generates 32 SCK’s for compatibility to 24-bit parts 'For use with most LTC24xy demo boards
designed for the PC Com Port, QBASIC 'Outputs are chan%,signneg%,d2400 (magnitude), PPM, and v (volts) CLS : ON ERROR GOTO 4970 cport = 1: REM INPUT "com port number "; cport GOSUB 1900: timestart$ = TIME$ mcr% = port + 4: msr% = port + 6 COLOR 15: LOCATE 3, 1: PRINT "Hit any key to stop… "; FOR np = 1 TO 2000: OUT port, c0%: NEXT np: 'Power Via TxD DO: '-------------------------START LOOP here--------
SCK
SDO
CS
Figure 28
CTS RTS
PC
SERIAL
PORT
24212 F28
24212f
25
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
nummeas = nummeas + c1% LOCATE 2, 2: PRINT "Scan#="; nummeas; " "; DATE$; " "; TIME$; OUT mcr%, c0%: 'Initialize SCLK=0 k1 = km: d2400 = 0: chan% = c0%: signneg% = c0% FOR bita% = 31 TO 0 STEP -1: v31 = 1 148 GOSUB 2200: v31 = v31 + 1 150 IF bita% = 31 THEN GOTO 152 ELSE 156 152 IF dfrm% = c0% THEN GOTO 156 155 IF v31 > 2 THEN LOCATE 16, 16: OUT port, c0%: PRINT "waiting for eoc": IF v31 < 20000 THEN IF dfrm% = c1% THEN GOTO 148 IF dfrm% = 1 THEN LOCATE 17, 16: PRINT "Timed out on EOC,not fatal" FOR bs = 1 TO 32: ' never got an eoc => clock it 32 times GOSUB 2000: NEXT bs: GOTO 1800 156 LOCATE 16, 16: PRINT" ": GOSUB 2000 IF bita% = 30 THEN 161 ELSE 171 ' CHANNEL BIT !!!!!!!!!!!!!!! 161 IF dfrm% = c1% THEN chan% = c1%: ch1% = c0% IF dfrm% = c0% THEN chan% = c0%: ch1% = ch1% + c1% IF ch1% > c4% THEN GOSUB 3700: ch1% = c1% 171 IF bita% = 29 THEN IF dfrm% = c0% THEN signneg% = c1%: ' NEG IF bita% <= 28 THEN d2400 = d2400 + (dfrm% * k1): k1 = k1 / c2% NEXT bita%: k1 = 1: digin% = c0%: 'MATH BELOW 1600 PPM = (d2400 / km) * kn: rw% = 6: hz% = (chan% * 20) + 1 IF signneg% = c1% THEN 1700 ELSE 1705
LOCATE 5, 21: PRINT "CHANNEL 1": LOCATE 5, 2: PRINT "CHANNEL 0" FOR n% = port TO port + 7: OUT n%, 0: NEXT n%: ’Init UART regs CLOSE #1: DEF SEG = 0: RETURN ’-------------------------------------­2000 ’SUB read MSR AND RETURN data dfrm% INTERFACE x3% = INP(msr%) AND c16%: OUT mcr%, c1%
GOSUB 3000: OUT mcr%, c0% 2040 IF x3% = c16% THEN dfrm% = c1% ELSE dfrm% = c0% OUT mcr%, c0%: RETURN ’--------------------------------------------­2200 ’SUB READ THE DATA BIT dfrm% does NOT change sclock x3% = INP(msr%) AND C16%: GOTO 2040: RETURN’---------------­3000 REM delay sub !!!!!!!!!! FOR n8% = 0 TO 1: OUT port, c0%: NEXT n8%: RETURN: ’---------­3700 FOR n = 6 TO 9: LOCATE n, 20 PRINT " ": NEXT n: RETURN’--------------------------­3800 ’SUB to convert PPM into Volts and print it v = PPM * (5 / 1000000): v1 = v * 1000000: hz% = (chan% * 20) + 12 IF v <= .1 THEN PRINT v1; " "; : LOCATE rw% + 1, hz%: PRINT "uV " IF v > .1 THEN PRINT v; " "; : LOCATE rw% + 1, hz%: PRINT "Volts"; RETURN’---------------------------------------------------------------­4970 PRINT "ERROR !!!!!!!!!!!!!!!" 5000 PRINT : LOCATE 18, 1: PRINT "Ending!!": PRINT "Hit any key to exit." PRINT "Start ="; timestart$; " End = "; TIME$; " # samples ="; nummeas
CLOSE #1: END
1700 IF d2400 <> c0% THEN PPM = (PPM - 2000000) 1705 LOCATE rw%, hz%: PRINT PPM; " "; : LOCATE rw%, hz% + 11: PRINT "PPM"; LOCATE rw% + 1, (chan% * 20) + 1: GOSUB 3800: 'THIS WORKS! 1800 LOOP WHILE INKEY$ = "": REM Works with "DO" GOTO 5000 ’rem END!!-------------- Subs follow !!----------------!!! 1900 ’ESSENTIAL INITIALIZATIONS REM set some constants, since they can be accessed much faster LET c128% = 128: c64% = 64: c32% = 32: c16% = 16: c8% = 8: c4% = 4 LET c3% = 3: c2% = 2: c1% = 1: c0% = 0: km = (2 ^ 30) - 1: kn = 1000000 IF cport = 2 THEN OPEN "COM2:300,N,8,1,CD0,CS0,DS0,OP0,RS" FOR
RANDOM AS #1: port = (&H2F8) IF cport = 1 THEN OPEN "COM1:300,N,8,1,CD0,CS0,DS0,OP0,RS" FOR
RANDOM AS #1: port = (&H3F8)
26
Single Ended Half-Bridge Digitizer with Reference and Ground Sensing
Sensors convert real world phenomena (temperature, pres­sure, gas levels, etc.) into a voltage. Typically, this voltage is generated by passing an excitation current through the sensor. The wires connecting the sensor to the ADC form parasitic resistors RP1 and RP2. The excitation current also flows through parasitic resistors RP1 and RP2, as shown in Figure 29. The voltage drop across these parasitic resis­tors leads to systematic offset and full-scale errors.
In order to eliminate the errors associated with these para­sitic resistors, the LTC2421/LTC2422 include a full-scale set input (FS (ZS
). As shown in Figure 30, the FS
SET
) and a zero-scale set input
SET
pin acts as a
SET
zero current full-scale sense input. Errors due to parasitic
24212f
WUUU
00000
H
12.5% UNDER RANGE
ADC DATA OUT
FFFFF
H
ZS
SET
FS
SET
V
IN
24212 F31
12.5% EXTENDED RANGE
APPLICATIO S I FOR ATIO
LTC2421/LTC2422
re
sistance RP1 in series with the half-bridge sensor are removed by the FS scale output of the ADC (data out = FFFFF at VIN = VB = FS
input to the ADC. The absolute full-
SET
) will occur
HEX
, see Figure 31. Similarly, the offset
SET
errors due to RP2 are removed by the ground sense input ZS
. The absolute zero output of the ADC (data out =
SET
00000
) occurs at VIN = VA = ZS
HEX
. Parasitic resistors
SET
RP3 to RP5 have negligible errors due to the 1nA (typ) leakage current at pins FS
SET
, ZS
and VIN. The wide
SET
dynamic input range (–300mV to 5.3V) and low noise (1.2ppm RMS) enable the LTC2421 or the LTC2422 to directly digitize the output of the bridge sensor.
The LTC2422 is ideal for applications requiring continu­ous monitoring of two input sensors. As shown in Figure 32, the LTC2422 can monitor both a thermocouple temperature probe and a cold junction temperature sen­sor. Absolute temperature measurements can be performed with a variety of thermocouples using digital cold junction compensation.
1
V
CC
LTC2421
2
FS
SET
9
V
IN
ZS
GND
SET
SCK SDO
CS
8 7
10
F
O
3
5
6
I
EXCITATION
R
IDC 0
P1
V
B
R
P3
IDC 0
R
P4
IDC 0
V
A
R
R
P5
P2
Figure 30. Half-Bridge Digitizer with Zero-Scale and Full-Scale Sense
3-WIRE SPI INTERFACE
24212 F03
+
V
I
EXCITATION
R
R
FULL-SCALE ERROR
P1
SENSOR SENSOR OUTPUT
P2
+ –
+
V
OFFSET ERROR
24212 F29
Figure 29. Errors Due to Excitation Currents
2.7V TO 5.5V
12k
THERMISTOR
100
COLD JUNCTION
+
THERMOCOUPLE
Figure 31. Transfer Curve with Zero-Scale and Full-Scale Set
LTC2422
110
V
CC
2
FS
3
CH1 SDO
4
CH0
5
ZS
SET
SET
SCK
CS
GND
F
O
9
8
7
6
ISOLATION
BARRIER
PROCESSOR
24212 F32
Figure 32. Isolated Temperature Measurement
24212f
27
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
The selection between CH0 and CH1 is automatic. Initially, after power-up, a conversion is performed on CH0. For each subsequent conversion, the input channel selection is alternated. Embedded within the serial data output is a status bit indicating which channel corresponds to the conversion result. If the conversion was performed on CH0, this bit (Bit 22) is LOW and is HIGH if the conversion was performed on CH1 (see Figure 33).
There are no extra control or status pins required to per­form the alternating 2-channel measurements. The LTC2422 only requires two digital signals (SCK and SDO). This simplification is ideal for isolated temperature mea­surements or systems where minimal control signals are available.
Pseudo Differential Applications
Generally, designers choose fully differential topologies for several reasons. First, the interface to a 4- or 6-wire bridge is simple (it is a differential output). Second, they require good rejection of line frequency noise. Third, they typically look at a small differential signal sitting on a large common mode voltage; they need accurate measurements of the differential signal independent of the common mode input voltage. Many applications cur­rently using fully differential analog-to-digital converters for any of the above reasons may migrate to a pseudo differential conversion using the LTC2422.
Direct Connection to a Full Bridge
The LTC2422 interfaces directly to a 4- or 6-wire bridge, as shown in Figure 34. The LTC2422 includes a FS a ZS
for sensing the excitation voltage directly across
SET
SET
and
the bridge. This eliminates errors due to excitation cur­rents flowing through parasitic resistors. The LTC2422 also includes two single ended input channels which can tie directly to the differential output of the bridge. The two
conversion results may be digitally subtracted yielding the differential result.
The LTC2422’s single ended rejection of line frequencies (±2%) and harmonics is better than 110dB. Since the device performs two independent single ended conver­sions each with >110dB rejection, the overall common mode and differential rejection is much better than the 80dB rejection typically found in other differential input delta-sigma converters.
In addition to excellent rejection of line frequency noise, the LTC2422 also exhibits excellent single ended noise rejection over a wide range of frequencies due to its 4
th
order sinc filter. Each single ended conversion indepen­dently rejects high frequency noise (> 60Hz). Care must be taken to insure noise at frequencies below 15Hz and at multiples of the ADC sample rate (15,360Hz) are not present. For this application, it is recommended the LTC2422 is placed in close proximity to the bridge sensor in order to reduce the noise injected into the ADC input. By performing three successive conversions (CH0-CH1-CH0), the drift and low frequency noise can be measured and compensated for digitally.
I
EXCITATION
IDC = 0
350 350
350 350
IDC = 0
Figure 34. Pseudo Differential Strain Guage Application
5V
1
V
CC
2
FS
SET
LTC2422
3
CH1
4
CH0
5
ZS
SET
GND
9
SCK
8
7
10
O
3-WIRE SPI INTERFACE
24212 F32
SDO
CS
F
6
28
SCK
SDO
EOC
CH1
• • • • • •
CH1 DATA OUT
EOC
CH0
Figure 33. Embedded Selected Channel Indicator
CH0 DATA OUT
24212 F33
24212f
WUUU
APPLICATIO S I FOR ATIO
LTC2421/LTC2422
The absolute accuracy (less than 10 ppm total error) of the LTC2422 enables extremely accurate measurement of small signals sitting on large voltages. Each of the two pseudo differential measurements performed by the LTC2422 is absolutely accurate independent of the com­mon mode voltage output from the bridge. The pseudo differential result obtained from digitally subtracting the two single ended conversion results is accurate to within the noise level of the device (3µV
) times the square
RMS
root of 2, independent of the common mode input voltage. Typically, a bridge sensor outputs 2mV/V full scale. With
a 5V excitation, this translates to a full-scale output of 10mV. Divided by the RMS noise of 8.4µV(= 6µV • 1.414), this circuit yields 1190 counts with no averaging or ampli­fication. If more counts are required, several conversions may be averaged (the number of effective counts is in­creased by a factor of square root of 2 for each doubling of averages).
An RTD Temperature Digitizer
resistance changes as a function of temperature (100 to 400 for 0°C to 800°C). The same excitation current flows back to the ADC ground and generates another voltage drop across the return leads. In order to get an accurate measurement of the temperature, these voltage drops must be measured and removed from the conversion result. Assuming the resistance is approximately the same for the forward and return paths (R1 = R2), the auxiliary channel on the LTC2422 can measure this drop. These errors are then removed with simple digital correction.
The result of the first conversion on CH0 corresponds to an input voltage of V second conversion (CH1) is –R1 • I
RTD
+ R1 • I
EXCITATION.
EXCITATION.
The result of the
Note, the LTC2422’s input range is not limited to the supply rails, it has underrange capabilities. The device’s input range is –300mV to V
+ 300mV. Adding the two conversion
REF
results together, the voltage drop across the RTD’s leads are cancelled and the final result is V
RTD
.
An Isolated, 20-Bit Data Acquisition System
RTDs used in remote temperature measurements often have long lead lengths between the ADC and RTD sensor. These long lead lengths lead to voltage drops due to exci­tation current in the interconnect to the RTD. This voltage drop can be measured and digitally removed using the LTC2422 (see Figure 35).
The excitation current (typically 200µA) flows from the ADC through a long lead length to the remote temperature sensor (RTD). This current is applied to the RTD, whose
P
100
I
+
t
V
RTD
I
EXCITATION
EXCITATION
IDC = 0
= 200µA
R1
= 200µA
R2
25
The LTC1535 is useful for signal isolation. Figure 36 shows a fully isolated, 20-bit differential input A/D converter imple­mented with the LTC1535 and LTC2422. Power on the isolated side is regulated by an LT1761-5.0 low noise, low dropout micropower regulator. Its output is suitable for driving bridge circuits and for ratiometric applications.
During power-up, the LTC2422 becomes active at VCC =
2.3V, while the isolated side of the LTC1535 must wait for V
to reach its undervoltage lockout threshold of 4.2V.
CC2
5V
1
V
CC
2
FS
SET
5k
1000pF
5k25
0.1µF
LTC2422
4
CH0
3
CH1
5
ZS
SET
GND
9
SCK
8
O
7
10
3-WIRE SPI INTERFACE
24212 F35
SDO
CS
F
6
Figure 35. RTD Remote Temperature Measurement
24212f
29
LTC2421/LTC2422
WUUU
APPLICATIO S I FOR ATIO
Below 4.2V, the LTC1535’s driver outputs Y and Z are in a high impedance state, allowing the 1k pull-down to de­fine the logic state at SCK. When the LTC2422 first be­comes active, it samples SCK; a logic “0” provided by the 1k pull-down invokes the external serial clock mode. In this mode, the LTC2422 is controlled by a single clock line from the nonisolated side of the barrier, through the LTC1535’s driver output Y. The entire power-up sequence,
1/2 BAT54C
+
10µF 16V TAN T
“SDO”
“SCK”
LOGIC 5V
T1
1/2 BAT54C
ST2
ST1
RO RE DE DI
V
CC1
+
10µF
10V
1
TANT
1
LTC1535
G1
G2
ISOLATION
BARRIER
T1 = COILTRONICS CTX02-14659 OR SIEMENS B78304-A1477-A3
1µF
V
CC2
= LOGIC COMMON
1
= FLOATING COMMON
2
from the time power is applied to V
until the LT1761’s
CC1
output has reached 5V, is approximately 1ms. Data returns to the nonisolated side through the LTC1535’s
receiver at RO. An internal divider on receiver input B sets a logic threshold of approximately 3.4V at input A, facili­tating communications with the LTC2422’s SDO output without the need for any external components.
LT1761-5
A B Y
Z
IN OUT
SHDN BYP
GND
2
+
10µF 10V TANT
2
1k
21 2
2
10µF
F
O
SCK SDO CS GND
+
LTC2422
FS
ZS
10µF 10V TANT
V
SET
CH1 CH0
SET
10µF
CERAMIC
2
CC
24212 F36
30
Figure 36. Complete, Isolated 20-Bit Data Acquisition System
24212f
LTC2421/LTC2422
UU
W
PACKAGE I FOR ATIO
5.23
(.206)
MIN
3.05 ± 0.38
(.0120 ± .0015)
TYP
RECOMMENDED SOLDER PAD LAYOUT
0.254 (.010)
GAUGE PLANE
0.18
(.007)
NOTE:
1. DIMENSIONS IN MILLIMETER/(INCH)
2. DRAWING NOT TO SCALE
3. DIMENSION DOES NOT INCLUDE MOLD FLASH, PROTRUSIONS OR GATE BURRS. MOLD FLASH, PROTRUSIONS OR GATE BURRS SHALL NOT EXCEED 0.152mm (.006") PER SIDE
4. DIMENSION DOES NOT INCLUDE INTERLEAD FLASH OR PROTRUSIONS. INTERLEAD FLASH OR PROTRUSIONS SHALL NOT EXCEED 0.152mm (.006") PER SIDE
5. LEAD COPLANARITY (BOTTOM OF LEADS AFTER FORMING) SHALL BE 0.102mm (.004") MAX
MS Package
10-Lead Plastic MSOP
(Reference LTC DWG # 05-08-1661)
0.889
± 0.127
(.035 ± .005)
3.2 – 3.45
(.126 – .136)
3.00 ± 0.102
PLANE
(.118 ± .004)
(NOTE 3)
4.88 ± 0.10
(.192 ± .004)
0.17 – 0.27
(.007 – .011)
DETAIL “A”
DETAIL “A”
0.50
(.0197)
BSC
° – 6° TYP
0
(.021 ± .006)
0.53 ± 0.01
SEATING
1.10
(.043)
MAX
12
0.50
(.0197)
TYP
8910
3
7
6
45
0.497 ± 0.076
(.0196 ± .003)
REF
3.00 ± 0.102
(.118 ± .004)
NOTE 4
0.86
(.034)
REF
0.13 ± 0.05
(.005 ± .002)
MSOP (MS) 1001
Information furnished by Linear Technology Corporation is believed to be accurate and reliable. However, no responsibility is assumed for its use. Linear Technology Corporation makes no represen­tation that the interconnection of its circuits as described herein will not infringe on existing patent rights.
24212f
31
LTC2421/LTC2422
TYPICAL APPLICATIO
U
Figure 37 shows the block diagram of a demo circuit (contact LTC for a demonstration) of a multichannel isolated temperature measurement system. This circuit decodes an address to select which LTC2422 receives a 24-bit burst of SCK signal. All devices independently
D1
RE
R0
SD0
(ADDRESS
OR COUNTER)
HC138SCK
HC138
HC595
D
IN
ADDRESS
LATCH
D1
RE
R0
D1
RE
R0
SEE FIGURE 34 FOR THE COMPLETE CIRCUIT
convert either the thermal couple output or the thermistor cold junction output. After each conversion, the devices enter their sleep state and wait for the SCK signal before clocking out data and beginning the next conversion.
V
CC
SDO
SCK
SDO
SCK
SDO
SCK
LTC2422
ZS
SET
LTC2422
ZS
SET
LTC2422
ZS
SET
FS
SET
CH1 CH0
V
CC
FS
SET
+
2500V
CH1 CH0
V
CC
FS
SET
CH1 CH0
24212 F37
LTC1535
LTC1535
LTC1535
A
Y
A
Y
A
Y
Figure 37. Mulitchannel Isolated Temperature Measurement System
RELATED PARTS
PART NUMBER DESCRIPTION COMMENTS
LT1019 Precision Bandgap Reference, 2.5V, 5V 3ppm/°C Drift, 0.05% Max LTC1050 Precision Chopper Stabilized Op Amp No External Components 5µV Offset, 1.6µV LT1236A-5 Precision Bandgap Reference, 5V 0.05% Max, 5ppm/°C Drift LTC1391 8-Channel Multiplexer Low RON: 45, Low Charge Injection Serial Interface LT1461-2.5 Precision Micropower Voltage Reference 50µA Supply Current, 3ppm/°C Drift LTC1535 Isolated RS485 Transceiver 2500V
RMS
Isolation
LTC2400 24-Bit, No Latency ∆Σ ADC in SO-8 4ppm INL, 10ppm Total Unadjusted Error, 200µA LTC2401/LTC2402 1-/2-Channel, 24-Bit, No Latency ∆Σ ADC in MSOP 0.6ppm Noise, 4ppm INL, Pin Compatible with the LTC2421/LTC2422 LTC2404/LTC2408 4-/8-Channel, 24-Bit, No Latency ∆Σ ADC 4ppm INL, 10ppm Total Unadjusted Error, 200µA LTC2413 24-Bit, No Latency ∆Σ ADC Simultaneous 50Hz and 60Hz Rejection, 0.16ppm Noise LTC2415 24-Bit, Fully Differential, No Latency ∆Σ ADC 15Hz Output Rate at 60Hz Rejection, Pin Conpatible with the LTC2410 LTC2420 20-Bit, No Latency ∆Σ ADC in SO-8 1.2ppm Noise, 8ppm INL, Pin Compatible with LTC2400 LTC2424/LTC2428 4-/8-Channel, 20-Bit, No Latency ∆Σ ADC 1.2ppm Noise, 8ppm INL, Pin Compatible with LTC2404/LTC2408 LTC2430 20-Bit, Fully Differential, No Latency ∆Σ ADC in SSOP-16 0.16ppm Noise, 2ppm INL, 10ppm Total Unadjusted Error, 200µA LTC2431 24-Bit, Fully Differential, No Latency ∆Σ ADC in MS10 0.29ppm Noise, 4ppm INL, 10ppm Total Unadjusted Error, 200µA
Linear Technology Corporation
32
1630 McCarthy Blvd., Milpitas, CA 95035-7417
(408) 432-1900 ● FAX: (408) 434-0507
www.linear.com
LINEAR TECHNOLOGY CORPORATION 2002
Noise
P-P
24212f
LT/TP 0202 2K • PRINTED IN USA
Loading...
